Linon 6206SF-AB-KD-U User manual

PAGE 1PAGE 4
ASSEMBLY INSTRUCTIONS
DOUBLE TRUNK
MODEL # 6206SF-AB-KD-U
WE ARE HERE TO HELP!
LINON HOME DECOR PRODUCTS, INC.
PLEASE READ ALL INSTRUCTIONS IN THIS BOOKLET BEFORE STARTING ASSEMBLY.
IMPORTANT:
TOLL FREE NUMBER 1.800.262.1852
MADE IN BRAZIL
FOR LINON HOME DECOR PRODUCTS, INC.
FIGURE 4
FIGURE 3
3.1. ATTACH THE PRE- ASSEMBLED UNIT
(PIECES # 1, AND # 2) TO THE
BASE # 3, FIX THE PIECES USING
(08) SCREWS (A), A PHILLIPS
HEAD SCREWDRIVER
(NOT PROVIDED) AND THE PRE-
DRILLED HOLES AS GUIDE,
AS SHOWN ON DRAWING.
4.1. ATTACH THE TOP PANEL # 4 TO ASSEMBLED UNIT USING THE DOWELS AS GUIDE,
AND FIX IT USING (04) SCREWS (A), A PHILLIPS HEAD SCREWDRIVER (NOT PROVIDED)
AND THE PRE-DRILLED HOLES IN THE RIGHT AND LEFT SIDE PANELS #2 AS GUIDE, AS
SHOWN ON DRAWING.
2
2
3
1
1
A
A
A
1
2
2
4A
A
TEL: [phone] FAX: [phone]
e-mail: [email protected]
STEP 3)
STEP 4)
WE TRY TO INSURE THAT YOUR FURNITURE ARRIVES IN EXCELLENT CONDITIONS.OUR
SERVICE REPRESENTATIVES ARE READY TO HELP YOU WITH QUICK SERVICE.PLEASE
CALL IF A PART IS DAMAGED OR MISSING. PLEASE CALL PRIOR TO RETURNING THE
ITEM TO THE STORE. OUR OFFICE IS OPEM 9 AM TO 5 PM EASTERN STANDARD TIME.
18”
35 5/8” 35 5/8”
BY RS3/034
04/03

SCREW 1 3/8" LONG
SCREW 5/8" LONG
HANDLE DETAIL
IRON DETAIL
IRON CORNER
WOOD DOWEL
HOOK
24
02
30
08
02
02
02
A
D
B
E
F
G
C
1 - FRONT AND BACK PANEL
2 - RIGHT AND LEFT
SIDE PANEL
3 - BASE
4 - TOP PANEL
STEP 1)
FIGURE 1
STEP 2)
FIGURE 2
PAGE 3PAGE 2
OPEN HARDWARE PACKAGE ON A FLAT SURFACE COVERED WITH NEWS PAPER.
COUNT EACH PIECE OF HARDWARE TO MATCH THE QUANTITY NUMBER IN THE
HARDWARE LIST COLUMN. CALL CUSTOMER SERVICE IF ANY PARTS ARE MISSING.
FOLLOW THE LETTER IDENTIFICATION WHEN READING THE ASSEMBLY DRAWING
"A" THROUGH "G".
HARDWARE PACKAGE COUNT.
HARDWARE IDENTIFICATION
A STANDARD PHILIPS HEAD SCREWDRIVER (NOT PROVIDED) IS REQUIRED TO
ASSEMBLE THIS UNIT.
TOOLS REQUIRED
PARTS IDENTIFICATION
1.1. FIX (02) IRON DETAIL (D) AND (02) HOOK (G) TO THE FRONT PANEL # 1 (2x) USING (06)
SCREWS (B), A PHILLIPS HEAD SCREWDRIVER (NOT PROVIDED) AND THE PRE-DRILLED
HOLES AS GUIDE, AS SHOWN ON FIGURE 1.
1.2. INSERT (02) WOODEN DOWELS (F) INTO THE HOLES LOCATED AT EDGES OF RIGHT
AND LEFT SIDE PANELS # 2, AS SHOWN ON FIGURE 1.
1.3. FIX (02) HANDLE DETAIL (C) TO RIGHT AND LEFT SIDE PANEL #02, USING (08) SCREWS (B),
A PHILLIPS HEAD SCREWDRIVER (NOT PROVIDED) AND THE PRE-DRILLED HOLES AS GUIDE,
AS SHOWN ON FIGURE 1.
2.1. FIX RIGHT AND LEFT SIDE PANELS # 2 TO THE FRONT AND BACK PANELS #1 ,
USING (12) SCREWS (A), A PHILLIPS HEAD SCREWDRIVER (NOT PROVIDED) AND THE
PRE-DRILLED HOLES AS GUIDE, AS SHOWN ON FIGURE 2.
2.2. NOW, FIX (08) IRON CORNER (E) TO PRE-ASSEMBLED UNIT USING (16) SCREWS (B),
A PHILLIPS HEAD SCREWDRIVER (NOT PROVIDED) AND THE PRE-DRILLED HOLES AS
GUIDE, AS SHOWN ON FIGURE 2.
1
23
4
12
1x2
x2
2
D
C
B
FB
BBB
G
2
2
1
1
B
B
B
B
E
E
B
B
E
E
B
B
A
A
A
A
A
A
B
B
E
E
B
B
E
E
B
B
