Capacity Estimates | Pies Per Hour:
BAKE TIME
Pie Size 3 min. 3½ min. 4 min. 4½ min. 5 min. 5½ min. 6 min. 6½ min. 7 min.
12”(30 cm) 182 155 135 120 108 99 90 84 78
14”(36 cm) 115 99 87 88 69 63 58 53 50
16”(41 cm) 101 87 76 67 61 55 51 47 44
Ventilation Requirements:
Ventilation is required. Local codes prevail. These are the “authority having jurisdiction”as stated by the
National Fire Protection Association, Inc., in NFPA 96-1994. Estimates of CFM requirements can vary from
2400 to as high as 6000 CFM exhaust. In all cases the ambient temperature around the oven must not
exceed 95°F (35°C) when the oven is operating. This information is shown as a guideline for ventilating
the Impinger®1600 Ovens.
18-24”
(457 mm -
610mm)
8”
(203 mm)
CAPTURE AREA CAPTURE AREA
CAPTURE VELOCITY 50 FPM CAPTURE
VELOCITY
50 FPM
78”
(1981 mm)
94” (2388 mm)
8”
(203 mm)
6”
(153 mm)
6”
(153 mm)
70” (1778 mm)
1. Dimensions shown are for ovens without long extension shelves. The outside end of the conveyor
frame must be a minimum of eight (8) inches (203 mm) inside the canopy as shown.
2. The capture velocity across the lower edge of the canopy is to be 50 FPM at sides and front.
3. Use lters at rear exhaust area of the hood, as shown. Do not just put an opening into a 4 sided canopy.
4. The ovens are to be centered in the canopy space left-to-right and front-to-back if possible.
5. A six (6) inch space at rear of oven is recommended for utilities.
6. Use of a Type I or Type II application and overall nal installation is determined per local codes.
7. Recommended 2400-3000 CFM exhaust, typical, or higher per local codes; as a guideline to obtain
adequate capture velocity.
8. Recommended 80% of make-up air provided outside of the canopy through perforated metal dif-
fusers directed straight down... not at the oven; located at front , side or both.
9. Room air diusers must not be directed onto the oven and should be positioned a minimum of
three (3) feet from the perimeter of the hood to keep airow from aecting the oven.
NOTE: Specications subject to change without notication.
1600 Series | Impinger® Low Prole Single Belt Conveyorized Oven

Global
1600 Series Impinger® Low Prole
Single Belt Conveyorized Oven
Lincoln Impinger®Conveyor Ovens are
the premier continuous cook platform
for the food service industry. Using the
latest advancements in air impingement
technology, Impinger®Ovens allow for
rapid heating, cooking, baking, and
crisping of foods, typically done two
to four times faster than conventional
ovens.
Easy to Operate:
•Digital controls with single
on/off power switch.
•Microprocessor controlled
bake time/conveyor speed.
•Improved view vacuum
florescent readout displays
set temperatures in degrees
(F° or C°), conveyor belt
speed, thermostat indicator
light, and diagnostic
messages for easy trouble
shooting.
•All settings are automatically
locked out to eliminate
accidental changes.
Easy to Clean:
•Front door for easy cleaning
and removal of finger
assemblies.
•Conveyor is removable
through the right side
opening.
Optional Features:
•FastBake™ Upgrade: Improve
your bake time by up to
35% without increased noise
levels or loss of product
quality!
•Entry and exit shelves.
•Flexible gas connector.
•Cleaning kit (#1050)
Models:
1111 North Hadley Road
P.O. Box 1229
Fort Wayne, Indiana 46801-1229
Tel [phone]
Fax [phone]
E mail [e-mail]
web www.lincolnfp.com
www.lincolnfp.com
•Faster bake times improve
time of service.
•Advanced Air Impingement
Technology enhances bake
quality and uniformity.
•Improved product flow
during cooking reduces
operation costs.
•Research and Applications
support for continued
operational success.
•Enodis Star service support
is committed to ongoing
customer satisfaction.
•New FastBake™Technology
designed to bake up to 35%
faster than other conveyor
ovens without increased
noise levels or loss of product
quality! (Optional)
Benets:
Approved by The Canadian Standards Association
•Stackable up to three (3) oven
cavities high.
•32” (812 mm) wide, 73” (1854
mm) long conveyor belt with
product stop.
•40” (1016 mm) baking
chamber.
•Temperature is adjustable from
250°F (121°C) to 600°F (316°C).
