1. General description
Lightware MX 8x8 DVI Pro is a DVI single link matrix switcher with 8 DVI inputs and 8 DVI
outputs, that routes any input (s) to any combination of output(s). The router conforms to DVI
1.0 specification, and switches signals between 25 - 165 MHz pixel clock frequency: from
640x480@60Hz to 1920x1200@60Hz or 2048x1080@60Hz PC resolutions, including HDTV
resolutions as well. Each input signal is equalized for distances of 50 meter high quality
24AWG cable and each output is reclocked for jitter free signal transmission.
The switcher has an RS 232 ( or RS422 optional) and an RJ45 LAN port for remote control
applications and a control panel for local control operation. Front panel buttons are
illuminated and easy field relegendable with text for informative system integration.
Box contents
Routing switcher
User's manual
IEC power cable
RS 232 9 pole D-sub Male to Female cable
CD-ROM with control software
Cross Link UTP patch cable

MX 8x8 DVI Pro
User’s Manual
Page 7 / 53
Features
50 meter input cable compensation – Using 24AWG high quality DVI cable, the
MX 8x8 DVI Pro automatically compensates up to 50 meter
cable length, which extends installation possibilities even on
highest HDTV or computer resolutions. In case of lower pixel
resolutions, this length can be even higher.
EDID routing – Advanced EDID management with EDID emulation. The user can
emulate any EDID on the switcher's inputs independently, read out
and store any attached monitor's EDID in 100 internal memory
locations, upload and download EDID files using Remote Control
Software.
8 Inputs, 8 Outputs non-blocking cross point matrix architecture – The router
allows any input to be switched to any output or more outputs
simultaneously.
Single link, max 1.65 Gb/s DVI-D transmission (1920x1200 or 2048x1080) –
The MX 8x8 DVI Pro routes any DVI single link signal between
25 and 165 MHz pixel clock frequency conforming to DVI 1.0
standard.
Supports all HDTV resolutions – 720p, 1080i and 1080p etc. without HDCP
encoding - Unencrypted HDTV signals up to 165 MHz pixel
clock frequency regardless of resolution are passed through MX
8x8 DVI Pro
Signal Detect LED-s at each input connector – Active DVI signals are detected:
clock channel activity is green indicated, when signal is applied
to the input.
Output PLL reclocking – (removes jitter caused by long cables ) each output has
a clean, jitter free signal, eliminating signal instability and
distortion caused by long cables or connector reflections.
Front panel buttons control – 8 source select, 8 destination select, Take, Load
preset, Save preset, Panel Lock, Output Lock
Relegendable buttons – Each button has an easy removable flat cap and a
translucent label which can be inserted under it to identify
sources and destinations.
RS 232 or RS422 control – Simple ASCII based RS232 protocol is used for
switching, preset calling, status request, etc.
Ethernet control – TCP/IP Ethernet 10Base-T or 100Base TX (Auto-Sensing)
Fiber cable support – Self powered DVI fiber cables using +5V from DVI sources
( VGA cards, etc.) usually are consuming more than 50 mA,
which load is maximum allowed by DVI 1.0 standard. MX 8x8
DVI Pro supports +5V 500 mA constant current output on each
DVI output to power long distance fiber optical cables.
Universal power supply – MX 8x8 DVI Pro accepts AC voltages from 100 to 240
Volts with 50 or 60 Hz line frequency on standard IEC
connector.
Power failure memory – In case of power failure the unit stores its latest
configuration, and after next power up it loads automatically.

Page 8 / 53
Front Panel view
CONTROL LOCK Sources 1 to 8 Take/ Load Save
Autotake Preset Preset
OUTPUT LOCK Destinations 1 to 8
Control Lock Disables or enables front panel operation. When red
illuminated, operations on front panel are prohibited.
Output Lock Locks and protects one ( or more ) outputs. Inhibits accidental
input changing on protected output.
Sources Source buttons have three functions: to select an input, to
select a preset and to view the selected input’s state (take
mode).
Destinations Destination buttons have two functions: to select an output, or
to view the selected output’s state.
Take/Autotake This button has two functions: displays the actual switching
mode of the router or executes switching on TAKE mode.
Load Preset Loads and executes a previously saved preset from one of the
preset memories.
Save Preset Stores actual matrix state, in one of preset memories.

