Lippert Tire Linc 2020114605 Installation instructions
1
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Table of Contents
Introduction ............................................ 1
Safety ................................................... 2
Parts List ................................................ 2
Installation .............................................. 3
Message To Power O Displays ....................... 3
Pairing, Conguration ................................. 3
Place Repeater Into Pair Mode ........................ 3
Sensor Pairing ......................................... 3
Sensor Pairing Sequence ............................. 5
Learn All Sensors ...................................... 7
Congure All Thresholds .............................. 8
Learn A Sensor ........................................ 8
Detach vehicles ...................................... 10
Reattach vehicles .................................... 11
Delete A Vehicle ..................................... 12
Add Another Vehicle ................................. 12
Replace Sensor ...................................... 14
Display ............................................... 15
Operation ............................................. 15
Tire Limits Example .................................. 17
Changing Units of Measure .......................... 17
Troubleshooting ...................................... 17
Relearn Sensors After Tire Rotation ................. 17
Internal Sensors ..................................... 17
Wrong Vehicle Chosen .............................. 17
Missing Stem Sensor ................................ 18
No Power ............................................ 18
Reset LCD Handheld Display ........................ 18
Notes .................................................. 19
Tire Linc™
LCD Display
Installation and
Owner’s Manual
(For Aftermarket Applications)
Tire Linc LCD Display Aftermarket KitTire Linc LCD Display Aftermarket Kit
Part #Part # DescriptionDescription
2020114605 Tire pressure, temperature monitoring system
Introduction
Tire Linc®is a tire pressure and temperature monitoring
system (TPMS). The TPMS display issues an alert
when a unit's pressure or temperature falls out of the
programmable range.
The system is operated by a handheld display, and a power
cord and stand are included with the kit.
NOTE: If utilizing the LCD handheld display with the
repeater, then neither the OneControl app nor the Tire Linc
Alert Indicator can be used with the repeater.
Additional information about this product can be obtained
from lci1.com/support or by using the LippertNOW app.
The LippertNOW app is available for free on Apple App
Store® for iPhone®and iPad®and also on Google Play™ for
Android™users.
App Store®and iPad® are registered trademarks of
Apple Inc.
Google Play™and Android™ are trademarks of Google Inc.
2
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Safety
Read and fully understand all instructions before installing
or operating this product.
Adhere to all safety labels. This manual provides general
instructions. Many variables can change the circumstances
of the instructions, e.g., the degree of difficulty, operation
and ability of the individual performing the instructions.
This manual cannot begin to plot out instructions for
every possibility, but provides the general instructions,
as necessary, for effectively interfacing with the device,
product or system. Failure to correctly follow the provided
instructions may result in death, serious personal injury,
severe product and/or property damage, including voiding
of the LCI limited warranty.
Parts List
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
THE "WARNING" SYMBOL ABOVE IS A SIGN THAT A
PROCEDURE HAS A SAFETY RISK INVOLVED AND
MAY CAUSE DEATH, SERIOUS PERSONAL INJURY,
SEVERE PRODUCT AND/OR PROPERTY DAMAGE
IF NOT PERFORMED SAFELY AND WITHIN THE
PARAMETERS SET FORTH IN THIS MANUAL.
A
B
C
FAILURE TO FOLLOW INSTRUCTIONS PROVIDED
IN THIS MANUAL MAY RESULT IN DEATH, SERIOUS
PERSONAL INJURY AND/OR SEVERE PRODUCT AND
PROPERTY DAMAGE, INCLUDING VOIDING OF THE
COMPONENT WARRANTY.
THE "CAUTION" SYMBOL ABOVE IS A SIGN THAT
AN INSTALLATION PROCEDURE HAS A SAFETY
RISK INVOLVED AND MAY CAUSE PERSONAL
INJURY AND/OR PRODUCT OR PROPERTY DAMAGE
IF NOT PERFORMED SAFELY AND WITHIN THE
PARAMETERS SET FORTH IN THIS MANUAL.
