DEMO MANUAL DC1668A-C
DESCRIPTION
LTM4627EV High Efficiency
50A PolyPhase Step-Down
Power Supply
BOARD PHOTO
Demonstration circuit 1668A-C is a PolyPhase
®
power
supply featuring four LTM
®
4627 high efficiency synchro-
nous buck µModule
®
regulators. The DC1668A-C input
voltage range is between 4.5V to 20V with a jumper pro-
grammable output voltage from 0.6V to 3.3V. The demo
circuit can deliver up to 50A of load with excellent current
sharing. Current derating may be necessary under certain
operating conditions.
The LTM4627 can be synchronized to an external clock be-
tween 250kHz to 770kHz. The default switching frequency
for the DC1668A-C is set to 500kHz through the onboard
LTC6902 clock generator. The external clock interleaves
the paralleled phases to minimize input and output ripple.
DC1668A-C demonstrates that paralleling LTM4627 mod-
ules is easy and reliable. These features and the availability
of the LTM4627 in a compact thermally enhanced 15mm ×
15mm × 4.32mm LGA package make the circuit ideal for
use in high density point of load regulation applications.
Design files for this circuit board are available at
http://www.linear.com/demo
L, LT, LTC, LTM, Linear Technology, PolyPhase, µModule and the Linear logo are registered
trademarks of Linear Technology Corporation. All other trademarks are the property of their
respective owners.

2
dc1668acf
DEMO MANUAL DC1668A-C
PARAMETER CONDITION VALUE
Input Voltage Range 4.5V to 20V
Output Voltage VOUT Remove VOUT SEL Jumper for VOUT = 0.6VDC 0.6VDC, 1VDC, 1.2VDC, 1.5VDC, 1.8VDC,
2.5VDC, 3.3VDC
Maximum Continuous Output Current IOUT(MAX) Current Derating May Be Necessary for Certain VIN,
VOUT, Frequency and Thermal Conditions.
50ADC
Default Operating Frequency 500kHz
External Clock Synchronous Frequency Range 250kHz to 770kHz
Output Voltage Ripple (Typical) VIN = 12V, VOUT = 1.8V
500kHz (20MHz BW)
< 10mVP-P at IOUT = 50A, See Figure 5
Efficiency VIN = 12V, VOUT = 1.8V
500kHz
87.7% at IOUT = 50A, See Figure 2
Load Transient VIN = 12V, VOUT = 1.8V See Figure 4
QUICK START PROCEDURE
PERFORMANCE SUMMARY
Demonstration circuit 1668A-C is easy to set up to evaluate
the performance of paralleled LTM4627 modules. Please
refer to Figure 1 for proper measurement equipment setup
and follow the procedure below:
1. With power off, connect the input power supply, load,
meters and VOUT BNC cable as shown in Figure 1.
Preset the load to 0A and VIN supply to be 0V. Place
jumpers in the following positions for a typical 1.8VOUT
application:
JP2 JP7 JP6
VOUT Select RUN TRACK/SS
1.8V OFF SOFT-START
2. Turn on the power at the input. Increase VIN to 12V
(Do not hot-plug the input supply or apply more than
the rated maximum voltage of 20V to the board or the
modules may be damaged).
3. Set the RUN pin jumper (JP7) to the ON position. The
output voltage should be regulated. The output voltage
meter should read 1.8V ±2% (1.76V to 1.84V).
4. Vary the input voltage from 5V to 20V and adjust the
load current from 0A to 50A. VOUT should remain
regulated at 1.8V ±2%. Observe the load regulation,
output voltage ripple, efficiency and other parameters.
Output voltage ripple should be measured at J6 with
a BNC cable and oscilloscope. The probe channel for
VOUT should be set at 50Ω termination resistance to
match the BNC cable.
5. For optional load transient testing apply an adjustable
positive pulse signal between IOSTEP CLK and GND
pins. The pulse amplitude sets the load step current
amplitude. The pulse width should be short (< 1ms)
and pulse duty cycle should be low (< 15%) to limit the
thermal stress on the load transient circuit. The load
step current can be monitored with a BNC connected
to J5 (5mV/A).

