Linetek 6 by 2 HDMI 1.4 Matrix User manual

6 by 2 HDMI 1.4 Matrix

1
User manual
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this manual for
future reference.
Introduction
The 6 by 2 HDMI matrix with 4kx2k supported which allows HDMI signal from any of its six sources
to be routed to and displayed on any of its two connected HDMI displays simultaneously. It supports 3D,
3Gbps bandwidth, 12-bit Deep Color, Hi-Def lossless audio and other features defined by HDMI
specifications. The management of source/ sink scenarios can be operated easily through on-panel
buttons, IR remote control.
Features
1. Compliant with HDMI 1.4a, CTS 1.4a, DVI 1.0.

2
2. HDMI 1.4 support: Audio Return Channel (ARC), 3D TV support, CEC1.4.
3. Support 3D Video & 4Kx2K, 8, 10, 12 &16 bits per color depth.
4. Support MHL input, Share your smart phone photos, music and movies on the TV.
5. Support PIP display fuction.
6. Audio support:
HDMI 1.4 compatible audio interface
Dolby TrueHD
DTS-HD Master Audio 7.1CH
Full audio input and output support
Package
1. HDMI 1.4 6by2 Matrix
2. 5V DC Power Supply Adaptor
3. Remote control

3
4. Operation Manual
5. MHL to HDMI Cable(option)
Specifications
Frequency Bandwidth 2.97Gbps
Input Ports 6 x HDMI Female ports.
Output port 2 x HDMI Female port,1x Toslink,1x Earphone
HDMI Audio Output PCM2, 5.1, 7.1CH, Dolby 5.1, DTS5.1, D-TrueHD, DTS-HD
Power Supply 5V/1A DC (US/EU standards, CE/FCC/UL certified)
ESD Protection Human Body Model: ± 8kV (air-gap discharge)
± 4kV (contact discharge)
Dimensions (mm) 250(D) x110 (W) x 26(H)
Weight (g) 720
Power Consumption(max) 5W

4
Operating Temperature 0˚C ~ 40˚C / 32˚F ~ 104˚F
Storage Temperature -20˚C ~ 60˚C / -4˚F ~ 140˚F
Operation controls and Fuctions
Front Panel
1. ON/OFF: Power on/off switch.
2. Input LED: These red LED illuminate when the output select to the corresponding input.
3. Audio EDID LED: These red LED illuminate when the audio EDID select to corresponding audio.
4. ARC LED: This red LED illuminate when the ARC fuction open.
5. POWER LED: This red LED illuminate when the device is connected with power supply.

5
6. OUTA BUTTON: Press this button to select the input source to HDMI OUTA.
7. OUTB BUTTON: Press this button to select the input source to HDMI OUT B.
8. EDID BUTTON: Press this button to select the 2.0CH,5.1CH,7.1CH audio output mode.
9. ARC BUTTON：Press this button to open or close the ARC fuction.
10.RST BUTTON: Press this button the matrix will reset to factory state(INPUT1, 2.0CH AUDIO
MODE,ARC fuction closed)
Rear Panel
1. Input Source: These slot is where you connect the HDMI source output from DVD, PS3.
2. HDMI OUT: This slot is where you connect the HDTV or monitor with HDMI cable.
3. Toslink OUT: This slot is where you connect to the amplifier with optical fiber cable.

6
4. Stereo OUT: This slot is where you connect to the speaker with 3.5mm earphone cable.
5. DC IN: Plug the 5V DC power supply into the unit and connect the adaptor to AC wall outlet.
Attention:
1.TheToslink and Stereo audio follow the OUTAHDMI audio.
2. The In6 support MHL/HDMI input only,use MHL to HDMI Cable to connect smart phone and
matrix.
Application Example

7
Remote control
STANDBY:Press this button will standby or power on the matrix.
Audio EDID: Press this button will Select the audio output mode
(2.0CH,5.1CH,7.1CH), and the LED will indicate the corresponding
state .

8
ARC: Press this button will Open or close the ARC fuction,and the LED will indicate the corresponding
state .
PIP: Press this button will Open or close the PIP fuction. The PIP fuciton can only work when OUTA
and OUTB select the same input source.
Select: Press this button will select the PIP source.
Enter: Press this button will confirm the select PIP source.
OUTA: Press these button will fast switch to select input source to HDMI OUTA. and the LED will
indicate the corresponding input source.
OUTB: Press these button will fast switch to select input source to HDMI OUTB. and the LED will
indicate the corresponding input source.
ARC fuciton : If you need use ARC,your HDTV must support this fuction, When you open the

9
ARC fuciton,the Toslink of the Matrix will output the HDTV current display content audio.
Otherwise will output the Matrix input source audio.
