Linkcom Link Marina3 User manual

Link Marina3
USER GUIDE
Pr i v at e m o b i l e r ad i o
1. LCD Screen
Channel Number. Changes
from 1 to 8 as selected by the
user.
Displays the current Battery
charge level.
LCD Screen
Displays the
current channel
selection and other
radio symbols.
MENU Button
Press to program
the PMR settings.
-
(Power) button
Press and hold to
turn the PMR unit
ON or OFF.
Speaker
Displayed when the Key Lock feature is activated.
Displays the current Speaker volume level.
Blinks when the Scan feature is turned ON.
Antenna
CALL button
- Press to send a
ringing tone to other
PMR units.
PTT (PUSH to
TALK) button
-Press and hold
to transmit.
Mic (Microphone)
(UP)/(DOWN)
buttons - Press to
change channels,
volume, and to
select settings
during programming.
Displayed when transmitting a signal.
Displayed when receiving a signal.
2. Installation
2.1 Removing the Belt Clip
a. Pull the Belt Clip Latch
away from the PMR.
b. While pulling the Belt
2.2 Loosen the screw counter
clock wise direction using a
coin or belt clip open the battery
compartment as shown in Figure 2
Clip Latch, push up
the Belt Clip as
shown in Figure 1.
2.3 Installing the Belt
Clip
a. Slide the Belt Clip into
the slot as shown in
Figure 3.
b. A “click” indicates the
Belt Clip is locked into
position.
a. Slide down the Battery Compartment Cover.
b. Insert 3 “AAA” size batteries (not included) by following the
polarity marking inside the Battery Compartment as shown in
Figure 4.
c. Replace the Battery Compartment Cover.Tighten the battery
door screw firmly to meet the IPX6 standard. See Figure 5.
Figure 4 Figure 5
Notes:
Use only same type and make of batteries on the PMR units.
The PMR units have a built-in Power Saver(PS) for maximum
battery life, but when not in use, turn the units OFF to
conserve battery power.
Remove the batteries if the units will not be used for a long
period of time.
Caution: Observe the proper battery polarity orientation when
installing batteries. Incorrect positioning can damage both the
batteries and the unit.
4.7 Channel Scan
Press and hold down the (UP) or (DOWN) button for
3 seconds. The channel number on the LCD Screen
changes rapidly until an active signal is detected.
When an active signal (one of the 8 channels) is detected,
channel scan pauses on the active channel.
Press the PTT button to communicate through the active
signal channel, and the channel scan will be deactivated.
(OR press the (UP) or (DOWN) button to continue
the channel scanning.)
Press the MENU button to stop the channel scanning
operation.
a.
b.
c.
d.
Channel scan performs searches for active signals in an
endless loop from channels 1 to 8. This allows you to find
other radios without having to change channel. To activate
this feature;
b. While the Channel icon is blinking, press the (UP) or
(DOWN) button to select the desired channel. The channel
changes from 1 to 8, or from 8 to 1.
c.Press the MENU button to confirm your selection and
return to the normal mode.
Note:
Refer to the "Channel Table" section of this Owner’s Manual for
detailed frequency listing.
4.8 Key Lock
To activate the Key Lock feature, press and hold the
MENU button until the Key Lock icon ( ) appears
on the LCD Screen.
To deactivate the Key Lock feature, press and hold the
MENU button again until the Key Lock icon ( )
disappears on the LCD Screen.
a.
b.
The Key Lock feature allows the user to disable the (UP),
(DOWN), and the MENU buttons so that the PMR settings
cannot be changed accidentally.
The PTT, CALL, and the (Power) buttons will remain
functional even if the Key Lock feature is activated.
4.9 Calling (Paging) Tone
With the PMR in normal mode, press and release the CALL
button. The unit will transmit a 2-second page tone to the
other unit/s set with the same channel within transmitting
range .
a.
You can use the CALL button to send a tone to other users on
the same channel. To activate this feature;
4.6.1 Monitor
You can use the Monitor feature to check for weak signals
on the current channel.
a. To activate,press and hold the MENU and the (UP)
button at the same time.
b.If you hear constant noise and hissing, press the
.noitcnufrotinoMehtffonrutotnottubUNEM
3. Waterproof standard IPX6
though this unit is designed to meet IPX6 standard,
it can be kept 1 meter under water for 1 minutes.