3
dc1668acf
DEMO MANUAL DC1668A-C
QUICK START PROCEDURE
Figure 1. Test Setup of DC1668A-C
–+
+–
V
A
+
+
–
–
V
A
VIN
BNC CABLE
TO OSCILLOSCOPE
TERMINATE INTO 50Ω
LOAD
1668ac F01

4
dc1668acf
DEMO MANUAL DC1668A-C
QUICK START PROCEDURE
Figure 2. Measured Efficiency at 12VIN, 500kHz
Figure 4. Measured Load Step Response
Figure 3. Thermal Capture at 12VIN, 1.8VOUT, 50A, 500kHz
No Forced Airflow (Convection). TA= 29°C
Figure 5. Measured Output Voltage Ripple (20MHz BW)
LOAD CURRENT (A)
0
EFFICIENCY (%)
504030
1668ac F02
95
90
2010
85
80
75
70
3.3VOUT
2.5VOUT
1.8VOUT
1.5VOUT
1.2VOUT
1VOUT
1668ac F04
20A/DIV
100mV/DIV
VOUT
IOUT STEP
VOUT = 1.8V
IOUT DC = 25A
IOUT STEP = 25A
fSW = 500kHz
1668ac F05
20mV/DIV
VOUT
VOUT = 1.8V
IOUT = 50A
fSW = 500kHz

5
dc1668acf
DEMO MANUAL DC1668A-C
PARTS LIST
ITEM QUANTITY REFERENCE-DESCRIPTION DESCRIPTION MANUFACTURER’S PART NUMBER
Required Circuit Components:
1 1 CIN1 Cap, 150µF 20% 35V Alum Sanyo 35MV150WXV
2 4 CIN13, CIN18, CIN20, CIN22 Cap, 1210 22µF 20% 25V X5R AVX 12103D226MAT2A
3 4 COUT1, COUT5, COUT9, COUT13 Cap, 1812 100µF 20% 6.3V X5R TDK C4532X5R0J107MZ
4 3 COUT20, COUT21, COUT25 Cap, 470µF 20% 4V POSCAP Sanyo POSCAP 4TPF470ML
5 2 R8 Res, 0603 0Ω Jumper Vishay CRCW06030000Z0EA
6 2 R18,R19 Res, 0603 10Ω 5% 1/10W AAC CR16-100JM
7 4 R30, R31, R32, R33 Res, 0603 100Ω 5% 1/10W KOA RK73B1JTTD101J
8 1 R34 Res, 0603 100k 5% 1/10W Vishay CRCW0603100KJNEA
9 1 R35 Res, 0805 0Ω Jumper Vishay CRCW08050000Z0EA
10 1 U5 IC, LTC6902CMS Multiphase Oscillator Linear Technology LTC6902CMS
11 1 C12 Cap, 0603 100pF 10% 50V NP0 AVX 06035A101KAT2A
12 4 C52, C53, C54, C61 Cap, 0603 180pF 5% 50V NP0 AVX 06035A181JAT
13 1 C61 Cap, 0603 180pF 5% 50V NP0 AVX 06035A181JAT
14 2 C65, C67 Cap, 0603 1000pF 10% 50V NP0 AVX 06035A102KAT2A
15 1 R1 Res, 0603 7.5k 1% 1/10W Vishay CRCW06037K50FKEA
16 1 R2 Res, 0603 10k 1% 1/10W Vishay CRCW060310K0FKEA
17 1 R3 Res, 0603 4.75k 1% 1/10W Vishay CRCW06034K75FKED
18 1 R4 Res, 0603 3.32k 1% 1/10W Vishay CRCW0603K32FKEA
19 1 R12 Res, 0603 22.6k 1% 1/10W Vishay CRCW060322K6FKEA
20 1 R14 Res, 0603 15k 1% 1/10W Vishay CRCW060315K0FKEA
21 1 R27 Res, 0603 0Ω Jumper Vishay CRCW06030000Z0EA
22 1 R29 Res, 0603 100k 1% 1/10W Vishay CRCW0603100KFKEA
23 4 U1, U2, U3, U4 IC, µModule Regulator Linear Technology LTM4627EV
Additional Demo Board Circuit Components:
1 2 C14, C28 Cap, 0603 0.1µF 20% 16V X7R Taiyo Yuden EMK107BJ104MA-T
2 1 C16 Cap, 0603 1µF 20% 10V X5R Taiyo Yuden LMK107BJ105MA-T
3 1 C60 Cap, 0603 1000pF 10% 50V NP0 AVX 06035A102KAT2A
4 1 D1 Diode, Zener 350mW Diodes Inc. MMBZ5227B
5 1 R7 Res, 0805 2k 5% 1/10W AAC CR10-202JM
6 1 Q14 XSTR, SUD50N03-10CP MOSFET Siliconix SUD50N03-10CP
7 1 R10 Res, 0603 10k 5% 1/10W AAC CR16-103JM
8 2 R20 Res, 0603 0Ω Jumper Vishay CRCW06030000Z0EA
9 3 R11, R16, R17 Res, 2512 0.015Ω 1% 1W Panasonic ERJM1WSF15MU
10 0 CIN2, CIN3 Cap, 1206 10µF 20% 35V X5R Option Taiyo Yuden GMK316BJ106ML-T Option
11 0 CIN14, CIN19, CIN21, CIN23 Cap, 1210 22µF 20% 25V X5R Option AVX 12103D226MAT2A Option
12 0 COUT2, COUT3, COUT6 Cap, 1812 100µF 20% 6.3V X5R Option TDK C4532X5R0J107MZ Option
13 0 COUT4, COUT7, COUT11 Cap, 1812 Option Taiyo Yuden JMK432BJ107MU-T Option
14 COUT15
15 0 COUT10, COUT14 Cap, 1812 100µF 20% 6.3V X5R Option TDK C4532X5R0J107MZ Option