MOVING PARTS CAN PINCH, CRUSH OR CUT. KEEP
CLEAR AND USE CAUTION.
Kit PN 2020114605
Letter PN Description Qty
A 2020222360 LCD handheld display stand 1
B 2020222357 LCD handheld display 1
C 2020222358 LCD display power cord 1
3
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Installation
To install the LCD handheld display stand:
1. Make sure to have a clean, level, nonporous surface for
the stand's suction base to adhere to.
2. Lift the locking lever located at the bass of the
mounting arm.
3. Set the stand's suction base over the clean area
then press down on the locking lever to mount the LCD
handheld display stand in-place.
If desired, the LCD handheld display can be mounted to
the display stand by pressing the mounting pocket on the
back of the handheld display onto the mounting bulb of
the stand.
Message To Power Off Displays
Whenever a user accesses one of two modes in the
Settings menu — Learn All Sensors or Learn A Sensor
— a screen will appear on the display for five seconds
(Fig.1) before automatically transitioning to the notifications
received before sensor learning takes place. This screen will
also appear after the user selects whether a spare tire is to
be added or not.
Pairing, Configuration
NOTE: Pair Mode is usually not necessary for the display
to pair to the repeater. Pair Mode is needed only when
attempting to pair the display to the repeater and more
than one repeater is located nearby. When the repeater
is in Pair Mode, the BLE (Bluetooth Low Energy) name
TireLinc changes to TireLinc*.
Place Repeater Into Pair Mode
1. If Pair Mode is needed, press and hold the Pair Mode
button on the repeater (Fig.2B) until there is one long
red blink followed by two short red blinks. This takes
approximately ve seconds.
2. Release the button.
A
B
Sensor Pairing
3. Turn on LCD display using On/O button on bottom of
the display (Fig.3).
4. Tap the Scan for New Bluetooth Devices arrow (Fig.4)
and look for the TireLinc listing.
NOTE: If the repeater is in Pair Mode, look for TireLinc*.
5. Select the rst listing (Fig.5) and tap CONTINUE.
Fig.1
Fig.2
4
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
micro USB port
for charging
On/Off
button sync button
reset
6. Tap SETUP COACH (Fig.6).
7. Select a vehicle class (Fig.7) and tap CONTINUE.
Fig.3
Fig.4
Fig.5
Fig.6
Fig.7
5
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
8. Select the type of vehicle to be set up by choosing
one of the pictures shown on the display (Fig.8) and
tap CONTINUE.
Fig.8
9. Determine if a spare tire will be added (Fig.9). Tapping
YES will add the spare tire icon to the vehicle selected.
Fig.9
10. After tapping YES or NO for a spare tire, the
display will automatically change to the LEARN ALL
SENSORS mode.
Sensor Pairing Sequence
The pairing sequence for tires begins with the left front
tire (Fig.11-1) first, continuing from front to rear and then
beginning again at the right front (Fig.11-5) and continuing to
the rear tires (Fig.11-4 and 8). The spare tire (Fig.11-9) is last.
With dual wheels on a vehicle, the outside tire
(Fig.11-2 and 6) on either side is paired first before the inside
tire (Fig.11-3 and 7).
Figure 11 provides an example of the pairing sequence for
tires on any vehicle.
11. A notification will appear on the display for 5
seconds (Fig.10) instructing you to turn off all other
displays connected to your repeater before automatically
transitioning to the notifications received before sensor
learning takes place.
Fig.10
12. Notications will instruct how to learn internal and
external sensors.
13. Continue to the Learn All Sensors section and use the
steps for learning sensors.
7
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Learn All Sensors
1. Before accessing the SETTINGS menu, check to make
sure the vehicle on which a sensor is to be learned is
present on the main tire pressure screen.
2. Tap the arrow to the right of Learn A Sensor (Fig.12A)
3. After entering the LEARN ALL SENSORS mode, hold
the LCD display close to the sidewall in the area opposite
the valve stem of the tire to be paired (Fig.13).
4. Press and hold the sync button on the LCD display
(Fig.3) to pair the sensor until the display beeps and the red
ashing circle turns green.
