DEMO MANUAL DC1886A
Description
LTC4232:
5A Integrated
Hot Swap Controller
Demonstration circuit 1886A features the LTC4232 5A
Integrated Hot Swap™ Controller. The LTC4232 is ideally
suited for demanding power distribution control in 2.9V
to 15V applications for hot board insertion protection,
high side power switching, and electronic circuit breaker
functions. The LTC4232 provides a rich set of features to
support Hot Swap applications including:
• 2%accurateundervoltageandovervoltageprotection
• Overtemperatureprotection
• Adjustableinrushcurrentcontrol
• Adjustable,10%accuratecurrentlimitwithprogram-
mable cutout time
performance summary
• Programmableoutputvoltageramprate
• Configurableforauto-retryorlatchoffonovercurrent
faults
• Powergoodandfaultoutputs
Available in a 16-lead 5mm × 3mm DFN package, the
LTC4232 is showcased on demonstration circuit 1886A,
configured for a 12V application. By changing a few pas-
sive components, 2.9V to 15V applications can easily be
evaluated.
Design files for this circuit board are available at
http://www.linear.com/demo
L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks and
Hot Swap is a trademark of Linear Technology Corporation. All other trademarks are the
property of their respective owners.
(TA= 25°C)
SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
VDD Input Supply Range 2.9 15 V
dVGATE/dt GATEPinTurn-OnRampRate 0.15 0.3 0.55 V/ms
RON MOSFET+SenseResistorOn-Resistance 15 33 50 mΩ
ILIM(TH) Current Limit Threshold VFB = 1.23V 5.0 5.6 6.1 A
ILIM(TH) Current Limit Threshold VFB=0V
VFB = 1.23V, RSET=20k
1.2
2.6
1.5
2.9
1.8
3.3
A
A
VTH OV,UV,FBPinThresholdVoltage VIN Rising 1.21 1.235 1.26 V
VUV(RTH) UVPinResetThresholdVoltage VUV Falling 0.55 0.62 0.7 V
VFB(HYST) FBPinPowerGoodHysteresis 10 20 30 mV
VTIMER(H) TIMERPinHighThreshold VTIMER Rising 1.2 1.235 1.28 V
VTIMER(L) TIMERPinLowThreshold VTIMER Falling 0.1 0.21 0.3 V
ITIMER(UP) TIMERPinPull-UpCurrent VTIMER=0 –80 –100 –120 µA
ITIMER(DN) TIMERPinPulldownCurrent VTIMER = 1.2V 1.4 2 2.6 µA
IGATE(UP) GatePull-UpCurrent GateDriveOn,VGATE = VOUT = 12V –18 –14 –29 µA
tD(AUTO-RET) Auto-RetryTurn-OnDelay 50 100 150 ms

2
dc1886af
DEMO MANUAL DC1886A
Quick start proceDure
Figure 1. Proper Measurement Equipment Setup
Demonstration circuit 1886A is easy to set up to evalu-
ate the performance of the LTC4232. Refer to Figure 1
for proper measurement equipment setup and follow the
procedure below.
Demonstration Circuit 1886A has two user configurable
jumperoptions:
• JP1TIMERDURATION:Setto2msfortheinternal2ms
timer or 12ms determined by C1. C1 may be replaced
for other timer durations. (Default position: 12ms)
• JP2AUTORETRY:SettoONforauto-retryorOFFfor
latchoffonovercurrentfaults.(Defaultposition:OFF)
+
–
+
–
+
–
ADJ
POWER SUPPLY +–
TEST LOADS

3
dc1886af
DEMO MANUAL DC1886A
Quick start proceDure
LEDs indicate the state of input power, output power, FAULT
andPG.LoadcurrentcanbemonitoredontheIMON turret,
whichhasagainof0.4V/AdeterminedbyRMON(20k).
Setanadjustablepowersupplycapableofsupplying10A
to 12V. Turn off power and connect the supply to the VDD
and GND turrets.
Connect a suitable load to the VOUT and GND turrets. This
load can be an electronic load or power resistors capable
ofdissipating100W.
NOTE:BecausetheLTC4232incorporatesfoldbackcur-
rent limiting, the nominal start-up current supplied to the
load is 1.5A and can be as low as 1.2A. This current limit
increaseslinearlyuntiltheFBpinexceeds0.6V(VOUT >
5.1V). An electronic constant current load set to 1.5A will
not permit the circuit to turn on unless it is gated on by the
PGsignal(aswouldbethecasewithaDC/DCconverter
controlledbythePGsignal).Resistiveloadingwillnot
have this problem.
Turn on the power supply, verify the input voltage is 12V.
Verify the output voltage and the load current, D2 and
D4 should both be lit (input voltage and output voltage,
respectively) and both D3 (F LT )andD5(PG)shouldbe
off.Onpower-up,observetheslopeofVOUT. This should
beintherangeof0.15to0.55V/ms,correspondingtoa
ramp-uptimeof22msto80msto12V.Withthecircuit
functioning, additional evaluations can now be performed.
OV/UV/PGthresholds:Settheinputsupplytozeroand
ramp the voltage slowly, observing the following events.
Above10.3V,thecircuitwillbeoutofUVlockoutandthe
outputshouldramp-up,lightingD4.Above10.9VtheFB
pinwillbepastitsthreshold,assertingthePGpinhighand
extinguishing D5. Increasing the supply past 15.8V will
engageOVlockout;D4willextinguishandD5willlight.
Note that the voltages indicated in this step are maximums,
taking into consideration the tolerances of the resistors
and the LTC4232 inputs.
CurrentLimitThresholds: With theinputsupply set to
12V, load the output with a 2.5Ω power resistor capable of
dissipating60W.Powershouldremainon,asthecurrent
willbebelowthe5.0Aminimumcurrentlimitthreshold.
Next,loadtheoutputwitha1.8Ωpowerresistor.Power
should be interrupted, as the current will be above the
6.1A maximum current limit threshold.

