DEMO MANUAL DC2164A-A
Description
LTM4630EY-1
High Efficiency, PolyPhase 70A
Step-Down Power µModule™ Regulator
Demonstration Circuit 2164A-A features a PolyPhase
®
design using the LT M
®
4630EY-1 (A-grade), the high ef-
ficiency, high density, dual 18A, switch mode step-down
power module regulator. The input voltage is from 4.5V
to 15V. The output voltage is jumper selectable from
0.9V to 1.8V. DC2164A-A can deliver nominal 70A output
current. As explained in the data sheet, output current
derating is necessary for certain VIN, VOUT, and thermal
conditions. The LTM4630-1A on DC2164A-A always
operate in continuous conduction mode. The switching
frequency can be programmed through a resistor or can
be synchronized to an external clock signal. The board
allows the user to program how its output voltage ramps
up and down through the TRACK pin. The output voltage
L, LT, LTC, LTM, Linear Technology, the Linear logo, µModule and PolyPhase are registered
trademarks of Linear Technology Corporation. All other trademarks are the property of their
respective owners.
is tightly regulated between VO+and VO–through remote
output voltage sensing which improves output voltage
regulation at heavy loads. The LTM4630-1A has ±0.8%
total DC errors. These features and the availability of the
LTM4630EY-1 in a compact 16mm × 16mm × 5.01mm
BGA package make it ideal for use in many high-density
point-of-loadregulation applications. The LTM4630-1 data
sheet must be read in conjunction with this demo manual
for working on or modifying the demo circuit DC2164A-A.
Design files for this circuit board are available at
http://www.linear.com/demo/DC2164A-A
Figure 1. 70A PolyPhase LTM4630-1/DC2164A-A Demo Board
Downloaded from Arrow.com.

2
dc2164aafa
DEMO MANUAL DC2164A-A
Quick start proceDure
Demonstration circuit 2164A-A is easy to set up to
evaluate the performance of PloyPhase operation of the
LTM4630EY-1. Due to the high input/output current, user
should select the proper input supply/load/cable which
can sustain the full load operation. It’s recommended to
pull load current from J2 and J4. The load current pulled
from J5 and J6 shouldn’t exceed 18A. Please refer to
Figure 2 for proper measurement setup and follow the
procedure below:
1. Place jumpers in the following positions for a typical
1VOUT application:
JP1 JP2 JP4 ~ JP8
CLK RUN VOUT SELECT
INT OFF ON JP5/1.0V
2. With power off, connect the input power supply, load
and meters as shown in Figure 2. Preset the load to 0A
and VIN supply to 12V.
3. Turn on the power supply at the input. Place JP2 to
ON position. The output voltage between VO+and VO–
should be 1V ±0.8% (0.992V ~ 1.008V).
4. Oncethe proper outputvoltage is established,adjust the
load within the operating range and observe the output
voltage regulation, output voltage ripple, efficiency
and other parameters. Output voltage ripple should
be measured at J7 with BNC cables. 50Ω termination
should be set on the oscilloscope or BNC cables.
5. (Optional) For optional load transient test, apply an
adjustable pulse signal between IOSTEP CLK and GND
test point. Pulse amplitude (3V~ 3.5V) sets the load
stepcurrent amplitude. The output transient current can
be monitored at the BNC connector J8 (5mV/A). The
pulse signal should be very small duty cycle (<10%)
to limit the thermal stress on the transient load circuit.
6. (Optional) LTM4630-1 can be synchronized to an
external clock signal. Place the JP1 jumper on EXT
and apply a clock signal (0V~ 5V, square wave) on
the EXT_CLK test point.
7. (Optional) The outputs of LTM4630-1 can track another
supply. The output voltage tracks the voltage on TRACK
when a valid signal is applied on the test point.
8. (Optional) DC2164A-A can be configured to a dual
outputs configuration with VOat 52A load current and
VO2 at 18A load current. Stuff 0Ω resistor on R61 and
0.1µF on C14. Remove R22, R23, R24, R26, R27, R28,
R32, R33, R35. Output voltage VO2 is set by R37 based
on the equation VO2 = 0.6V(1 + 60.4k/R37).
performance summary
Specifications are at TA= 25°C
PARAMETER CONDITIONS MIN TYP MAX UNITS
Input Voltage Range 4.5 15 V
Output Voltage VOUT VIN = 4.5 ~ 15V, IOUT = 0A ~ 70A, JP5: 1V 1 ±0.8%
(0.992 ~ 1.008)
V
Maximum Continuous Output Current Derating Is Necessary for Certain VIN, VOUT and Thermal
Conditions, See Data Sheet for Detail
70 A
Default Operating Frequency 400 kHz
Resistor Programmable Frequency Range 400 780 kHz
External Clock Sync. Frequency Range 400 780 kHz
Efficiency VIN = 12V, VOUT = 1V, IOUT = 70A, fSW = 400kHz 83.5
(See Figure 3)
%
Load T
ransient VIN = 12V, VOUT = 1V, ISTEP = 0A ~ 17.5A <58.1
(See Figure 4)
mV
Downloaded from Arrow.com.Downloaded from Arrow.com.

