X10 XX17A User manual

1. Refer to the setup and operating instructions that came
with the 2.4 GHz Video Receiver, Model VR31A or
VR36A (sold separately) to set up the Receiver.
2. Mountthecamerainasuitablelocationwiththeantenna
on top so the camera is the right way up. If you install it
outdoors, run the small cable adapter through a hole in
the wall so you can plug the power supply into an AC
outlet indoors.
3. Plug the power supply’s jack into the adapter cable on
the camera.
4. Set the Housecode and Unit Code. (See instructions
included with X10 remote controls).
5. Plug the power supply into any 120V AC outlet.
6. Set the channel switch on the camera to the same setting
as the one on the VR31A or VR36A Video Receiver.
7. Adjust the antenna on the camera if necessary to aim it
in the direction of the VR31A/VR36A Receiver that
you have connected to your TV.
LIMITED1-YEARWARRANTY
X10.com, a division of X10 Wireless Technology, Inc. (X10)
warrants X10 products to be free from defective material and
workmanshipforaperiodofone(1)yearfromtheoriginaldateof
purchase at retail. X10 agrees to repair or replace, at it’s sole
discretion, a defective X10 product if returned to X10 within the
warranty period and with proof of purchase.
If service is required under this warranty:
Call1-800-675-3044orvisitwww.x10.com,ore-mail
[email protected] to obtain a Return Merchandise Authorization
(RMA) number. Please do not return any products without an
RMAnumber.
Pleasevisitwww.x10.com/warranty
tocompleteyouron-linewarrantyregistration.Thankyou.
●Wide Angle lens.
●Built-in 2.4 GHzVideo Sender.
●Can be turned on and off remotely (remote controlled power supply included).
●Use it outdoors to monitor your front door, back yard, etc.
●Use it indoors to monitor a child’s bedroom, etc.
Model XX17A
XX17A-09/01
The XX17A includes the XC19A camera and XM13A remote controlled power supply. The XC19A is a very small and
compactcolorvideocamerawithbuilt-in 2.4 GHztransmitter. Youcanattachit toawallanywhereyouwantto monitor.The
XC19AtransmitsvideoandsoundtotheVR31A,orvideoonlytotheVR36AreceiverwhichisconnectedtoyourTVlocated
anywherein yourhome (up to 100 ft. away). TheXM13A powersupply letsyou turnthe cameraon andoffremotely,from
X10remote controls (soldseparately).
F.C.C.CAUTION-THISDEVICECOMPLIESWITHPART15OF THEFCCRULES.OPERATIONISSUBJECTTOTHEFOLLOWINGTWO
CONDITIONS:(1)THISDEVICEMAYNOTCAUSEHARMFULINTERFERENCE,AND(2)THISDEVICEMUSTACCEPTANYINTERFERENCE
RECEIVED,INCLUDINGINTERFERENCETHATMAYCAUSEUNDESIREDOPERATION.NOTE:NOCHANGESORMODIFICATIONSMAYBE
MADETOTHEUNITS. ANYCHANGESMADETOTHEUNITSWILLVOIDTHEUSER'SAUTHORITYTOOPERATETHEEQUIPMENT.
XCam2 WideEye InstantON Video Camera
™
X10.com, a Div. of X10 Wireless Technology, Inc.
For additional help, visit www.x10.com/support
Point the raised dimple
on the antenna towards
the Receiver’s location.
Plugpower
supplyin
here.
XC19A 2
5
Pluginto
any AC
outlet
Attach
to a wall.
3Cableadapter.
7
Outdoors
Indoors
Set the code used to
turn on and off from
X10 remote controls.
4XM13A
6
Set channel switch
(under rubber plug)
to match setting on
VR31A or VR36A
Receiver. (A is at
bottom, D is at top).
It is factory set to A.
Remove clear cap and turn
lens counterclockwise to
focus (replace cap for
outdoor use).
Point backwards from
direction shown here if
you install the camera
outdoors.
