lil SOLID 2.0 User manual

მომხმარებლის სახელმძღვანელო
User Guide

23
When the Cap
is removed
Cap
Charging Port
Styler Deco
Button (Status LED light)
By pressing the Button or once the device is plugged into a power outlet
through the Charging Port, the charging status of the device is displayed.
Charge the device before your first use.
Takes approximately 2 hours to be fully
charged, available for use for approximately
25 sticks (the number of sticks can vary according
to the use environment).
Cover of stick
insertion part
Only use the USB Cable and AC Power Adaptor
designed for lil SOLID™ 2.0 that come with your
device.
You may charge the device whenever it is
convenient regardless of the battery charge status.
When the device is being charged, the Status LED lights.
• The Status LED blinks while the device is being charged.
• The Status LED goes off after the device is fully charged.
* Due to the nature of the parts used for the Status LED, the brightness and
color of the LED light may vary slightly.
Blue
100~60%
Ice Blue
60~30%
Orange
30~1%
Red
needs to be charged
1. Name and component of each part

24
2. Box Contents
lil SOLID 2.0 Device
User Kit
User Guide, Safety Warnings and Instructions and Warranty
USB CableAC Power Adaptor Dual
Cleaner

25
3. Safety Warnings and Instructions
Read all instructions in this User Guide
carefully before use to operate the device in
a safe and correct manner.
The Safety Warnings and Instructions
discussed in this User Guide cannot cover
all possible situations that could occur
during the use of the device. Caution and
care must be exercised when using or
maintaining an electronic device.
Keep these safety warnings and
instructions for future reference as
they contain important information.
Failure to follow these instructions may
result in personal injuries.

26
Device electronic and battery
• Do not use the device with its Cap removed.
• Be careful not to drop the device in water.
• This product contains no user-serviceable parts.
Do not attempt to open, modify, disassemble or
repair the battery or any component of this device.
• If the device appears to be damaged, modified,
disassembled, tampered with, or immersed in liquid
after purchase, do not activate the device.
• Do not touch the device, AC Power Adaptor and USB
Cable if they overheat, fume, ignite, spark or burn.
• Do not use the device if it has been exposed to excessive heat.
• Do not connect the device through electric wires or other
metallic materials. Doing so may cause damage.
• Do not use the device where flammable materials,
liquids or gases are present, or under conditions
with high oxygen supply. Doing so presents an
explosion hazard.
• Device, AC Power Adaptor and USB Cable should
not be exposed to any liquid, oils, solvents, etc. Do
not touch the device or its parts if it becomes wet or
has been immersed in liquids, oils, solvents, etc.

27
• Do not clean the device using liquids, oils, solvents, etc.
• Caution must be exercised so that foreign materials
do not enter the stick insertion part. Do not use
device unless foreign particles have been removed.
• If any fluid leaking from the device comes in contact
with skin, wash the affected area, including hands
and do not touch eyes. In case any fluid comes in
contact with eyes, immediately flush with clean,
running water for at least 15 minutes and seek
medical attention.
• Do not use the device if battery is leaking.
• Only use USB Cable and AC Power Adaptor designed
for lil SOLID 2.0. See the Technical Data section of
this User Guide for approved Power Adaptor models.
Do not use other cables and power adaptors - doing
so may result in damage.
• Charge the device indoors only, as indicated by symbol .
• Only use Fiit™ tobacco sticks specifically designed for
lil SOLID device. The performance of the device is
not guaranteed if you use it with other consumables.
Use and storage

28
• Do not modify Fiit tobacco sticks in any way or
add any substance to Fiit tobacco sticks. Doing so
may cause injury.
• K eep device, USB Cable, AC Power Adaptor and
tobacco sticks out of reach of children and pets at all
times. Caution: Parts may be swallowed by children.
• This device is intended for adult-use only.
Children and minors should never use the device
under any circumstances.
• The device and tobacco sticks are prohibited for sale
to minors.
• Do not remove Cap while device is in use or immediately
after use as device may be hot. Allow for device to
cool before removing Cap.
• Even if the tobacco stick is removed during use,
the heating process continues. To stop it, turn off
power by pressing the Button for 2 seconds.
• Clean the device after cooling.
• After removing the tobacco stick from the device,
do not touch the tobacco portion of the stick as it
will be hot after use.
• Handle the device with care. Do not drop this device