MX 8x8 DVI Pro
User’s Manual
Page 9 / 53
Rear Panel view
Signal presence LED-s INPUT connectors 1 to 8 CPU Live LED
AC Power AC DC Power OUTPUT Connectors1 to 8 Ethernet RS 232/422
connector Fuse LED's control port port
Input connectors 24 pole DVI–D digital-only female receptacle connectors.
Connect DVI source devices to these connectors.
Input signal LED-s Indicates input signal presence (TMDS clock channel active) on
associated input connector: Green lighting when signal is
present.
CPU LIVE Continuously blinking LED if the CPU works properly
AC Power Standard IEC power connector. The router works with 90 to 264
Volts, 50 or 60 Hz power sources.
AC Fuse Replace with F 3.15 A type only.
DC Power LED's Indicators for presence of internal DC power voltages: +3.3
Volts and + 5 Volts. Green lighting when power voltages are
present.
Ethernet port RJ 45 connector. Remote control port for connecting the unit to
Local Area Network.
RS 232/422 connector 9 pole Dsub female connector for remote control applications.
Can be ordered with RS232 or RS422 control.
Output connectors 24 pole DVI–D digital-only female receptacle connectors.
Connect DVI monitors or other displays to these connectors.

Page 10 / 53
DVI inputs
MX 8x8 DVI Pro provides 24 pole „digital only” DVI-D connectors for input
connections. Always use high quality DVI cable for connecting sources and
displays.
Each input has a built in signal detection circuit with an LED located next to the
input connector. The LED lights green, if the associated connector has an active
DVI clock signal applied.
Pin Signal Pin Signal Pin Signal
1 TMDS Data2- 9 TMDS Data1- 17 TMDS Data0-
2 TMDS Data2+ 10 TMDS Data1+ 18 TMDS Data0+
3 TMDS Data2 Shield 11 TMDS Data1 Shield 19 TMDS Data0 Shield
4 nc 12 nc 20 nc
5 nc 13 nc 21 nc
6 DDC Clock 14 +5V Power 22 TMDS Clock Shield
7 DDC Data 15 GND (for +5V) 23 TMDS Clock+
8 nc 16 Hot Plug Detect 24 TMDS Clock-
Table1. - DVI-D ”digital only” connector Single Link pin assignments
Cable length at inputs
MX 8x8 DVI Pro has an advanced built in cable compensation circuit, which
automatically provides cable length compensation. This circuit extends the
maximum usable cable length to even 60 meter using high quality 22AWG copper
cable on WUXGA 1920x1200 graphics resolution.
Cabel type
Signal
22 AWG
Reference type
DVI GEAR: SHR DVI
24 AWG
Reference type
TASKER: TSK 1060
Resolution Max length (meter) Max length (meter)
1920x1200; 1600x1200;
2048x1080p; 1080p 60 m 50 m
1680x1050; 1400x1050;
1280x1024 75 m 62 m
1024x768; 1365x768;
720p; 1080i; 92 m 77 m
800x600 100 m 84 m
640x480; 480p; 576p 120 m 100 m
Table2. - Maximum DVI cable lengths at inputs