3
dc2164aafa
DEMO MANUAL DC2164A-A
Quick start proceDure
Figure 2. Test Setup of DC2164A-A
Figure 3. Measured Efficiency VIN = 12V, fSW = 400kHz
LOAD CURRENT (A)
0
EFFICIENCY (%)
100
90
80
70
60 4020 60
dn2164aa F03
70
3010 50
VO= 0.9V
VO= 1.0V
VO= 1.2V
VO= 1.5V
VO= 1.8V
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

4
dc2164aafa
DEMO MANUAL DC2164A-A
parts List
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 1 CIN1 CAP, 150µF 25% 25V ALUM SUN ELECT., 25CE150AX
2 2 CIN2, CIN11 CAP, 1206 1µF 10% 25V X5R TAIYO YUDEN, TMK316BJ105KL-T
3 8 CIN3-CIN10 CAP, 1210 22µF 10% 25V X5R AVX, 12103D226KAT2A
4 12 CO1, CO2, CO5, CO6, CO7, CO8, CO11, CO13,
CO15, CO16, CO56, CO57
CAP, 1206 220µF 20% 4V X5R MURATA, GRM31CR60G227ME11L
5 1 C1 CAP, 0603 330pF 10% 50V NPO AVX, 06035A331KAT2A
6 4 C4, C10, C18, C22 CAP, 0603 2.2µF 20% 10V X5R TAIYO YUDEN, LMK107BJ225MA-T
7 6 C6, C11, C19, C23, C27, C28 CAP, 0603 1µF 10% 10V X7R TAIYO YUDEN, LMK107BJ105KA-T
8 2 C7, C25 CAP, 0603 0.1µF 10% 25V X7R AVX, 06033C104KAT2A
9 2 C24, C31 CAP, 0603 0.01µF 10% 100V X7R AVX, 06031C103KAT2A
10 2 Q1, Q2 MOSFET, N-CH D-S 30V TO252 VISHAY, SUD50N04-8M8P-4GE3
11 4 R1, R3, R25, R29 RES, 0603 10Ω 5% 1/10W VISHAY, CRCW060310R0JNEA
12 5 R2, R14, R21, R39, R47 RES, 0603 121k 1% 1/10W VISHAY, CRCW0603121KFKEA
13 4 R4, R36, R41, R54 RES, 0603 10k 5% 1/10W VISHAY, CRCW060310K0JNEA
14 4 R9, R31, R43, R51 RES, 0603 100k 1% 1/10W VISHAY, CRCW0603100KFKEA
15 1 R11 RES, 0603 2.32k 1% 1/10W VISHAY, CRCW06032K32FKEA
16 1 R15 RES, 0603 90.9k 1% 1/10W VISHAY, CRCW060390K9FKEA
17 1 R16 RES, 0603 60.4k 1% 1/10W VISHAY, CRCW060360K4FKEA
18 1 R17 RES, 0603 40.2k 1% 1/10W VISHAY, CRCW060340K2FKEA
19 1 R18 RES, 0603 30.1k 1% 1/10W VISHAY, CRCW060330K1FKEA
20 2 R56, R57 RES, 2512 0.010Ω 1% 1W VISHAY, WSL2512R01000FEA
21 2 U1, U2 IC, VOLTAGE REGULATOR, BGA LINEAR TECH., LTM4630IY-1A#PBF
Quick start proceDure
Figure 4. Load Transient 0A to 17.5A (VIN = 12V, VOUT = 1V)
Figure 5. Thermal Capture at 12VIN, 1VOUT, 70A
(TA= 25°C, 400 LFM Airflow and No Heat Sink)
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

5
dc2164aafa
DEMO MANUAL DC2164A-A
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Additional Demo Board Circuit Components
1 0 CIN12-CIN19 DO NOT STUFF
2 0 CO3, CO9, CO14, CO17, CO18, CO20, CO21,
CO22, CO24, CO26, CO27, CO28, CO30, CO32-
CO36, CO38, CO40, CO42, CO45, CO46, CO48,
CO50, CO52, CO54, CO55, CO58, CO59
CAP, 1210 OPTION OPTION
3 0 CO4, CO10, CO12, CO19, CO23, CO25, CO29,
CO31, CO37
CAP, 7343 OPTION OPTION
CO39, CO41, CO43, CO44, CO47, CO49, CO51,
CO53,
4 0 C2, C3, C5, C8, C9, C12-, C17, C20, C21, C26,
C29, C30, C32