29
or subject it to strong shock.
• Storing the device in places with high temperatures
(such as inside a vehicle or near heat sources such as
radiators or fires), high humidity or low temperatures,
may reduce battery performance.
• Device battery will deplete if left unused for an extended
period of time. Recharge the device before use.
• Fiit Tobacco sticks specifically designed for
lil SOLID device are single-use. Do not re-insert a
used stick into the device. The performance of
the device is not guaranteed if used sticks are
re-inserted.
• The tobacco stick should never be lit with a match,
lighter, or any other flame source.
• Fiit Tobacco sticks may show spots or discoloration
after normal use.
• Do not insert the device in your mouth.
• Do not operate the device where use of electronic
devices is prohibited.
• This device is not intended for use by persons with
reduced physical, sensory or mental capabilities or
lack of knowledge unless they have been given

30
Tobacco and nicotine
• Fiit Tobacco sticks contain nicotine, which is addictive.
Nicotine is naturally present in tobacco used in tobacco
sticks.
• Swallowed tobacco sticks can pose a risk of nicotine
intoxication. If tobacco sticks are swallowed, seek
medical attention immediately.
• The best way to reduce tobacco-related health risks
is to quit tobacco and nicotine use altogether.
• Stopping smoking cigarettes or switching to other
nicotine-containing products may require the
adjustment of the dosing of certain medicines
(e.g. theophylline, clozapine, ropinirole).
• Using nicotine-containing tobacco sticks may cause
s ide effects such as headache, nausea, throat
supervision or instruction to use the product in a
safe way and understand the hazards involved.
• Being exposed to sweat, UV rays and chemicals in a
repeated manner may discolor the device exterior.
• Proximity to magnetic field may cause malfunction.

31
• If you experience any unwanted health effect when
using the device, consult a health care professional.
• You can report any adverse event or incident
directly by contacting Customer Service Centre
at 0800 003 003.
• By reporting side effects, you can help provide
more information on the safety of this product.
irritation, or stomatitis. If you experience these
symptoms, stop use of the product immediately.
• If you are pregnant, think you may be pregnant, or
are breastfeeding, or have heart disease, diabetes,
epilepsy, seizures or other serious conditions, you
should quit tobacco and nicotine use altogether and
consult a health care professional.
• Use of tobacco sticks may cause an allergic reaction.
Seek medical attention immediately if you experience
any of the following symptoms: swelling of the face,
lips, tongue, etc., and/or difficulty breathing.
Reporting of adverse events or incidents

32
4. Use
The device is in the sleep
mode and does not operate
unless activated for your first
use. To wake up the device
press the Button for 2 seconds
or connect the charger to the
charging port.
• If you insert the stick upside down, the device can break down during use. Please check the insertion
direction of the stick before use.
• Close the cover of the stick insertion part when the device is not in use to prevent any substances from getting inside.
Get your device. Slide and open the Cover of
the stick insertion part at the
top of the device.
Insert a Fiit tobacco stick designed
for lil SOLID into the stick insertion
part with the tobacco part facing
down and press the stick in until
it touches the bottom of the stick
insertion part.
While the device wakes up,
the Status LED blinks twice in
red, orange, ice blue and blue,
sequentially.
Once the device is activated,
the Status LED blinks in
ice blue for one second
and vibration occurs twice,
simultaneously.
Steps before use
To conserve battery life, the device will return to sleep mode:
① if it is not charged for 24 hours when the Status LED light is red.
② if it is not used for 7 days when the Status LED light is orange, ice blue, or blue.

33
Press the Button for 2 seconds
until vibration occurs.
The device with Fiit tobacco
stick is ready to use.
You have up to 14 puffs or 5
minutes, whichever comes
first.
Press the Button for 2 seconds and remove the tobacco stick only if you want to stop the session
and the use of the device.
After 2 seconds, the Status LED
blinks in ice blue, and vibration
occurs simultaneously. During
around 25 seconds, the preheating
process starts. The duration time
of the preheating process can vary
according to the use environment.
To signal the last 30 seconds
of the session or the last 3
puffs, whichever comes first,
the device will vibrate once
and the Status LED will blink
in ice blue until the end of the
session.
When the preheating process
ends, the Status LED lights
come on, and vibration occurs
simultaneously.
This means that the preheating
process has ended, and the
stick is ready for use.
When the session comes to
an end, the Status LED and the
device turn off automatically.
You do not need to press the
Button.
Start device
Use

