Livoo SA110 User manual

User manual
WWW.LIVOO.FR
Reference: SA110
Version: 1.4
Language: English
Disinfectant generator
spray

User manual
1
Thank you for buying our LIVOO product. We take great care in design, ergonomics and ease of use of our products.
We hope that this product will give you complete satisfaction.
This instruction manual is also available on our website www.livoo.fr
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY ALL THESE INSTRUCTIONS BEFORE USING THE DEVICE AND PRESERVE
THEM FOR ANY LATER NEED.
1. Please follow the rules depicted in this manual closely to ensure your safety.
2. Be more wary of any edges, uneven surfaces, metal parts, accessories and its packaging
so as to prevent any possible injury or damage.
3. Keep this appliance out of reach of children. Take note that this appliance is not edible
and should not be placed in your mouth.
4. Do not modify, repair or dismantle the appliance. Doing so may result in fires, electric
shocks, complete breakdown of the appliance, etc. All of which, are not covered under
warranty.
5. Do not use any diluents or volatile liquid to clean the appliance. Keep in mind that the
surface of the appliance should only be wiped with a clean dry cloth.
6. Do not use this appliance in locations whereby there are high-temperatures or high
humidity levels; ideally, the appliance should be used in locations free of dust and
exposure to direct sunlight.
7. Do not insert foreign objects, such as pins, into this appliance.
8. Do not touch this appliance when your hands are wet as this may result in electric shocks.
9. Refrain from dropping the appliance as well any collision with other objects.
10. Should any abnormal situations or problems occur while using this appliance, discontinue
use of the appliance immediately.
11. If the appliance is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard (*).
12. Do not immerse the appliance or its bottom in water or any other liquid.
13. Do not place the appliance in dishwasher.
14. When removing the plug, hold it and pull it out. Do not pull or twist the power cord with
force, to prevent the power cord being damaged and the danger of leakage
15. To prevent electric shock or fire, the power must be disconnected in the following
situations : when there is no water in the container, when water is added, when not in
use, when cleaning or moving the appliance, when there is a problem during use.
(*) qualified competent Person: technician of the after-sales service of the builder (manufacturer) or the
importer or every qualified, authorized and competent person to make this type (chap) of repair.

User manual
2
WARNING
The following should be noted to ensure trouble-free operation:
Do not tighten the nut during the electrolysis to allow gas rushing out. Only tighten the
nut once disinfectant production is finished.
When using for the first time or not using for an extended period of time, please clean
the appliance thoroughly before using.
Do not drink the disinfectant.
Specifications :
Output : 5V 1A
Making of sodium hypochlorite allowing disinfection of harmful microorganisms such as bacteria and
mold. Suitable for surfaces, fruits or vegetables.
Electrolysis time : 8 minutes
3 concentration levels : low, medium, high
Capacity of 300ml
Package contents :
1 x Disinfectant generator spray
1 x USB/micro USB charging cable
1 x Measuring spoon
1 x User Manual
PRODUCT DESCRIPTION
1. Liquid nozzle
2. Spray trigger
3. Nut
4. Pump straw
5. Body container
6. Base
7. Switch button

User manual
3
USE
Instructions
1. Pour 300ml of tap water into the pot, and add edible salt to water. The salt quantity shall be measured
according to the disinfectant concentration required (low concentration 7.5g / about half a spoon ;
medium concentration 15g / 1 spoon ; high concentration 22.5g / about 1 spoon and a half) and cover
with spray head without tighten it.
2. Connect the disinfectant generator spray onto power supply (wall socket, PC or laptop) by using the USB
/ micro USB charging cable. The power indicator lights on, then click the switch button to start
electrolysis process.
3. The disinfectant solution can be used only after 8mins, when the electrolysis is fully completed. Tighten
the nut once disinfectant production is finished. For the using method, please refer to the methods listed
in this user manual.
4. Long press on switch button to turn the appliance off.
Concentration Range
Amount of Salt Classification Concentration Range
1/2 spoon (approx. 7.5g) Low concentration 300-500mg/L
1 spoon (approx. 15g ) Medium concentration 500-800mg/L
1+1/2 spoon (approx. 22.5g) High concentration 1000-1500mg/L
Spray modes
1. There are two modes of spraying.
Wide spraying “ ” / Straight spraying “ ” (Figure 1)
2. According to your needs, adjust the spray mode by rotating left and right (Figure 2)
Figure 1
Figure 2