CAP, 0603 OPTION OPTION
5 0 R5, R7, R8, R10, R30, R37, R38, R42, R44,
R48-R50, R52, R53, R55, R61, R64
RES, 0603 OPTION OPTION
6 0 R13, R34 RES, 0603 OPTION OPTION
7 12 R6, R19, R20, R27, R28, R32, R33, R35, R40,
R45, R62, R63
RES, 0603 0Ω JUMPER VISHAY, CRCW06030000Z0EA
8 4 R22, R23, R24, R26 RES, 2010 0Ω JUMPER VISHAY, CRCW20100000ZEA9
9 0 R58, R59 RES, 2512 OPTION OPTION
10 1 R60 RES, 1206 0Ω JUMPER VISHAY, CRCW12060000ZOEA
11 0 U3, U4 DO NOT STUFF
Hardware: For Demo Board Only
1 11 E1-E4, E6-E9, E12, E13, E22 TESTPOINT, TURRET, 0.063" MILL MAX, 2308-2-00-80-00-00-07-0
2 2 E19, E20 TESTPOINT, TURRET, 0.094" MILL MAX, 2501-2-00-80-00-00-07-0
3 2 JP1, JP2 HEADER, 3 PIN 0.079 SINGLE ROW SULLINS, NRPN031PAEN-RC
4 5 JP4, JP5, JP6, JP7, JP8 HEADER, 2 PIN 0.079 SINGLE ROW SAMTEC, TMM-102-02-L-S
5 4 J1, J2, J3, J4 STUD, TEST PIN PEM, KFH-032-10
68 J1, J2, J3, J4 (x2) NUT, BRASS PL # 10-32 ANY, 10-32M/S BR PL
7 4 J1, J2, J3, J4 LUG RING, #10 KEYSTONE, 8205
8 4 J1, J2, J3, J4 WASHER, TIN PLATED BRASS ANY, #10EXT BZ TN
9 2 J5, J6 JACK, BANANA KEYSTONE, 575-4
10 2 J7, J8 CON, BNC, 5 PINS CONNEX, 112404
11 3 XJP1, XJP2, XJP4 SHUNT SAMTEC, 2SN-BK-G
parts List
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

6
dc2164aafa
DEMO MANUAL DC2164A-A
schematic Diagram
5 5
4 4
3 3
2 2
1 1
D D C C B B A A

VOUT SELECT
NOTE:UNLESSOTHERWISESPECIFIED,
1.ALLCAPACITORS,RESISTORS0603.
ASSY I.C.
‐A U1,U2
U1,U2,U3 U1,U2,U3,U4
‐B ‐C
70A 105A 140A
Iout
OPT
0
OPT
R13
OPT
0 0
R34
OPT 22uF 22uF
Cin12, 13, 14, 15
OPT OPT 22uF
Cin16, 17, 18, 19
OPT 220uF 220uF
Co20, 21,26
OPT OPT 220uF
Co30, 32,34
*
*
*Co24,27,58 Co35, 55,59
1206 1206
1206 1206 1206 1206
VFB PGOOD COMP RUN
TRACK
VOUT
VFB PGOOD COMP RUN TRACK DIFFP DIFFN
VFB
PGOOD COMP
CLKOUT_U1
RUN TRACK VFB
VIN
INTVCC_U1
INTVCC_U1
VOUT
VO+
VO-
VO+
INTVCC_U1
VIN
VO+ VO-
VOUT
EXTVCC
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY
Fax: [phone]
Milpitas, CA 95035 Phone: [phone]
1630 McCarthy Blvd.
LTC CONFIDENTIAL - FOR CUSTOMER USE ONLY
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
DEMO CIRCUIT 2164A
Monday, September 28, 2015
14
HIGH EFFICIENCY, POLYPHASE, DC/DC
N/A
LTM4630EY-1A
LT
HW
STEP-DOWN POWER MODULE REGULATOR
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY
Fax: [phone]
Milpitas, CA 95035 Phone: [phone]
1630 McCarthy Blvd.
LTC CONFIDENTIAL - FOR CUSTOMER USE ONLY
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
DEMO CIRCUIT 2164A
Monday, September 28, 2015
14
HIGH EFFICIENCY, POLYPHASE, DC/DC
N/A
LTM4630EY-1A
LT
HW
STEP-DOWN POWER MODULE REGULATOR
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY
Fax: [phone]
Milpitas, CA 95035 Phone: [phone]
