Lncoon JC261P User manual

JC261P Dash Camera
(User Manual)
Email: [e-mail]
Website: www.lncoon.com
Tracking Platform: lncoon.com/download
@Lncoon
@lncoon.gps
WhatsApp Group

Content List
Appearance ..............................................................................................................................................3
Accessories ...............................................................................................................................................3
Hardwire connection ................................................................................................................................4
Wiring Diagram.........................................................................................................................................6
Install SIM & TF Card.................................................................................................................................7
Download App ..........................................................................................................................................8
Sign up & Log in ........................................................................................................................................9
Add Device..............................................................................................................................................10
Top up ....................................................................................................................................................12
Ensure Device Online ..............................................................................................................................13
Status Indicator.......................................................................................................................................13
Device Inactive ........................................................................................................................................................13
Device Offline..........................................................................................................................................................13
Install Camera.........................................................................................................................................14
Install Accessories...................................................................................................................................15
Get Help..................................................................................................................................................16
App Instruction.......................................................................................................................................17
Media Center..........................................................................................................................................18
Live Stream.............................................................................................................................................19
Event Video Setting.................................................................................................................................20
Real Time Tracking..................................................................................................................................21
History Playback .....................................................................................................................................22
Geo Fence...............................................................................................................................................23
Alert Setting............................................................................................................................................24
FAQ.........................................................................................................................................................25
LED Indicators.........................................................................................................................................26

Appearance
Accessories
External SOS Key*1
Screwdriver*1
Hardwire Cable*1
Relay*1
Screw*2
Card Slot Cover*1
Windshield
3M Mount *1
GSM
GPS
Power
Speaker
Light sensor
Mount
Front camera 1080P
Inner camera 720P
IR light
Restart Button
SIM&TF
Slot

Hardwire connection
⚫Wire Definition:
⚫Install Video: JC261P Install Guide
⚫How to connect:
1. Connect Power Supply: Take out the attached wire, connect the red end to
the positive of the car battery, and the black end to the negative.
If the device is powered on successfully, the red LED will light up.
(When the engine is turned on, a 12V voltage can be detected with a multimeter between
the positive and negative)
2. ACC Detection: Connect the yellow end to the ACC fuse to ensure the engine
detection works correctly.
3. Remote Power Cut-off (Optional):
(i)Find the fuel tank wire and cut it in two at the proper location.
GND
Black
Battery - (Negative)
B+
Red
Battery + (Positive)
ACC
Yellow
Remote Fuel Cut
Green
White
ACC

5
(ii)Twist the white end and the green (87a) end together and connect to the
end of the oil pump wire near the ACC fuse.
(iii)Connect the green (30) end to the end of the oil pump wire near the oil
pump.
(iv)Connect the yellow end(camera end) to the yellow end(86) of the relay to
ensure the fuel cut-off works correctly.

6
Wiring Diagram
⚫Please connect the wires when ACC off. Once the wiring is completed, connect the
cable bus to the power cord of the camera.
⚫If the device turned even the ACC is off, it means the ACC line is connected incorrectly.
Please check the wiring again.
⚫Ignite the car and the camera turns on, means the device is connected correctly.

7
Install SIM & TF Card
⚫SIM Card Standards: 4G/3G/2G Nano SIM
⚫Recommend: Lncoon SIM
Before install, you can confirm the following points in
advance:
1. The PIN is disabled.
2. There is no restriction of the IMEI# from the operator.
3. The SIM card is with balance and data.
⚫TF Card Standards: 32GB to 258GB TF Card
⚫Recommend: 128GB TF Card (FAT32 Speed Class 10)
Install Step:
⚫ACC off, insert both SIM and TF card into the camera.
⚫Turn on the car and press the restart button to restart.
⚫Once the blue led went solid, means the SIM is working.

