LIVARNO home 373232-2104 User manual

DECORATIVE SOLAR-POWERED LIGHT
IAN 373232_2104
DEKO-SOLARLEUCHTE
Bedienungs- und Sicherheitshinweise
DECORATIVE
SOLAR-POWERED LIGHT
Operation and safety notes

GB/IE/NI Operation and safety notes Page 5
DE/AT / CH Bedienungs- und Sicherheitshinweise Seite 25

AHG05660A B
C
3
8
45
6
7 1
11
2

AHG05660B B
C
1
5
7
4
1212
13

5GB/IE/NI
List of pictograms used................................................................. Page 6
Introduction............................................................................................. Page 7
Proper use ...................................................................................................... Page 7
Description of parts and features.................................................................. Page 8
Scope of delivery........................................................................................... Page 8
Technical data................................................................................................ Page 8
Safety instructions............................................................................. Page 9
Product-specific safety instructions ................................................................ Page 11
Safety instructions for batteries/rechargeable batteries ............................ Page 11
Functioning............................................................................................... Page 13
Preparing for use............................................................................... Page 14
Preparing the product.................................................................................... Page 14
Setting up the product ................................................................................... Page 15
Switching the product on and off.................................................................. Page 16
Replacing the rechargeable battery............................................................. Page 17
Charging the rechargeable battery.............................................................. Page 18
Maintenance and care.................................................................. Page 19
Troubleshooting.................................................................................. Page 19
Disposal....................................................................................................... Page 20
Warranty.................................................................................................... Page 22
Warranty claim procedure............................................................................ Page 23
Service............................................................................................................ Page 24

6 GB/IE/NI
List of pictograms used
Splashproof
Rechargeable battery included
Battery type: Ni-MH battery
Direct current/voltage
CE mark indicates conformity with relevant
EU directives applicable for this product.
UKCA mark indicates conformity with relevant
Great Britain regulations applicable for this product.
(The UKCA mark logo is valid in Great Britain only.)

7GB/IE/NI
Decorative solar-powered light
Introduction
We congratulate you on the purchase of your new product. You
have chosen a high quality product. The instructions for use are part
of the product. They contain important information concerning safety,
use and disposal. Before using the product, please familiarise your-
self with all of the safety information and instructions for use. Only
use the product as described and for the specified applications. If
you pass the product on to anyone else, please ensure that you also
pass on all the documentation with it.
Proper use
The product is intended for outdoor use. The product is suitable for
use in private household and is not intended for commercial use or
for use in other applications.
This product is only intended as a decoration and is not
suitable for lighting purposes.

8 GB/IE/NI
Description of parts and features
1ON/ OFF button
(HG05660A), ON/ OFF
switch (HG05660B/
HG05660C)
2Axle cap (HG05660A)
3Fan blade (HG05660A)
4Battery compartment
5Rechargeable battery
6Rechargeable battery
compartment cover
7Fastening screw
8Stub axle (HG05660A)
9Hook (HG05660C)
10 Lamp (HG05660C)
11 Gasket (HG05660A)
12 Head of lighthouse
(HG05660B)
13 Beacon (HG05660B)
Scope of delivery
1 LED solar lamp with preassembled battery
1 User manual
Technical data
Operating voltage: 1.2V
Rechargeable battery: For HG05660A/ HG05660B:
1 x Ni-MH rechargeable battery
(AAA/ 1.2 V / 600 mAh)

9GB/IE/NI
For HG05660C:
1 x Ni-MH rechargeable battery
(2/3 AAA 1.2V /300 mAh)
LED: 1 x LED
Rated power: 11 mW for HG05660A
18 mW for HG05660B
11 mW for HG05660C
Protection type: IP44 (splash proof)
Lighting time
(with full charge): approx. 8 hours
Safety instructions
PLEASE READ THE INSTRUCTIONS FOR USE PRIOR TO USE!
PLEASE KEEP THE INSTRUCTIONS IN A SAFE PLACE! IF PASS-
ING THIS PRODUCT ON TO A THIRD PARTY ALSO INCLUDE
ALL DOCUMENTS.