1630 McCarthy Blvd.
LTC CONFIDENTIAL - FOR CUSTOMER USE ONLY
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
DEMO CIRCUIT 2164A
Monday, September 28, 2015
14
HIGH EFFICIENCY, POLYPHASE, DC/DC
N/A
LTM4630EY-1A
LT
HW
STEP-DOWN POWER MODULE REGULATOR
REVISION HISTORY
DESCRIPTION DATE APPROVEDECO REV
HW
PRODUCTION-1 9/28/15
REVISION HISTORY
DESCRIPTION DATE APPROVEDECO REV
HW
PRODUCTION-1 9/28/15
REVISION HISTORY
DESCRIPTION DATE APPROVEDECO REV
HW
PRODUCTION-1 9/28/15
+
CO4
OPT
7343
C1
330pF
+
CO39
OPT
7343
J1
4.5V -15V
VIN
CO9 OPT 1210
CO8 220uF 4V
E5
SW1-1
CIN6
22uF 25V
1210
C6
1uF 10V
R60
0 Ohm
1206
R9
100k
1%
CO1 220uF
4V
U1
LTM4630EY-1A
VOUT1
A1
VOUT1
A2
VOUT1
A3
VOUT1
A4
VOUT1
A5
VOUT1
B1
VOUT1
B2
VOUT1
B3
VOUT1
B4
VOUT1
B5
VOUT1
C1
VOUT1
C2
VOUT1
C3
VOUT1
C4
VFB1
D5
SW1
G2
PGOOD1
G9
COMP1
E6
RUN1
F5
TRACK1
E5
VOUTS1
C5
VOUT2
A8
VOUT2
A9
VOUT2
A10
VOUT2
A11
VOUT2
A12
VOUT2
B8
VOUT2
B9
VOUT2
B10
VOUT2
B11
VOUT2
B12
VOUT2
C9
VOUT2
C10
VOUT2
C11
VOUT2
C12
VFB2
D7
SW2
G11
PGOOD2
G8
COMP2
E7
RUN2
F9
TRACK2
D8
VOUTS2
C8
VIN
M2
VIN
M3
VIN
M4
VIN
M5
VIN
M6
VIN
M7
VIN
M8
VIN
M9
VIN
M10
VIN
M11
VIN
L2
VIN
L3
VIN
L4
VIN
L5
VIN
L6
VIN
L7
VIN
L8
VIN
L9
VIN
L10
VIN
L11
VIN
K2
VIN
K3
VIN
K4
VIN
K9
VIN
K10
VIN
K11
VIN
J2
VIN
J3
VIN
J4
VIN
J9
VIN
J10
VIN
J11
GND
A6
GND
A7
GND
B6
GND
B7
GND
D1
GND
D2
GND
D3
GND
D4
GND
D9
GND
D10
GND
D11
GND
D12
GND
E1
GND
E2
GND
E3
GND
E4
GND
E10
GND
E11
GND
E12
GND
F1
GND
F2
GND
F3
GND
F10
GND
F11
GND
F12
GND
G1
GND
G3
GND
G10
GND
G12
GND
H1
GND
H2
GND
H3
GND
H4
GND
H5
GND
H6
GND
H7
GND
H9
GND
H10
GND
H11
GND
H12
GND
M12
GND
M1
GND
L12
GND
J1
GND
J5
GND
J8
GND
J12
GND
K1
GND
K5
GND
K6
GND
K7
GND
K8
GND
K12
GND
L1
SGND
C7
SGND
D6
SGND
F6
SGND
F7
SGND
G6
SGND
G7
FSET
C6
PHASMD
G4
DIFFP
E8
DIFFN
E9
CLKOUT
G5
MODE-PLLIN
F4
TEMP
J6
INTVCC
H8
EXTVCC
J7
DIFFOUT
F8
R62 0 Ohm
E2
VO+
R16
60.4K
1%
CIN4
22uF 25V
1210
C5
OPT
C2
OPT
R7 OPT
+
CIN1 150uF
25V
R1
10
JP1
EXT
INT
CLK
1 3 2
R13
OPT
J4
GND
CIN2
1uF 25V 1206
E10
SW2-1
E4
VIN-
CIN3
22uF 25V
1210
R18
30.1K
1%
J3
GND
R8
OPT
+
CO10 OPT 7343
R17
40.2K
1%
R5
OPT
CO42
OPT 1210
C31 0.01uF
CO6 220uF 4V
J2
0.6 - 1.8V
VOUT
E22
SGND
R4
10K
CO7 220uF 4V
R11
2.32K
R14
121K
1%
CO5 220uF 4V
E1 EXT_CLK
CIN5
22uF 25V
1210
JP5
1.0V
R63
0 Ohm
JP6
1.2V
E6
VO-
CO2 220uF 4V
JP7
1.5V
R2
121K
1%
JP4
0.9V
C7 0.1uF
JP2
ON
OFF
RUN
1 3 2
JP8
1.8V
E9
TRACK
E7
PGOOD
+
CO41 OPT
7343
CO3
OPT
1210
R3
10
R6 0 Ohm
C4
2.2uF
10V
E3
VIN+
C3 OPT
CO40
OPT
1210
R10
OPT
R15
90.9K
1%
E8
EXTVCC
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

7
dc2164aafa
DEMO MANUAL DC2164A-A
schematic Diagram
5
5
4
4
3
3
2
2
1
1
D D C C B B A A

REMOVE 0 OHM JUMPERS FOR SEPARATE VOUT2_U2.
*
1206
1206 1206 1206 1206
1206 1206
COMP_U2 RUN_U2
COMP
TRACK_U2
VFB PGOOD RUN TRACK
PGOOD_U2
DIFFOUT_U2
DIFFOUT_U2
VFB_U2
PGOOD_U2 VFB_U2 RUN_U2 COMP_U2 TRACK_U2
COMP
CLKOUT_U1
CLKOUT_U2
RUN TRACK PGOOD VFB
VOUT
INTVCC_U2
VOUT2_U2
VIN
EXTVCC
INTVCC_U2
VO2+
VO2-
VO2+ VO2-
INTVCC_U2
VO2+
VOUT2_U2VOUT
VOUT2_U2
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY
Fax: [phone]
Milpitas, CA 95035 Phone: [phone]
