PRODUCT DATA
Model No: WRT150N (EU)
Start a wireless network with
up to 4X the range and
12X the speed!
Internet-sharing Router and
4-port 10/100 Switch, with
a built-in speed and range
enhanced Wireless Access Point
MIMO technology uses multiple
radios to create a robust signal
that travels up to 4 times farther
and reduces dead spots
Up to 12 times faster than
Wireless-G, but also works great
with Wireless-G and -B devices
Wireless signals protected by
wireless encryption, and your
network protected from Internet
attacks by a powerful SPI rewall
Wireless-N
Home Router

PRODUCT DATA
Wireless-N Home Router
The Wireless-N Home Router is really three devices in one box. First, there’s the Wireless
Access Point, which lets you connect to the network without wires. There’s also a built-
in 4-port full-duplex 10/100 Switch to connect your wired-Ethernet devices together.
Finally, the Router function ties it all together and lets your whole network share a
high-speed cable or DSL Internet connection.
The Access Point built into the Router uses the very latest wireless networking
technology: Wireless-N (draft 802.11n). By overlaying the signals of multiple radios,
Wireless-N’s “Multiple In, Multiple Out” (MIMO) technology multiplies the eective
data rate. Unlike ordinary wireless networking technologies that are confused by
signal reections, MIMO actually uses these reections to increase the range and
reduce“dead spots” in the wireless coverage area. The robust signal travels farther,
maintaining wireless connections up to 4 times farther than standard Wireless-G.
With Wireless-N, the farther away you are, the more speed advantage you get. It works
great with standard Wireless-G and -B equipment, but when both ends of the wireless
link are Wireless-N, the router can increase the throughput even more by using twice
as much radio band, yielding speeds up to 12 times as fast as standard Wireless-G. But
unlike other speed-enhanced technologies, Wireless-N can dynamically enable this
double-speed mode for Wireless-N devices, while still connecting to other wireless
devices at their respective fastest speeds. In congested areas, the “good neighbor”
mode ensures that the Router checks for other wireless devices in the area before
gobbling up the radio band.
To help protect your data and privacy, the Router can encode all wireless transmissions
with industrial-strength 256-bit encryption. It can serve as your network’s DHCP Server,
has a powerful SPI rewall to protect your PCs against intruders and most known
Internet attacks, and supports VPN pass-through. Conguration is a snap with the web
browser-based conguration utility.
The incredible speed of Wireless-N makes it ideal for media-centric applications like
streaming video, gaming, and Voice over IP telephony, and gives you plenty of room to
run multiple media-intense data streams through the network at the same time, with
no degradation in performance. With the Linksys Wireless-N Home Router at the center
of your home or oce network, you can share a high-speed Internet connection, les,
printers, and multi-player games, and run media-intensive applications at incredible
speeds, without the hassle of stringing wires!
Features
Complies with IEEE draft
802.11n standards
Blazing fast wireless speeds for
high bandwidth applications
such as video streaming or le
sharing
Expanded wireless coverage
up to 4X the range of 802.11g
products
All LAN ports support auto-
crossover (MDI/MDI-X)—no
need for crossover cables
•
•
•
•

PRODUCT DATA
The maximum performance for wireless is derived from IEEE Standard 802.11 specications. Actual performance can vary, including lower wireless
network capacity, data throughput rate, range and coverage. Performance depends on many factors, conditions and variables, including distance
from the access point, volume of network trac, building materials and construction, operating system used, mix of wireless products used,
interference and other adverse conditions.
Check the product package and contents for specic features supported. Specications are subject to change without notice. Linksys is a registered
trademark or trademark of Cisco Systems, Inc. and/or its aliates in the U.S. and certain other countries. Copyright © 2007 Cisco Systems, Inc.
All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
7040310NC-AI Model No: WRT150N (EU)
Linksys
Web: www.linksys.com/international
Linksys products are available in more than
50 countries, supported by 12 Linksys Regional
Oces throughout the world. For a complete
list of local Linksys Sales and Technical Support
contacts, visit our worldwide website at
www.linksys.com/international
Wireless-N Home Router
Specifications
Model WRT150N
Standards Draft 802.11n, 802.11g, 802.11b, 802.3, 802.3u
Ports Power, Internet, Ethernet
Buttons Reset
LEDs Power, Ethernet (1-4), Internet, Wireless, Security
Cabling Type CAT 5e
# of Antennas 2
RF Pwr (EIRP) in dBm 17 dBm
Antenna Gain in dBi 1,8 dBi
UPnP able/cert Able
Security Features WEP, WPA, WPA2
Security Key Bits 128-Bit, 256-Bit
Environmental
Dimensions 150 x 36 x 170 mm
Weight 371 g
Power 12V, 1A
Certication FCC, CE, IC-03, Wi-Fi
Operating Temp. 0 to 40°C
Storage Temp. -20 to 60°C
Operating Humidity 10 to 85% Noncondensing
Storage Humidity 5 to 90% Noncondensing
Package Contents
Wireless-N Home Router
Setup CD-ROM with Norton Internet Security
User Guide on CD-ROM
Ethernet Network Cable
Quick Install
Power Adapter
Minimum Requirements
Internet Explorer 6.0 or Firefox 1.0
CD-ROM Drive
Windows XP or Vista
Network Adapter
•
•
•
•
•
•
•
•
•
•