5. If you are using external stem sensors:
A. Screw the sensor onto the valve stem until
securely fastened.
B. Watch the display until the flashing circle turns green.
NOTE: This may take up to 90 seconds.
C. If the sensor does not show as learned within 90
seconds, unscrew the sensor for 10 seconds then screw it
back onto the valve stem to reattempt learning the sensor.
6. The display will feature a red dot (Fig.14A) representing
the tire that is being paired, which will then turn green
when it is successfully paired (Fig.15A).
A
Fig.12
Fig.13
A
Fig.15
A
Fig.14
8
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Configure All Thresholds
1. Before accessing the SETTINGS menu, check to make
sure the vehicle selected to have thresholds congured is
present on the main tire pressure screen.
2. Select the Congure All Thresholds arrow on the
SETTINGS screen (Fig.17A).
A
Fig.17
Fig.18
Fig.16
7. When pairing has been completed, the display will ask
if another vehicle is to be added to the system (Fig.16). If
tapping YES, pair the additional sensors in the proper
sequence. If not, continue to Congure All Thresholds.
NOTE: There are limits of three vehicles and 20 tires.
3. Set the Minimum Pressure, Maximum Pressure,
Maximum Temperature and Maximum Temp Change for
the sensors (Fig.18). After each selection, tap FINISH.
Learn A Sensor
1. Before accessing the SETTINGS menu, check to make
sure the vehicle on which a sensor is to be learned is
present on the main tire pressure screen.
2. Tap the arrow to the right of Learn A Sensor (Fig.19A).
A
Fig.19
9
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
3. A notification will appear on the display for 5 seconds
(Fig.20) instructing you to turn off all other displays
connected to your repeater before automatically
transitioning to the notifications received before sensor
learning takes place.
A
A
Fig.20
Fig.21
Fig.22
4. The vehicle will at rst appear without a red blinking dot.
Select the tire with a sensor to be learned (Fig.21A) and
observe a red blinking dot on that tire (Fig.22A).
NOTE: The procedure for learning a sensor is the same as
relearning sensors.
5. Hold the LCD display close to the sidewall in the area
opposite the valve stem of the tire to be paired (Fig.23).
6. Press and hold the sync button on the LCD display
(Fig.3) to pair the sensor until the display beeps and the red
ashing circle turns green.
Fig.23
7. If you are using external stem sensors:
A. Screw the sensor onto the valve stem until
securely fastened.
B. Watch the display until the flashing circle turns green.
NOTE: This may take up to 90 seconds.
C. If the sensor does not show as learned within 90
seconds, unscrew the sensor for 10 seconds then screw it
back onto the valve stem to reattempt learning the sensor.
8. The display will feature a red dot representing the tire
that is being paired, which will then turn green when it is
successfully paired.
10
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Detach vehicles
1. Scroll down the SETTINGS screen and tap the arrow to
the right of Detach Vehicles (Fig.24A).
2. Select which vehicle to detach (Fig.25).
3. Conrm which vehicle to detach and tap
CONTINUE (Fig.26).
4. Select another vehicle to detach or tap FINISH (Fig.27)
to return to the main tire pressure screen.
NOTE: The red X on a vehicle indicates the vehicle is
detached (Fig.27).
NOTE: The display will not detach a vehicle if it is the only
vehicle in the configuration.
A
Fig.24
Fig.25
Fig.26
Fig.27
11
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Reattach vehicles
1. Scroll down the SETTINGS screen and tap arrow to
right of Re-Attach Vehicles (Fig.28A).
2. Select which vehicle to reattach (Fig.29).
NOTE: The red X on a vehicle indicates the vehicle is
detached (Fig.29).
3. Conrm which vehicle to reattach and tap
CONTINUE (Fig.30).
4. Select another vehicle to reattach (Fig.31) or tap FINISH
to return to the main tire pressure screen.
A
Fig.28
Fig.29
Fig.30
Fig.31
12
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Delete A Vehicle
1. Tap the Delete A Vehicle entry in the SETTINGS screen
(Fig.32A).
