Lightware DA2DVI-DL User manual
DA2DVI-DL
User’s Manual
DA2DVI-DL – User's Manual 2
Important Safety Instructions
Class II apparatus construction.
The equipment should be operated only from the power source
indicated on the product.
To disconnect the equipment safely from power, remove the power
cord from the rear of the equipment, or from the power source. The
MAINS plug is used as the disconnect device, the disconnect device
shall remain readily operable.
There are no user-serviceable parts inside of the unit. Removal of the
cover will expose dangerous voltages. To avoid personal injury, do not
remove the cover. Do not operate the unit without the cover installed.
The appliance must be safely connected to multimedia systems.
Follow instructions described in this manual.
Ventilation
For the correct ventilation and to avoid overheating ensure enough
free space around the appliance. Do not cover the appliance, let the
ventilation holes free and never block or bypass the ventilators (if any).
WARNING
To prevent injury, the apparatus is recommended to securely attach to
The apparatus shall not be exposed to dripping or splashing and that
be placed on the apparatus.
Waste Electrical & Electronic Equipment
WEEE
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life. To
prevent possible harm to the environment or human
health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material
resources. Household users should contact either the
retailer where they purchased this product, or their local government
environmentally safe recycling. Business users should contact their
supplier and check the terms and conditions of the purchase contract.
This product should not be mixed with other commercial wastes for
disposal.
Common Safety Symbols
Symbol Description
Direct current
Alternating current
Double insulation
Caution, possibility of eletric shock
Caution
DA2DVI-DL – User's Manual 3
Symbol Legend
The following symbols and markings are used in the document:
WARNING! Safety-related information which is highly recom-
mended to read and keep in every case!
ATTENTION! Useful information to perform a successful procedure;
it is recommended to read.
INFO: A notice which may contain additional information. Procedure
can be successful without reading it.
DEFINITION: The short description of a feature or a function.
TIPS AND TRICKS: Ideas which you may have not known yet but can
be useful.
Navigation Buttons
Go back to the previous page. If you clicked on a link peviously,
you can go back to the source page by the button.
Navigate to the Table Contents.
Step back one page.
Step forward to the next page.
Document Information
This User’s Manual applies to the following versions of the mentioned
Item Version
Lightware Device Controller (LDC) software 1.17.1b3
Lightware Bootloader Software 3.3.3
Controller rmware 1.2.1
Hardware 1.1
Document revision: 3.0
Release date: 04-09-2017
Editor: Tamas Forgacs
DA2DVI-DL – User's Manual 4
1. INTRODUCTION...................................................................................5
...................................................................................5
...............................................................................5
.......................................................................................5
.....................................................................5
2. INSTALLATION.....................................................................................6
........................................................................6
........................................................................... 6
................................................................. 6
..................................................... 6
.........................................................................7
3. PRODUCT OVERVIEW ........................................................................8
....................................................................................8
......................................................................................8
...............................................................9
................................................................................. 9
............................................................................ 9
.................................................................................. 9
4. OPERATION .......................................................................................10
...............................................................................10
.........................................................................10
....................................................................... 10
......................................................................... 11
........................................................................... 11
5. SOFTWARE CONTROL – LIGHTWARE DEVICE CONTROLLER ...12
..................................................................12
.....................................................13
.................................................................13
...................................................................... 13
................................................................... 14
...................................................................................14
..............................................................................
.................................................................
