Slow Cooker
INSTRUCTION MANUAL
MODEL: SRO8319

........................................................................ 1
..................................................................................................... 3
.......................................................................................................4
IMPORTANT SAFEGUARDS.
Part Name
Operating
General Cooking Advice
Approximate Cooking Times
Cleaning and Maintenance
Product Specifications
Environmental Protection
................................................................................ 5
........................................................................ 5
............................................................................ 6
....................................................................... 6
............................................................................... 6

1
IMPORTANT SAFEGUARDS
Caution
For safety reasons and to avoid damage to the appliance
or injuries to people, please abide by all the safety
instructions below. Ignoring safety warnings may result in
injuries.
This appliance does not take into consideration the
following situations:
--- Use by children or disabled people without supervision;
--- children treating it as a toy.
1. Read all instructions.
2. This appliance is for household use only. Do not use
outdoors.
3. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children unless
they are older than 8 and supervised. Keep the
appliance and its cord out of reach of children aged
less than 8 years.
4. Unplug from outlet when not in use and before cleaning.
Allow to cool before cleaning.
5. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
6. Children should be supervised to ensure that they do
not play with the appliance
7. The use of accessory attachments not recommended by
the appliance manufacturer may cause injury.

2
IMPORTANT SAFEGUARDS
Caution
8. Please turn off and unplug the appliance before
cleaning, maintenance or relocation and whenever it is
not in use.
9. Do not let cord hang over edge of table or counter, or
touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or
in a heated oven.
11. Extreme caution must be used when moving an
appliance containing hot food, water or other hot
liquids.
12. Do not use the appliance for other than intended use.
13. Lift and open cover carefully to avoid scalding, and
allow water to drip into unit.
14. To disconnect turn the control to OFF, then remove plug
from wall outlet.
15. Containers are designed for use with this appliance
only. They must never be used on a range top.
Do not set a hot container on a wet or cold surface. Do
not use a cracked container.
16. Do not immerse the appliance in water or any other
liquid.
17. This appliance is intended to be used in household and
similar applications such as:
-staff kitchen areas in shops, offices and other working
environments;
-farm houses;
-by clients in hotels, motels and other residential type
environments;
-bed and breakfast type environments.
18. Children shall not play with the appliance.
The surfaces of the appliance are liable to get hot
during use.

3
Glass lid
Handle
Removable bowl
Indicator light
Function switch
Cooker housing
Part Name
No.
Description
IMPORTANT SAFEGUARDS
Caution
1
2
3
4
5
6
19. To protect against electrical shock, do not immerse
cord, plug or appliance in water or other liquid.
20. The heating element surface is subject to residual heat
after use, do not touch.
21. Warning: Misuse may cause potential injury
22. Do not touch hot surfaces. Use handles or knobs. Use
potholders when removing cover or handling hot
containers.
23. Do not place on or near a hot gas or electric burner, or
in a heated oven.
1
2
3
64
5

4
Operating
1. Clean thoroughly before use.
2. Place the cooker housing on a stable, flat, heat resistant surface and
away from surfaces that may be damaged by steam.
3. After making reference to the food safety and general cooking advice,
place the ingredients to be cooked into the removable bowl. Heat liquids
such as water and stock before adding to the bowl and do not fill to the
brim.
4. Cover the bowl with the glass lid and place into the cooker housing.
5. Fully unwind the cable, plug in and switch on. For your safety do not
allow the cable to dangle over the edge of units.
6. Using the function switch, select the cooking function of choice (the
indicator light will illuminate) and if cooking times allow, select the HIGH
setting in preference to the low setting.
Cooking food on HIGH will require less time than cooking at LOW.
The slow cooker can operate on LOW all day and night if required.
7. When the cooking is complete, select the WARM function to keep the food
warm (maximum 4 hours) until it is ready to serve.
8. When ready to serve, turn the slow cooker off using the function switch.
The indicator light will extinguish.
Notes:
Before using for the first time, wash loose parts (removable bowl and lid)
in hot water with a little washing up liquid. Rinse and dry thoroughly. Not
suitable for the dishwasher..
General Cooking Advice
1. When adding liquid or stock to the slow cooker is recommended that
hot liquid is added to reduce the cooking time and to ensure that the
slow cooker reaches the higher cooking temperatures more quickly.
2. Avoid lifting the glass lid during the cooking process as this breaks the
seal formed around the lid and adds time to the cooking process.
3. Vegetables such as carrots, potatoes and turnips require longer
cooking than many types of meat and should be cut into the smallest
sizes practical. Place in the bottom or the sides of the bowl and
cover with liquid.

5
General Cooking Advice
Approximate Cooking Times
4. Trim excess fat from meat, as the cooking method does not allow the
fat to drain away.
5. If adding fresh milk or yoghurt, this should be done in the final two
hours of cooking. Evaporated milk may be added at the start of
cooking.
6. Rice, noodles and pasta are not recommended for long cooking
periods. Cook them separately and then add to the slow cooker during
the final 30 minutes.
1. The cooking times stated in the chart below give an approximate guide.
For slow cooker recipes, techniques and specific cooking times consult a
specialist recipe book.
2. Browning meats before they are added to the slow cooker can reduce
cooking times.
Chicken soup (made with approx 1kg
diced chicken):
Split pea soup
Minestrone soup
Beef casserole (made with approx
500g diced beef):
Pork or lamb chops (6 thick chops):
Beef or lamb curry (made with approx
1.3kg diced meat): Beef 1.3 kg
Beef stroganoff (made with approx
1.3kg diced beef)
Porridge
Baked apples
(4 apples with 125ml water)
Mulled wine
Finished quantity
(approx.)
Approximate cooking times (hr)
Low High
8-10
8-11
8-9
8-10
8-10
8-10
5-6
2-3
6-8
4-6
5-6
6-7
6-8
6-8
7-9
4-6
2-4
1-2
2½ - 3 litres
2½ - 3 litres
1½ - 2 litres
1 litres
2½ - 3 litres
1½ - 2 litres
1½ - 2 litres
1 litres
1½ - 2 litres
2 litres
8-11
8-11

6
Clean after each use.
1. Switch off and unplug the slow cooker and allow to cool completely.
2. Wash loose parts (removable bowl and lid) in hot water with a little
washing up liquid. Rinse and dry thoroughly. Not suitable for the
dishwasher.
3. Wipe the external surface of the slow cooker with a soft damp cloth and
dry surfaces with a soft dry cloth. Do not use detergent or abrasives as
these may scratch the surface. Never immerse the cooker housing in
water.
CLEANING & MAINTENANCE
Product Specifications
SRO8319
Slow Cooker
Product name Model No. Rated voltage Rated frequency Rated power
220 - 240V~ 50/60Hz 135 - 160W 3L
Capacity

Environmental protection
Responsible Disposal
At the end of its working life, do not throw this product out with your household
rubbish. Electrical and electronic products contain substances that can have a
detrimental effect on the environment and human health if disposed of
inappropriately. Observe any local regulations regarding the disposal of
electrical consumer goods and dispose of it appropriately for recycling. Contact
your local authorities for advice on recycling facilities in your area.
Please keep the original packaging carton and materials in a safe place. It will
help to prevent any damage if the product needs to be transported in the future.
In the event it is to be disposed of, please recycle all packaging material where
possible.

Warranty
We pride ourselves on producing a range
of quality home appliances that are both packed with features
and completely reliable. We are so confident in our products,
we back them up with a 3 year warranty.
Now you too can relax knowing that you are covered.
Customer Helpline NZ: 0800 422 274
This Product is covered by 3 year warranty when
accompanied by proof of purchase.
