Introduction
The Schwintek Motorized TV Lift is a great way to save on
counter space and an impressive way to display TV. The
lightweight system is easy to install and program, and smart
technology shuts the motor off in case of obstruction.
Features:
• Patented worm rail design efficiently moves TV
up and down
• Easy one-button programming in under one minute
Additional information about this product can be obtained
from lci1.com/support or by using the myLCI app.
Replacement kits can be ordered from https://store.lci1.com/
or by using the myLCI app.
The myLCI app is available for free on iTunes®for iPhone®
and iPad®and also on Google Play™for Android™users.
iTunes ®, iPhone®, and iPad®are registered trademarks of
Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
Safety
Read and fully understand all instructions before installing
or operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables
can change the circumstances of the instructions, i.e.,
the degree of difficulty, operation and ability of the
individual performing the instructions. This manual
cannot begin to plot out instructions for every possibility,
but provides the general instructions, as necessary, for
effectively interfacing with the device, product or system.
Failure to correctly follow the provided instructions
may result in death, serious personal injury, severe
product and/or property damage, including voiding of the
LCI limited warranty.
THE “WARNING” SYMBOL ABOVE IS A SIGN THAT
A SAFETY RISK IS INVOLVED AND MAY CAUSE
DEATH, SERIOUS PERSONAL INJURY AND/OR
SEVERE PRODUCT OR PROPERTY DAMAGE IF
NOT SAFELY ADHERED TO AND WITHIN THE
PARAMETERS SET FORTH IN THIS MANUAL.
FAILURE TO FOLLOW THE INSTRUCTIONS
PROVIDED IN THIS MANUAL MAY RESULT IN
DEATH, SERIOUS PERSONAL INJURY, SEVERE
UNIT DAMAGE OR VOIDING OF THE COMPONENT
WARRANTY.
THE “CAUTION” SYMBOL ABOVE IS A SIGN THAT
A SAFETY RISK IS INVOLVED AND MAY CAUSE
PERSONAL INJURY AND/OR PRODUCT OR PROPERTY
DAMAGE IF NOT SAFELY ADHERED TO AND WITHIN
THE PARAMETERS SET FORTH IN THIS MANUAL
ALWAYS WEAR EYE PROTECTION WHEN
PERFORMING SERVICE OR MAINTENANCE TO THE
UNIT. OTHER SAFETY EQUIPMENT TO CONSIDER
WOULD BE HEARING PROTECTION, GLOVES AND
POSSIBLY A FULL FACE SHIELD, DEPENDING ON
THE NATURE OF THE SERVICE.
MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP
CLEAR AND USE CAUTION.

3
lci1.com 574-537-8900 Rev: 08.14.20
Schwintek
Motorized TV Lift
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002647
Prior to Installation
Read the manual in its entirety and review all components
and understand how the TV Lift is assembled. The Slide
Rack Assembly (A) will fit in the TV Lift Assembly (B) and
the counter material will be fastened to the top. Once
established this will be the approximate location of the
bearing block fastening point. The bearing block needs to
be located high enough to accommodate the counter top
setting flush, but not so low that the TV does not extend all
the way up.
NOTE: The maximun weight capacity for the installed
Motorized TV Lift is 75 lbs.
NOTE: Cabinet modification is at the customer’s discretion.
Installing an aesthetic piece on top of the cabinet top
transition piece (A) is also at the customer’s discretion.
Parts List
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
LetterLetter PNPN DescriptionDescription QtyQty
A 260992 Cabinet Top Transition Piece 1
B 252208 TV Lift Assembly 1
C 253395 TV Lift Controller 1
D 245701 Radio Frequency Remote 1
E 199082 TV Lift Switch 1
F 193925 9” x 9” TV Plate 1
Resources Required
• Cordless or electric drill or
screw gun
• Appropriate drill bits
• Appropriate drive bits
• #10 Phillips pan
head screws
• Phillips screwdriver
• ¼” Spade-type
electrical connectors
A B
C D
E F
Installation
1. Make sure the unit is level.
2. Locate the four pre-drilled holes in the bearing block
(Fig.1A). Using #10 screws, mount the bearing block with
motor (Fig.1B) to solid backer, centered within cabinet.
Fig.1
A A
A A
B
C