............................................................................... 16
........................................... 16
............................................................................17
......................................................................... 17
................................................................................................... 17
........................................................................18
Table of Contents
6. PROGRAMMER'S REFERENCE .......................................................19
................................................................19
......................................................................19
.......................................................................... 19
....................................................................... 19
.................................................................. 20
.................................................................................. 20
....................................................................... 20
................................................................. 20
.......................................................................... 20
..............................................................20
............................................................ 20
........................................................ 20
.............................................................. 21
........................................................................... 21
............................................................. 22
................................................................. 22
............................................... 22
.......................................................23
7. FIRMWARE UPGRADE ......................................................................24
..................................................24
................................................................24
8. TROUBLESHOOTING........................................................................26
9. TECHNOLOGIES................................................................................27
.......................................................................27
................................................................. 27
........................................................ 27
..................................................................28
10. APPENDIX ........................................................................................29
............................................................................29
..............................................................30
.....................................................................30
................................................................31
1. Introduction
1
Introduction
would like to introduce the device highlighting the most important features in
the below listed sections:
Î
Î
Î
Î
Advanced EDID Management
The user can emulate any EDID on the inputs
independently, read out and store any attached
monitor's EDID in 100 internal memory locations,
Controller software.
DUAL-LINK
Dual-Link Resolutions
Supports all Dual-Link signal resolutions up to 9.9
with CVT-RB blanking.
POWER
5V
+
sources (VGA cards, etc.) usually consuming more
output on both of its outputs to power long distance
0
1
2
3
4
5
6
7
8
9
EDID ADDRESS selection with two decimal rotary
switches, LEARN EDID button is available for Advanced
EDID Management.
Typical Application
Description
Lightware's DA2DVI-DL is an EDID emulator and repeater that can
it can provide stable signal which is distributed to the two outputs.
Thanks to our Advanced EDID Management, the device can trick
HDMI display (LCD monitor, projector) for continuous video output –
emulation, the user can set up any DVI or HDMI output resolution,
regardless of the used projector or monitor. This ensures that the
29 user programmable presets available, and the last attached display
device's EDID is also stored separately on address #00, to be able to
copy it to the input (repeater mode).
DA2DVI-DL can be rack mounted or used standalone. The unit is
equipped with the highest grade gold plated connectors and gold
plated printed circuit boards to ensure reliable connections and long-
term operation.
Software) users can create their own EDID by completing four simple
steps. More experienced users can use the Advanced EDID Editor to
manage every possible setting in the EDID, which they can upload to
the memory of the DA2DVI-DL.
Model Denomination
Box Contents
DA2DVI-DL
2x DVI outputs
Distribution Amplifier DVI dual-link support
DA2DVI-DL
interchangeable plugs
Safety & warranty info,
Safety and
Warranty
Info
Quick
Start
Guide
2. Installation DA2DVI-DL – User's Manual 6
2
Installation
The chapter is about the installation of the device and connecting to other
appliances, presenting also the mounting options and further assembly steps:
Î
Î
Mounting Options
To mount the extenders Lightware supplies optional accessories for
different usage. There are three kinds of mounting kits with similar
Under-desk
mounting kit
Under-desk double
mounting kit
1U high rack shelf
The device has two mounting holes with inner thread on the bottom
side; see the bottom view in the Mechanical Drawings section. Fasten
the device by the screws enclosed to the accessory.
To order mounting accessory kits please contact .
WARNING! Always use the supplied screws. Using different (e.g.
longer) ones may cause damage to the device.
1U High Rack Shelf
units.
1U high rack shelf provides mounting holes for fastening two half-
fastened on the self.
EDID STATUS
EDID
LEARN
N
Y
SRC +5V
HPD
EDID ADDRESS DVI-DLINPUT
5V 1A
PIN: 2.35mm
00
11
22
33
44
55
66
77
88
99
00
11
22
33
44
55
66
77
88
99
EDID STATUS
EDID
LEARN
N
Y
SRC +5V
HPD
EDID ADDRESS DVI-DL INPUT
5V 1A
PIN: 2.35mm
00
11
22
33
44
55
66
77
88
99
00
11
22
33
44
55
66
77
88
99
Under-desk Mounting Kit
INFO: The chipboard screws are not supplied with the mounting kit.
Under-desk Double Mounting Kit
The UD-kit double makes it easy to mount a single transmitter or
INFO: The chipboard screws are not supplied with the mounting kit.
