CLOSED CAPTION DECODER PAL & NTSC, CV, CAV, & Y/C
MODEL PDC-888
FEATURES
Field 1 & Field 2
Captions
Text
XDS
EIA-608 Extended Character Set
All video Channels Power Line by-pass
The PDC-888 is a high performance Closed Cap-
tion Decoder for the NTSC/PAL system. It is capa-
ble of displaying captions for CV, CAV and Y/C as
required by EIA-608. This includes the codes
specified by the FCC Report and Order on General
Docket No. 91-1 and EIA-608 recommended prac-
tices for Captions, Text and XDS.
Nine standard data channels are supported by the
PDC-888: Caption channels 1 through 4 (CC1-
CC4),Textmodes1through4(T1through T4), and
Extended Data Services (XDS). The various
operational modes are selectable from four front
panel switches.
The component inputs accept RGB or YUV. All
connectors use BNC except the S-Video connector
The caption data is keyed into all component
channels. Packaged in LINK's standard 1 RU 800
Series chassis, the PDC-888 is both rugged and
reliable.
PAL/NTSC Auto Detect
S-Video I/O
Composite Video I/O
Component Video I/O
Standard Rack Mountable
120/240 AC Line Voltage Detect
ThePDC-888automaticallydetectsPAL or NTSC
The AC line voltage selects between 96 to 245
volts.
Designed with the professional user in mind, the
PDC-888processesCompositevideo,Component
video and S-Video. All video inputs including CV,
CAVand Y/C have AC power by-pass in theevent
power line failure. Component video is internally
terminated. S-Video is standard levels, using a 4-
pin Mini-Din connector for ease of operation. A
complementary differential input amplifier assures
highcommonmoderejectionwhileitsphase-linear
keyer cleanly inserts decoded characters into the
video image. Differential gain and phase are well
within 0.1% and 0.1° respectively.
In addition, the PDC-888 is backed by a standard
10-yearwarranty.Highperformance,flexibility,and
economy are equally represented in the PDC-888
Closed Caption Decoder.
PROFESSIONAL SERIES--
stand-alone system products--by LINK
LINKELECTRONICS, INC. g2137 Rust Avenue gCape Girardeau, MO 63703-7668
Phone [phone] gFAX 573 334 9255
CLOSED CAPTION SERIES

CLOSED CAPTION DECODER
MODEL PDC-888
SPECIFICATIONS
COMPOSITE INPUTS & OUTPUTS:
Number: .......................................................................One
Connector: ..................................................................... BNC
Level:...................................................................1.0Vpp±6dB
Character Video: .......................................................... 90IREUnits
Character Background: ..................................................... 10IREUnits
Impedance: .................................................................75Ω±1%
Frequency Response: .................................................. ±0.1dBat15MHz
....................................................................-0.5dBat17MHz
.................................................................. -1.0dBat18.5MHz
....................................................................-3.0dBat26MHz
DifferentialGain: ............................................................... 0.10%
DifferentialPhase:............................................................... 0.10°
Propagation Delay: ............................................................19nS ±3
Hum and Noise: .........................................................>60dB to 5 Hz
................................................................. >40dB above 5MHz
DC Offset: ............................................................ <2mV,Clamped
LineRateTilt: ................................................................. <0.1%
FieldRateTilt:................................................................. <0.1%
S-VIDEO INPUT & OUTPUT:
YLevel: .................................................................. 1Vpp±6dB
CLevel:.............................................................. 0.6VppNominal
Impedance: .................................................................75Ω±1%
Connector: ........................................................... FourPinMiniDin
COMPONENT INPUT & OUTPUT:
Red&U: ................................................................ 0.7Vpp±5%
Blue&V ................................................................ 0.7Vpp±5%
Green & Y: .............................................................. 1.0Vpp±5%
Y Channel Frequency Response: ..................................... ±1dB,30Hzto3.5MHz
ENVIRONMENTAL:
Temperature:........................................................0°to50°Cambient
Humidity: ..................................................... 10%/90%non-condensing
Power:......................................................................9.5VAR
AC Voltage: ................................................. 120/240 VAC±10%, 50/60Hz
MECHANICAL:
Height: Standard 1 Rack Unit . ............................................... 1.719 inches
Width: Standard 1 Rack Unit ................................................ 17.250 inches
Depth: ......................................................................7inches
Weight: ....................................................................4lbs.,4oz.
