Lippert FURRION Aurora Veranda Series User manual

1
lippert.com 432-LIPPERT (432-547-7378) Rev. 02.17.23
Furrion Aurora Landscape
Speaker Systems
Add-Ons & Replacement Parts
Installation Manual
(For Aftermarket Applications)
CCD-0007422
Table of Contents
Introduction ............................................ 1
Safety ................................................... 1
Parts List ................................................ 2
Resources Required ................................... 3
Installation Recommendations........................ 3
Wiring Plan ............................................. 4
Installation .............................................. 5
Wiring ................................................... 5
Specications ................................................................ 6
Technical Assistance .................................. 7
Warranty ................................................. 7
Notes .....................................................
Furrion Aurora®
®
Landscape
Speaker Systems
Add-Ons & Replacement Parts
Installation Manual
(For Aftermarket Applications)
FURRION AURORA 4.1 LANDSCAPE SPEAKER KITSFURRION AURORA 4.1 LANDSCAPE SPEAKER KITS
Part #Part # DescriptionDescription
2022323828 Veranda Series
2022323829 Terrace Series
Introduction
Thank you for your purchase of the Veranda or Terrace
HiFi Landscape Speaker System. You have made a great
investment in an outdoor audio system that will provide
many years of enjoyment. The components in this system
are made to withstand the harshest weather conditions.
This system is designed to work well with most any two-
channel receivers or amplifiers, and will support up to eight
(8) satellite speakers and two (2) dual VC subwoofers.
Four satellite speakers and one subwoofer are included
with this system. Each system can be expanded by adding
two additional pairs of satellite speakers; to the Veranda
(#2022323831) or the Terrace (#2022323830) systems.
Use only FURRION brand speakers to connect to
these systems. No other brand of speaker will have the
correct impedance and could easily damage your audio
equipment.
Additional information about this product can be obtained
from lci1.com/support or by using the LippertNOW app.
Replacement kits can be ordered from https://store.lci1.
com/ or by using the LippertNOW app.
The LippertNOW app is available for free on Apple App
Store®for iPhone®and iPad®and also on Google Play™for
Android™users.
App Store®and iPad®are registered trademarks of Apple
Inc.
Google Play™and Android™are trademarks of Google Inc.
Safety
Read and fully understand all instructions before installing
or operating this product.
Adhere to all safety labels.
INSTALLATION OF THIS SYSTEM MAY REQUIRE
DIGGING OR TRENCHING. FURRION RECOMMENDS
CALLING 811 OR CONTACT THE DIG AGENCY IN
YOUR AREA PRIOR TO INSTALLATION.
CONTACTING OR RUPTURING POWER, GAS OR
WATER LINES COULD RESULT IN PROPERTY
DAMAGE, PERSONAL INJURY OR DEATH.

2
lippert.com 432-LIPPERT (432-547-7378) Rev. 02.17.23
Furrion Aurora®Landscape
Speaker Systems
Add-Ons & Replacement Parts
Installation Manual
(For Aftermarket Applications)
CCD-0007422
PNPN DescriptionDescription
A 2022323837 Subwoofer
B 2022323831 Satellite Speaker (2)
C 2022323839 Surface Mount Bracket
D 2022323843 Ground Stake (4)
E 2022323842 Ground Stake - Bulk Pack (40)
Optional Veranda Series
Add-ons & Accessories
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
PNPN DescriptionDescription
A 2022323834 Subwoofer
B 2022323830 Satellite Speaker (2)
C 2022323839 Surface Mount Bracket
D 2022323843 Ground Stake (4)
E 2022323842 Ground Stake - Bulk Pack (40)
Optional Terrace Series
Add-ons & Accessories
A
C
D & E
C
D & E
B
A
B

3
lippert.com 432-LIPPERT (432-547-7378) Rev. 02.17.23
Furrion Aurora®Landscape
Speaker Systems
Add-Ons & Replacement Parts
Installation Manual
(For Aftermarket Applications)
CCD-0007422
Installation Recommendations
Resources Required
• Burial Grade Wire
• Wire cutters
• Shovel or
• Trenching Tool
The satellite speakers & subwoofer should be placed
so the sound will be distributed evenly throughout your
landscape area. For best results, plan the exact locations
of each speaker along with the direct burial wire prior to
digging the trench.
NOTE: FURRION recommends that the satellite speakers
be placed 6–8 feet apart, and no more than 10 feet for
the best listening experience. An example of a landscape
audio layout is shown below.
NOTE: The ideal position for the subwoofer is in the center
of the satellite speaker arrangement; bass response is
enhanced if placed next to a wall or solid surface.
Speaker Wire RecommendationSpeaker Wire Recommendation
Always use multi-strand two or four conductor directAlways use multi-strand two or four conductor direct
burial wire designed for speaker connections to theburial wire designed for speaker connections to the
receiver or amplifier.receiver or amplifier.
Use this chart to select the minimum wire gauge for theUse this chart to select the minimum wire gauge for the
length of the run.length of the run.
Maximum Wire Length (ft)Maximum Wire Length (ft) Recommended GaugeRecommended Gauge
100 18
150 16
250 14
400 12
Example of a Landscape Layout