10 GB/IE/NI
This product is not suitable for children under
14 years of age. This product must be kept out
of the reach of children.
This product may be used by children age 14 years and up, as
well as by persons with reduced physical, sensory or mental
capacities, or lacking experience and/ or knowledge, so long
as they are supervised or instructed in the safe use of the
product and understand the associated risks. Children should
not be allowed to play with the product. Cleaning and user
maintenance should not be performed by children without
supervision.
Do not use the product if you detect any kind of damage.
Always switch off the product, when storing it in dark environ-
ment, in order not to discharge the rechargeable battery.
The illuminant is not replaceable.
If the illuminant fails at the end of its life, the entire product must
be replaced.
This product is not a toy.

11GB/IE/NI
Product-specific safety instructions
Make sure that the solar cell is free of dirt and free of snow
and ice in winter. Otherwise the performance of the solar cell
will diminish.
Cold temperatures have a negative influence on the operating
life of the rechargeable battery. If the product is not going to
be used for a long time, e.g. in winter, it should be taken up,
cleaned and stored in a dry, warm room.
Safety instructions for batteries /
rechargeable batteries
DANGER TO LIFE! Keep batteries/rechargeable batteries
out of reach of children. If accidentally swallowed seek imme-
diate medical attention.
Swallowing may lead to burns, perforation of soft tissue, and
death. Severe burns can occur within 2 hours of ingestion.
DANGER OF EXPLOSION! Never recharge
non-rechargeable batteries. Do not short-circuit bat-
teries/rechargeable batteries and/ or open them.
Overheating, fire or bursting can be the result.

12 GB/IE/NI
Never throw batteries/rechargeable batteries into fire or water.
Do not exert mechanical loads to batteries / rechargeable bat-
teries.
Risk of leakage of batteries/rechargeable batteries
Avoid extreme environmental conditions and temperatures, which
could affect batteries/rechargeable batteries, e.g. radiators /
direct sunlight.
If batteries/rechargeable batteries have leaked, avoid contact
with skin, eyes and mucous membranes with the chemicals!
Flush immediately the affected areas with fresh water and
seek medical attention!
WEAR PROTECTIVE GLOVES! Leaked or dam-
aged batteries/rechargeable batteries can cause
burns on contact with the skin. Wear suitable pro-
tective gloves at all times if such an event occurs.
In the event of a leakage of batteries/rechargeable batteries,
immediately remove them from the product to prevent damage.
Only use the same type of batteries/rechargeable batteries.
Do not mix used and new batteries/ rechargeable batteries.

13GB/IE/NI
Remove batteries /rechargeable batteries if the product will
not be used for a longer period.
Risk of damage of the product
Only use the specified type of battery/rechargeable battery!
Insert batteries/ rechargeable batteries according to polarity
marks (+) and (-) on the battery/rechargeable battery and
the product.
Use a dry lint-free cloth or cotton swab to clean the contacts
on the battery/rechargeable battery and in the battery com-
partment before inserting!
Remove exhausted batteries/ rechargeable batteries from the
product immediately.
Functioning
The solar cell installed in the product converts sunlight into electrical
energy and stores it in 1 Ni-MH rechargeable battery. Switch on
the product with the ON/ OFF button (HG05660A) / ON / OFF
switch (HG05660B/ HG05660C) 1. The product will automati-
cally light on as it begins to get dark. The built-in light-emitting diod es

14 GB/IE/NI
are a very long-life and energy-saving light source. The light duration
depends on the amount of sunlight, the angle of light on the solar cell
and the temperature (the battery capacity is temperature-depe
ndent).
A vertical angle of light at temperatures above the freezing point
is ideal. The rechargeable battery does not achieve maximum
capacity until after several charge and discharge cycles.
In summer a completely drained rechargeable battery takes about
2 to 4 days to fully recharge in constant sunlight.
Preparing for use
Note: Remove all packaging material before first use.
Preparing the product
For HG05660A:
First connect the parts of the fan blades 3together then place
the fan blades 3on the stub axle 8. Place the axle cap 2
on the stub axle 8to secure all parts (see fig. B).
For HG05660B:
Your product is ready for use. The beacon 13 will turns in the dark.

15GB/IE/NI
For HG05660C:
Mount the lamp 10 as shown in Figure A.
Bend the holder then install the lamp 10 to the hook 9on
the product (see fig. B).
Your product is ready for use.
Setting up the product
Do not put the product directly on the ground, so that no rain
penetrates during rainfall! Make sure that the product does not
pose a stumbling hazard.
In order to achieve the best result, set the product up in a place
where the solar cell will get direct sunlight for as long as possible.
Make sure that the solar cell is not influenced by any other
source of light such as yard or street lighting as otherwise the
light will not come on in twilight.
The product automatically switches on in twilight conditions
and off again when normal outdoor lighting conditions return.