•Conveyor speed is adjustable
from one (1) minute to thirty
(30) minutes cooking time.
•Dual heating systems for
maximized cooking efficiency.
•Front-loading access door with
cool handle.
•Customer-specific setups give
customer very specific results.
•Indirect conveyor drive is
powered by an AC motor.
•Stainless Steel top, front and
sides.
•Oven Start-Up/Check-Out
by Enodis Star service agent
included in price.
Standard Features:
1600-000-U
1601-000-U
1621-000-E
1622-000-U
1623-000-U
1624-000-U
1628-000-N
1629-000-N
1633-000-E
1634-000-E
1635-V00-E
1636-V00-E
1637-000-E
1600 Series | Impinger® Low Prole Single Belt Conveyorized Oven

Global
Gas Supply Pressure Recommendations:
Gas Type Supply (Inlet) Pressure (mbar)
Recommended
Minimum
Gas Pipe Size
Natural 9-14” WC (2.2 kPA / 22.4 mbar - 3.5kPa / 34.9 mbar) 2” (51 mm)
LP 11-14” WC (2.7 kPa / 27.36 mbar - 3.5 kPa / 34.9 mbar) 2” (51 mm)
*Gas supply pressures are dependent on local gas type and on all applicable local codes. Agency approved exible
connection to each oven must be minimum¾”(19 mm) NPT and length must not exceed six (6) feet (1829 mm).
Electrical Service:
Each oven deck requires voltage, phase and hertz as indicated by model number. Neutral must be grounded
at electrical service and receptacle properly polarized. Gas 120V units have a cord with NEMA 5-15 plug.
All other models have terminal block connections. It is recommended that a separate circuit breaker be
provided for each oven deck.
Recommended Minimum Clearances:
Rear of oven to combustible surface: 6”(152 mm). Clearance on each side from other cooking equipment: 24”
(610 mm). Clearance required to remove conveyor for cleaning: 11’(3553 mm).
Warranty:
All new impinger®ovens installed in the United States and Canada come with a one (1) year parts and labor
warranty starting from the date of start-up/check-out. All ovens installed in locations other than the US and
Canada are warranted for one (1) year parts and ninety (90) days labor starting from the date of start-up/
check-out. Start-up/check-out must occur within 24 months of date of manufacture.
General Information:
All 1600 Models
Length Depth Height
Single
Height
Double Stacked
Height
Triple Stacked
80”
(2032 mm)
60 ¹/₂”
(1537 mm)
44 ¹/₈”
(1121 mm)
63 ³/₈”
(1610 mm)
66 ³/₈”
(1686 mm)
Model
Number Agency Utility Input Rate Voltage Hertz Phase Supply
1600-000-U NSF/CSA Natural
110,000 BTU
32.2 kW
(116 MJ)
120 60 1 3
1633-000-E NSF/AGA/CE Natural 230 50 1 3
1635-V00-E -- Natural 220 60 1 5
1601-000-U NSF/CSA LP 120 60 1 3
1634-000-E NSF/AGA/CE LP 230 50 1 3
1636-V00-E -- LP 220 60 1 5
1621-000-E CE Electric
29 kW
400/230 50 3 5
1622-000-U UL/NSF Electric 120/208 60 3 5
1623-000-U UL/NSF Electric 120/240 60 3 5
1624-000-U UL/NSF Electric 120/220 60 3 5
1628-000-N -- Electric 380/220 50 3 5
1629-000-N -- Electric 415/240 50 3 5
1637-000-E CE Electric 215/240 50 3 5
NOTE: Panel setups are added as kit numbers to the end of the model number to complete the oven order; (example: 1600-000-U-K1819 is a 1600-000-U with
standard setup, left to right.)

Global
91”
(2311mm)
3/4” N.P.T. INLET w/Tee
(19 mm)
120 VOLT
10 FT. LONG
POWER CORD
3/4” N.P.T.
(19 mm)
UNION
GAS
DOOR SWING
80” (2032 mm)
18”
(457 mm)
40”
(1016 mm)
22”
(585 mm)
7 1/2”
(191 mm)
44 1/8”
(1121 mm)
32 1/8”
(816 mm)
7 1/2”
(191 mm)
32 1/8”
(816 mm)
51 3/8”
(1305 mm)
63 3/8”
(1610 mm)
5 5/8”
(143 mm)
16”
(406 mm)
35 1/2”
(901 mm)
54 3/8”
(1387 mm)
66 3/8”
(1692 mm)
3 1/8”
(79 mm)
OPENING GAS
60 1/2”
(1537 mm)
58 1/4”
(1479 mm)
33 1/2”
(851 mm)
OPENING 64 1/2”
(1638 mm)
27 5/8”
(702 mm)
91”
(2311mm)
3/4” N.P.T. INLET w/Tee
(19 mm)
120 VOLT
10 FT. LONG
POWER CORD
3/4” N.P.T.