EDID STATUS
EDID
LEARN
N
Y
SRC +5V
HPD
EDID ADDRESS DVI-DL INPUT
5V 1A
PIN: 2.35mm
00
11
22
33
44
55
66
77
88
99
00
11
22
33
44
55
66
77
88
99
EDID STATUS
EDID
LEARN
N
Y
SRC +5V
HPD
EDID ADDRESS DVI-DL INPUT
5V 1A
PIN: 2.35mm
00
11
22
33
44
55
66
77
88
99
00
11
22
33
44
55
66
77
88
99
EDID STATUS
EDID
LEARN
N
Y
SRC +5V
HPD
EDID ADDRESS DVI-DL INPUT
5V 1A
PIN: 2.35mm
00
11
22
33
44
55
66
77
88
99
00
11
22
33
44
55
66
77
88
99
2. Installation DA2DVI-DL – User's Manual 7
Connecting Steps
DVI
Connect the source device (e.g. a PC) to the distribution
DVI
output port(s) by a dual-link DVI cable.
USB
a laptop) by a USB cable.
Power
Connect the power adaptor to the DC input on the device
ProjectorMonitor
DA2DVI-DL
PC
LaptopPower adaptor
USB
Power
DVI DVI DVI
EDID STATUS
EDID
LEARN
N
Y
SRC +5V
HPD
EDID ADDRESS DVI-DL INPUT
5V 1A
PIN: 2.35mm
00
11
22
33
44
55
66
77
88
99
00
11
22
33
44
55
66
77
88
99
3. Product Overview DA2DVI-DL – User's Manual 8
3
Product Overview
output ports and connectors:
Î
Î
Î
1DC 5V
input
adaptor or use Lightware’s rack mountable power
supply unit. See more information in the
Connection section.
2Rotary
switches
The rotary switches select one of the EDID
memory addresses. See more information in the
EDID Operations section.
3Learn
button
Stores the EDID of the display device attached
to DVI-DL OUTPUT 1 in the selected memory
see the Learning the EDID section.
4Status
LEDs
Display EDID information during operation and
boot up. See the details below.
5DVI-DL
input
Connect one single or dual-link DVI cable (only
digital pins are connected internally) between the
DVI source and DA2DVI-DL. See more information
in the DVI-I Connector section.
Status LEDs
1
2
3
4 5
EDID status N (red)
EDID status Y (green)
HPD (green)
SRC +5V (green)
The LEDs display basic information about EDID and connected
devices’ status:
LED label LED is illumenated LED is blinking
EDID STATUS N Selected EDID is invalid EDID learn failure
EDID STATUS Y Selected EDID is valid EDID learn success
HPD Hotplug detect: OUTPUT 1 is
connected -
on INPUT -
described in the Powering On section.
Rear View
1USB control Advanced EDID management and
USB interface.
2DVI-DL outputs Connect single or dual-link DVI cables
(only digital pins are connected
internally) between DA2DVI-DL and the
display devices. The output connectors
more information in the DVI-I Connector
section.
1
2
3. Product Overview DA2DVI-DL – User's Manual 9
Electrical Connections
DVI-I Connector
DA2DVI-DL provides 29 pole „digital only” DVI-I Dual-Link connectors
(only digital pins are internally connected). This way, users can plug in
any DVI connector, but keep in mind that analog signals (such as VGA
or RGBHV) are not processed.
Always use high quality DVI cable for connecting sources and displays.
Signal Signal
1TMDS Data2- 16 Hot Plug Detect
2TMDS Data2+ 17 TMDS Data0-
34Shield 18 TMDS Data0+
4TMDS Data4- 19 8Shield
5TMDS Data4+ 20
6DDC Clock 21
7DDC Data 22 TMDS Clock Shield
8not connected 23 TMDS Clock+
9TMDS Data1- 24 TMDS Clock-
10 TMDS Data1+ C1 not connected
11 3Shield C2 not connected
12 TMDS Data3- C3 not connected
13 TMDS Data3+ C4 not connected
14 C5 GND
15
DVI-DL Output
Monitor hotplug is detected on the DVI-DL OUTPUT 1 (HPD LED lights
green). After a hotplug event, the DA2DVI-DL tries to read the EDID of
the connected device.