8
Download App
⚫Search “Lncoon IOT” in App Store or Google Play to
download.
⚫Visit Lncoon website: Lncoon.com/download to find
quick download link.
Download
LNCOON IOT
LNCOON IOT

9
Sign up & Log in
⚫Click Sign Up
①Choose your country or region
②Enter a valid email address
③Click ‘→’ to get a verification code from [e-mail]
*(If no email received, please check the trash or spam.)
④Set up and confirm Password
⑤Check and agree the terms and policy
⑥Click on Submit
*The App will automatically log in to your account, please remember your account
and password for future login.
①
②
③
④
⑤
⑥

10
Add Device
1. Click the ‘+’ on the top right to add device.
2. Scan or type in the IMEI number on the package or device body.
Add Device
Find the IMEI barcode on
package or camera body
Scan barcode to quickly
enter IMEI
(To use this feature, the App will ask to
allow phone camera authorization)

11
3. Click ‘Add Device’ to confirm.
4. Edit basic info about this device, or click on ‘Save’ directly to
skip this step.
5. You can always come back and edit in the ‘Detail’ Page later.
Edit
JC261P
JC261P
JC261P

12
Top up
⚫Activate with Lncoon SIM card
1. Go to ‘List’, you will see the device you just bind.
2. Click the ‘Top-up’ icon, or go to plan.lncoon.com
3. Choose a plan and finish the payment.
4. Restart the camera to activated.
*Alternate top-up page: lncoon.com/JC261P
⚫Activate with another SIM card
If the camera did not activate after restart. Please try send the APN command
via text messages to the SIM inside the camera.
1. For AT&T SIM, please copy and send:
APN,NXTGENPHONE,NXTGENPHONE,310,410#
2. For T-MOBILE SIM, please copy and send:
APN,fast.t-mobile.com,fast.t-mobile.com,310,260#
If still not working, then try send:
APN,epc.tmobile.com,epc.tmobile.com,310,240#
3. For VERIZON SIM, please copy and send:
APN,vzwinternet,vzwinternet,310,12#
JC261P

13
Ensure Device Online
1. Go to ‘List’, you will see the JC261P you just bind.
2. You can tell the status of the device via the color of the icons.
3. When the icons displayed in green or orange or red, it means the
device is online.
Device Inactive
⚫Check the LED indicators and contact us.
Device Offline
⚫Check whether the device is well connected to the power supply.
⚫Check whether your SIM card balance has been used up.
⚫Check the LED indicators and contact us.
OFFLINE
Status Indicator
JC261P

14
Install Camera
1. Wind the connected hardwire wire to the top of the windshield
along the red dotted line.
2. After confirming the installation position of the camera, bury the
cable into the lining of the car to fix the power cable.
3. Wipe and clean the windshield, and then attach the 3M mount to
the windshield.
4. Install the camera on the mount.

15
Install Accessories
⚫SOS key:
It is used to seek help in emergencies. Connect the SOS key to the
corresponding interface on the device, remove the protective film
from the 3M tape, and then attach it to a proper position (such as
① in the above figure).
⚫Relay:
It is used to cut off the power and fuel of the vehicle remotely to
force it to stop (only when the moving speed is lower than 20km/h
or 12.4mph). Connect it to the corresponding interface on the
device and place it in a proper position, such as ②in the above
figure.

16
Get Help
⚫Live chat with us by clicking the service icon
⚫Email: [e-mail]
⚫Messenger us on Facebook: m.me/lncoon
⚫Check the FAQ Library on website: lncoon.com/FAQ

17
App Instruction
⚫Bottom Menu
⚫Console Menu
1. Tapping the icon to check the device.
2. Tapping the button to expand the menu.
Map Page
Device List
Alerts Report
Account Setting
Note:
If there is no map display, please install Google Maps app.
Device Status
Last Location
Console Menu

18
Media Center
⚫Tapping on ‘Camera’ to enter Media Center.
Live Stream
Record Video
Take Snapshot
Check Media
Share Video
Remove Video
Connect TF Card

19
Live Stream
⚫Tapping on ‘Live’ on Media Center to check live video.
To check multi-channel of multi devices, you can login
on LNCOON web platform: https://us.lncoon.com
Switch Channel
History Video
Full Screen
Record Video
Talk to Driver
Take Snapshot
Voice On/Off
Time & Speed
Current Location

20
Event Video Setting
⚫Tapping on ‘Setting’ to turn on/off event video.
Upload only Front / Inward
Upload both Front & Inward