User manual
4
Application
Fruits, vegetables, tableware (which need to be rinsed with water after disinfection), household, offices,
restaurants, hotels, hospitals, schools, beauty salons, pets salons, bath centers, toys etc.
Precautions
1. After disinfectant production is completed, the charging cable shall be removed.
2. The disinfectant should be used immediately. It shall not be stored in the pot for a long time. If remaining
solution, please poor into another liquid container for storage and further use, then clean the pot with
water and dry to extend working life.
3. Make sure the disinfectant cannot be reached by children.
4. The disinfectant has an oxidation effect on metal, so metalware should not be used to store disinfectant
solution.
5. In case of direct application on metalware, it shoud be rinsed with water immediately after disinfection
and then wiped clean.
6. The disinfectant has bleaching effect on fabric, please be cautious when using on colored or dark clothes.
Do not soak silk or leather into disinfectant solution.

User manual
5
Using methods
The concentration of the original disinfectant solution diluted below is based on a high concentration of
1200mg/L
Application
Concentration Range
Preparation method
Use
Fruits,
vegetables
150-200mg
(low)
-Prepare disinfectant with high
concentration using 1+1/2
spoon (approx. 22.5g) salt
quantity.
-Dilute the original disinfectant
solution 5 times (Simple
operation : 1L water + 200ml
disinfectant, dilution ratio 1:5)
-Soak the fruits/vegetables
in disinfectant solution for
5 mins then rinse
thoroughly with clear
water.
Hands
150-200mg
(low)
-Prepare disinfectant with high
concentration using 1+1/2
spoon (approx. 22.5g) salt
quantity.
-Dilute the original disinfectant
solution 5 times (Simple
operation : 1L water + 200ml
disinfectant, dilution ratio 1:5)
-After washing your hands
with soap, rinse with clear
water. Then rinse or spray
your hands with the
disinfectant solution.
Floor,
surfaces,
objects
500-600mg
(medium)
-Prepare disinfectant with high
concentration using 1+1/2
spoon (approx. 22.5g) salt
quantity.
-Dilute the original disinfectant
solution 1 time (Simple
operation : 1L water + 1L
disinfectant, dilution ratio 1:1)
-Soak the mop or rag in the
disinfectant solution for
10 mins, then use for
cleaning.
Floor
drains
500-600mg
(medium)
-Prepare disinfectant with high
concentration using 1+1/2
spoon (approx. 22.5g) salt
quantity.
-Dilute the original disinfectant
solution 1 time (Simple
operation : 1L water + 1L
disinfectant, dilution ratio 1:1)
-Pour 500 ml disinfectant
solution into the drain,
leave for 5 to 10 mins,
then rinse with clear
water. Recommendation:
2 applications / week in
summer.

User manual
6
Correct disposal of the unit
(Electrical and Electronic Equipment)
(Applicable in the European Union and the rest of Europe that have adopted separate collection systems
countries)
The European Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old
household electrical appliances must not be disposed of in the normal household waste stream. Old appliances must be
collected separately in order to optimize the recovery and recycling of the materials they contain and reduce the impact on
human health and the environment. The symbol of the crossed out dustbin is marked on all products to remind the obligations
of separate collection. Consumers should contact their local authority or retailer for information concerning the correct disposal
of their product.
Non contractual illustration
Product information is subject to change without prior notice