4
lippert.com 432-LIPPERT (432-547-7378) Rev. 02.17.23
Furrion Aurora®Landscape
Speaker Systems
Add-Ons & Replacement Parts
Installation Manual
(For Aftermarket Applications)
CCD-0007422
Wiring Plan
The satellite speakers and subwoofer should be connected in two parallel wire runs and possibly be buried in a single
trench. The Furrion Aurora Landscape Speakers Systems are designed for speakers to be evenly divided between two
wire runs with the subwoofer connected to both right and left. Below is a recommended connection.
NOTE: The The Furrion Aurora Landscape expansion speakers are specifically designed for these systems. Do not add
any other brand of speakers to the system. Any other brand will have the wrong impedance and could damage your AVR
or Amplifier.

5
lippert.com 432-LIPPERT (432-547-7378) Rev. 02.17.23
Furrion Aurora®Landscape
Speaker Systems
Add-Ons & Replacement Parts
Installation Manual
(For Aftermarket Applications)
CCD-0007422
Installation
Position the satellite speakers and subwoofer in your
selected location. Adjust them where they would appear to
deliver the best sound coverage.
INSTALLATION OF THIS SYSTEM MAY REQUIRE
DIGGING OR TRENCHING. FURRION RECOMMENDS
CALLING 811 OR CONTACT THE DIG AGENCY IN
YOUR AREA PRIOR TO INSTALLATION.
CONTACTING OR RUPTURING POWER, GAS OR
WATER LINES COULD RESULT IN PROPERTY
DAMAGE, PERSONAL INJURY OR DEATH.
Multi-Mount Subwoofer – there are multiple ways to
position and mount this model. It can simply sit on the
deck or patio, set on the ground using the ground stake or
positioned in the ground, as shown below.
Accessories Provided
• Ground Stake
• Mounting Brackets
• Adjustable Leveling Feet
NOTE: If the Subwoofer is mounted in-ground, it is a good
idea to add 1”– 2” of gravel at the bottom of the hole to
facilitate drainage around the base of the unit. If you add a
layer of gravel, dig the hole 1”– 2” deeper to accommodate
it. See the Subwoofer In-ground Depth Chart for
Wiring
FURRION recommends that you use only multi-strand
direct burial wire. The gauge of the wire will depend on the
length of the run (see page 3).
The subwoofer comes pre-wired with the industry standard
(Right Positive (+) White, Right Negative (-) Green, Left
Positive (+) Red, Left Negative (-) Black (see page 3).
It is very important that the same wire attached to the
positive connector of the receiver or amplifier be attached
to the positive connector of the speakers.
DO NOT connect your receiver or amplifier to an AC power
outlet until all of the speakers are connected.
DO NOT allow any stray (+) and (–) wire strands to come in
contact with each other. This could damage your receiver
or amplifier.
Bundle all three of the right channel Positive (+) wires from
the first speaker, and wire the remaining speakers together
as noted above. Then, do the same for the left channel
negative wires. Run the wires to the next speaker and
connect them the same way.
Subwoofer In-ground Option Depth Chart

6
lippert.com 432-LIPPERT (432-547-7378) Rev. 02.17.23
Furrion Aurora®Landscape
Speaker Systems
Add-Ons & Replacement Parts
Installation Manual
(For Aftermarket Applications)
CCD-0007422
SUBWOOFERSUBWOOFER
• 10” (254mm) Dual VC Long Throw Driver
• PP Waterproof Cone with Rubber Surround
• Magnet Structure: 80 oz. (2 x 40)
• 
• Frequency Response: 35 – 150Hz ± 3 dB
• SPL: 90 dB @ 1w/1m
• Material: HDPE-ASA
• Dimensions: 16” dia. X 26.8” H (405 x 680 mm)
• Weight: 31 lbs. (14.06kg)
• Mounting Accessories Included
SATELLITE SPEAKERSATELLITE SPEAKER
• 4” (101.6mm) PP Waterproof Cone with Rubber Surround
• Tweeter: 0.75” (19.05mm) Marine Grade PEI Tweeter
• Frequency Response: 80Hz–20kHz + 3dB
• SPL: 87 dB @ 1w/1m
• 
• Made with acrylonitrile styrene acrylate (ASA). Made to
withstand the harshest weather conditions
Specifications - Veranda
SUBWOOFER
• 8” (203mm) Dual VC Long Throw Driver
• PP Waterproof Cone with Rubber Surround
• Magnet Structure: 37 oz.

