FXLE30C4N LED FIXTURE
Version 1.0 OWNERS MANUAL 12/04/2020
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
FEATURES AND SPECIFICATIONS
LEDs: 300 Watt 4-in-1 Quad-Color, RGBW array
White Color Temperature: 2950K –10800K
CRI: 93 CQS: 92
Beam Angle: 19º, 26º or 36º
Control System: DMX512 + Stand Alone
DMX Channels: 4 or 9 channel mode
DMX Connectors: 3 pin XLR I/O
Power Input: 100-230VAC, 50/60Hz
Max. Power Consumption: 330 Watts @ 120VAC
Standby Power Consumption: 6 Watts @ 120VAC
Body Material: All Metal Construction
Body Color: Black or White Available
Reflector: Glass
Gel Frame and Size "B" Gobo Holder Included
FX Accessory Slot
Sliding Yoke Assembly on 12.75” Track
Size: 28"L x 13.5"W x 20"H (with yoke)
Weight: 23 lbs.
DESCRIPTION
The FXLE30C4N is a four color LED ellipsoidal fixture
that is suitable for stage, houses of worship,
entertainment venues and other artistic applications. It
has automatic stand-alone control modes and can
operate via an external DMX512 signal.
A mounting yoke enables the fixture to be installed and
operated in various positions and orientations.
INSTALLATION
LOCATION
The FXLE30C4N is rated IP20 and is intended for
INDOOR USE ONLY.
Locate the unit in a well-ventilated area away from
moisture or heat. Maintain a minimum spacing of 20"
between the unit and other objects. The maximum
ambient operating temperature is 40ºC (104ºF). Keep
the vent holes clear. Holes are provided on the yoke to
install a traditional lighting C-clamp for mounting on
batten pipe. Use a safety cable attached to the safety
eye when hanging the fixture.
GOBO/FX SLOT ALIGNMENT
To rotate barrel, loosen the two 3mm hex socket head
cap screws on both sides of body behind the shutter
handles. Then loosen both adjustment knobs at top
and bottom of fixture behind the shutter handles. Once
the GOBO or FX slot is aligned, retighten screws and
knobs.
LENS TUBE ADJUSTMENT
To focus beam, loosen the knobs on the top and
bottom of the barrel, extend/retract tube as needed for
intended beam and tighten knobs. Support lens tube in
process.
YOKE ADJUSTMENT
To slide yoke along track, loosen 4 screws on both
side brackets with a #2 Phillips screwdriver, adjust
yoke and retighten screws once in desired location.
POWER CONNECTIONS
The FXLE30C4N has a line cord for connection to a
100-230 VAC, 50/60Hz, grounded service. Do not
power the unit from a dimmer pack.
When using 120VAC, only connect a maximum of
four FXLE30C4N fixtures together with power
connectors.
The safety ground pin on the power cord must be
used.
DMX CONNECTIONS
A system using DMX control should be connected as a
chain of devices. In other words the control signal
DANGER
RISK OF ELECTRIC SHOCK

Page 2 of 4
FXLE30C4N LED FIXTURE
Version 1.0 OWNERS MANUAL 12/04/2020
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
cable should originate at the controller to the first
receiving device and then to others in a continuous
"daisy chain" fashion. An optically isolated DMX splitter
is recommend when installing the FXLE30C4N in a
system with various other DMX devices.
The FXLE30C4N has a DMX IN and a DMX OUT
connector which are used to connect the DMX data
chain. The control cable can NOT be split into a Y or
multiple run/star arrangement with a cable running
directly from the controller to each receiving device.
DMX CONNECTOR PIN ASSIGNMENTS
Predominantly two connectors are used for connecting
fixtures and other DMX devices to a DMX control
chain. They are both “XLR type”connectors. Some
units use 3 pin connectors, others use 5 pin
connectors. The FXLE30C4N receives a DMX signal
on the 3 pin MALE connector on the rear of the unit.
The 3 pin FEMALE connector is used to connect to the
next DMX device on the control chain.
If your console uses a 5 pin XLR connector, an adapter
cable can be purchased or fabricated to accommodate
this conversion. The following table shows the pin
assignments for both 3 pin and 5 pin XLR connectors:
DMX TERMINATION
It is recommended that a DMX data chain be
terminated at the last receiving device on the chain.