MX 8x8 DVI Pro
User’s Manual
Page 11 / 53
DVI outputs
MX 8x8 DVI Pro provides 24 pole "digital only” DVI-D connectors for output
connections. As standard DVI outputs, there can be used limited length cables,
since there is no output amplification applied. For using longer cable runs at
outputs, use fiber optical DVI cables or active DVI repeaters/extenders.
Output reclocking
MX 8x8 DVI Pro reclocks the signal on all outputs. Signal reclocking is an essential
important procedure in digital signal transmission. After passing the reclocking
circuit, the signal becomes stable and jitter free, and can be transmitted over more
equipment like processors, or event controllers. Without reclocking there can be
seen sparkles, noise and jaggies on the image.
Fiber Cable powering
As special feature MX 8x8 DVI Pro on DDC +5V output (pin 14 on output
connectors) is able to supply 500 mA current to power fiber optical DVI cables.
Standard DVI outputs or VGA cards supply only 55 mA current on +5V output, thus
unable to power directly a fiber optical cable.
Info MX 8x8 DVI Pro does not check if the connected sink (monitor, projector or other
equipment) supports Hotplug or EDID signals but outputs the selected signal
immediately after switch command.

Page 12 / 53
RS 232/422 control port
Lightware MX 8x8 DVI Pro can be remote controlled through industry standard 9
pole sub-D female connector located on the rear panel of the unit. The router can
be ordered with RS232 or RS422 control port.
Pin 5 Pin 1
Pin 9 Pin6
RS 232 port pin locations
Table3. - RS232 and RS422 pin connections
Pin nr. RS 232 RS 422
1 NC non connected TX- data transmit complement
2 TX data transmit TX+ data transmit true
3 RX data receive RX+ data receive true
4 DTR internally connected to Pin 6 RX- data receive complement
5 GND signal ground (shield) GND signal ground (shield)
6 DSR internally connected to Pin 4 NC non connected
7 RTS internally connected to Pin 8 NC non connected
8 CTS internally connected to Pin 7 NC non connected
9 NC non connected NC non connected

MX 8x8 DVI Pro
User’s Manual
Page 13 / 53
EDID Management
MX 8x8 DVI Pro provides an EDID Management feature with advanced functions
that helps system integration. The built in EDID Router stores and emulates 100
EDID data plus all monitor's EDID that are connected to the output connectors.
First 50 EDID are factory presets, while memories 50 to 99 are user
programmable.
On all inputs there can be emulated different or same EDID, that are copied from
EDID router's memory, or the attached monitor. For example, the router can be set
up to emulate any device, that is connected to one of the inputs, and the EDID is
automatically changed, if the monitor is replaced with an other.
EDID is independently programmable for all inputs without affecting each other. All
input has it’s own EDID circuit.
User must not disconnect DVI cables during change an EDID opposite to other
manufacturer’s products.
EDID Router can be controlled with included Matrix Control Software via RS232
port or Ethernet .

Page 14 / 53
2. Operation
POWER
Connect the power cord to the router’s IEC standard power input connector. MX
8x8 DVI RPO is immediately powered on when the power cord is connected to the
AC source. The router does not have a power switch, it remains powered on, until
AC line voltage is present.
After powered on, the unit performs a self test, all front panel buttons light up for
one second. After the self test the router reloads its last configuration and it is
ready for use.
Info At switching on, the router reloads the latest settings which were used before was
turning off. MX 8x8 DV Pro has an internal emergency memory which stores all
current settings, and ties configurations. This memory is independent from presets
and invisible for the user. This built-in feature helps the system to be ready
immediately in case of power failure or accindentally powering down.
FRONT PANEL OPERATIONS
TAKE / AUTOTAKE modes
The router has two different switching modes: TAKE and AUTOTAKE. If the TAKE
button is unlit, TAKE mode is active. When the TAKE button is continuously lighting
green, AUTOTAKE mode is selected.
Press and hold the TAKE button for two seconds to change between TAKE and
AUTOTAKE modes.
TAKE mode allows the user to make multiple connections and deselections at
once. This mode is useful when time delay is not allowed between multiple
switchings.
AUTOTAKE mode is useful when immediate actions must be done or fast
switching is needed between sources on a destination.
CONTROL LOCK
Front panel button operations can be enabled or disabled using CONTROL LOCK
button, while RS232/422 control is still enabled. If it unlits, front panel button
operations are enabled. If there is a coninuous red lighting, front panel operations
are inhibited.
Press and release CONTROL LOCK button to toggle the control lock state.