16 GB/IE/NI
Switching the product on and off
For HG05660A:
Press the ON/ OFF button 1to turn on the product automati-
cally when it is dark.
Press the ON/ OFF button 1again to completely switch off
the product.
For HG05660B:
The ON/OFF switch 1is positioned under the head of light-
house 12 . Slide the ON/ OFF switch 1to the ON position to
automatically turn on the product in the dark.
Slide the ON/ OFF switch 1to the OFF position to completely
turn off the product.
For HG05660C:
Open the lantern 10 first and then slide the ON/OFF switch 1
to ON position to turn on the product automatically when it is dark.
Slide the ON/OFF switch 1to the OFF position to completely
turn off the product.

17GB/IE/NI
Replacing the rechargeable battery
The rechargeable battery should be replaced every 12 months to
ensure optimum performance.
1. For HG05660A: Turn the product upside down. Press the
ON/ OFF button 1to switch off the product. Loosen the
fastening screws 7by using a small cross head screwdriver
and then lever out the rechargeable battery compartment cover
6with the help of a slot screwdriver.
2. For HG05660B: Rotate the solar housing anticlockwise out of
the housing. The solar unit with two cables is connected to the
housing. Be careful not to damage the cables. Carefully loosen
the fastening screws 7by using a small cross head screwdriver
under the head of lighthouse
12
and lift the head of lighthouse
12
.
3. For HG05660C: First remove lantern 10 from the hook 9.
Rotate the solar housing anticlockwise out of the housing.
Loosen the fastening screws 7by using a small cross head
screwdriver and then lever out the rechargeable battery com-
partment cover 6with the help of a slot screwdriver.
4. Exchange the old rechargeable battery 5to a new one,
ensure that you do not damage the wiring. Take care to the

18 GB/IE/NI
correct polarity, when inserting the new rechargeable battery.
The polarity is indicated in the battery compartment 4. The
new rechargeable battery has to have the same technical data
like the old one.
5. Now again fasten the rechargeable battery compartment
cover 6and install back the product.
For HG05660A: Make sure the rechargeable battery com-
partment cover 6and gasket 11 are correct installed. Press
the ON/OFF button 1to turn on the product automatically
when it is dark.
For HG05660B/HG05660C: Slide the ON/OFF switch
1
to the ON position to automatically turn on the product in
the dark.
Charging the rechargeable battery
Note that the product must be switched on when the rechargeable
battery is charging.
The charging time of the rechargeable battery when the solar cell is
used depends on the intensity of the sunlight and the angle of incidence
of the light on the solar cell. Place the solar cell as perpendicular

19GB/IE/NI
as possible to the angle of incidence of the light. In this way you
will receive the highest light levels.
Maintenance and care
The light-emitting diodes cannot be replaced. The product is mainte-
nance-free, except for any necessary change of rechargeable battery.
Clean the product regularly with a dry, lint-free cloth. Use a
slightly dampened cloth to remove more stubborn dirt.
Regular cleaning of the solar panel to achieve the best result.
Troubleshooting
Note: This product has delicate electronic components. This means
that if it is placed near an object that transmits radio signals, it could
cause interference. If you notice that the product is malfunctioning,
remove any sources of interference from the area of the product.
Note: Electrostatic discharges may cause product to malfunction.
In the event of such malfunctions, remove the rechargeable battery
briefly and reinsert it.

20 GB/IE/NI
Error Cause Solution
The light will not
switch on even
though the sun
shone on the
product all day.
Artificial sources
of light, e.g. street
lighting, are inter-
fering with the
product.
Mount the product in
a place where it can-
not be disturbed by
other sources of light.
The light does not
come on or comes
on only briefly.
The rechargeable
battery is broken
or there was not
enough daylight.
Replace the recharge-
able battery or mount
the
product in a pla ce
where it can receive
more sunlight.
Disposal
The packaging is made entirely of recyclable materials, which you
may dispose of at local recycling facilities.
b
a
Observe the marking of the packaging materials for
waste separation, which are marked with abbreviations
(a) and numbers (b) with following meaning: 1–7:
