TK-7360(H)/8360(H)
VHF/UHF Compact FM Mobile Radios
Kenwood's new TK-7360/8360 offers extra
wideband coverage (UHF: 70MHz) and a wealth
of user-friendly features. The bright 10-character,
13-segment LCD clearly displays all essential
information, including status messages, ID and
GPS info. Also available are 10 programmable
function keys, QT/DQT signalling and multiple
scan functions to ensure superb performance 24/7.
128 CHANNELS, 128 ZONES
The TK-7360/8360 offers ample channel/zone capacity to
enable a large organization to manage a wide range of
different operations efficiently.
ENHANCED KENWOOD AUDIO
Clear audio means confident communications, but power
output is not the only factor that determines how easy it is to
use a radio in varying noisy environments. As an audio
specialist experienced in psychoacoustics, Kenwood can draw
on decades of expertise at every step: component selection,
construction, optimisation, evaluation and analysis. The
resulting audio performance – specially engineered for
transceivers and with frequency response optimised for the
human voice – is undeniably clearer and crisper.
EXTERNAL D-SUB 15-PIN INTERFACE
A D-sub 15-pin terminal enables the simple connection
of various types of external equipment. It can be used
for Ignition sense, External Switch, Horn Alert, and
External Mic, among others. A Molex interface is also
available with the optional KCT-60M cable.
HIGH OUTPUT
TX output can be set (by FPU) to 5, 25, or 50 watts (45
watts for UHF).
10 PROGRAMMABLE FUNCTION KEYS
The programmable function keys can be assigned a
variety of functions to suit different applications and
thus maximise convenience.
STATUS MESSAGES
Status messages are displayed clearly thanks to the
large LCD with adjustable brightness. It is also possible
to operate an external device (via AUX output) – such as
a gate or an alarm – on receipt of a status ID.
MULTIPLE SIGNALING
❚QT/DQT/DTMF
Encoder/decoder function uses QT/DQT to segregate talk
groups, so users only hear calls from their own group.
DTMF PTT ID is included for dispatch operations or for a
simple remote control application.
❚FleetSync®PTT ID, SelCall & Status
Utilising Kenwood's FleetSync®signalling protocol, the
TK-7360/8360 has PTT ID (ANI: automatic number
identification) and Selective Calling capabilities for
managed dispatch operations. Programmed Status
(by FPU) can also be sent.
❚2-tone (encode/decode)
The 2-tone signalling format is provided for use with the
most common radio systems.
❚MDC-1200 signalling
Built-in MDC signalling added with an LCD display
mean that the following features are available:
•PTT ID Encode/Decode •Emergency Encode/Decode
•Stun/Revive Decode •Radio Check Decode
❚Emergency alert
For hazardous/hostile duty environments, a PF key can be
programmed for emergency use to alert the dispatcher or
other group members via DTMF, FleetSync®or MDC-1200
signalling.
PROGRAMMABLE BLUE LED
The blue LED indicator can
be customised to provide
useful status information.
For example, it can be used
in combination with the
orange LED for Selective
Call differentiation.
GPS FEATURE
Connected to an external GPS receiver, the TK-7360/8360
can transmit accurate vehicle location data to the
central base station for fleet management purposes.
Designated scrambler and GPS modules can be installed
internally.
VOICE GUIDE & STORAGE OPTION (VGS-1)
Audible announcement is provided by the optional
VGS-1 unit, which also provides storage for GPS data as
well as voice recording/playback.
OTHER FEATURES
•Multiple Scan Functions, including Priority Scan •Voting
(automatic repeater search & selection) •Independent
Setting Per Channel (compander, scrambler) •BCL (Busy
Channel Lockout) •Talk Around •Horn Alert Function
•Companded Audio (narrow/wide) •3-colour LED (red,
orange, green) •Password Protection •Time-out Timer
•Programmable Voice Inversion Scrambler*1 •Minimum
Volume Setting (by FPU) •Operator Selectable Tone
Settings •Embedded Message •8 Programmable Accessory
Ports (for external control) •Scan Del/Add Function
•Kenwood ESN (Electronic Serial Number) •Radio Stun
•Adjustable Microphone Gain (FPU only): High/Normal/Low
•Microsoft Windows®PC Programming & Tuning
*1 This function cannot be used in certain countries.
Please contact your Kenwood dealer for further information.