No output reclocking is provided. If a long DVI cable is connected then
the cable.
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
C1 C2
C4C3
C5
17 18 19 20 21 22 23 24
optical DVI transmitters. Standard DVI outputs or VGA cards supply
optical cable.
INFO: The device does not check if the connected sink (monitor,
projector or other equipment) supports hotplug or EDID signals but
outputs the input signal directly.
DVI-DL Input
The input has Dual-Link disable option, which ensures Single-Link
compatibility. Devices supporting Dual-Link output can confuse
Single-Link inputs; disabling the Dual-Link TMDS channel distribution
solves this problem. For more information see Output Port Properties
section.
Cable length at inputs
please use one of our cable extender solutions, for example the
Lightware DVIDL-Extender.
DC 5V Connection
The device has a locking DC connector to establish robust and safe
power connection. After plugging it in, turn the plug clockwise as you
can see in the picture below.
Locking DC connector
Do not forget to turn the plug clockwise direction before disconnecting
the power adaptor.
WARNING! Always use the supplied 5V power adaptor or Light-
ware’s rack mountable power supply. Warranty void if damage oc-
curs due to use of a different power source.
12V 1A
5V 1A
PIN: 2.35mm
PIN: 2.35mm
USB Connector
The device provides standard USB 2.0 mini B-type connector
Software Control –
Lightware Device Controller and in Programmer's Reference chapters.
Firmware
Upgrade chapter.
4. Operation DA2DVI-DL – User's Manual 10
4
Operation
This chapter is about the powering and operating of the device describing the
Î
Î
are powered down before connecting them. Powered on devices may
have dangerous voltage levels that can damage sensitive electronic
circuits.
the unit and then to the power outlet. The unit is immediately powered
ON.
Step 1.
version using the EDID Status LEDs. The following example
Step 2. EDID
Status LED lights up depending on the selected EDID’s validity:
–Red – ‘N’: the selected EDID is invalid.
–Green – ‘Y’: the selected EDID is valid
Step 3. If a display device is connected to DVI-DL OUTPUT 1, the
DA2DVI-DL reads the EDID from the attached monitor’s EDID
memory.
–If the read process is successful, the STATUS LED blinks
green four times.
–If the read process is unsuccessful, the STATUS LED blinks
red four times.
Step 4. The normal function of the LEDs is in effect.
WARNING! If none of the LEDs light up upon power-up, the unit is
-
tact [email protected].
Short pause
1x 2x 1x
Short pause
EDID Operations
About EDID memory
Lightware factory preloaded EDIDs are specially provided to force
graphic cards to output only the exact pixel resolution and refresh rate.
Universal EDID (address 49#) allows multiple resolutions including all
support. The use of universal EDID is advised for fast and easy system
setup.
DA2DVI-DL contains a 79 block non-volatile memory bank. EDID
memory is structured as follows:
Rotary switch
state
Memory bank
number
Factory Preset EDID list
U01..U29 User programmable slots
#00 D01 Last attached monitor’s EDID
Factory EDID list can be found in Factory EDID List section.
the most commonly used resolutions.
extended EDID structures.
INFO: The attached monitor’s EDID is stored automatically, until a
new monitor is connected to the OUTPUTs. In case of powering the
unit off, the last attached monitor’s EDID remains in non-volatile
memory.
4. Operation DA2DVI-DL – User's Manual 11
Switching the EDID
Avoid the use of keys, coins, knives and other sharp objects be-
cause they might cause permanent damage to the rotary switches.
Step 1. Use a screwdriver to change the EDID ADDRESS by the rotary
switches on the front panel of the DA2DVI-DL.