34
If a stick is not removed as described above, the remnants of a used stick may remain inside.
If there are some remnants inside the stick insertion part, refer to of 6. Troubleshooting.
For consecutive use, please repeat the above - steps.
May use up to 3 consecutive uses.
Consecutive uses
Unscrew the stick to one
direction 3 times or more.
Close the Cover of the stick
insertion part.
Pull the stick out the device.
3 times
Removing the tobacco stick
5. Cleaning and handling
Grab the Dual Cleaner. To use the Cleaning Brush,
gently snap open the side
with the mark.
To use the Cleaning Wiper,
gently snap open the side
with the ⊙mark.
Cleaning with the Dual Cleaner

35
Quickly press the Button
5 times (within 2 seconds).
When the cleaning process ends,
the Status LED automatically goes
off, and vibration occurs 2 times.
The Status LED blinks in orange,
for 90 seconds, and the cleaning
process proceeds automatically.
* Cleaning with heat means heating the remnants stuck to the heater. The heater can get very hot, so
do not let anything come into contact with the heater during or immediately after cleaning with heat.
Cleaning with heat
* We recommend cleaning the device after using 20 sticks for optimum performance of the device.
* Do not clean the device during heating or right after the use of the device. Let the device to cool
down, otherwise the Cleaning Wiper or the Cleaning Brush can melt and stick to the device.
* Take care not to let the Cleaning Wiper or the Cleaning Brush come into contact with any liquid, oils,
solvents, etc.
* Take care not to let the Cleaning Wiper or the Cleaning Brush come into contact with eyes.
* Keep the Cleaning Wiper or the Cleaning Brush away from fire.
* Caution should be exercised when using the Cleaning Wiper and Cleaning Brush as they can be sharp.
* Use of other cleaning tools aside from Cleaning Wiper or Cleaning Brush or using excessive force
may damage the heater.
Remove the Cap from the
device.
Insert the Cleaning Brush into
the device and clean the device
by spinning the Cleaning Brush.
Insert the Cleaning Wiper into
the device and clean the device
by spinning the Cleaning Wiper.

36
6. Troubleshooting
If there are remnants from the previous stick inside the stick insertion part, a stick may not
be inserted. Remove the remnants by pulling the Cap out of the device and try to insert the
stick again.
Check for any remnants
inside the stick insertion part.
Status LED lights in red for
3 seconds and vibration occurs
3 times, simultaneously.
The battery is insufficient.
Charge the device.
Remove the remnants from
the Cap.
Status LED blinks in orange for
3 seconds. After 3 consecutive
sessions the device will cool
down automatically.
Please wait until the device
temperature is stabilized.
If there are remnants of a
used stick, remove the Cap
from the device.
Status LED blinks in red 5 times.
The device is malfunctioning.
Reset the device.
I cannot insert the stick into the device.
My device does not work.
* For your safety, the device cannot be used more than 3 times within 18 minutes as it needs to
cool down. It will take 3 minutes and 30 seconds before you can have another session.

37
7. Disposal
8. Warranty
How can I reset the device?
Press the Button for
8 seconds, even if vibration
occurs within 2 seconds.
When the device is completely
reset, the Status LED lights in ice
blue for 1 second, and vibration
occurs twice, simultaneously.
The device is reset, and the
Status LED blinks twice in
red, orange, ice blue and blue,
sequentially.
The duration of using the stick is too short.
The device is designed to provide up to 14 puffs or 5 minutes, whichever comes first.
The warranty period for the device is one year, subject to the terms and conditions described
in the warranty.
• The device uses a lithium ion battery.
Dispose your device in accordance with the applicable regulations.
• Please contact the local municipal authorities to learn more information about the disposal
of the device and the power adaptor.
Warranty Period
• The duration of this product warranty on lil SOLID 2.0 device, AC Power Adaptor and USB
Cable is 12 months from the date of purchase.
• In the absence of the proof of purchase, the company reserves the right to voluntarily apply
the warranty duration starting from the manufacturing date of the product in question
based on its own records.
Warranty Coverage
• The company will, at its option (but without affecting your statutory rights), repair or replace
any components which are defective in terms of material or workmanship when used in