1630 McCarthy Blvd.
LTC CONFIDENTIAL - FOR CUSTOMER USE ONLY
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
DEMO CIRCUIT 2164A
Monday, September 28, 2015
24
HIGH EFFICIENCY, POLYPHASE, CD/CD
N/A
LTM4630EY-1A
LT
HW
STEP-DOWN POWER MODULE REGULATOR
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY
Fax: [phone]
Milpitas, CA 95035 Phone: [phone]
1630 McCarthy Blvd.
LTC CONFIDENTIAL - FOR CUSTOMER USE ONLY
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
DEMO CIRCUIT 2164A
Monday, September 28, 2015
24
HIGH EFFICIENCY, POLYPHASE, CD/CD
N/A
LTM4630EY-1A
LT
HW
STEP-DOWN POWER MODULE REGULATOR
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY
Fax: [phone]
Milpitas, CA 95035 Phone: [phone]
1630 McCarthy Blvd.
LTC CONFIDENTIAL - FOR CUSTOMER USE ONLY
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
DEMO CIRCUIT 2164A
Monday, September 28, 2015
24
HIGH EFFICIENCY, POLYPHASE, CD/CD
N/A
LTM4630EY-1A
LT
HW
STEP-DOWN POWER MODULE REGULATOR
R22
0 Ohm
2010
C11
1uF 10V
CO14
OPT
1210
C13 OPT
CIN9
22uF 25V
1210
R23
0 Ohm
2010
R27
0 Ohm
J6
GND
+
CO12 OPT 7343
C8 OPT
C32 OPT
+
CO43 OPT 7343
C9 OPT
+
CO25 OPT
7343
R24
0 Ohm
2010
R21
121K
1%
C15 OPT
R31
100K
1%
R20
0 Ohm
R25
10
+
CO44 OPT 7343
J5
VOUT/
VOUT2_U2
CO56
220uF 4V
R61
OPT
CO38 OPT
1210
+
CO19 OPT 7343
R26
0 Ohm
2010
CO45
OPT
1210
CO57
220uF 4V
CO13 220uF 4V
CO46
OPT
1210
U2
LTM4630EY-1A
VOUT1
A1
VOUT1
A2
VOUT1
A3
VOUT1
A4
VOUT1
A5
VOUT1
B1
VOUT1
B2
VOUT1
B3
VOUT1
B4
VOUT1
B5
VOUT1
C1
VOUT1
C2
VOUT1
C3
VOUT1
C4
VFB1
D5
SW1
G2
PGOOD1
G9
COMP1
E6
RUN1
F5
TRACK1
E5
VOUTS1
C5
VOUT2
A8
VOUT2
A9
VOUT2
A10
VOUT2
A11
VOUT2
A12
VOUT2
B8
VOUT2
B9
VOUT2
B10
VOUT2
B11
VOUT2
B12
VOUT2
C9
VOUT2
C10
VOUT2
C11
VOUT2
C12
VFB2
D7
SW2
G11
PGOOD2
G8
COMP2
E7
RUN2
F9
TRACK2
D8
VOUTS2
C8
VIN
M2
VIN
M3
VIN
M4
VIN
M5
VIN
M6
VIN
M7
VIN
M8
VIN
M9
VIN
M10
VIN
M11
VIN
L2
VIN
L3
VIN
L4
VIN
L5
VIN
L6
VIN
L7
VIN
L8
VIN
L9
VIN
L10
VIN
L11
VIN
K2
VIN
K3
VIN
K4
VIN
K9
VIN
K10
VIN
K11
VIN
J2
VIN
J3
VIN
J4
VIN
J9
VIN
J10
VIN
J11
GND
A6
GND
A7
GND
B6
GND
B7
GND
D1
GND
D2
GND
D3
GND
D4
GND
D9
GND
D10
GND
D11
GND
D12
GND
E1
GND
E2
GND
E3
GND
E4
GND
E10
GND
E11
GND
E12
GND
F1
GND
F2
GND
F3
GND
F10
GND
F11
GND
F12
GND
G1
GND
G3
GND
G10
GND
G12
GND
H1
GND
H2
GND
H3
GND
H4
GND
H5
GND
H6
GND
H7
GND
H9
GND
H10
GND
H11
GND
H12
GND
M12
GND
M1
GND
L12
GND
J1
GND
J5
GND
J8
GND
J12
GND
K1
GND
K5
GND
K6
GND
K7
GND
K8
GND
K12
GND
L1
SGND
C7
SGND
D6
SGND
F6
SGND
F7
SGND
G6
SGND
G7
FSET
C6
PHASMD
G4
DIFFP
E8
DIFFN
E9
CLKOUT
G5
MODE-PLLIN
F4
TEMP
J6
INTVCC
H8
EXTVCC
J7
DIFFOUT
F8
R19
0 Ohm
R34 0 Ohm
R64
OPT
CIN10
22uF 25V
1210
R32
0 Ohm
R33
0 Ohm
R35
0 Ohm
C14 OPT
E11
SW1-2
R28
0 Ohm
R38
OPT
CO18 OPT 1210
CIN8
22uF 25V
1210
CO16 220uF 4V
R37
OPT
R36
10K
C10
2.2uF
10V
CO11
220uF 4V
R29
10
CIN7
22uF 25V
1210
CO15 220uF 4V
E13
VO2-
E12
VO2+
C12 OPT
R30
OPT
E14
SW2-2
CO17
OPT
1210
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

8
dc2164aafa
DEMO MANUAL DC2164A-A
schematic Diagram
5 5
4 4
3 3
2 2
1 1
D D C C B B A A

**** *
**
***
1206 1206 1206 1206
1206 1206
COMP RUN
COMP
CLKOUT_U2 CLKOUT_U3
PGOOD
RUN
VFB TRACK PGOOD
TRACK
VFB
COMP
CLKOUT_U2 CLKOUT_U3
RUN VFB PGOOD TRACK
VOUT
INTVCC_U3
VOUT
VIN
EXTVCC
INTVCC_U3
INTVCC_U3
INTVCC_U3
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY
Fax: [phone]
Milpitas, CA 95035 Phone: [phone]
