Litmor Capsule User manual
INSTALLATION
MANUAL
Please download
the LitmorTM app
by visiting.
Get
ready!
HERE COMES
YOUR NEWEST
FAMILY GUARDIAN.
Welcome to LitmorTM family!
You are about to set up the world's rst A.I. powered camera
oodlight. Please watch the installation videos in the LitmorTM
app rst, then carefully follow the instructions in this manual.
Make sure you read all the tips and cautions before taking action.
Tips： This manual is for informational purposes only. Working with electricity can be
dangerous, hire a licensed electrician is highly recommended.
Litmor
What’s in the box
This bracket screws into your
before attaching to your LitmorTM
Capsule Camera Floodlight.
Tips： Please make sure you have all parts and tools with you before starting the
installation. If any parts are missing, please contact our online customer service.
We don't suggest to use any substitute to do the installation. These instructions
assume you are replacing an existing oodlight and/or have a junction box where
oodlight camera can be mounted. If you don't have a junction box, please read
the step 3/7 "without junction box".
How it all
fits together
Insert TF card
Do you have a TF card with you?
Please make sure you have successfully inserted the card
from the back of the product before starting installation.
Tips： We recommend to use a . LitmorTM Capsule supports up to
128GB TF card. It will store up to 2-month video locally, and all the data is encrypted.
1
2
Open the cover
Insert the card
Anti-theft screw
LitmorTM Capsule
Camera Floodlight
Bracket
screws
Mounting
bracket
Junction box
Wire nuts
Installation
height and angle
We recommend mounting your LitmorTM Capsule
at 8.5 feet o the ground, 30 degrees facing down.
With this conguration, the motion detection
range for activating LitmorTM Capsule's is up to
33 feet (10 meters).
Get
started!
7-steps
installation
Motion
Detection
Area
STEP 2/7
Remove the existing
oodlight
Make sure the breaker is
power o.
Disconnect the wires and
remove your existing oodlight
from the junction box.
If there is a bracket attached to
your junction box, remove that
as well. Check your junction
box to make sure water cannot
get into it. Junction box
Tips: LitmorTM Capsule DO NOTrequire ground wire
connection because its bracket is made of plastic.
STEP 1/7
Shut power off at the breaker
If you do not know where your breaker is or how to turn o power
to your oodlight circuit, hire a .
CAUTION: Risk of re.
DO NOT install near combustible
or ammable.
WARNING: Risk of electrical shock.
Disconnect power at the fuse or circuit breaker.
Verify that the supply voltage is correct.
Connect xture to a 100V ~ 240V AC 50/60Hz
power source.
Ensure proper ground xture.
Always follow code standards when installing
wired connections.
1
2
3
4
STEP 3/7
Install the mounting bracket Without junction box
Install the mounting
bracket following the
engraved direction.
Make sure your
existing wires come
through the middle of
the bracket.
Make sure the ground
wire is securely kept
inside the junction box.
Attach the bracket to your
junction box using at least
two screws, and use the
level to adjust even.
Position the bracket at the
installation spot and mark the
spots with a pen on the wall
where you will screw.
Drill a hole in the wall, then
insert expansion nut.
Carefully push all the wires
through the large opening in
the center of the bracket.
Mount the bracket using at
least two screws and use the
level to adjust even.
1
1
2
2
2
3
3
4
4
4
4
1
2
3
If the installation spot does not have an existing junction box or requests
extra wiring, please hire a licensed electrician and use the following steps
as reference:
3
STEP 4/7
Connect the power wires
Use the built-in hook to hang LitmorTM Capsule
from the bracket while connecting wires. Hook
one end onto the bracket as illustrated.
Use a wire nut to connect the white wire coming
out from your junction box to the white wire on
your LitmorTM Capsule.
Connect the black wire from your junction box
to the black wire on your LitmorTM Capsule with
another wire nut.
Tips：If you don't have clearly colored black and white wires coming out
from your junction box, consult a licensed electrician.
1
3
2
Hang your LitmorTM Capsule
from the bracket
Connect white wires
Connect black wires
1
2
3
STEP 5/7
Place LitmorTM Capsule
on the bracket
Carefully push all the wires
through the large opening in the
bracket.
Hold LitmorTM Capsule with
both hands as illustrated
on the right and align
its bottom with the
mounting bracket.
1
2
55o
Rotate LitmorTM Capsule clockwise to its lock position.
Make sure it's tight connected to the bracket.
3
STEP 6/7
Secure the LitmorTM Capsule
with the anti-theft screw
Secure the LitmorTM Capsule with the .
STEP 7/7
Turn on power at the breaker
After restoring power, the indicator light will turn on in blue.
Easy adjustment
of camera angle
LitmorTM Capsule allows you to adjust camera angle up to + 30
degrees with a simple gesture. Push LitmorTM Capsule against
the wall and rotate.
DO NOT adjust angle before the end of installation.
30o
12
Push Rotate
ALMOST
FINISHED!
Launch the LitmorTM app on your phone or tablet and follow the
in-app instructions to setup your LitmorTM Capsule.
Make sure you connect your phone or tablet to a Wi-Fi network.
Easy
Setup
Multi-cam
Access
Video
Play-back
All-in-one APP
Protect your family
wherever you are.
You are just minutes away
to start a whole new
smart home security experience!
Setup your device
in the LitmorTM app
APP
setup
Connect LitmorTM Capsule
with your phone or tablet
After sign-up, you may start the setup
process. Follow the in-app instructions
to connect LitmorTM Capsule to your
Wi-Fi network.
All set! Watch
live video,
and react.
LitmorTM app provides multi-cam access
and function setting shorcuts on the homepage.
Enter cloud service settings.
Last 12 hours events quick view. Talk to visitors from your
phone or tablet.
Turn on/o 100+ decibel
siren in real time.
Record and save live video
on your phone or tablet.
Take snapshot of live video
and save it.
Check previous notication
using the calendar.
Turn on/o light and adjust
brightness.
Turn on/o smart notication.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference,
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
WARNINGS
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
Note: The Grantee is not responsible for any changes or modications not
expressly approved by the party responsible for compliance. such modi-
cations could void the user's authority to operate the equipment.
The device has been evaluated to meet general RF exposure require-
ment. To maintain compliance with FCC's RF exposure guidelines, the
distance must be at least 20 cm between the radiator and your body, and
fully supported by the operating and installation congurations of the
transmitter and its antenna(s).
If you have any problem
in terms of installation and usage，
Please visit litmor.com/support.
Our service team will be there to help.
Need helps?
