Living 168-0103-8 User manual

Assembly Instructions
IMPORTANT: Please read this manual carefully
before beginning assembly of this product.
Keep this manual for future reference.
NEED HELP? GIVE US A CALL!
WE’RE HERE FOR YOU.
TOLL-FREE:
1-877-483-6759
Product No. 168-0103-8
Adjustable Arm Office Chair

From your rst apartment to
downsizing your family home,
Uncomplicate your life with timeless
style and reliable quality that delivers
everyday solutions for your home.
Let us know how our products
work for you. Rate and review at
canadiantire.ca
For is a great place to start.
LIVING®

3
Table of Contents
Needed for Assembly:
Warning! Please use your furniture correctly and safely. Improper use
can cause safety hazards or damage to your furniture or household
items. Carefully read the following safety information.
• Please read and understand this entire manual before attempting to assemble,
operate, or install the product.
• Any assembly or maintenance of the product must be carried out by adults only.
• Some parts may contain sharp edges. Wear protective gloves if necessary.
• To prevent damage, place all parts on a level surface during assembly.
Add a layer of protective surface if needed.
• Due to the nature of steel, surface oxidation (rusting) will occur if this protective coating is
scratched. This is a natural process. To minimize this condition, it is recommended that care
be taken when assembling and handling the product in order to prevent the paint from
being scratched.
Parts List 4
Before You Begin Assembly 7
Step-by-step Guide 8
Technical Data 15
Troubleshooting 16
Caring for Your Item 16
Warranty 17
Hardware List 6
1 Person
Adjustable Arm Office Chair

4
Parts List
Item Description 6JWODPCKN 3WCPVKV[
11
2 1
3 2
4 1
5 1
6 1
5
7
Backrest
Arm
Seat
Seat Plate
Cylinder
Base
Castor
Adjustable Arm Office Chair

5
Exploded Parts
4
5
6
1
2
3x2
Adjustable Arm Office Chair
7x5
7

6
Hardware List
Item Description Thumbnail Quantity
AM6x20 Combination
Bolt 4
BM8x20 Combination
Bolt 3
C
Hex Key
2
D 4
E 1
M6x35 Combination
Bolt
M6x45 Combination
Bolt
Adjustable Arm Office Chair

7
Before You Begin Assembly
?
Make Sure All Parts Are Present
Compare all pieces to the parts and hardware lists, and make sure you have all tools
required for assembly.
Assemble in a Cleared Area
Place all parts from the box on the oor in front of you in a clean, dry, level surface
to protect the product as it is being built.
Remove Packaging Materials
Place packing materials back in the box. Do not dispose of packaging materials until
assembly is complete.
Read Each Step Carefully
Adjustable Arm Office Chair
Make sure you understand each step. If you have any questions, Call the for LIVING
customer service centre at 1-888-660-6684 (toll free).
®

8
Step-by-step Guide
Step 1
6
7
6x1 7x5
7
Insert five castors (7) into base (6). Push
hard until you feel or hear the castors (7)
snap into place.
Adjustable Arm Office Chair

9
Step-by-step Guide
Step 2
5
5x1
Remove cap from cylinder (5).
Adjustable Arm Office Chair

10
Step-by-step Guide
Step 3
6
5
Attach cylinder (5) into base (6) as shown.
Adjustable Arm Office Chair

Step-by-step Guide
Step 4
2
2x1 3x2 Dx4 Cx2
DC
3
Attach arms (3) to seat (2). Secure with
two bolts (C) and four bolts (D) using
Ex1
11
D
Adjustable Arm Office Chair
the he key (E).
x

Step-by-step Guide
Step 5
4
4x1 Ex1 Ax4
2
Attach seat plate (4) to seat (2) with tension
knob facing the front of the seat. Secure using four
bolts (A)
A
12 Adjustable Arm Office Chair
and he key (E).
x

Step-by-step Guide
Step 6
1x1 Bx3 Ex1
1
B
Attach backrest (1) to seat plate (4)
using three bolts (B)
4
13
Adjustable Arm Office Chair
and he key (E).
x

Step-by-step Guide
Step 7
14 Adjustable Arm Office Chair

Technical Data
Specications
Assembled Dimensions (W x D x H)
Assembled Weight
13.2 kg
Maximum Weight Capacity
242 lb
110 kg
15
Adjustable Arm Office Chair
39 3/16 – 42 15/16"
(99.5 – 109 cm)
26"
(66 cm)
25 3/16"
(64 cm)
29 lb 2 oz
64 x 66 x 99.5 1 09 cm
25 3/16 x 26 x 39 3/16 42 15 16/ ''
–
–

Troubleshooting
Need help?
Give us a call! We’re here for you.
If you have questions regarding your product
or require warranty assistance, please call our
customer service helpline.
Toll-free: 1-877-483-6759
Before returning your
product to store Call us rst!
Caring for Your Item
1
3
2
Always keep children under close supervision while they are using or around this
product. Never leave children unattended.
Check all nuts and bolts periodically for tightness. When required, tighten them
again.
Do not shake, lean or climb on the product.
16 Adjustable Arm Office Chair

Warranty
materials. Trileaf Distribution agrees to replace the defective product free of charge within
the stated warranty period, when returned by the original purchaser with proof of purchase.
This product is not guaranteed against wear or breakage due to misuse and/or abuse.
Made in China
Imported by Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
Model No.
1-Year Limited Warranty*
168-0103-8
17
Adjustable Arm Office Chair
This For LIVING®product carries a one (1) year warranty against defects in workmanship and