2. Select a vehicle to delete (Fig.33) and tap NEXT.
3. Conrm which vehicle to delete (Fig.34) and tap DELETE.
4. Select another vehicle to delete or tap FINISH (Fig.35) to
return to the main tire pressure screen.
NOTE: The display will not delete a vehicle if it is the only
vehicle in the configuration.
A
Fig.32
Fig.33
Fig.34
Fig.35
Add Another Vehicle
1. Select Add Another Vehicle on the SETTINGS screen
(Fig.36A).
2. Select a class of vehicle (Fig.37) and the type of vehicle
to be set up by choosing one of the pictures shown on the
display (Fig.38).
3. Determine if a spare tire will be added. Tapping YES
(Fig.39) will add the spare tire icon to the vehicle selected.
13
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
4. A notification will appear on the display for 5 seconds
(Fig.40) instructing you to turn off all other displays
connected to your repeater before automatically
transitioning to the notifications received before sensor
learning takes place.
A
Fig.36
Fig.37
Fig.38
Fig.39
Fig.40
5. Notications will instruct how to learn internal and
external sensors.
6. Continue to the Learn All Sensors section.
14
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Replace Sensor
1. Tap a tire location (Fig.41) to launch its properties window
with sensor details (Fig.42).
2. Tap arrow to the right of Replace Sensor (Fig.42A).
3. Tap CONTINUE for all notications.
4. The vehicle will appear on the screen with a red blinking
dot next to the sensor chosen to relearn.
5. Follow the instructions for the variant of the sensor being
learned in the RELEARN SENSOR screen (Fig.43).
A
Fig.41
Fig.42
Fig.43
15
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Display
1. Scroll down the SETTINGS screen and tap the arrow to
the right of Display (Fig.44A).
2. Select preferred entries on the DISPLAY screen,
including whether the system will always be on or will go to
sleep and if U.S. or metric terms are used (Fig.45).
3. Tap the back arrow (Fig.45A) to return to the
SETTINGS screen.
A
A
Operation
When Sensors are under pressure, data is transmitted to
the repeater when tires are:
• moving/rotating, every one minute;
• not moving/not rotating, every 15 minutes.
1. Tap a tire location (Fig.46) to launch its properties window
(Figs.47 and 48). Within the selected tire’s properties window,
various tire and sensor specications can be observed
and altered.
A. Pressure — posts the currently-sensed pressure of
the selected tire.
B. Temperature — posts the currently-sensed
temperature of the selected tire.
C. Battery Level — posts the current battery voltage of
the sensor’s battery.
Fig.44
Fig.45
Fig.46
16
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
NOTE: The individual tire thresholds listed below can only
be accessed by entering the SETTINGS menu while in the
individual tire menu.
D. Minimum/Maximum Pressure — posts the currently-
programmed minimum and maximum pressure limit for
the selected tire.
E. Maximum Temperature — posts the currently-
programmed maximum temperature limit for the selected
tire.
F. Maximum Temp Change — posts the currently-
programmed maximum +/- temperature change limit for
the selected tire.
2. When a fault is active, the display will beep and the text
box that displays the temperature and pressure for the tire
experiencing the fault will turn red (Fig.49).
NOTE: The text for the spare tire with a fault will not turn
red — only the spare tire icon will turn red (Fig.49).
TIRES THAT HAVE HIGH OR LOW AIR PRESSURE
CAN CAUSE UNFORESEEN DETRIMENTAL EFFECTS
ON TIRES AND THE UNIT, INCLUDING UNDESIRABLE
TREAD WEAR. TIRES SHOULD ALWAYS BE
PRESSURIZED TO WITHIN THE
MANUFACTURER'S RECOMMENDATIONS.
Fig.47
Fig.48
Fig.49
17
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Changing Units of Measure
To change the units of measure—to/from Imperial/Metric—
go to the SETTINGS screen:
1. Tap the Display button's next arrow (Fig.44A).
2. From the DISPLAY screen (Fig.45), select the desired
unit of measure; US or Metric.