4
lci1.com 574-537-8900 Rev: 08.14.20
Schwintek
Motorized TV Lift
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002647
5. Mount the TV assembly to the rack (Fig.3C) using
customer supplied hardware into the pre-drilled holes in
the rack.
NOTE: The amount of hardware used and the placement
of screws in the pre-drilled holes in the TV plate and rack
will vary depending on the model of TV. Flip the TV plate
(Fig.3A) horizontal or vertical to accommodate installation
to the TV. Make sure the TV is secure to the TV plate and
the TV assembly is secure to the rack. The top of the TV
(Fig.3B) should not exceed the top of the rack (Fig.3C).
3. Mount TV lift controller (Fig.2) close to end of motor wire
harness (Fig.1C) using two #10 screws in the pre-drilled
locations (Fig.2B).
Fig.2
A. Plug motor control wires (Fig.1C) into TV lift
controller (Fig.2A).
B. Attach the power, ground and switch wires with ¼”
spade type connectors (Fig.2C). See the Wiring Diagram
section for proper wiring.
NOTE: The wire harness-to-battery and switch are
customer-supplied items. Harness wires must be 10
AWG minimum. Also, 30 amp circuit protection should be
installed on the power lead wire between the battery and
the controller. See the Wiring Diagram section.
4. Mount included TV plate (Fig.3A) to the back of the TV
(Fig.3B) using customer-supplied hardware.
A
B B
C
Fig.3
A
B
C

5
lci1.com 574-537-8900 Rev: 08.14.20
Schwintek
Motorized TV Lift
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002647
B. Press the switch’s RETRACT button (Fig.5B) until the
rack is fully inserted into the bearing block.
Fig.5
Fig.4
7. Mount the cabinet top transition piece onto
the rack.
A. Place the block (Fig.6A) of the transition piece (Fig.6B)
into the grooves of the assembled rack (Fig.6C).
Fig.7
B. Locate the two holes at the top of the assembled rack
(Fig.7A). Use two self tapping screws to secure the block
to the rack.
A
B
A
B
C
back view
of rack
A
C
6. Insert the assembled rack (Fig.4A) into the bearing block
(Fig.4E) by aligning the V-grooves (Fig.4B) in the rack to the
V-rollers (Fig.4D) in the bearing block (Fig.4E).
A. Insert the assembled rack (Fig.4A) until the gear in the
bearing block comes into contact with the serpentine
groove of the rack (Fig.4C).
Fig.6
A
E
B
D
back view
of rack

6
lci1.com 574-537-8900 Rev: 08.14.20
Schwintek
Motorized TV Lift
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002647
Setting the Extend and Retract Limits
1. To set the lower electronic stop, press and hold the
switch’s RETRACT button (Fig.10B) to lower the TV
into the desired position, then press the control’s white
Conguration button once (Fig.8A).
2. To set the raised electronic stop, press and hold
the switch’s EXTEND button (Fig.10A) to raise the TV
into the desired position, then press the control’s white
Conguration button once.
3. Test the receiver’s programming by lowering and raising
(retracting and extending) the TV.
Sync Remote, if Included
1. Locate white Conguration button (Fig.8A).
2. Press the button two times and hold on the third time.
3. The green LED (Fig.8B) and the red LED (Fig.6C) will
alternately ash.
4. Hit any button on the remote (Fig.7).
5. The green LED (Fig.6B) and the red LED (Fig.6C) will ash
at the same time, then stop.
6. The remote is now synced.
Operation
1. To raise the TV, press and release the switch’s UP
button on the remote (Fig.9A) or press and release the
EXTEND button on the switch (Fig.10A) until the TV lift is
fully raised into position.
2. To lower the TV, press and hold the switch’s DOWN
button on the remote (Fig.9B) or press and hold the
RETRACT button on the switch (Fig.10B) until the TV
is fully lowered into the cabinet.
NOTE: For safety purposes, the switch will need to be held
until lowered to the preset stop limit.
TV and Rack Removal from Lift
To remove the TV and rack out of the lift unit,
do as follows:
1. Press and hold the control’s white CONFIGURATION
button (Fig.8A) for ve seconds.
NOTE: The control’s red LED (Fig.8C) will light up solid and
the green LED (Fig.8B) will flash.
2. Press and hold the switch’s EXTEND button (Fig.10A)
until the rack and TV are fully raised so they can be
removed from the system.
Programming
To enter programming mode, press and hold the white
CONFIGURATION button (Fig.8A), located on the control,
for five seconds. The control’s green LED (Fig.8B) will flash
and its red LED (Fig.8C) will light up solid.
Fig.8 A CB
Fig.9
A
B
A
B
Fig.10

7
lci1.com 574-537-8900 Rev: 08.14.20
Schwintek
Motorized TV Lift
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002647
Wiring Diagram
SwitchSwitch ControllerController Circuit ProtectionCircuit Protection 12V DC Battery12V DC Battery
Top Pin (EXTEND) UP SW
Middle Pin (Power) BATT (+) 30 Amp Positive (Red) Post
Bottom Pin (RETRACT) DOWN SW
BATT (-) Negative (Black) Post
PN 253396
controller
PN 325978
motor
PN 199082
back of
switch
PN 199082
front of
switch
12V DC battery
30 amp
circuit
protection

8
lci1.com 574-537-8900 Rev: 08.14.20
Schwintek
Motorized TV Lift
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0002647
Manual information may be distributed as a complete
document only, unless Lippert Components provides
explicit consent to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lci1.com. Manual information is considered
factual until made obsolete by a revised version.
Please recycle all obsolete materials and contact
Lippert Components with concerns or questions.
Notes