Location #17 is selected by the rotary switches
Step 2. After either one of the rotary switches has been rotated, the
unit waits approximately two seconds before the selected
EDID becomes active.
Step 3. Check the state of the device:
EDID LED Description State
EDID status Y lights in
green.
The selected LED is
valid.
EDID status N lights in
red.
The selected EDID
memory is invalid
empty user memory).
The address #00 has a special function. If a monitor is connected to
OUTPUT 1, then its EDID is copied to the DVI-DL INPUT connector. If
no monitor is connected to the OUTPUT 1 then the EDID transmitted to
ATTENTION! If an invalid EDID is selected, DA2DVI-DL does NOT
give a HOT PLUG signal to the source connected to DVI-DL INPUT.
INFO: After every EDID change, DA2DVI-DL toggles the HOT PLUG
signal for approximately 2 seconds. Some graphics cards or DVD
players do not sense the HOT PLUG signal, and even if EDID has
been changed, the set resolution is not affected. In this case the
source device must be restarted, or powered OFF and ON again.
00
11
22
33
44
55
66
77
88
99
00
11
22
33
44
55
66
77
88
99
Learning the EDID
ATTENTION! The factory preset EDIDs cannot be changed by the
Step 1. After connecting the sink device to DVI-DL OUTPUT 1, use a
screwdriver to select a user programmable memory address.
EDIDs are stored in multiple programmable non-volatile
memories.
EDID LED Description State
EDID status N lights in
red.
The memory slot is
empty and ready to be
programmed.
EDID status Y lights in
green.
The memory was
already used before,
but still available for
reprogramming.
Step 2. Push the LEARN EDID button on the front panel of the DA2DVI-DL
and hold it down for approximately 2 seconds.
EDID LED Description State
EDID status Y blinks in
green four times.
The EDID has been
learnt successfully.
EDID status N blinks in
red four times.
The EDID learning was
unsuccessful.
Step 3. The normal function of the LEDs is in effect.
DA2DVI-DL – User's Manual 12
5
Software Control – Lightware Device Controller
The device can be controlled by a computer through the USB port Lightware
Mac OS X. The application and the User’s Manual can be downloaded from
www.lightware.eu. The Windows and the Mac versions have the same look and
functionality.
Î
Î
Î
Î
Î
Î
Install and Upgrade
Installation for Windows OS
Run the installer. If the User Account Control drops a pop-up message
click Yes.
During the installation you will be prompted to select the type of the
installation: normal and the snapshot install:
Normal install
(recommended) Snapshot install
The installer can update
only this instance Cannot be updated
Only one updateable instance
can exist for all users
More than one different version
can be installed for all users
Comparison of installation types
Installation for Mac OS X
has the same look and functionality. This type of the installer is
updateable version with the same attributes.
over the Applications icon to copy the program into the Applications
folder. If you want to copy the LDC into another location just drag the
icon over the desired folder.
Upgrading of LDC
Step 1. Run the application.
The Device Discovery window appears automatically and the program
checks the available updates on Lightware’s website and opens the
update window if the LDC found updates.
The current and the update version number can be seen at the top of
the window and they are shown in this window even with the snapshot
install. The Update window can also be opened by clicking the About
icon and the Update button.
Step 2. Set the desired update setting in the Options section.
▪If you do not want to check for the updates automatically,
uncheck the circle, which contains the green tick.
▪If you want to postpone the update, a reminder can be set with
different delays from the drop down list.
▪If the proxy settings traverse the update process, set the proper
values then click the OK button.
Step 3. Click the Download update button to start the upgrading.
The updates can be checked manually by clicking the Check now
button.
DA2DVI-DL – User's Manual 13
Establishing the Connection
Step 1. Connect the device to a computer via USB.
Step 2. Run the controller software; device discovery window appears automatically.
Device Discovery window in LDC
Step 3. Select the USB Devices tab and pick the unit from the discovered USB devices. Double click on the
name of the device or select it and click on the Connect button.