4
dc1886af
DEMO MANUAL DC1886A
Quick start proceDure
Inrushintocapacitiveload:Oneofthemainfunctionsof
a hot swap circuit is to provide controlled ramp-up into a
capacitive load to avoid disturbing the input power supply.
Forthefollowingtests,ensurethattheAUTORETRYjumper
issettoOFFandtheTIMERDURATIONjumperissetto
12ms. To guarantee that current limit is never reached
during ramp-up into a capacitor, the current must be less
than the minimum current limit threshold of 1.2A when
thegateramprateisatitsmaximumvalueof0.55V/ms.
(Note that the minimum current limit threshold occurs
whentheFBpinisatzero.)
 C=I/(dV/dt)=1.2A/(0.55V/ms)=2182µF
Thus, the circuit will always power up successfully with a
2000µFcapacitoratVOUT, and observation of the TIMER
turret post will show that it never begins to ramp. Figure 2
showssuccessfulramp-upintoa1200µFcapacitor.Inrush
current is determined by ramp rate alone.
It is more complicated to find the smallest capacitor that is
guaranteed to prevent successful ramp-up, since the cur-
rent into the load capacitor is afunction of the scaled output
voltage at the FB pin. As a starting point, the minimum
ramprateof0.15V/msshouldproduceacurrentgreater
than the maximum current limit threshold of 1.8A (when
FBisatzero)toensurethatthetimerbeginstorampas
soon as the output begins to rise.
 C=I/(dV/dt)=1.8A/(0.15V/ms)=12000µF
Figure 2. Successful Ramp-Up into 1200µF
IOUT
1A/DIV
VOUT
5V/DIV
TIMER
1V/DIV

5
dc1886af
DEMO MANUAL DC1886A
Quick start proceDure
ObservationoftheTIMERpinwillshowthatitbeginsto
ramp as soon as the output begins to ramp. At this ramp
rate, the output voltage will only be at 1.8V after 12ms,
andhencetheFBpinwillbeat0.21V,abovethepointat
which the current limit threshold begins to increase. If the
ramp-up becomes limited by the slew rate of the gate pin,
the output voltage will continue to rise and successfully
power up. However, if the ramp-up continues to be limited
by the current limit threshold, the timer will expire. Figure 3
showsunsuccessfulramp-upintoan8000µFcapacitor.
CurrentreachestheinitiallimitwhenFBisatzero.Once
FB rises above approximately 100mV the current (and
hence the output ramp rate) increases, however the timer
expires before the output reaches its final value.
The correct way to ensure successful power-up into an
output capacitance greater than 2000µF is to reduce
the ramp rate by installing a 1k resistor and a suitable
capacitor for RGATE and CGATE following the procedure in
the data sheet. Increasing the timer duration carries the
riskofexceedingtheSafeOperatingArea(SOA)ofthe
internalMOSFET.
Circuit Testing Notes: As in all high current testing, it is
agoodideatousetwistedpairpowerleadstominimize
circuitinductance.Understeploadssignificantvoltage
spikes can occur as a result of this inductance causing
false overvoltage or undervoltage trips. If there is sig-
nificant lead length between the power supply and the
DC1886A, add additional bulk capacitance across the VIN
and GND turrets. This capacitance may also be needed if
stepping the load results in significant voltage steps on
the input, particularly if performing tests of the circuit
breaker function.
Figure 3. Unsuccessful Ramp-Up into 8000µF
IOUT
1A/DIV
VOUT
5V/DIV
TIMER
1V/DIV

6
dc1886af
DEMO MANUAL DC1886A
schematic Diagram
