Lightolier FIXTURE Instruction Manual

lc-
,’---
,,-
INSTR.UCTION.SHEET@. _‘
INSTRUCTIONS FOR ASSEMBLY AND INSTALLATION IS:4120AZ
R0391
READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE.
This fixture is intended for .instsllation in accordance with the National Electrical Code and local regulations.
To assure full compliance with local codes and regulations, check with your local electrical inspector bsfore
~installation. To prevent electrical shock, turn off electricity at fuse box before proceeding.
Retain these instructions for maintenance reference.
1.
2.
3.
4.
:5.
6.
7.
~8.
9.
Thread FIXTURE SCREWS into UNIVERSAL CROSSbAR.
Secure UNIVERSAL CROSSBAR to OUTLET BOX with OUTLET BOX SCREWS.
Support BACKPLATE and make connections Black fixture lead or fixture lead without tracer mark to
black supply lead; white fixture lead or fixture lead with tracer mark to white supply lead; fixture ground
lead (uninsulated wire) to supply ground lead. or other grounding terminal in OUTLET BOX. Uae WIRE
NUTS (local hardware item). Place connections in OUTLET BOX.’
Position BACKPLATE over FIXTURE SCREWS’ and secure with BRIDGE KNOBS.
Lamp with the correct lamp type.
CAUTION: MAXIMUM WAlTAGE MARKED ON FIXTURE MUST NOT BE EXCEEDED.
Slide one SPACER over each of the (2) SUPPORT STUDS.
Place protective screen on top of SPACERS.
Position SCALINI STACKED GLASS ASSEMBLY over the SUPPORT STUDS so the (2) rear SUPPORT
STUDS slide up through (2) holes in the GLASS ASSEMBLY.
Secure GLASS ASSEMBLY by threading the (2) GLASS FASTENERS into the ends of each of the (2) rear
,SUPPORT STUDS. Do not overtighten.
10. ”Slide END CAP up over SACKPlATE so BOSSES on the inside of the END CAP fit into SLOT in the
bottom of the BACKPIATE. Secure by threeding HOLDER KNOBS through the holes in side of END CAP
11. To relamp fixture, remove the (2) GIASS FASTENERS and remove SCALINI GLASS ASSEMBLY. Lift
protective screen and relamp with recommended lamp. Replace protective screen, SCALINI GLASS
ASSEMBLY and GLASS FASTENERS.