6
dc1668acf
DEMO MANUAL DC1668A-C
ITEM QUANTITY REFERENCE-DESCRIPTION DESCRIPTION MANUFACTURER’S PART NUMBER
16 0 COUT19 Cap, 1206 Option Taiyo Yuden EMK316BJ475ML-T Option
17 0 COUT23, COUT26, COUT27 Cap, 470µF 20% 4V POSCAP Option Sanyo POSCAP 4TPF470ML Option
18 0 COUT24 Cap, 1812 Option Taiyo Yuden JMK316BJ226ML-T
19 0 C15 Cap, 0603 1µF 20% 10V X5R Option Taiyo Yuden LMK107BJ105MA-T Option
20 0 C18, C55, C56, C57, C58, C62 Cap, 0603 Option Option
21 C74 to C77
22 0 C59, C63, C66, C68 Cap, 0805 Option Option
23 0 C64 Cap, 0603 1000pF 10% 50V NP0 Option AVX 06035A102KAT2A Option
24 0 C69, C71, C72, C73 Cap, 150µF 20% 35V Alum Option Sanyo 35MV150WXV Option
25 1 C70 Cap, 0603 0.22µF 20% 10V X5R Option Taiyo Yuden LMK107BJ224MA-T Option
26 0 R9, R13, R15, R23, R24 Res, 0603 51k 5% 1/10W Option AAC CR16-513JM Option
27 0 R21, R22, R36 Res, 0603 Option Option
28 0 COUT22 Cap, 470µF 20% 4V POSCAP Option Sanyo POSCAP 4TPF470ML Option
29 1 COUT25 Cap, 470µF 20% 4V POSCAP Option Sanyo POSCAP 4TPF470ML
30 1 R26 Res, 0603 Option Option
Hardware
1 6 JP1, JP2, JP3, JP4, JP5, JP8 Header, 2 Pin, 2mm Samtec TMM 102-02-L-S
2 2 JP6, JP7 Header, 3 Pin, 2mm Samtec TMM-103-02-L-S
3 4 J1, J2, J3, J4 Stud, Press-Fit PEM KFH-032-10
4 2 J5, J6 Conn, BNC, 5 Pins Connex 112404
5 10 TP1 to TP8, TP13, TP14 Turret Mill Max 2501-2-00-80-00-00-07-0
6 3 JP1, JP6, JP7 Shunt, 2mm Samtec 2SN-BK-G
7 4 Standoff, Snap On Keystone 8834
8 8 J1, J2, J3, J4 Nut, Brass #10-32 Any
9 4 J1, J2, J3, J4 Washer, Brass #10 Any
10 4 J1, J2, J3, J4 Lug, Ring Keystone 310 PbF
PARTS LIST

7
dc1668acf
DEMO MANUAL DC1668A-C
SCHEMATIC DIAGRAMS
SOFTSTART
EXT.TRACK
1 3
2
VIN
GND
VIN+
VIN-
COMP
IOSTEP CLK
VO+ VOUT
GND
VO- TRACK/SS
VOUT
OFF ON
IOSTEP
0.6V - 3.3V
3.3V1.2V 1.5V 2.5V1.8V
VOUT SEL
4.5V - 20V
SHT 2,3
SHT 2,3
SHT 2,3
SHT 2,3
SHT 3 SHT 2,3
SGND
1 2 3
TRACK/SS
RUN
** ****
1.0V
PGOOD
*
*
4
402K
U1-U4
15k
IC
100pF
OPT OPT
4TPF470ML
68pF
45.3k
10k
3.32k
30.1k OPT
CIN22
1nF
47pF
100K OPT
Poscap
1nF100uF
R27
0
0
OPT40A
R1
Poscap
100uF
10k15k
6.34k
180pF
OPT
C61
68pF
OPT 22uF
R29
9.53k
3
30A
R12
180pF
OPT
COUT22R26ASSY
1nF OPTOPT6.65k
OPT13.3k 4.42k
COUT25 C54
180pF
47pF
R2
- A
*
100uF
CIN20
180pF7.5k
IOUT R3
U1,U2
30.1k 22uF
C53C12
OPT
2
50A
OPT
OPT
OPT 68pF OPT
4.75k
U1-U3 4TPF470ML
OPT
C65COUT9 OPT
OPT
* FSW = 500KHz
- C
20k
PHASE No.
22.6k
C67COUT13 C52R14
100pF
OPT
22uF
20k- B 133K
R4
47pF
