Lloyd LI2788ES User manual

Please read these instructions manual carefully before using the appliance
LI2788ES
INSTRUCTION MANUAL
STEAM IRON

Dear Customer
Congratulations on being the proud owner of Lloyd Steam
Iron. Your Steam Iron comes with a Lloyd Guarantee of
Quality.
Lloyd takes great pride in providing its customers with perfect
products that adheres to international quality standards.
Lloyd is committed to provide the ultimate customer
satisfaction as nothing brings us greater joy than having
satisfied customers of Lloyd.
At Lloyd, feedback and suggestions based on your product
usage experience are greatly appreciated.
Please feel free to contact us at [email protected]
NIPUN SINGHAL
DIRECTOR

Attention:
* Please read the owner’s manual before using the product.
* Before using, please check the voltage of the product if it is the same
with the one in your home.
* When using steam ironing and self cleaning function, you are
recommended to use distilled water.
* The water will leak from the soleplate if using ironing with steam but
temperature below level **. Please note, its a normal
phenomenon.
* During the iron is electrified, operator must not leave, and let
children not touch the iron.
*
* After using, turn the steam knob to “ ”, turn the temperature
regulating knob to “0”, pull out the plug, put the iron on the smooth
and stable place vertically.
* If the supply cord is damaged, it must be replaced by the
* The iron is not to be used if it has been dropped, if there are visible
signs of damage or if it is leaking.
service personnel in order to avoid a hazard.

* The iron must be used and placed on a stable surface.
* When placing the iron on its stand, ensure that the surface on which
the stand is placed is stable.
* Children should be supervised to ensure that they do not play with
the appliance.

Main features:
The product has many functions such as Temperature Regulation, Water
Spray, Dry Ironing, Steam Function, Burst of Steam Function etc. and has
an aesthetic shape and appeal.
A: Steam regulating Knob G: Water tank
B: Strong steam button H: Non-Stick Soleplate
C: Spraying button I: Spraying mouth
D: Indicator bulb J: Cover
E: Movable wire K: Self-clean button
F: Temperature Resistant Board

1. High precision temperature adjuster: high precision temperature
adjuster was used; it is called thermostat. W rature
range according to the kind of materials.
2. Thermal Fuse protecting: when the working temperature pass its
normal one. The fuse will melt automatically, and cut off the power
supply. When the failure happens, it must be sent to its service agent
in order to avoid a hazard.
Method of Operation
Steam Ironing:
1. Before ironing, please make sure the material can be ironed.
2.
reaches the “max” position. Water capacity is 300g.
3. Push the cap back to its original position.
4. Turn the temperature regulation knob to the “0” position, ensure the
iron is on the smooth and stable surface, placed vertically. Then put the
plug into the socket.
5. After about 1.5 to 3 minutes, the indicator will turn off, when the
indicator turn on again, your can start ironing with steam.

6. Press the steam burst button, the steam will burst continuously (you
can use it i ) .If you want to stop, just turn off
the steam button
7. You can use vertical ironing as well for clothes which are hung on.
8. During ironing clothes, if you need some water on the clothes for easy
iron, you could press Spray button, and some water will come out from
spraying mouth
9. If no steam goes out, it means there is no water in the water tank
now. At this moment, you must turn off the steam button. If you want it
to work on, pull ou
socket. Then you can continue to use it.
10. After ironing is complete, turn the temperature regulating knob to “0”
position, pull the plug out of the socket. Then pour the water out and
turn the temperature regulating knob to the “MAX” position. Put the
plug into the socket again and press the steam button again and again,
till no water inside. This method is used to prevent remained water into
boil off box, and damage the steam function. This process will prevent
scale formation and damaging the box from left over water.

Function
Powerful steam spurting:
Strong and High-pressure steam helps
1. Dry Cleaning Function:
Strong and powerful steam will give you a wonderful effect, no less than a
dry cleaning shop.
2. Sterilization Function:
With a 100o C high temperature burst of steam, all kinds of germs will be
killed. It can be used in your kitchen, toy, mattress, sofa and so on
3. Removes Bad Odour:
With High-pressure steam burst, bad smell could clear away.
Correct fabric ironing
Attention:
1. Heat sensitive clothes ironing, please cover a piece of cloth on the
ing, otherwise the clothes will be burnt.
2. Different material ironing, please adjust temperature according to the
heat resistant of the material.

Cloth
material
Temperature
setting
Marks in
clothes
Preferable ironing method
Nylon * Ironing the back of clothes
without any water or cover a
piece of cloth on the goods you
want to iron
Synthetic
fabric or Silk
* Dry ironing the back of the
clothes
Wool **
According to the thickness and
gauffer to iron with steam. For
some fuscous clothes, we
would better adopt to back
Cotton ***
Linen MAX
Correct ironing with steam
Before using, please read the items as follow:
1. Fill in cold boiled water or pure water.
2. According to fabric material, adjust the temperature. If you are not
familiar with the cloth material, you may choose a piece for testing and
adjust the temperature accordingly.
ironing.

3. When the soleplate reaches its adjusted temperature, the indicated light
turns off, then you can start ironing.
4. Use the steam burst function to recover the elasticity of the fabric. Rub
and press the polished cloth, then it will come back. If burst steam to
the opposite side of the cloth at the same time, the effect will be better.
5. Do not put the ironed clothes into wardrobe immediately. Hang the
clothes to clothes rack till it is cold.
6. After ironing, pour out the rest water . If some
water left in the water tank, put the plug into the socket for dry ironing
for a while. You can pull the plug out till you make sure no water in it.
7. Keep the iron upright. And the life of the iron can be longer.

Troubleshooting
Water tank Temperature
adjusting knob
Steam bore power
supply
Heating body
power
No steam * * * *
Little steam * * *
Can not heat up * *
Cloth burnt and
shrink *
Water drop from the
steam bore *
water tank
without
water
Temperature
adjusting knob
in the correct
position or not,
choose a right
temperature,
Clean out
dirts from
steam bore
check the
indicator light
is working or
not, and
power supply
correctly
Check if the
indicator light is
on
Inspection
part
Failure
