Liverage Fiber Checker User manual

Technologies , Inc.Technologies , Inc.
Fiber Checker
Page 1 of 8
2009Y VER A
Liverage Technology Inc.
3F-3, No. 30 Taiyuan Street, Chupei City, Hsinchu County 302, Taiwan
TEL:[phone] FAX: [phone]
http://www.liverage.com.tw E-mail: [email protected]
Copyright 2009 ,Liverage Technology Inc. reserves the right to modify specifications without prior notice
Fiber Checker
Specification
&
User Manual
2009 VER A

Technologies , Inc.Technologies , Inc.
Fiber Checker
Page 2 of 8
2009Y VER A
Liverage Technology Inc.
3F-3, No. 30 Taiyuan Street, Chupei City, Hsinchu County 302, Taiwan
TEL:[phone] FAX: [phone]
http://www.liverage.com.tw E-mail: [email protected]
Copyright 2009 ,Liverage Technology Inc. reserves the right to modify specifications without prior notice
Table of Contents
1. Description and Features…..…………..……………...3
2. Specification………….….……………………..………..4
3. Operating Instructions...……….…………………..…...5
4. Maintenance …………..………………..………………...6
5. Warranty ………………..…………………………………7
6. Ordering Information ..………………………………….7
7. Service Contacts..………………………………………..8

Technologies , Inc.Technologies , Inc.
Fiber Checker
Page 3 of 8
2009Y VER A
Liverage Technology Inc.
3F-3, No. 30 Taiyuan Street, Chupei City, Hsinchu County 302, Taiwan
TEL:[phone] FAX: [phone]
http://www.liverage.com.tw E-mail: [email protected]
Copyright 2009 ,Liverage Technology Inc. reserves the right to modify specifications without prior notice
1.1 Description:
The Fiber Checker is a very useful tool designed for
checking the defects of a fiber cable. It emits a visible
635 nm or 650 nm wavelength red laser light through
fiber optic cables, then if there are breaks or defects in
the fiber will refract the light, creating a bright glow
around the faulty area.
The universal connector can be used for all the most widespread fiber
interfaces such as ST / SC / FC connector. It is suitable to test both
Singlemode and Multimode cables. With an optional 2.5 mm to 1.25 mm
optional Adapter, you can easily test 1.25 mm diameter fiber LC or MU
connector. The visibility is up to 3 Km to 5 km depends upon the output power
of the Fiber Checker.
Internally there is also a specifically designed power circuit APC ( Auto
Power Control ) circuit provides steady power which avoids unstable laser
output when the battery is low.
The LD output signal can be switched on CW or Pulse Mode to obtain
different visual effects. There is a dust proof cover which will prevent dust from
getting into the inside of the LD connector. The cover also helps you to avoid
evading incidental exposure of the laser directly into your eyes.
1.2 Features:
Easy to check fiber faults by using 635 nm or 650 nm visual red laser
Range: visibility up to 3 ~ 5 Km
Universally Connector for test different ST, SC, FC, MU ( via Optional
Adapter ) , LC ( via Optional Adapter ) interfaces
For both Singlemode and Multimode cables
Highly effective power circuits designed for stable laser power
Operating in both CW ( Continuous Wave) & Pulse Mode
Dust-proof design keeps fiber connectors clean
Two AAA-size alkaline batteries
LED indicator for Power On, Battery Low

Technologies , Inc.Technologies , Inc.
Fiber Checker
Page 4 of 8
2009Y VER A
Liverage Technology Inc.
3F-3, No. 30 Taiyuan Street, Chupei City, Hsinchu County 302, Taiwan
TEL:[phone] FAX: [phone]
http://www.liverage.com.tw E-mail: [email protected]
Copyright 2009 ,Liverage Technology Inc. reserves the right to modify specifications without prior notice
2. Specification
Laser Class Class 2M
Wavelength 635 nm ± 10 nm @ 25℃
650 nm ± 10 nm @ 25℃
Spectral Width < 10 nm
Output Power > 0.5 mW @ 25℃into 9 µm fiber
Output Power (Part number -1) > 1 mW @ 25℃into 9 µm fiber
Output Power (Part Number -2) > 2 mW @ 25℃into 9 µm fiber
Mode CW / Pulse Mode
Battery Type AAA 1.5 V x 2
LED Indicator GREEN Light - Power ON
RED Light - Battery Low
Emitting Range Visibility to 3 ~ 5 Km
Operating Temp. 0℃~ 50℃
Storage Temp. 0℃~ 70℃

