Lloyd LI1088AS User manual

LI1088AS
Please read these instructions manual carefully before using the appliance
INSTRUCTION MANUAL
STEAM IRON

Dear Customer
Congratulations on being the proud owner of Lloyd Steam
Iron. Your Steam Iron comes with a Lloyd Guarantee of
Quality.
Lloyd takes great pride in providing its customers with perfect
products that adheres to international quality standards.
Lloyd is committed to provide the ultimate customer
satisfaction as nothing brings us greater joy than having
satisfied customers of Lloyd.
At Lloyd, feedback and suggestions based on your product
usage experience are greatly appreciated.
Please feel free to contact us at [email protected]
NIPUN SINGHAL
DIRECTOR

Attention:
* Please read the owner’s manual before using the product.
* Before using, please check the voltage of the product if it is the same
with the one in your home.
* When using steam ironing and self cleaning function, you are
recommended to use distilled water.
* The water will leak from the soleplate if using ironing with steam but
temperature below level **. Please note, its a normal
phenomenon.
* During the iron is electrified, operator must not leave, and let
children not touch the iron.
*
* After using, turn the steam knob to “ ”, turn the temperature
regulating knob to “0”, pull out the plug, put the iron on the smooth
and stable place vertically.
* If the supply cord is damaged, it must be replaced by the
* The iron is not to be used if it has been dropped, if there are visible
signs of damage or if it is leaking.
service personnel in order to avoid a hazard.

* The iron must be used and placed on a stable surface.
* When placing the iron on its stand, ensure that the surface on which
the stand is placed is stable.
* Children should be supervised to ensure that they do not play with
the appliance.

Main features:
The product has many functions such as Temperature Regulation, Water
Spray, Dry Ironing, Steam Function, Burst of Steam Function etc. and is
wit to use
A: Steam Regulation Knob F: Temperature Adjustment Knob
B: Steam Burst Button G: Water tank
C: Water Spray Button H: Non-stick Soleplate
D: Indicator Cover I: Spray Nozzle
E: 360 Degree Rotation Chord J: Water Fill Mouth Cover

Technical information:
1. High Precision Temperature Control: With the high precision
temperature control knob, the user can adjust the temperature of the
heating plate as per the material of clothes to be ironed.
2. Thermal Fuse Protection: The iron bears an inbuilt thermal protector
which cuts of the power supply when the temperature exceeds a
certain temperature so as to avoid any possible hazard. The user can
have the fuse replaced by a authorized service personnel in such a
case.
Method of Operation
Steam ironing:
1. Use suitable container to fill the water tank.
2. Turn the temperature adjusting knob to the “0” position, and ensure that
the iron is on a smooth and stable surface, placed vertically. Then put
the plug into the socket and adjust the temperature adjusting knob on or
above * level according to your fabric material needs . The
temperature below * level is for dry ironing only.
3. After about 1.5 to 3 minutes, the indicator will turn off, when the
indicator turn on again, your can start ironing with steam.

4. Adjust the Steam Regulation Knob to place and the steam will
be released. If you want to stop, just adjust Steam regulating
Knob to place.
5. You also could press Steam Burst Button and a burst of steam will be
released from soleplate (it could be used in a vertical or a .
7. If you need some water on the clothes for easy ironing, you could press
Spray button, and some water will come out from spraying mouth
8. If steam doesn’t come out of the sole plate, it means there is no water
in the water tank now. At this moment, you must adjust Steam regulating
Knob to ” ” place. If you want it to work on with steam ironing, pull
out the plug , then . Put the plug into
the socket. Then you can continue to use it.
6. You can use the iron for vertical ironing as well.
9. After ironing is complete, turn the temperature regulation knob to “0”
position, pull the plug out of the socket, then pour the water out.
turn the temperature regulation knob to the “0” position. Put the plug
into the socket again and adjust the steam regulating knob to place,
till no water inside. This process will prevent scale formation and damaging
ill no water inside. This process will prevent scale formation and damaging

for Powerful burst steam by strong steam button:
Strong and High-pressure steam helps to smooth the gauffer
1. Dry Cleaning Function:
Strong and powerful steam will give you a wonderful effect,
no less than a dry cleaning shop.
2. Sterilization Function:
With a 100o C high temperature burst of steam, all kinds of germs will be
killed. It can be used in your kitchen, toy, mattress, sofa and so on
3. Removes Bad Odour:
With High-pressure steam burst, bad smell could clear away.
4. Convenience:
Correct fabric ironing
Attention:
1. Heat sensitive clothes ironing, please cover a piece of cloth on the
ing, otherwise the clothes will be burnt.
2. Different material ironing, please adjust temperature according to the
heat resistant of the material.
discription missing

Correct ironing with steam
Before using, please read the items as follow:
1. Fill in cold boiled water or pure water.
2. According to fabric material, adjust the temperature. If you are not
familiar with the cloth material, you may choose a piece for testing and
adjust the temperature accordingly.
Cloth
material
Temperature
setting
Marks in
clothes
Preferable ironing method
Nylon * Ironing the back of clothes
without any water or cover a
piece of cloth on the goods you
want to iron
Synthetic
fabric or Silk
* Dry ironing the back of the
clothes
Wool **
According to the thickness and
gauffer to iron with steam. For
some fuscous clothes, we
would better adopt to back
Cotton ***
Linen
MAX
ironing.

3. When the soleplate reaches its adjusted temperature, the indicated light
turns off, then you can start ironing.
4. Use the steam burst function to recover the elasticity of the fabric. Rub
and press the polished cloth, then it will come back. If burst steam to
the opposite side of the cloth at the same time, the effect will be better.
5. Do not put the ironed clothes into wardrobe immediately. Hang the
clothes to clothes rack till it is cold.
6. After ironing, pour out the rest water . If some
water left in the water tank, put the plug into the socket for dry ironing
for a while. You can pull the plug out till you make sure no water in it.
7. Keep the iron upright. And the life of the iron can be longer.
Troubleshooting
Water tank Temperature
adjusting knob
Steam bore power
supply
Heating body
power
No steam * * * *
Little steam * * *
Can not heat up * *
Cloth burnt and
shrink *
Water drop from the
steam bore *
water tank
without
water
Temperature
adjusting knob
in the correct
position or not,
choose a right
temperature,
Clean out
dirts from
steam bore
check the
indicator light
is working or
not, and
power supply
correctly
Check if the
indicator light is
on
Inspection
part
Failure