4.3 Receiving a Call
The unit is continuously in Receive mode when the
unit is turned ON and not transmitting. When a signal is
received on the current channel, the receive signal icon
“RX” will be displayed on the LCD Screen.
4. Operation
4.1 Turning the Unit ON/OFF
To Turn ON;
a. Press and hold the (Power) button. A special “beep"
sound will be heard. The LCD Screen will be illuminated by
an orange light for several seconds, and will display the
current channel.
To switch OFF;
b. Press and hold the (Power) button. A special “beep"
sound will be heard and the LCD Screen will turn blank.
4.5 Roger Beep
The Roger Beep is a tone which is automatically transmitted
whenever the PTT button is released. This alerts the
receiving party that you have ended the transmission, and
you are now in receive mode.
4.6 Changing Channels
The PMR has 8 available channels. To change channels, in
normal mode;
a. Press the MENU button, the Channel icon “ ” on the LCD
Screen will start blinking.
AAA
AAA
AAA
2.4 Installing the Batteries
Figure 2
open
Figure 1 Figure 3
Belt clip
latch
4.2 Adjusting the Speaker volume
There are 8 volume levels, the current speaker volume
level is displayed on the LCD Screen.
To adjust the speaker volume level, press the (UP)
button to increase, or press the (DOWN) button to
decrease. The LCD Screen will display the speaker volume
icon bars ascending, or descending respectively.
4.4 Transmitting (sending)
Press and hold the PTT (Push to Talk) button to transmit
your voice. The transmit signal icon “TX” will display on
the LCD Screen.
Hold the unit in a vertical position with the Mic
(Microphone) 5 cm away from the mouth. While holding
the PTT button, speak into the mic (microphone) in a
normal tone of voice.
Release the PTT button when you have finished
transmitting.
a.
b.
c.
Important:
In order for other people to receive your transmission, they must
also be on the same channel that you are currently using. Refer
to the "Changing
Channel" s ection for more informati on.
When the PTT and/or CALL buttons are continuously pressed,
your PMR cannot receive any transmissions.
Waterproof

5.1 LCD Screen Back Light
Every time a button is pressed (except PTT button), the LCD
Screen back light will illuminate for 4 seconds.
5.2 Power Saving
Your PMR unit has special circuitry designed to extend the
life of your battery. When the unit is not used for 4 seconds,
it will automatically switch into a low power mode.
The Power Saving feature does not affect the PMR’s ability to
receive transmissions. When a signal is detected, it
automatically returns to full power mode.
5.3 Battery Meter Indicator
The PMR can detect the battery charge levels. The Battery
icon will display the battery charge status as follows;
Battery charge at high level.
Battery charge at low level.
Important: Replace the Batteries. Use only Alkaline
“AAA” 1.2V batteries.
5. Auxiliary Features
0 Range (Km) 3
Signal Strenght
Range Slope
Optimum (open area)(1)
Medium ground based
obstruction(2)
Heavily built up area (3)
The Transmission range of the product is dependent on the environment
terrain where it is being used, the following diagram attempts to guide
the user on the sort of performance to expect for everyday use.
Range Check
The Transmission range will be affected as shown in the above diagram.
The transmitting range typical values for different environment conditions
will be (1) 3 km (2) 1.5 km (3) 750m. It should be remembered that
these are only guide values as actual achieved distances will be
dependent on the environment and terrrain.
6. Effective Range
7. Specifications
8 Channels
0.5W
Up to 3 Kms. (2 Miles)
Channels Available
Outpu t Power (TX)
Range
C AUTIO N
Damaged Antenna
Do not use any PMR that has a damaged antenna. If a damaged antenna comes
in contact with the skin, a minor burn may result.
Potentially Explosive Atmospheres
Turn your PMR OFF w hen i n a ny area with a potentially explosive atmosphere , unless
it is a type especially qualified f or such us e ( for ex ample, Factory M utual Approved).
Sparks in such areas could cause an explosion or fire resulting in injury o r e ven death.
Batteries
Do not replace or charge batteries in a potentially explosive atmosphere. Contact
sparking may occur while installing or removing batteries and cause an explosion.
WARNING
For Vehicles with an Air Bag
Do not place your PMR in the area over an air bag or in the air bag deployment area.