The USB devices tab in Device Discovery window
The most important information and settings are available in the menu. There are three buttons on the right
side of the panel: the input port and the two output ports properties window can be accessed by selecting
them.
Input port properties tab
parameter will be "detected".
DA2DVI-DL – User's Manual 14
Output port properties tab
The Hotplug detect parameter is "detected" if the sink device is powered and connected to the DVI-DL output
The following settings are available for the output ports:
▪You can set if any parameter change is applied to the current output or to both outputs. (The factory
default value is the current output.)
▪Pre-emphasis
▪Mode: enable or disable DVI dual link. (The factory default value is enabled.);
▪Reload factory defaults
EDID Menu
Advanced EDID Management can be accessed by selecting the EDID menu. There are two panels: left one
contains Source EDIDs, right one contains Destination places where the EDIDs can be emulated or copied.
EDID menu
Control Buttons
A
Save Exporting an EDID (save to a
A
Executing EDID emulation or
copying (Transfer button)
A
Upload Importing an EDID (load from
A
Delete selected Deleting EDID (from User
memory)
A
Info Display EDID Summary
window
A
Select All Selecting all memory places
in the right panel
A
Edit Opening Advanced EDID
Editor with the selected EDID
A
Deselect All Selecting none of the memory
places in the right panel
A
Create Opening Easy EDID Creator
EDID Operations
Learning an EDID
The process is the same as changing the emulated EDID; the only difference is the Destination panel: press
the User button. Thus, one or more EDIDs can be copied into the user memory either from the factory memory
or from a connected sink (Dynamic).
Exporting an EDID
ATTENTION!
Chrome web browsers only.
Step 1. Select the desired EDID from the Source panel (line will be highlighted with yellow).
Step 2. Press the Save
Importing an EDID
Step 1. Press the User button on the top of the Source panel and select a memory slot.
Step 2. Press the Upload button below the Source panel.
Step 3. Open button. Browsed EDID is imported into the
selected User memory.
ATTENTION! The imported EDID overwrites the selected memory place even if it is not empty.
Deleting EDID(s)
The EDID(s) from User memory can be deleted as follows:
Step 1. Press User button on the top of the Destination panel.
Step 2. Select the desired memory slot(s); one or more can be selected (“Select All” and “Select None” buttons
can be used). The EDID(s) will be highlighted with yellow.
Step 3. Press the Delete selected button to delete the EDID(s).
EDID Summary Window
Select an EDID from Source panel and press Info button to display EDID summary.
EDID summary window
DA2DVI-DL – User's Manual 16
Editing an EDID
Select an EDID from Source panel and press Edit button to display Advanced EDID Editor window. The editor
the raw EDID and displays it as readable information to the user. All descriptors can be edited, and saved in
(www.lightware.eu) and download EDID Editor user's manual.
EDID Editor window
Creating an EDID - Easy EDID Creator
Since above mentioned Advanced EDID Editor needs more complex knowledge about EDID, Lightware
create custom EDIDs in four simple steps. By clicking on the Create button below Source panel, Easy EDID
Creator is opened in a new window. For more details about EDID Editor please visit our website
(www.lightware.eu) and download EDID Editor user's manual.
Easy EDID Creator window
DA2DVI-DL – User's Manual 17
Settings Menu
Device Information
Device Information tab in the Settings menu
Device Information tab.
Log
Events logged by the device and report generators can be found on Log tab.
Log tab in the Settings menu
be sent to Lightware support team when a problem may arise with the device.
Press the red button
After generating the report, a ‘Save as’ dialog box appears. Select the folder where you want to save the
The report contains the following device-dependent information (if available):
▪Device type and serial number,
▪Firmware versions of all the internal controllers,
▪Hardware health status,
▪All EDID headers and status (emulated, dynamic, factory, user),
INFO: This function is only for special troubleshooting cases.