NOTE: Displayed units of measure will change to match
the newly selected units.
3. Tap the back arrow above the screen title (Fig.45A) to
return to the SETTINGS screen.
Tire Limits Example
When a specic tire information button is tapped, the tire's
programmable settings become available. Find the desired
setting, select it, then tap the “back” arrow (<) located
above the tire’s setting name.
The following example illustrates the interaction between
the various tire settings and how the resulting information is
relayed by the monitoring system for display.
1. Select a tire by tapping its information button to launch
its settings window.
A. In this example, the reported current TIRE PRESSURE
is listed as 16 psi (11 kPa).
NOTE: Stem Sensor Pressure Reading Tolerance: +/-1.5
psi (+/-10.3 kPa). For example—because of dierences in
accuracy and conversion between a Stem Sensor and a
tire gauge—actual tire pressure at 38 psi (262 kPa) may be
reported by the Stem Sensor as 36 psi (248.2 kPa) while
the tire gauge may report 40 psi (275.8 kPa).
B. Compare the tire’s low/high pressure range against
the reported tire pressure (16 psi). Always make sure tire
pressures are within recommended limits.
2. If the Maximum Pressure requires adjusting, tap the next
arrow to launch its settings window (Fig.49). Scroll through
the window until the current setting is found, then scroll to
a new limit and select it.
3. If the Minimum Pressure requires adjusting, tap the next
arrow to launch its settings window (Fig.49). Scroll through
the window until the current setting is found, then scroll to
a desired limit and select it.
NOTE: The Maximum Temperature and the Maximum
Temp Change (Fig.49) can also be adjusted in
similar fashion.
NOTE: Stem Sensor Temperature Reading Tolerance:
+/-5.4 °F (+/-3 °C). For example, if a Stem Sensor reports
tire temperature at 85 °F (29 °C), actual tire temperature
may be 90.4–79.6 °F (32–26 °C).
NOTE: Stem Sensor Working Range: 185 to -4 °F
(85 to -20 °C).
Troubleshooting
Relearn Sensors After Tire Rotation
If a tire rotation is performed on the vehicle, the user
can relearn the sensors by utilizing the Learn All
Sensors mode.
Internal Sensors
When the battery voltage begins to approach 1.9V on a
tire sensor, it is time to schedule a service appointment
to replace the sensor for that tire. If the battery is dead,
the sensor assembly must be replaced. The battery life is
estimated to be three years.
NOTE: Use of tire sealant will cause damage to the internal
sensor and may impact sensor readings.
Wrong Vehicle Chosen
In the event a wrong vehicle type is chosen, delete the
incorrect vehicle from the Delete A Vehicle option in the
SETTINGS menu. See Delete A Vehicle section. Choose
Add Another Vehicle to add a corrected vehicle. See Add A
Vehicle section.
18
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Missing Stem Sensor
If a stem sensor becomes detached from the valve stem,
or an issue has occurred to where the repeater does not
receive data from a sensor for an extended period of
time, the repeater will flag the sensor as missing and the
tire’s readout button will display a “loss of communication”
symbol (Fig.50A).
Reattach the sensor, remove any metal obstructions
directly in front of the repeater or replace the sensor with a
new one to resolve the issue.
reset
No Power
If system is not working, check the in-line fuse to the
repeater dock to ensure the dock has power.
Reset LCD Handheld Display
1. Bend the end of a paper clip or use a similar tool that will
t into the reset hole in the LCD display (Fig.51).
2. Insert the tool then press and hold for two seconds to
reset the display.
A
Fig.50
Fig.51
20
lippert.com 432-LIPPERT (432-547-7378) Rev: 01.28.22
Tire Linc™LCD Display
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004222
Manual information may be distributed as a complete
document only, unless Lippert provides explicit consent
to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lippert.com. Manual information is
considered factual until made obsolete by a revised
version.
Please recycle all obsolete materials and contact
Lippert with concerns or questions.
Notes
Table of contents
Other Lippert Monitor manuals