38
accordance with the associated lil SOLID 2.0 User Guide and which are subject to a valid
warranty claim.
• If repair is not possible, replacement will be provided with a product of equivalent functionality.
To the extent permitted by local law, the replacement color and/or model are subject to
such color and/or model availability. In case of replacement of the product under this
warranty, any replacement part becomes your property and the replaced part becomes the
property of the company or entity which makes the exchange.
• The provisions of this warranty are only valid in the country of purchase.
Exclusions to warranty
Products with expired warranty or damaged by consumer negligence are excluded from the warranty service.
The following are excluded from the terms of this warranty:
malfunction damage caused by normal wear and tear elements;
cosmetic damages (such as scratches, dents, broken plastic, etc.) that do not impact the
functionality of the product;
damage caused by misuse, abuse, accidents, unsuitable operating environment, natural
disasters, power surge, contact with liquids or fire;
malfunction due to use with non-compatible consumables, power adaptor or cable;
damage or malfunction caused by attempt to open, modify and repair, either by a user or
by a service provider not accredited by the manufacturer;
damage or malfunction caused by failure to use as described in the associated
lil SOLID 2.0 User Guide;
normal battery performance depreciation, unless battery failure has occurred due to
a defect in materials or workmanship;
devices containing fully or partially non genuine parts;
loss or theft of the product or its parts;
operation of the product in a country for which it was not originally designed or approved.
a)
b)
c)
d)
e)
f)
g)
h)
i)
j)
Claim under warranty
To make a claim under this warranty, please contact your Customer Service Centre number
below for assistance or visit one of our stores. It is recommended to have a proof of
purchase when making a warranty claim.
Other
Under no circumstances is the company liable for any personal or third-party claims for
damages related to the use of the product besides the ones mentioned in this document.

39
lil SOLID 2.0
Model: S-MONO-21
Battery type: Li-ion rechargeable battery
Input: 5.0V 2.0A
The lil SOLID 2.0 is marked with the symbol [ ] followed by “xx-1007EMTx”, which indicates that
lil SOLID 2.0 can only be charged using the approved Power Adaptor models designed for lil SOLID 2.0.
AC Power Adaptor
Model: HM-1007EMTE
Input: 100-240V~ 50-60Hz 0.35A
Output: 9.0V 1.67A or 5.0V 2.0A
Output power: 15.0W or 10.0W
Average active efficiency: 86.15% or 82.95%
Efficiency at low load(10%): 81.05% or 80.00%
No load power consumption: <0.07 W
USB Cable
Dual Cleaner
To find out the month and year of manufacturing of the lil SOLID device you should call the
Customer Service Centre and tell the 14-digit alphanumeric code placed under the cap of
the device.
Storage conditions: in dry, conditioned premises, temperature regime: from 5 °C to 30 °C
relative humidity less than 70%.
Customer Service Centre: 0800 003 003
9. Technical Data
This limitation does not apply for cases where the company is liable towards you under law.
In EU member states buyers may have rights and remedies against the seller for a longer
period, at least two years, in respect to any defect existing at the time of delivery.

BATTERY REMOVAL INSTRUCTIONS
(FOR DISPOSAL AND RECYCLING)
Battery must not be removed by the consumer. At the end of product life, only an authorized
recycler may safely remove battery by using the following steps.
Model S-MONO-21
Step 1: The device should be fully discharged before disassembling it.
Step 2: Detach the Styler Decos from both sides of the device.
Step 3: Remove the labels (black stickers with printing) on both sides, then remove the screws.
Step 4: Remove the long plastic in the center of both sides.
Step 5: Detach the housing from the internal components.
Step 6: Remove all screws and connectors, then detach the FPCB and PCB from the hull.
Step 7: Remove battery and dispose of according to local regulations.
Confirmation of Compliance
This device complies with the RF exposure limits and has been evaluated in compliance with
portable exposure condition according to the EN 62311:2008.
Caution
Only use this device with Fiit tobacco sticks designed for lil SOLID.
Fiit Tobacco sticks are sold separately.
This device must not be sold to minors.
lil, lil SOLID and Fiit are trademarks owned by KT&G Corporation and used under license by
Philip Morris Products S.A.
IQOS is a trademark owned by Philip Morris Products S.A.