DA2DVI-DL – User's Manual 18
Terminal Window
This general purpose terminal is intended mainly for testing and debugging purposes. All commands can be
used here that are discussed in the programmer’s reference. The command text can be typed directly.
Terminal window
By default commands are automatically surrounded by framing brackets. Every sent command and every
The timecode in every row shows the exact time when the command was sent or the response received.
If the Command framing checkbox is unchecked, you can send multiple commands together, however in this
case you have to type in the framing brackets manually.
The terminal can also be opened after starting the LDC - press the Terminal button on the Device discovery
page on the bottom of the window.
TIPS AND TRICKS: The typed commands can be "browsed" when the cursor is in the command line and
you press the up button on the keyboard. The commands are stored until the LDC is closed.
6. Programmer's Reference DA2DVI-DL – User's Manual 19
6
Programmer's Reference
The device can be controlled by a command set of protocol commands to ensure
the compatibility with other Lightware products. The supported commands are
described in this chapter.
Lightware devices can be controlled with external devices which can
a secondary protocol is also provided.
Î
Î
Î
Î
The protocol description hereinafter stands for Lightware protocol.
The device accepts commands surrounded by curly brackets - { } - and responds data surrounded by round
brackets - ( ) - only if a command was successfully executed. All input commands are converted to uppercase,
but respond commands can contain upper and lower case letters as well.
Legend for control commands:
<loc> = location number in 1, 2 or 3 digit ASCII format
<id> = id number in 1 or 2 digit ASCII format
<id²> = id number in 2 digit ASCII format
CrLf = Carriage return, Line feed (0x0D, 0x0A)
●= space character (0x20)
→= each command issued by the controller
←= each response received from the router
System Commands
Description
Explanation: The connected device is a DA2DVI-DL.
View Serial Number
Description: The device responds its 8-digit serial number.
Legend: < SERIAL_N > shows the serial number of the device.
Explanation
Example
Command {I} →{i}
Response (<PRODUCT_TYPE>)CrLf ←(I: DA2DVI-DL)
Example
Command {S} →{s}
Response (SN:<SERIAL_N>)CrLf ←
6. Programmer's Reference DA2DVI-DL – User's Manual 20
Description
command.
Legend
Compile Time
Description
Legend:
Explanation
View Installed Board
Description: Shows the hardware name and revision of the installed board.
Explanation: The device reports that it has an installed motherboard, the hardware revision is 1.1.
View Board Information
Description
Explanation
Example
Command {F} →{f}
Response ←
Example
Command {CT} →{ct}
Response (Compiled:<DATE>●<TIME>)CrLf ←
<DATE> Month, day and year
<TIME> Hours, minutes and seconds
Example
Command {IS} →{is}
Response (SL#●0●<MB_DESC>)CrLf
(SL●END)CrLf
←
←
(SL# 0 DA2DVI-DL SCH_1.1 PCB_1.1)
(SL END)
Example
Command {FC} →{fc}
Response (CF●<DESC>)CrLf
(CF END)CrLf
←
←
(CF END)
Restart the Device
Description
Explanation: The device reboots without any response.
EDID Router Commands
Save EDID to User Memory
Description: Learn EDID from <loc2> to <loc1>.
Explanation: EDID from output 3 is saved to user EDID #4.
Legend: <loc1> has to be ‘Uxx’.
<loc2> can be ‘Fxx’ or ‘Uxx’ or ‘Dxx’ or ‘Exx’.
View Emulated EDID on Input
Description: Shows the currently emulated EDIDs for the input.
Explanation: EDID from the output(s) is dynamically emulated on the input.
Example
Command {RST} →{rst}
Response
Example
Command {<loc1>:<loc2>} →{u4:d3}
Response
(E_S_C) CrLf
←
←
(E_S_C) CrLf
Example
Command {VEDID} →{vedid}
Response (VEDID●<IN>)CrLf ←(VEDID D1)
Table of contents
Other Lightware Amplifier manuals