Air bags inflate with great force. If a PMR is placed in the air bag deployment
area and the air bag inflates, the PMR may be propelled with great force and
cause serious injury to the occupants of the vehicle.
Batteries
All batteries can cause property damage and/or bodily injury such as burns if
conductive material such as jewelry, keys, or beaded chains touch exposed
terminals. The material may complete an electrical circuit (short circuit) and
become quite hot. Exercise care in handling any charged battery, particularly
when placing it inside a pocket, purse, or other container with metal objects.
8. Safety
NOTE:Areas with pot ent iall y explosive atmo spheres a re often, but n ot always ,
clearly ma rke d. They incl ude fue ling areas
such as below deck on boats; fue
l or
chemical transfer or sto rag e faci litie s; areas where the air con tains chem ica ls or
particles, such as g rain , dust, or me tal po wde rs; and any other are a wher e you
would nor mal ly be adv
ised to
tur n off your veh icle
engine.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn your PMR OFF near
electrical blasting caps or in a “blasting area” or in areas posted: “Turn off the two-
way radio.” Obey all signs and instructions.
9. Cleaning and Care
To clean your PMR, use a soft cloth dampened with water. Do not use cleaners or
solvent, which may cause damage that may not be covered by guarantee.
Channel Frequency Table
8
446.05 625
446.06 875
446.08 125
Channel
1
2
3
4
5
6
7
446.00 625
446.01 875
446.03 125
446.04 375 44 6.0 93 75
Frequency (MHz) Channel Frequency (MHz)
Symptom Solution
No power.
Reception
is weak.
Cannot change
channels.
Range is limited.
Wearing the radio close to the body, such as in a pocket or on
a belt, will decrease range; change the location of the radio.
limit the range significantly.may
Open fields provide the maximum range, while steel/concrete
structures, heavy foliage, and use in buildings and in vehicles
The maximum range will vary depending on terrain and environment.
Replace with new if the battery charge level
indicator is low.
batteries
Batteries may be weak.
Sound distortion
problems.
Radios too far apart. Obstacles interfere with transmission.
Talk range is up to 3 Km (2 miles) in clear unobstructed
conditions.
Radios too close. Radios must be at least 1.5 meters apart;
your distance.increase
If you are transmitting, speak in a normal tone of voice, 3 cm
away from the Mic (microphone.).
If you are receiving, lower the volume to a comfortable level.
11. Troubleshooting Guide
The may be weak.batteries
Check the batteries are installed properly.
Replace the old batteries with new ones.
Press the (UP) button to increase the receiver volume level.
The receiving signal may be weak and/or out of range.
Key lock mode must be deactivated if the Key lock icon ( ) is
displayed on the LCD Screen.
To change channels, press the MENU button then press the
(UP) or (DOWN) buttons to change the current channel.
Batteries may be weak.
Linkcom operates a policy of continuous product
improvement, and so reserves the right to make changes to the product
and functions without prior notice.
Declaration of Conformity
And conforms to the following relevant standards:
The Link marina 3 complies with the essential requirements
Waste electrical products must not be
disposed of with household waste.
This equipment should be taken to
your local recycling centre for safe
treatment.
The Link marina 3 is fully guaranteed for 12 months from the date
purchase shown on you r sales receipt. The guarantee does not cover
damage by misuse or negligence, or by excessive voltage.
10. Guarantee and service
When unpacking your Link marina 3, check for visible damage.
If you see any damage, do not use the PM R - return the whole unit to
where you bought it.
If your Link marina 3 develop
s a fault, re fer to the “ Troubleshooting
Guide.” section of this manual. If you can’t solve the problem, return the
whole unit as follows;
This does not affect your statutory rights.
Linkcom operates apolicy of continuous product
improvement, and so reserves the right to make changes to the product
and functions without prior notice.
Please keep your sales (till) receipt - this is your guarantee. You should
also keep the original packaging materials.
This equipment is intende d for use in:
Austria Finland Latvia
Denmark Ireland Portugal
Estonia Italy Slovenia
Spain
Belgium France
Liechtenstein Sweden
Bulgaria Germany Luxemburg Switzerland
Croatia Greece
The Netherlands Turkey
Cyprus Hungary Norway UK
Czech Iceland Poland Romania
Countries of use
Caution: Use only same type and make of batteries. To reduce the
risk of electric shock, do not expose this appliance to rain or
moisture.
of