1630 McCarthy Blvd.
LTC CONFIDENTIAL - FOR CUSTOMER USE ONLY
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
DEMO CIRCUIT 2164A
Monday, September 28, 2015
34
HIGH EFFICIENCY, POLYPHASE, DC/DC
N/A
LTM4630EY-1A
LT
HW
STEP-DOWN POWER MODULE REGULATOR
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY
Fax: [phone]
Milpitas, CA 95035 Phone: [phone]
1630 McCarthy Blvd.
LTC CONFIDENTIAL - FOR CUSTOMER USE ONLY
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
DEMO CIRCUIT 2164A
Monday, September 28, 2015
34
HIGH EFFICIENCY, POLYPHASE, DC/DC
N/A
LTM4630EY-1A
LT
HW
STEP-DOWN POWER MODULE REGULATOR
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY
Fax: [phone]
Milpitas, CA 95035 Phone: [phone]
1630 McCarthy Blvd.
LTC CONFIDENTIAL - FOR CUSTOMER USE ONLY
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
DEMO CIRCUIT 2164A
Monday, September 28, 2015
34
HIGH EFFICIENCY, POLYPHASE, DC/DC
N/A
LTM4630EY-1A
LT
HW
STEP-DOWN POWER MODULE REGULATOR
+
CO49 OPT
7343
C17 OPT
+
CO23
OPT
7343
CO58 220uF 4V
R39
121K
1% CO20
220uF 4V
+
CO29 OPT
7343
CO28 OPT 1210
C16 OPT
R40 0 Ohm
CIN11
1uF 25V 1206
E16 SW2-3
CIN15
22uF 25V
1210
+
CO47
OPT
7343
U3
LTM4630EY-1A
VOUT1
A1
VOUT1
A2
VOUT1
A3
VOUT1
A4
VOUT1
A5
VOUT1
B1
VOUT1
B2
VOUT1
B3
VOUT1
B4
VOUT1
B5
VOUT1
C1
VOUT1
C2
VOUT1
C3
VOUT1
C4
VFB1
D5
SW1
G2
PGOOD1
G9
COMP1
E6
RUN1
F5
TRACK1
E5
VOUTS1
C5
VOUT2
A8
VOUT2
A9
VOUT2
A10
VOUT2
A11
VOUT2
A12
VOUT2
B8
VOUT2
B9
VOUT2
B10
VOUT2
B11
VOUT2
B12
VOUT2
C9
VOUT2
C10
VOUT2
C11
VOUT2
C12
VFB2
D7
SW2
G11
PGOOD2
G8
COMP2
E7
RUN2
F9
TRACK2
D8
VOUTS2
C8
VIN
M2
VIN
M3
VIN
M4
VIN
M5
VIN
M6
VIN
M7
VIN
M8
VIN
M9
VIN
M10
VIN
M11
VIN
L2
VIN
L3
VIN
L4
VIN
L5
VIN
L6
VIN
L7
VIN
L8
VIN
L9
VIN
L10
VIN
L11
VIN
K2
VIN
K3
VIN
K4
VIN
K9
VIN
K10
VIN
K11
VIN
J2
VIN
J3
VIN
J4
VIN
J9
VIN
J10
VIN
J11
GND
A6
GND
A7
GND
B6
GND
B7
GND
D1
GND
D2
GND
D3
GND
D4
GND
D9
GND
D10
GND
D11
GND
D12
GND
E1
GND
E2
GND
E3
GND
E4
GND
E10
GND
E11
GND
E12
GND
F1
GND
F2
GND
F3
GND
F10
GND
F11
GND
F12
GND
G1
GND
G3
GND
G10
GND
G12
GND
H1
GND
H2
GND
H3
GND
H4
GND
H5
GND
H6
GND
H7
GND
H9
GND
H10
GND
H11
GND
H12
GND
M12
GND
M1
GND
L12
GND
J1
GND
J5
GND
J8
GND
J12
GND
K1
GND
K5
GND
K6
GND
K7
GND
K8
GND
K12
GND
L1
SGND
C7
SGND
D6
SGND
F6
SGND
F7
SGND
G6
SGND
G7
FSET
C6
PHASMD
G4
DIFFP
E8
DIFFN
E9
CLKOUT
G5
MODE-PLLIN
F4
TEMP
J6
INTVCC
H8
EXTVCC
J7
DIFFOUT
F8
CO21 220uF 4V
R44
OPT
R41
10K
CIN13
22uF 25V
1210
R43
100K
1%
R42
OPT
CO27 220uF 4V
CO48 OPT
1210
CO50 OPT 1210
CO26
220uF 4V
E15
SW1-3
C19
1uF 10V
C18
2.2uF
10V
CO22 OPT
1210
CIN14
22uF 25V
1210
CO24 220uF 4V
CIN12
22uF 25V
1210
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

9
dc2164aafa
DEMO MANUAL DC2164A-A
Information furnished by Linear Technology Corporation is believed to be accurate and reliable.