This is done by installing a commonly available 1/4
Watt, 120 Ohm resistor across the DATA - and DATA
+ wires at the last device. If you have only a few
fixtures installed very close together and with a short
run of DMX cable to the controller then you may be
able to operate without the terminator.
OPERATION
Power is applied once the power cord is connected to
a live power source. There is not an on/off switch.
Connect power cord to fixture first, then outlet. A
display and user interface is located on the back of the
unit. This interface is used to set the operating options
and settings. It consists of a backlit LCD display and
four buttons (MODE, DOWN, UP and ENTER).
Use MODE to scroll through the available choices.
The current setting for the option will be shown. Use
UP and DOWN until you reach the desired setting or
mode then push ENTER to lock in the new setting.
In case of loss of power to fixture, the fixture will return
to the last setting that was locked in with ENTER being
pressed.
STAND ALONE MODE
FXLE30C4N MENU OPTIONS
MENU
Value (D:)
Function
DMX - 9CH
000-512
9 channel start address
DMX - 4CH
000-512
4 channel start address
Jump
00-99
Color Change (speed)
Gradient
00-99
Color Fade (speed)
Pulse
00-99
Fast On/ Slow fade
with mix of colors
selected below.
Voice Running
Enter on/
Enter off
Sound control
Color R
000-255
Red intensity
Color G
000-255
Green intensity
Color B
000-255
Blue intensity
Color W
000-255
White intensity
Color Temp
2000K-
12000K
Color temperature
If connecting multiple FXLE30C4N fixtures together in
stand-alone mode, set the DMX address on additional
units to d001 to follow the main fixture.
Jump: Colors change with no fade. 15 steps. No color
selection required.
Gradient: Colors change with fade. 15 steps. No color
selection required.
Pulse: Colors come on quickly and fade out, number
of steps vary based on colors chosen from the RGBW
selections. Set color intensity to 001-255, but actual
PIN #
SIGNAL NAME
1
DMX COMMON
2
DMX DATA -
3
DMX DATA +
4
NOT USED
5
NOT USED
MODE
ENTER
UP
P
DOWN
CONTROL PANEL

Page 3 of 4
FXLE30C4N LED FIXTURE
Version 1.0 OWNERS MANUAL 12/04/2020
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
value chosen is irrelevant. 2 colors selected = 12
steps, 3 colors selected = 14 steps. 4 colors selected =
15 steps.
DMX OPERATION
Use the DMX-Addr menu to set the unit DMX starting
address. The range is 001 - 512.
Once you select the DMX mode and address, press
ENTER to ensure that if power is lost, the fixture
will return to the preset DMX mode and address.
The fixture has 2 DMX modes: 4 channel and 9
channel. For proper DMX operation, the highest DMX
address setting should be 509 (4 channel mode) and
504 (9 channel mode)
4 CHANNEL DMX ASSIGNMENTS
DMX CHN
FUNCTION
1
Red Intensity (0-255)
2
Green Intensity (0-255)
3
Blue Intensity (0-255)
4
White Intensity (0-255)
9 CHANNEL DMX ASSIGNMENTS
DMX CHN
FUNCTION
1
Overall Intensity (0-255)
2
Strobe (Speed 0-255) (Color Required)
3
Effect
0-5: No Effect
6-100: Colors Jump
101-150: Gradient Color Change
151-200: Colors Pulse
201-255: Sound Control
4
Effect Speed (0-255)
5
Red Intensity (0-255)
6
Green Intensity (0-255)
7
Blue Intensity (0-255)
8
White Intensity (0-255)
9
Color Temperature
0:Off, 1-255: 2000K-12000K)
MAINTENANCE AND REPAIR
TROUBLESHOOTING
Fixture will not power up.
Check that you have power applied to the
unit.
Check the fuse located on the back panel of
the fixture.
Unable to control fixture.
Check that the LCD display currently
indicates the correct DMX channel mode
and is addressed properly. If not, select the
proper channel mode and address then
press ENTER.
Check the LCD display on the fixture; if there
is a flashing decimal after the DMX value, a
valid DMX signal is present. If there is not a
decimal showing, then a valid DMX signal
is not present.
Check the DMX control cable for continuity
and polarity.
Remove the fixture from the DMX chain and
all other DMX devices.
Check the address settings or patch at the
controller.
CLEANING
DISCONNECT THE POWER CORD BEFORE
HANDLING THE UNIT.
A mild detergent can be used sparingly if needed.