• Frequency Response: 45 – 150Hz ± 3 dB
• SPL: 89 dB @ 1w/1m
• Material: HDPE-ASA
• Dimensions: 14” dia. X 24”H (355.6 x 609.6 mm)
• Weight: 20 lbs. (9.07 kg)
• Mounting Accessories Included
SATELLITE SPEAKER
• 3” (76.2mm) PP Waterproof Cone with Rubber Surround
• Tweeter: 0.50” (12.7mm) Marine Grade PEI Tweeter
• Frequency Response: 100Hz–20kHz + 3dB
• SPL: 86 dB @ 1w/1m

• Made with acrylonitrile styrene acrylate (ASA). Made to
withstand the harshest weather conditions
• Fluorocarbon Textured Finish
• ½” NPT Connector
• 150°Pivoting Arm Assembly
• Comes with 11” Ground Stake
• Dimensions (D x L x H): 5” × 6.4” × 8” (without stake)
127 x 162.6 × 203.2 mm
• Weight: 2 lbs. (0.998 kg)
Specifications - Terrace
• Fluorocarbon Textured Finish
• ½” NPT Connector
• 150°Pivoting Arm Assembly
• Comes with 11” Ground Stake
• Dimensions (D x L x H): 6” × 7.5” × 8.9”6” × 7.5” × 8.9” (without stake)
152.4 × 190.5 × 226.6mm
• Weight: 2.7 lbs. (1.22kg)

7
lippert.com 432-LIPPERT (432-547-7378) Rev. 02.17.23
Furrion Aurora®Landscape
Speaker Systems
Add-Ons & Replacement Parts
Installation Manual
(For Aftermarket Applications)
CCD-0007422lippert.com 432-LIPPERT (432-547-7378) Rev. 02.17.23
Furrion Aurora®Landscape
Speaker Systems
Add-Ons & Replacement Parts
Installation Manual
(For Aftermarket Applications)
CCD-0007422
Warranty
Limited Three-Year Warranty
Limited Warranties & Liability
FURRION warrants that its speaker systems, speakers
& accessories are free from defects in materials and
workmanship for a period of three (3) years when
purchased from a Authorized FURRION Dealer.
At FURRION’s exclusive discretion, replace or repair of
a authorized returned item(s) found to be defective upon
inspection within the warranty period, shall constitute
fulfillment of all FURRION’s obligations under its warranty.
This warranty does not apply to amplifiers or other
equipment not manufactured by FURRION. These items
are covered as stated in their respective manufacturer’s
warranty. The warranty period commences on the date of
purchase. All conditions of installation and operation must
have been complied with, or all applicable warranty is void.
FURRION assumes no responsibility for the improper
installation of its products or labor cost involved in repairs
or replacements.
No other warranty or guarantees, either expressed or
implied, exist beyond the stated warranty herein.
No employee or agent of FURRION may extend, modify
and/or change the terms of this warranty.
Under no condition will FURRION be liable for any
incidental, consequential, special or money damage in
connection with any breach of its aforementioned warranty.
Merchandise Returns
No speakers or accessories may be returned by a
customer without a prior written authorization in the form
of a Return Goods Authorization (RGA) which has been
issued by FURRION. RGAs will be issued art the sole
discretion of FURRION and must be requested within sixty
(60) days of shipment. All merchandise returned must be
in its original carton and shipped to FURRION prepaid.
Technical Assistance
If you have any trouble with the installation or have any
technical questions, please call us at 432-LIPPERT
(432-547-7378) or email us at:[e-mail].
Additional Speaker Pairs
You can safely add two additional pairs (four extra
speakers) of our Satellite Speakers to the system.
The pair is known as the Furrion Aurora Landscape
Speakers (2-Pack). For the Veranda Series, please use
part number 2022323831 and for the Terrace Series,
part number 2022323830. These optional add-ons can
be purchased from any FURRION Dealer.
NOTE: Do not add any other brand of speakers to the
system. The Furrion Aurora Landscape Speakers are
specifically designed for these systems. Any other brand
will have the wrong impedance and could damage your
AVR or Amplifier.

8
Notes
lippert.com 432-LIPPERT (432-547-7378) Rev. 02.17.23
Furrion Aurora®Landscape
Speaker Systems
Add-Ons & Replacement Parts
Installation Manual
(For Aftermarket Applications)
CCD-0007422
Manual information may be distributed as a complete
document only, unless Lippert provides explicit consent
to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lippert.com. Manual information is
considered factual until made obsolete by a revised
version.
Please recycle all obsolete materials and contact
Lippert with concerns or questions.
