Wireless Bluetooth Switch
(BCS03)
Installation Instructions
Page 1/47/28/23 - V1.1
WHAT COMES IN THE BOX
Switch
Holder for existing switch
Holder for wall switch
Wall Plate
Screws (2)
Installation Instructions
TOOLS NEEDED
Phillips and flathead screwdriver
Power drill
REQUIRED
Two CR2032 batteries
(not included)
ATTENTION
1. Please check if there is any damage during shipping.
If so, please contact Litetronics customer service.
2. Please read the installation instruction carefully to
check whether all the accessories are included.
3. After confirmation, install the switch according to
nstallation steps.
Tip: This Bluetooth device is compatible with Litetronics
lighting control system only.
Important: Battery model #CR2032 can be used for 5 years
based on twice a day usage.
Note: Do not use in a metal region or strong,
electromagnetic wave area.
SWITCH FUNCTIONALITY INSTALLATION
1
Sensor ON/OFF:
Work with wired
PIR motion sensor.
2
Dim Up
3
Dim Down
4
ON / OFF 5
Scene Switch:
Three scenes
selected from
App settings.
Switch
Screws
Holder for
existing switch
Holder for
wall switch
Wall plate
Fixtures can be controlled wirelessly through a remote
Bluetooth switch, which can be wall mounted or remotely
located for convenience.
1. Battery installation - Page 2
2. Wall surface installation - Page 2
3. Wireless Bluetooth switch set up - Page 3
Note: Install LiteSmart App before setting the switch.
Page 2/47/28/23 - V1.1
1. Open the back cover of the remote controller
with a flat screw driver.
1. Remove the cover plate carefully
with scissors.
2. Install two CR2032 batteries (sold separately).
3. Attach the cover.
BATTERY INSTALLATION
WALL SURFACE INSTALLATION
2. Mark hole position as required
for installation.
3. Drill two holes with
power drill.
4. Attach the bracket with supplied
self-tapping screws.
5. Slide remote controller into
the bracket.
6. Attach the wall plate.
Cover plate
Wall
holder
Self-tapping screws
Troubleshooting
• When the voltage is less than 2.6V, press any buttons and the red light flashes.
Page 3/47/28/23 - V1.1
DOWNLOAD THE LITESMART APP WIRELESS BLUETOOTH SWITCH SET UP
LITESMART
1. Download the LiteSmart mobile app for iOS or
Android. Scan QR code below.
1. Go to the Switches page and tap +
icon to add a new switch.
5. Choose the new switch by tapping on
the Gear/settings icon.
6. Rename the switch by tapping on the
name. Rename and tap Save.
7. Next, choose the individual lights or group that the switch should be applied to.
Then tap Next Step.
8. Select three scenes to be used via the switch, then tap Save.
9. The fixtures will flash 3 times to confirm the settings have been saved.
10. From the switch, you can now power on/
off, brighten or dim, or select from the
preset Scene.
2. LiteSmart will scan for recognizable
switches.
3. On the switch, press buttons and
(see switch functionality illustration)
together over 2 seconds to enter pairing
mode or activate reset function.
This switch can be rescanned in the
next 30 seconds.
4. Tap Done.
1 2
The information and product specifications contained in these instructions
are based upon data believed to be accurate at the time of printing. This
information is subject to change without notice and without incurring liability.
If you have questions regarding specific product details, please contact us at
800-860-3392 or via email at customerservice@litetronics.com. To check for an
updated version of these instructions, please visit www.litetronics.com.
WWW.LITETRONICS.COM
CustomerService@Litetronics.com or 1-800-860-3392
6969W. 73rd Street
Bedford Park, IL 60638
Thank you for choosing