MX 8x8 DVI Pro
User’s Manual
Page 15 / 53
SWITCHING
Creating a connection or multiple connections in TAKE mode
1. First press and release the selected source button. The pressed source
button and all destination buttons which are currently connected to this
source will light up. The dark remaining destination buttons are not
connected to this source. This is an informative display about current status
of the selected input. (view only)
2. Press and release the selected destination button or buttons which has to be
connected to the selected source. The preselected destination button(s) start
blinking.
3. Press and release TAKE button to execute the tie or ties. Now the selected
input is switched to the selected output or to the multiple outputs.
Deselecting or muting in TAKE mode
1. First press and release the selected source button. The pressed source
button and all destination buttons which are currently connected to this
source will light up. The dark remaining destination buttons are not
connected to this source. This is an informative display about current status
of the selected input. (view only)
2. Press and release the selected, green lighting destination button which has
to be disconnected from the selected source. The pressed destination or
multiple destinations will turn dark.
3. Press and release TAKE button to execute disconnection.
Info Deselected destinations are disconnected from any source, thus output devices will
display black image or "no signal" message, or automatically will turn off.
Info Multiple switching and deselecting actions can be done simultaneously, during only
one TAKE action.
Creating a connection in AUTOTAKE mode
1. Press and release the selected destination button. The pressed destination
button, and the actually connected source button are lighting green. If no
source is connected ( the output is muted) no source button will light.
2. Press and release the selected input button. The switch action will be
executed immediately. Switching between sources to the selected
destination can be done directly.
Deselecting or muting in AUTOTAKE mode
1. Press and release the selected destination button. The pressed destination
button, and the actually connected source button are lighting green. If no
source is connected ( the output is muted) no source button will light.

Page 16 / 53
2. Press and release the active green lighting source button. The output is
muted.
Info Deselected destinations are disconnected from any source, thus output devices will
display black image or "no signal" message or automatically will turn off.
SAVE or LOAD PRESETS
MX 8x8 DVI Pro has 8 user programmable presets. Each preset stores a
configuration regarding all input connections for all outputs. All presets are stored
in a non volatile memory, the router keeps presets even in case of power down.
Memory numbers are assigned to source buttons 1 to 8
Saving a Preset in TAKE mode
1. Press and release SAVE PRESET button.
2. Press and release the desired source (memory address) button (source 1 to
8)
3. Press and release TAKE button. Now the current configuration is stored in
selected memory.
Info Preset save action always stores the current configuration for all outputs
Loading a Preset in TAKE mode
1. Press and release LOAD PRESET button.
2. Press and release the desired source (memory address) button (source 1 to
8)
3. Press and release TAKE button. Now the selected preset is loaded.
Info Loading a preset always modifies all output states.
Saving a Preset in AUTOTAKE mode
1. Press and release SAVE PRESET button.
2. Press and release the desired source (memory address) button (source 1 to
8). Now the current configuration is stored in the selected memory.
Info Preset save action always stores the current configuration for all outputs .

MX 8x8 DVI Pro
User’s Manual
Page 17 / 53
Loading a Preset in AUTOTAKE mode
1. Press and release LOAD PRESET button.
2. Press and release the desired source (memory address) button (source 1 to
8). Now the selected preset is loaded.
Info Loading a preset always modifies all output states.
VIEW current state
User can check the current switching status on the front panel using front panel
buttons. View mode is slightly different in TAKE or AUTOTAKE modes because of
different switching philosopy of the two modes.
Info View mode does not mean, that the router has to be switched in different mode,
viewing and switching can be done after each other, without pressing any special
button.
View current state in TAKE mode
If the router is in TAKE mode, user can verify both input and output connections. In
TAKE mode no accidental change can be done unless TAKE button is pressed.
Press and release a source button. Now the selected source button and all
destination buttons will light up which are currently connected to the selected
source. This informative display will remain for 5 seconds, then turns all buttons
unlit.
If all source and destination and TAKE buttons are unlit (the unit is in TAKE mode,
and no input was selected in last 5 seconds), press and release a destination
button to see its current state. Now the source button which is connected to the
selected destination will light up. If no source button is lighting, the selected
destination is in muted state. Pressing another destination button, there can be
seen the last pressed state of destination.
View current state in AUTOTAKE mode
In AUTOTAKE mode only states of destination can be viewed.
Press and release the required destination button. Now the source button which is
connected to the selected destination will light up. If no source button is lighting,
the selected destination is in muted state. Pressing another destination button,
there can be seen the last pressed current state of destination.

