Linon 20459 User manual

IDO - 20459

Assembly Instructions
Caution : Please read this carefully before you proceed
Indah Round Chair w/Feet
Part List
FMiddle Left Side Panel 1
Label Picture Description QTY
A
B
C
D
E
Front Left Leg
Front Right Leg
Back Left Leg
Back Right Leg
Bottom Seat Panel
1
1
1
1
1
G
H
I
Middle Right Side Panel 1
1
1
Top Panel
Seat Cushion

Hardware List / Liste des pieces / Lista de piezas
Label Picture Description QTY
1
4
5
Cap Nut
Allen Key
6Wrench
27
1
1
2
Ring Washer
54
3Short Bolt M6 45mm 12
Nut 27
Long Bolt M6 60mm 15
7
Assembly Instructions
Caution : Please read this carefully before you proceed
Indah Round Chair W/Feet
Assembly Steps
Overview
This Chair has multiple parts and may require up to 30 minutes to assemble. To give you an
overview of the Chair parts, the above picture is provided to help you put the various parts into
perspective. Please read through the instructions below to familiarise yourself with the parts
and steps before assembly.
Top Panel (H)
Middle Right Side Panel (G)
Seat Cushion (I)
Bottom Seat Panel (E)
Back Right Leg (D)
Front Right Leg (B)
Middle Left Side Panel (F)
Back Left Leg (C)
Front Left Leg (A)

B
DC
A
Assembly Step 1
Open the carton and place all the parts onto a clean surface. Unpack all hardware packages.
Place the Bottom Seat Panel (E) with its mounting positions, facing upwards, attach Front Left Leg (A)
to Bottom Seat Panel (E) using Short Bolt (3), Ring Washers (2), Nut (5), Cap Nut (1) and tighten using
Allen Key (7) and Wrench (6). Repeat the same process with Front Right Leg(B), Back Left Leg (C) and
Back Right Leg(D). Do not fully tighten the Bolts.
Stand the Bottom Seat Panel (E) upright. Assemble the Middle Side Panel first, by attaching Middle
Left Side Panel (F) and Middle Right Side Panel (G), using Long Bolt (4), Ring Washers (2), Nut (5),
Cap Nut (1) and tighten using Allen Key (7) and Wrench (6). And then Assemble the Middle Side
Panels to the Bottom Seat Panel (E) by aligning the end pipes on the Middle Side Panels to the end
pipes of Bottom Side Panel (E), then using Long Bolt (4), Ring Washers (2), Nut (5), Cap Nut (1) and
tighten using Allen Key (7) and Wrench (6). Do not fully tighten the Bolts.
Caution: Two or Three adults required for assembly at this step
Assembly Step 2
7
3
2
2
5
6
E
G
F
E
74225
6
74225
6
G
F
1
1
7
4
2
5
6
1
2

2
4
5
6
7
2
Assembly Step 3
Attach Top Panel (H) to the Middle Left Side panel (F), and Middle Right Side Panel (G) by first aligning
the end pipes of Top Panel (H), to the end pipes of Middle Side Panel, then assemble them
by using Long Bolt (4), Ring Washers (2), Nut (5) and tighten using Allen Key (7) and Wrench (6)
Do not fully tighten the bolts.
Caution : Two or three adults required for assembly at this step.
1
Cover all the Bolts using Cap Nuts (1)
Check for stability and then tighten all Bolts at all joints.
Note : DO NOT fully tighten a Bolt in one go and the move on the next.
Rather in sequential manner, gradually tighten each Bolts are evenly secured.
This methodology will ensure maximum evenness once all Bolts are fully tightened.
Assembly Step 4
Assembly Step 5
H

Place the Seat Cushion (I) to the assemled Indah Round Chair w/Feet and once the Seat Cushion is
well positioned,secure it by tightening the rope on the back of Seat Cushion (I) to the back frame of
Indah Round Chair w/Feet.
Your Indah Round Chair w/Feet is now ready to use.
Assembly Step 6
CARE & MAINTENANCE
Do not put hot items directly on furniture surface.
Do not clean furniture with harsh cleansers or polish.
To obtain the longest lifespan of your outdoor products, minimizing exposure to direct sunlight is
recommended.
Children should not climb or jump on the furniture.
Do not write on furniture without a padded barrier to protect the surface.
To obtain the longest lifespan of your outdoor furniture products, avoid extended and lengthy
exposure to rain, snow and direct sunshine. Whenever possible cover the product and/or place
under patio or awnings.
Not for commercial use. For residental use only.
Stains may be removed with mild soap solution and damp cloth.
Keep away from sources of ignition.
Dust and pick-up solls using a clean, non-colored, lint-free cloth.