However, no responsibility is assumed for its use. Linear Technology Corporation makes no representa-
tion that the interconnection of its circuits as described herein will not infringe on existing patent rights.
schematic Diagram
5
5
4
4
3
3
2
2
1
1
D D C C B B A A

LOAD TRANSIENT CIRCUIT
**** * *
**
**
1206 1206 1206 1206
1206 1206
COMP RUN COMP TRACK VFB
PGOOD
RUN VFB TRACK PGOOD
CLKOUT_U3
VFB COMP
CLKOUT_U3
RUN TRACK PGOOD
INTVCC_U4
VOUT
VOUT
VIN
EXTVCC
INTVCC_U4
VOUT
VO+
VO-
VOUT
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY
Fax: [phone]
Milpitas, CA 95035 Phone: [phone]
1630 McCarthy Blvd.
LTC CONFIDENTIAL - FOR CUSTOMER USE ONLY
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
DEMO CIRCUIT 2164A
Monday, September 28, 2015
44
HIGH EFFICIENCY, POLYPHASE, DC/DC
N/A
LTM4630-1EY
LT
HW
STEP-DOWN POWER MODULE REGULATOR
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY
Fax: [phone]
Milpitas, CA 95035 Phone: [phone]
1630 McCarthy Blvd.
LTC CONFIDENTIAL - FOR CUSTOMER USE ONLY
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
DEMO CIRCUIT 2164A
Monday, September 28, 2015
44
HIGH EFFICIENCY, POLYPHASE, DC/DC
N/A
LTM4630-1EY
LT
HW
STEP-DOWN POWER MODULE REGULATOR
SIZE DATE:
IC NO. REV.
SHEET OF
TITLE:
APPROVALS
PCB DES.
APP ENG.
TECHNOLOGY
Fax: [phone]
Milpitas, CA 95035 Phone: [phone]
1630 McCarthy Blvd.
LTC CONFIDENTIAL - FOR CUSTOMER USE ONLY
CUSTOMER NOTICE
LINEAR TECHNOLOGY HAS MADE A BEST EFFORT TO DESIGN A CIRCUIT THAT MEETS CUSTOMER-SUPPLIED SPECIFICATIONS; HOWEVER, IT REMAINS THE CUSTOMER'S RESPONSIBILITY TO VERIFY PROPER AND RELIABLE OPERATION IN THE ACTUAL APPLICATION. COMPONENT SUBSTITUTION AND PRINTED CIRCUIT BOARD LAYOUT MAY SIGNIFICANTLY AFFECT CIRCUIT PERFORMANCE OR RELIABILITY. CONTACT LINEAR TECHNOLOGY APPLICATIONS ENGINEERING FOR ASSISTANCE. THIS CIRCUIT IS PROPRIETARY TO LINEAR TECHNOLOGY AND
SCHEMATIC
SUPPLIED FOR USE WITH LINEAR TECHNOLOGY PARTS.
SCALE = NONE
www.linear.com
1
DEMO CIRCUIT 2164A
Monday, September 28, 2015
44
HIGH EFFICIENCY, POLYPHASE, DC/DC
N/A
LTM4630-1EY
LT
HW
STEP-DOWN POWER MODULE REGULATOR
J7
VOUT
R49
OPT
R53
OPT
CO30 220uF 4V
CO52 OPT 1210
R51
100K
1%
C22
2.2uF
10V
C26 OPT C27
1uF 10V
R52
OPT
CIN19
22uF 25V
1210
R58 OPT
2512
Q2 SUD50N04-8M8P-4GE
R48
OPT
CO36
OPT
1210
R47
121K
1%
C23
1uF 10V
CO54
OPT
1210
R57 0.010 1% 2W
2512
R45
0 Ohm
Q1
SUD50N04-8M8P-4GE
C21
OPT
E18 SW2-4
CIN16
22uF 25V
1210
CO33 OPT 1210
CO34
220uF 4V
R50
OPT
CO32 220uF 4V
R55
OPT
C30
OPT R59
OPT
2512
C29
OPT
CIN18
22uF 25V
1210
R54
10K
+
CO53 OPT 7343
E17
SW1-4
CO35
220uF 4V
C28 1uF 10V
+
CO37 OPT
7343
C24 0.01uF
CO55 220uF 4V
J8
IOSTEP
CIN17
22uF 25V
1210
CO59 220uF 4V
R56 0.010 1% 2W
2512
+
CO51 OPT 7343
U4
LTM4630EY-1A
VOUT1
A1
VOUT1
A2
VOUT1
A3
VOUT1
A4
VOUT1
A5
VOUT1
B1
VOUT1
B2
VOUT1
B3
VOUT1
B4
VOUT1
B5
VOUT1
C1
VOUT1
C2
VOUT1
C3
VOUT1
C4
VFB1
D5
SW1
G2
PGOOD1
G9
COMP1
E6
RUN1
F5
TRACK1
E5
VOUTS1
C5
VOUT2
A8
VOUT2
A9
VOUT2
A10
VOUT2
A11
VOUT2
A12
VOUT2
B8
VOUT2
B9
VOUT2
B10
VOUT2
B11
VOUT2
B12
VOUT2
C9
VOUT2
C10
VOUT2
C11
VOUT2
C12
VFB2
D7
SW2
G11
PGOOD2
G8
COMP2
E7
RUN2
F9
TRACK2
D8
VOUTS2
C8
VIN
M2
VIN
M3
VIN
M4
VIN
M5
VIN
M6
VIN
M7
VIN
M8
VIN
M9
VIN
M10
VIN
M11
VIN
L2
VIN
L3
VIN
L4
VIN
L5
VIN
L6
VIN
L7
VIN
L8
VIN
L9
VIN
L10
VIN
L11
VIN
K2
VIN
K3
VIN
K4
VIN
K9
VIN
K10
VIN
K11
VIN
J2
VIN
J3
VIN
J4
VIN
J9
VIN
J10
VIN
J11
GND
A6
GND
A7
GND
B6
GND
B7
GND
D1
GND
D2
GND
D3
GND
D4
GND
D9
GND
