Sunjoy L-GZ822PCO User manual

1
Domed 10' x 13' Gazebo
Item# L-GZ822PCO
Congratulations on your purchase of our Domed 10’ x 13’ Gazebo. Our clear, easy to follow,
step-by-step instructions will guide you through the assembly process from start to finish.
WARNING:
 This unit is heavy. Do not assemble this item alone. 6 to 8 people are recommended for safe assembly.
 Keep all children and pets away from assembly area. Children and pets should be supervised when
they are in the area of the Gazebo construction.
 Keep assembly area at least 6ft/1.8m from any obstruction such as a fence, garage, house,
overhanging branches, laundry line or electrical wires.
 Some parts may contain sharp edges. When assembling and using this product, basic safety
precautions should always be followed to reduce the risk of personal injury and damage to the product.
 Please read all instructions before assembly and use.
 Check all bolts for tightness before use, and periodically check and tighten bolts as necessary.
 Assemble on level ground.
 For outdoor use only
IMPORTANT
Please take time to read these instructions thoroughly and follow each step carefully for safe and
easy operation. Keep this manual for future reference.
We would like to hear from you with any comments or suggestions. In the continental U.S., you
can call us toll-free at 1-888-301-0332 from 8 a.m. to 5 p.m. CST Monday – Friday. You can also
send us an email using the feedback icon at SamsClub.com.

2
No.
A1 Top Connector 2
A2 Top Connecting Middle Beam 1
B Oblique Beam 4
C Middle Beam 6
DBottom Connecting Oblique
Beam 4
E1 Long Mosquito Netting Runner 1 2
E2 Long Mosquito Netting Runner 2 2
F1 Short Mosquito Netting Runner 1 2
F2 Short Mosquito Netting Runner 2 2
G Beam Connector 4
H Corner Support 4
I Pole Support Slice 8
J Pole 4
K Base 4
L Hook 1
M1 Big Canopy 1
M2 Small Canopy 1
N Mosquito Netting 1
O Curtain 1
P Baffle 4
Q1 Small Top Connector 2
Q2 Small Top Beam 1
R Small Top Arc Beam 4
S Beam Connector 6
Parts List
Description Qty Picture

3
Hardware Pack 1
AA Bolt M6x20 92pcs
BB Flat Washer M6 108pcs
CC Bolt M6x50 16pcs
DD Wrench M6 1pc

4
·
Fig.1: Assemble Long Mosquito Netting Runner 1&2 (E1&E2) together by Beam Connector (G), Bolt (AA),
Flat Washer (BB). (Note: Assemble Short Mosquito Netting Runner 1&2 (F1&F2) as above same way.)
Fig.2: Put Base (K) under Post (J), then use Bolt (AA) and Flat Washer (BB) to fasten.
Fig.3: Put assembled Long Mosquito Netting Runner 1&2 (E1&E2) on Pole (J), then use Bolt (CC) and Flat Washer (BB) to
insert Bottom Connecting Oblique Beam (D) and lock on Pole (J). Don’t tighten the bolts at this step.
Fig.4: Insert Short Mosquito Netting Runner 1&2 (F1&F2) into the gap between Pole (J) and Bottom Connecting
Oblique Beam (D), then use Bolt (CC) and Flat Washer (BB) to lock them tightly. Tighten the other side’s bolts also at
this step.
Fig.5: Connect Pole Support Slice (I) to Post (J), Long Mosquito Netting Runner 1&2 (E1&E2), Short Mosquito Netting
Runner 1&2 (F1&F2) by Bolt (AA) and Flat Washer (BB).

5
KK Bolt M5x15 4pcs
LL Flat Washer M5 4pcs
BB Flat Washer M6 10pcs
JJ Mosquito Netting Hook
（Pre-assembled） 112pcs
EE Bolt M6X30 4pcs
HH Bolt M6x40 6pcs
II Nut M6 6pcs
Hardware Pack 2
Fig.6: Connect Corner Support (H) to Long Mosquito Netting Runner 1&2 (E1&E2) and Short Mosquito Netting
Runner 1&2 (F1&F2) by Bolt (AA) and Flat Washer (BB).
Fig.7: Attach Beam Connector (S) to Short Mosquito Netting Runner 1&2 (F1&2) by Bolt (AA) and Flat
Washer (BB).
Fig.8: Attach Beam Connector (S) to Long Mosquito Netting Runner 1&2 (E1&2) by Bolt (AA) and Flat
Washer (BB).

6
Fig.12: Insert Middle Beam (C) into Top Connector (A1).
Fig.13: Attach Middle Beam (C) to Beam Connector (S) by Bolt (HH), Flat Washer (BB) and Nut (II). Put Big
canopy (M1) on the big top and do not expand it now.
Fig.14: Attach Baffle (P) on Long Mosquito Netting Runner 1&2(E2&2) by Bolt (EE) and Flat Washer (BB).
Fig.9: Insert Top Connecting Middle Beam (A2) to Top Connector (A1) by Bolt (KK) and Flat Washer (LL). Then
screw Hook (L) onto Connecting Middle Beam (A2).
Fig.10: Insert Oblique Beam (B) into Top Connector (A1).
Fig.11: Insert bottom of Oblique Beam (B) into Bottom Connecting Oblique Beam (D).
Fig.15: Insert Small Top Beam (Q2) into Small Top Connector (Q1).
Fig.16: Insert Small Top Arc Beam (R) into Small Top Connector (Q1).
Fig.17: Put Small Canopy (M2) on Small Top Arc Beam (R).
Fig.18: Attach assembled small top on Oblique Beam (B) by Small Top Arc Beam (R).

7
Hardware Pack 3
GG Stake￠6 x 180 12pcs
Fig.19: Connect Stake (GG) and Base (K) to ground.
Fig.20: Connect Mosquito Netting (N) and Curtain (O) to Mosquito Netting Hook (JJ).
(Note: Mosquito Netting should be inside, Curtain should be outside.)
Fig.21: Set the Big Canopy (M1), insert the hooks into the grooves on the outside of the beam.

8
Care & Maintenance
Before using, clean the flower tower completely with a soft dry towel. When not in use, wipe free of any
dirt or loose objects, wash with a mild solution of soap and water; rinse thoroughly and dry completely.
Do not use strong detergent or abrasive cleaners.
Steel components of garden accessories and furniture are treated with rust inhibiting paint. However,
due to the nature of steel, surface oxidation (rusting) will occur if this protective coating is scratched.
To minimize this condition, it is recommended that care be taken when assembling and handling the
product, in order to prevent the paint from being scratched.
Limited Manufacturer’s Warranty
This product carries a 1 year warranty against defects in workmanship and materials. We agree to
replace the defective product free of charge within the stated warranty period, when returned by the
original purchaser with proof of purchase. This product is not guaranteed against wear or breakage
due to misuse and/or abuse.
Exclusions
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts
of nature, vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware
is not covered. Proof of purchase (dated register receipt) is required for warranty claims. Warranty is to
the original purchaser and is non-transferable. Any replacement of warranted items will be in the
original style and color, or a similar style and color if the original is unavailable or has been
discontinued. As some states do not allow exclusions or limitations on an implied warranty, the above
exclusions and limitations may not apply. This warranty gives you specific rights, and you may also
have other rights, which vary from state to state.
AA Bolt M6X20 10pcs
BB Flat Washer M6 20pcs
CC Bolt M6X50 4pcs
EE Bolt M6X30 2pcs
HH Bolt M6X40 2pcs
II NutM6 2pcs
JJ Mosquito Netting Hook 10pcs
Back U
p
Hardware
