LIGHTSIDE LS 125 User manual

9/11CH

1. Specifications
Power Supply:
AC100-240V, 50-60Hz
Power Consumption:
26W
LED Source:
1pcs*12W LUMINUS LED white
Beam Angle:
13°
Gobo wheel:
7 fixed gobos + spot, Gobo Shake effect, Gobo scroll mode
Color Wheel:
7 colors+white
Control mode:
DMX 512,Master-slave,Auto run,Sound-activated
DMX Channel:
7/12CH
Rotation Angle:
540° pan / 230° tilt (16-bit), Pan /Tilt Inversion mode
Focus:
Manual focus
Dimming: 0%-100% linear dimming
Shutter:
Pulse effect; random strobe slow to fast
Connector:
DMX via 3-pin XLR cable
Highest temperature:
40
Date In and out:
3-pin XLR cathode and anode plug
N.W/G.W:
3kg/3.5kg
Dimension:
159*147*265mm
2. SAFETY INTRODUCTION
• If the device has been exposed to temperature changes due to environmental changes, do not
switch it on immediately. The arising condensation could damage the device. Leave the device
switched off until it has reached room temperature.
• It is essential that the device is earthed. A qualified person must carry out the electric
connection.
• Make sure that the available voltage is not higher than stated at the end of this manual.
• Make sure the power cord is never crimped or damaged. If it is damaged, ask your dealer or
authorized agent to replace the power cord.
• Always disconnect from the mains, when the device is not in use or before cleaning it. Only
handle the power cord by plug. Never pull out the plug by tugging the power cord.
• DISCONNECT DEVICE: Where the MAINS plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain readily operable.
• Due to the magnifying type lens, please keep the lens out of contact with direct us. Direct we can
cause heat to build up inside of the unit, which will seriously damage unit.
CAUTION:
1. Be very careful during installation. Since you will be working with a dangerous voltage you
can suffer a life-threatening electric shock when touching live wired.
2. Never look directly into the light source, as sensitive persons may suffer an epileptic shock.
3. Please be aware that damages caused by manual modifications to the device are not subject to
warranty. Keep away from children and non-professionals.

4. The light doesn’t include any spare parts for repair, please check if all the parts are well
installed and screws are fitted tightly before operating. Do not use the light when the cover is
open.
GENERAL GUIDELINES
• This device is only allowed to be operated with an alternating current of max. 220-240V
AC/50-60Hz and was designed for indoor use only.
• Do not shake the device. Avoid brute force when installing or operating it.
• Operate the device only after having familiarized yourself with its functions. Do not permit
operation by person not qualified for operating the device. Most damages are the result of
unprofessional operation.
• Please use the original packaging if the device is to be transported.
• For safety reasons, please be aware that all modifications on the device are forbidden.
Furthermore, any other operation may lead to short-circuit, burns, electric shock, lamp
explosion, crash, etc. If this device will be operated in any way different to the one described in
this manual, the product may suffer damages and the guarantee becomes void.
3. Operation
1.Illustration Part
：
A.Menu
A B C D B.Up
C.Down
D.Enter
Operating Instructions: Press button A
“
Menu
”
to choose different functions ，Press button
“B” or “C” to amend parameter values, Press button “D” to“Enter”

LCD display different functions:（Press button“Enter” to enter）
NO. Display Function
1 ADDR
A001-A512 address settings
2
CHND
CH, 12CH channel selection
3 SLND
MAST, SL1, SL2, main and
auxiliary machinery selection
4 SHND
Select SOUD, AUTO control
5 SOUD
ON,OFF sound control switch
6 SENS
Sensitivity of sound control(0
closed, 100 is most sensitive)
7 BLND
YES, NO; the switch of
standby
8 LED
YES, NO; the switch of Back
light
9
DISP
YES, NO; reverse display
10 PAN
YES, NO; level motor reverse
11 TILT
YES,NO; vertical motor
reverse
12 MANU
PAN, TILT, COLOR,
GOBO,DIMM,
STROB,Manual testing
13 TEST
Automatic testing
14 HOUR
0 ---- 9999 time of use
machine
15 VER
V101 software version
number
16 RSET
YES, NO reset factory
settings