Page 18 / 53
OUTPUT LOCK
Using MX 8x8 DVI Pro there is a possibility to lock a destination. This feature
prevents an accidental switching to the locked destination in case of important
signal. Locking a destination means, that no input configuration can be changed or
deselected on that particular destination.
Destinations can be indepentently locked or unlocked. Locking a destination does
not affect other destinations.
Output Lock in TAKE mode
1. Press and release the required destination button. Now the selected
destination button and the currently configured source button will light up
(view mode)
2. Press and release the Output Lock button. Now the Output Lock button will
light up in red colour.
3. Press and release TAKE button. The desired destination now is locked.
Unlock in TAKE mode
1. Press and release the required destination button which was previously
locked. Now the selected destination button and the currently configured
source button and the Output Lock button will light up.
2. Press and release the Output Lock button (deselect). Now the Output Lock
button will turn off, however the locking function has not been unlocked yet.
3. Press and release TAKE button. The desired destination now is unlocked.
Output Lock in AUTOTAKE mode
1. Press and release the required destination button. Now the selected
destination button and the currently configured source button will light up
(view mode)
2. Press and release the Output Lock button. Now the Output Lock button will
light up in red colour, and lock function is activated. No source can be
changed at the locked destination.
Unlock in AUTOTAKE mode
1. Press and release the required destination button which was previously
locked. Now the selected destination button and the currently configured
source button and the Output Lock button will light up
2. Press and release the Output Lock button (deselect). Now the Output Lock
button will turn off, and the locking function has been unlocked.

MX 8x8 DVI Pro
User’s Manual
Page 19 / 53
3. RS 232 / 422 and Ethernet control
RS232 / RS422 ports
M8x8DVI-Pro can be ordered with either RS232 or RS422 communication port.
The port settings are done in the factory. D-sub connector pin assignments can be
found on chapter 1.
Changing and viewing protocols
M8x8DVI-Pro is equipped with multiple router protocols.
1. Switch the router in TAKE mode if used prevoiously in AUTOTAKE mode by
pressing TAKE button for 2 seconds. ( TAKE will not light continuously)
2. Press and release Control Lock ( Control Lock button lights in red colour
continuously)
3. Press and keep pressed Output Lock button. Now one of the source buttons
will light up ( view protocol)
If Source#1 button lights: Lightware protocol is active
If Source#2 button lights: Protocol#2 is active
4. During Output Lock pressed, press the desired Source button, accordingly to
the new protocol. The desired Source button starts blinking, the router
performs a reset and all buttons light up for 4 seconds. Now the new
protocol is active.
Port settings:
The device uses standard RS-232 interface with the following settings:
9600 Baud
8 data bit
1 stop bit
no parity
null modem cable
The matrices accept commands surrounded by curly brackets - { } - and responds
surrounded by round brackets - ( ) - only if a command was successfully executed.
Input, output numbers and values must be sent as two digit ASCII numbers.

Page 20 / 53
Ethernet setup
The matrix switchers can be controlled via ethernet identically the same way as via
serial port. The same commands can be issued on the ethernet as on the serial
port. The Ethernet settings can be accessed through Ethernet connection only.
Enter current IP address into the address line of your browser ( eg. Internet
Explorer, etc) and press OK to proceed. The default IP is 192.168.254.254
Select “Use the following IP configuration”. Enter your settings (the default is
shown), then press OK to proceed.