D10
GND
D11
GND
D12
GND
E1
GND
E2
GND
E3
GND
E4
GND
E10
GND
E11
GND
E12
GND
F1
GND
F2
GND
F3
GND
F10
GND
F11
GND
F12
GND
G1
GND
G3
GND
G10
GND
G12
GND
H1
GND
H2
GND
H3
GND
H4
GND
H5
GND
H6
GND
H7
GND
H9
GND
H10
GND
H11
GND
H12
GND
M12
GND
M1
GND
L12
GND
J1
GND
J5
GND
J8
GND
J12
GND
K1
GND
K5
GND
K6
GND
K7
GND
K8
GND
K12
GND
L1
SGND
C7
SGND
D6
SGND
F6
SGND
F7
SGND
G6
SGND
G7
FSET
C6
PHASMD
G4
DIFFP
E8
DIFFN
E9
CLKOUT
G5
MODE-PLLIN
F4
TEMP
J6
INTVCC
H8
EXTVCC
J7
DIFFOUT
F8
E19
IOSTEP CLK
C25 0.1uF
+
CO31 OPT 7343
E20
GND
C20
OPT
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

10
dc2164aafa
DEMO MANUAL DC2164A-A
Linear Technology Corporation
1630 McCarthy Blvd., Milpitas, CA 95035-7417
[phone] ●FAX: [phone] ●www.linear.com
© LINEAR TECHNOLOGY CORPORATION 2015
LT 0915 REV A • PRINTED IN USA
DEMONSTRATION BOARD IMPORTANT NOTICE
Linear Technology Corporation (LTC) provides the enclosed product(s) under the following AS IS conditions:
This demonstration board (DEMO BOARD) kit being sold or provided by Linear Technology is intended for use for ENGINEERING DEVELOPMENT
OR EVALUATION PURPOSES ONLY and is not provided by LTC for commercial use. As such, the DEMO BOARD herein may not be complete
in terms of required design-, marketing-, and/or manufacturing-related protective considerations, including but not limited to product safety
measures typically found in finished commercial goods. As a prototype, this product does not fall within the scope of the European Union
directive on electromagnetic compatibility and therefore may or may not meet the technical requirements of the directive, or other regulations.
If this evaluation kit does not meet the specifications recited in the DEMO BOARD manual the kit may be returned within 30 days from the date
of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE WARRANTY MADE BY THE SELLER TO BUYER AND IS IN LIEU
OF ALL OTHER WARRANTIES, EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE. EXCEPT TO THE EXTENT OF THIS INDEMNITY, NEITHER PARTY SHALL BE LIABLE TO THE OTHER FOR
ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user releases LTC from all claims
arising from the handling or use of the goods. Due to the open construction of the product, it is the user’s responsibility to take any and all
appropriate precautions with regard to electrostatic discharge. Also be aware that the products herein may not be regulatory compliant or
agency certified (FCC, UL, CE, etc.).
No License is granted under any patent right or other intellectual property whatsoever. LTC assumes no liability for applications assistance,
customer product design, software performance, or infringement of patents or any other intellectual property rights of any kind.
LTC currently services a variety of customers for products around the world, and therefore this transaction is not exclusive.
Please read the DEMO BOARD manual prior to handling the product. Persons handling this product must have electronics training and
observe good laboratory practice standards. Common sense is encouraged.
This notice contains important safety information about temperatures and voltages. For further safety concerns, please contact a LTC application
engineer.
Mailing Address:
Linear Technology
1630 McCarthy Blvd.
Milpitas, CA 95035
Copyright © 2004, Linear Technology Corporation
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.