(19 mm)
UNION
GAS
DOOR SWING
80” (2032 mm)
18”
(457 mm)
40”
(1016 mm)
22”
(585 mm)
7 1/2”
(191 mm)
44 1/8”
(1121 mm)
32 1/8”
(816 mm)
7 1/2”
(191 mm)
32 1/8”
(816 mm)
51 3/8”
(1305 mm)
63 3/8”
(1610 mm)
5 5/8”
(143 mm)
16”
(406 mm)
35 1/2”
(901 mm)
54 3/8”
(1387 mm)
66 3/8”
(1692 mm)
3 1/8”
(79 mm)
OPENING GAS
60 1/2”
(1537 mm)
58 1/4”
(1479 mm)
33 1/2”
(851 mm)
OPENING 64 1/2”
(1638 mm)
27 5/8”
(702 mm)
91”
(2311mm)
3/4” N.P.T. INLET w/Tee
(19 mm)
120 VOLT
10 FT. LONG
POWER CORD
3/4” N.P.T.
(19 mm)
UNION
GAS
DOOR SWING
80” (2032 mm)
18”
(457 mm)
40”
(1016 mm)
22”
(585 mm)
7 1/2”
(191 mm)
44 1/8”
(1121 mm)
32 1/8”
(816 mm)
7 1/2”
(191 mm)
32 1/8”
(816 mm)
51 3/8”
(1305 mm)
63 3/8”
(1610 mm)
5 5/8”
(143 mm)
16”
(406 mm)
35 1/2”
(901 mm)
54 3/8”
(1387 mm)
66 3/8”
(1692 mm)
3 1/8”
(79 mm)
OPENING GAS
60 1/2”
(1537 mm)
58 1/4”
(1479 mm)
33 1/2”
(851 mm)
OPENING 64 1/2”
(1638 mm)
27 5/8”
(702 mm)
91”
(2311mm)
3/4” N.P.T. INLET w/Tee
(19 mm)
120 VOLT
10 FT. LONG
POWER CORD
3/4” N.P.T.
(19 mm)
UNION
GAS
DOOR SWING
80” (2032 mm)
18”
(457 mm)
40”
(1016 mm)
22”
(585 mm)
7 1/2”
(191 mm)
44 1/8”
(1121 mm)
32 1/8”
(816 mm)
7 1/2”
(191 mm)
32 1/8”
(816 mm)
51 3/8”
(1305 mm)
63 3/8”
(1610 mm)
5 5/8”
(143 mm)
16”
(406 mm)
35 1/2”
(901 mm)
54 3/8”
(1387 mm)
66 3/8”
(1692 mm)
3 1/8”
(79 mm)
OPENING GAS
60 1/2”
(1537 mm)
58 1/4”
(1479 mm)
33 1/2”
(851 mm)
OPENING 64 1/2”
(1638 mm)
27 5/8”
(702 mm)
91”
(2311mm)
3/4” N.P.T. INLET w/Tee
(19 mm)
120 VOLT
10 FT. LONG
POWER CORD
3/4” N.P.T.
(19 mm)
UNION
GAS
DOOR SWING
80” (2032 mm)
18”
(457 mm)
40”
(1016 mm)
22”
(585 mm)
7 1/2”
(191 mm)
44 1/8”
(1121 mm)
32 1/8”
(816 mm)
7 1/2”
(191 mm)
32 1/8”
(816 mm)
51 3/8”
(1305 mm)
63 3/8”
(1610 mm)
5 5/8”
(143 mm)
16”
(406 mm)
35 1/2”
(901 mm)
54 3/8”
(1387 mm)
66 3/8”
(1692 mm)
3 1/8”
(79 mm)
OPENING GAS
60 1/2”
(1537 mm)
58 1/4”
(1479 mm)
33 1/2”
(851 mm)
OPENING 64 1/2”
(1638 mm)
27 5/8”
(702 mm)
Technical Drawings:
NOTE: Specications subject to change without notication.