4. DMX512 Channels:
Mode 1:7 Channels
No Functions Illustration
1
0-255
X motor operation
2
0-255
Y motor operation
3
Dimming
0-255 1-100%
4
Strobe
0-7 off light, 8-15 opening,
16-
131 from slow to fast
strobe, 132-
139 open light,
fast off slowly open 140-181,
182-189 opening, 190-231
slow off quick opening,
232-239 opening, 240-247
248-
255 open random strobe
light,
5
Color wheel
0-31 Open,
32-
63 Color 1,
64-95 Col
or2,
96-
127 Color3,
128-
159 Color4,
160-
191 Color5,
192-
223 Color6,
224-255 Color7.
6
Gobo wheel
0-15 Open,
16-3 Color 1,
32-
47 Color2,
48-
63 Color3,
64-
79 Color4,
80-
95 Color5,
96-
111 Color6,
112-
127 Color7.
128-
146 Color7 jitter,
147 --- 164 Color6 jitter,
165 --- 182 Color5 jitter,
183 --- 201 Color4 jitter,
202 --- 219 Color3 jitter,
220 --- 237 Color2 jitter
238 --- 255 Colorl jitter
7
Marco
0-69 no functional, 70-89
Close light effective when the

horizontal or vertical motor
moves, 90-
109 close light
invalid when X or Y axis
moving, 110-
129 close light
effectively when the color
wheel move , 130-149 invalid
to close light when the color
wheel move , 150-
169 close
light effectively when Gobo
move. 170-189 close light
invalidly when Gobo move,
190-
199 no functional,
200-
209 overall reset,
210-
249 no functional,
250-255 sound control effect
nonfunctional, 200-209
overall reset, 210-
249 free
function, 250-
255 random
sound control effect
Mode 2:12 Channels
No Data Illustration
1
0-255
The level of motor travel
2
0-255
The level of motor tuning
3
0-255
Vertical stroke motor
4
0-255
Vertical motor tuning
5
0-255
Horizontal / vertical motor
speed, from fast to slow
6
level / vertical motor effect
No effect 0-15, 16-35 2,56-75
effect effect effect 1,36-
55 3,
76-95 effect 4, 96-
115 effect
5, 116-135 effect 6, 136-155
effect 7, 156-
175 results 8,
176-195 effect 9, 196-215

effect 10, 216-235 effect 11,
236-255 effect 12
7
0-255
0-255 horizontal / vertical
speed motor effect, from fast
to slow
8
Color wheel
0-31 Open, 32-63 Colorl,
64-95 Color2, 96-127 Color3,
128-159 Color4, 160-191
Color5, 192-
223 Color6,
224-255 Color7
9
GOBO wheel
0-15 Open,
16-
3 Color 1,
32-
47 Color2,
48-
63 Color3,
64-
79 Color4,
80-
95 Color5,
96-
111 Color6,
112-
127 Color7.
128-
146 Color7 jitter,
147 --- 164 Color6 jitter,
165 --- 182 Color5 jitter,
183 --- 201 Color4 jitter,
202 --- 219 Color3 jitter,
220 --- 237 Color2 jitter
238 --- 255 Colorl jitter
10
Marco
0-69 non-functional, 70-89
when the horizontal or
vertical motor motor moves
off the light and effective,
90-109 when moving off light
invalid X or Y axis, 110-129
when the color wheel to move
off the light effectively,
130-149 when the color wheel
to move off the light invalid,
150-169 Gobo move off when
the light effectively, 170-189
Gobo move off when the light
is invalid, 190-199
nonfunctional, 200-209
overall reset, 210-249 free
function, 250-255 random

sound control effect
11
0-255
dimming
12
Strobe
0-7 close light, 8-15
opening,16-131 strobe from
slow to fast , 132-139 open
light, fast off slowly open
140-181, 182-189 opening,
190-231 slow off quick
opening, 232-239 opening,
240-247 random strobe,
248-255 opening