Technologies , Inc.Technologies , Inc.
Fiber Checker
Page 5 of 8
2009Y VER A
Liverage Technology Inc.
3F-3, No. 30 Taiyuan Street, Chupei City, Hsinchu County 302, Taiwan
TEL:[phone] FAX: [phone]
http://www.liverage.com.tw E-mail: [email protected]
Copyright 2009 ,Liverage Technology Inc. reserves the right to modify specifications without prior notice
3. Operating Instructions
To touch then bend the Dust Cap to open the connector
To press to release Linchpin then to push
Battery Lid backward.
To open Battery Lid to change batteries.
1. Dust Cap : prevent dirt contaminates the LD
2. Button : pressing to Turn On / Turn Off the LD emitting.
3. Mode Switch : to select CW Continuous Wave Mode / Pulse Mode.
4. Pen Clip : a design to fasten the tool while put inside pocket.
5. Battery Lid : to open to change batteries.
6. Linchpin : a mechanical design to lock the Battery Lid.
1. The Fiber Checker is powered by two pieces 1.5 V AAA batteries
2. To check the power on please press the button and see if the LED is
GREEN.
3. Lift the front of the dustproof up and insert on end of the fiber
connector to the universal connector or directly insert to an output
connector of the fiber or patch cord.
1
2
3
4
5
1
6

Technologies , Inc.Technologies , Inc.
Fiber Checker
Page 6 of 8
2009Y VER A
Liverage Technology Inc.
3F-3, No. 30 Taiyuan Street, Chupei City, Hsinchu County 302, Taiwan
TEL:[phone] FAX: [phone]
http://www.liverage.com.tw E-mail: [email protected]
Copyright 2009 ,Liverage Technology Inc. reserves the right to modify specifications without prior notice
The breaks or
defects in the fiber.
4. Switch to CW / Pulse Mode.
5. Press the Button and check those breaks or defects in the fiber will
refract the light, creating a bright glow around the faulty area. ( Shown
as below Illustration 1 )
Illustration 1.
6. When the LED is RED, this means that batteries are almost drained
out and in low voltage status and you will need to replace the
batteries right away.
7. Do not touch the fiber’s interface to avoid dirt into the connector.
8. Keep the fiber connector capped at all the time when the device is not
in use.
9. With proper cleaning tools to clean the fiber before testing so that to
obtain the right tests results and make the service longer.
4. Maintenance
This tool requires no maintenance other than periodic battery charges. Like
any other electronic equipment, this tool should be kept away from water, high
damp, dust, electricity, and environments of extreme temperature. And the
internal Fiber Checker there is a fiber stub needed to be cleaned by
specific cleaning tools regularly ( Shown as Illustration 2. ). Please do not
drop this tool on hard surface. Modifying internally any of this tool components
can cause a malfunction and will invalid the manufacturer’s warranty.
Illustration 2. Fiber Stub Cleaning

Technologies , Inc.Technologies , Inc.
Fiber Checker
Page 7 of 8
2009Y VER A
Liverage Technology Inc.
3F-3, No. 30 Taiyuan Street, Chupei City, Hsinchu County 302, Taiwan
TEL:[phone] FAX: [phone]
http://www.liverage.com.tw E-mail: [email protected]
Copyright 2009 ,Liverage Technology Inc. reserves the right to modify specifications without prior notice
5. Warranty
The manufacturer warrants this product to be free of defects in
workmanship and materials for a period of 1 year after purchase. This warranty
(excluding batteries) is solely limited to the repair and replacement of original
parts, which are defective in workmanship of materials. All other costs should
be the sole responsibility of the owner. This warranty does not cover any
defects, damage, and deterioration due to misuse, alteration, or negligence.
6. Ordering Information:
Description
Part Number Wavelength Output Power
S200111-635 635 nm > -3 dBm ( 0.5 mW )
S200111-635-1 635 nm > 0 dBm ( 1 mW )
S200111-635-2 635 nm > +3 dBm ( 2 mW )
S200111-650 650 nm > -3 dBm ( 0.5 mW )
S200111-650-1 650 nm > 0 dBm ( 1 mW )
S200111-650-2 650 nm > +3 dBm ( 2 mW )
Part Number Description
S200411 LC adapter, 2.5 mm to 1.25 mm
S200421 MU adapter, 2.5 mm to 1.25 mm

Technologies , Inc.Technologies , Inc.
Fiber Checker
Page 8 of 8
2009Y VER A
Liverage Technology Inc.
3F-3, No. 30 Taiyuan Street, Chupei City, Hsinchu County 302, Taiwan
TEL:[phone] FAX: [phone]
http://www.liverage.com.tw E-mail: [email protected]
Copyright 2009 ,Liverage Technology Inc. reserves the right to modify specifications without prior notice
7. Service Contacts
Please contact us :
Liverage Technology Inc.
3F-3, No. 30 Taiyuan Street,
Chupei City, Hsinchu County 302,
Taiwan
TEL:[phone]
FAX: [phone]
e-mail: [email protected]
http://www.liverage.com.tw