Apply to cloth only; do not apply detergents directly to
fixture. Do not use chemicals or solvents when
cleaning the fixture. Ensure that the unit is dry before
use.
REPAIR
The only FXLE30C4N user serviceable part is a 5 mm
x 20 mm externally accessible fuse on the rear panel.
DISCONNECT THE POWER CORD BEFORE
CHECKING OR REPLACING THE FUSE.
Replace fuse ONLY with 5.0 Amp, 250VAC, fast acting
fuse. Requires a #2 Philips head screwdriver to
access. Use care to not overtighten.
Internal service on the unit by other than Lightronics
authorized agents will void the warranty.
If service is required, contact the dealer from whom
you purchased the item, or contact the Lightronics,
Service Department, 509 Central Drive, Virginia Beach,
VA 23454. Tel: [phone].
DANGER DO NOT OPEN UNIT
RISK OF ELECTRIC SHOCK
RISK OF FIRE

Page 4 of 4
FXLE30C4N LED FIXTURE
Version 1.0 OWNERS MANUAL 12/04/2020
www.lightronics.com
Lightronics Inc. 509 Central Drive, Virginia Beach, VA 23454 757 486 3588
FXLE30C4N
10 Foot
20 Foot
30 Foot
19°
Beam (ft.)
FC
Lux
Beam (ft.)
FC
Lux
Beam (ft.)
FC
Lux
Red
3.3
294
3050
6.6
64
682
10.5
27
455
Green
3.3
302
3210
6.6
70
758
10.5
30
508
Blue
3.3
492
5200
6.6
113
1226
10.5
50
840
White
3.3
550
5950
6.6
136
1458
10.5
57
966
All Colors
3.3
1535
16120
6.6
366
3920
10.5
158
2580
FXLE30C4N
10 Foot
20 Foot
30 Foot
26°
Beam (ft.)
FC
Lux
Beam (ft.)
FC
Lux
Beam (ft.)
FC
Lux
Red
4.7
160
1810
9.4
40
443
14.2
18
196
Green
4.7
186
1995
9.4
45
489
14.2
21
228
Blue
4.7
300
3160
9.4
76
824
14.2
34
372
White
4.7
340
3720
9.4
86
936
14.2
39
427
All Colors
4.7
950
10120
9.4
237
2520
14.2
105
1168
FXLE30C4N
10 Foot
20 Foot
30 Foot
36°
Beam (ft.)
FC
Lux
Beam (ft.)
FC
Lux
Beam (ft.)
FC
Lux
Red
6.5
89
960
12.9
23
255
19.5
11
121
Green
6.5
99
1100
12.9
27
294
19.5
12
134
Blue
6.5
170
1835
12.9
45
486
19.5
20
223
White
6.5
192
2050
12.9
51
554
19.5
28
309
All Colors
6.5
532
5590
12.9
140
1530
19.5
77
820
PHOTOMETRIC CALCULATIONS

This product is warranted for a period of TWO YEARS from the date of purchase against
defects in materials and workmanship.
This warranty is subject to the following restrictions and conditions:
A) If service is required, you may be asked to provide proof of purchase from an
authorized Lightronics dealer.
B) This warranty is valid only for the original purchaser of the unit.
C) This warranty does not apply to damage resulting from abuse, misuse, accidents,
shipping, and repairs or modifications by anyone other than an authorized
Lightronics service representative.
D) This warranty is void if the serial number is removed, altered or defaced.
E) This warranty does not cover loss or damage, direct or indirect arising from the use or
inability to use this product.
F) Lightronics reserves the right to make any changes, modifications, or updates as
deemed appropriate by Lightronics to products returned for service. Such changes
may be made without prior notification to the user and without incurring any
responsibility or liability for modifications or changes to equipment previously
supplied. Lightronics is not responsible for supplying new equipment in accordance
with any earlier specifications.
G)This warranty is the only warranty either expressed, implied, or statutory, upon which
the equipment is purchased. No representatives, dealers or any of their agents are
authorized to make any warranties, guarantees, or representations other than
expressly stated herein.
H) This warranty does not cover the cost of shipping products to or from Lightronics for
service.
I) Lightronics Inc. reserves the right to make changes as deemed necessary to this
warranty without prior notification.
Lightronics Inc. 509 Central Drive Virginia Beach, VA 23454 20100211
WARRANTY
