KNIGHT®FLOOR STANDING AND WALL MOUNT HEATING BOILERS
KNIGHT
HEATING BOILER
Submittal Sheet
KBN-Sub-09
JOB NAME ______________________________________________________________________
LOCATION ______________________________________________________________________
ARCH./ENGR.____________________________________________________________________
WHOLESALER __________________________________________________________________
MECH. CONTRACTOR ___________________________________________________________
MODEL NO. _____________________________________________________________________
TYPE GAS ______________________________________________________________________
Btu/hr INPUT_____________________________________________________________________
Btu/hr OUTPUT___________________________________________________________________
NOTES
Standard Features
>Energy Star®Qualified
> Up to 96% DOE AFUE Efficiency
> Modulating Burner with 5:1 Turndown
> Direct-Spark Ignition
> Low NOx Operation
> Field Convertible from Natural to LP Gas
> Vertical & Horizontal Direct-Vent
> PVC, CPVC or SS Venting up to 100 Feet
> Factory Supplied Sidewall Vent Termination
> ASME Stainless Steel Heat Exchanger
> Automatic Reset High Limit
> Inlet & Outlet Temperature Sensors
> Boiler Circulating Pump
> 30 psi ASME Relief Valve
> Adjustable Leveling Legs (KB Models only)
> Wall Mount Bracket (WB Models only)
> Zero Clearances to Combustible Material
> 12 Year Limited Warranty (See Warranty for Details)
SMART SYSTEMTM Features
> SMART SYSTEM Digital Operating Control
> 2 line, 16 Character Display
> Dual Level Password Security
> Domestic Hot Water Prioritization
> Built in Cascading Sequencer for up to 8 Boilers
> 0-10 VDC Input Control
> Outdoor Reset Control with Outdoor Air Sensor
> Low Water Flow Safety Control & Indication
> Alarm on Any Failure Contacts
> Service Reminder
> Freeze Protection
> Night Setback
> Time Clock
> Three Pump Control (System, Boiler & DHWP)
> Data Logging
> Examples: Hours Running, Space Heating
> Programmable System Efficiency Optimizers
> Examples: Anti-cycling, Ramp Delay
Optional Equipment
Place an X in the box by all options that apply
Adjustable High Limit w/ Manual Reset
Flow Switch
Low Water Cutoff w/Manual Reset & Test
Alarm Bell
Concentric Vent Kit
Condensate Neutralization Kit
SMART SYSTEM PC Software
Multi-Stack Frame
Firing Codes
M9 Standard Construction
M7 California Code

Lochinvar Corporation • 300 Maddox Simpson Pkwy • Lebanon, TN 37090 • 615-889-8900 / Fax: [phone]
www.Lochinvar.com
5/09—Printed in U.S.A.
KNIGHT Heating Boiler and Wall Mount Dimensions & Specifications
KNIGHT Heating Boiler Dimensions & Specifications
M
Models:
KBN80-210
Models:
WBN50-210
Models:
KBN285
Input Heating NET
Model Min Max AFUE Capacity I=B=R Gas Water Air Vent Shipping
Number MBH MBH % MBH MBH A C D E F G H I J K M Conn. Conn. Inlet Size Weight
WBN050 10 50 95.3 45 39 29-1/4" 15-3/4" NA 10-3/4" 10-3/4" 2" 6-3/4" NA 3-1/4" 4-1/4" 2-3/4" 1/2" 1" 2" 2" 130
WBN080 16 80 95.3 72 63 29-1/4" 15-3/4" NA 10-3/4" 10-3/4" 2" 6-3/4" NA 3-1/4" 4-1/4" 2-3/4" 1/2" 1" 2" 2" 130
WBN105 21 105 95.4 94 82 29-1/4" 15-3/4" NA 10-3/4" 10-3/4" 3-1/2" 5-1/2" NA 3-1/4" 4-1/4" 2-3/4" 1/2" 1" 2" 2" 134
WBN150 30 150 95.5 135 119 29-1/4" 20-3/4" NA 15-3/4" 8-1/2" 3-1/2" 5-1/2" NA 8-3/4" 9-3/4" 1-1/2" 1/2" 1" 3" 3" 162
WBN210 42 210 95.7 190 165 29-1/4" 25" NA 20" 12" 3-1/2" 5-1/2" NA 13" 14" 1-1/2" 1/2" 1" 3" 3" 177
KBN080 16 80 95.3 72 63 33-1/4" 14" 7" 5-3/4" 5" 3" 20-1/2" 22" 1-3/4" 6-1/2" NA 1/2" 1" 3" 3" 125
KBN105 21 105 95.4 94 82 33-1/4" 14" 6-1/2" 5-3/4" 4-1/2" 1-1/2" 20-1/2" 22" 1-3/4" 6-1/2" NA 1/2" 1" 3" 3" 129
KBN150 30 150 95.5 135 119 33-1/4" 18" 12-1/4" 11-1/2" 10" 1-1/2" 21-1/4" 23" 1-3/4" 12" NA 1/2" 1" 3" 3" 157
KBN210 42 210 95.7 190 165 33-1/4" 22-1/4" 16-1/2" 15-3/4" 14-1/4" 5-1/4" 21-1/4" 23" 1-3/4" 16-1/4" NA 1/2" 1" 3" 3" 172
KBN285 57 285 96.0 260 226 42-1/2" 19-3/4" 12-3/4" 13-1/2" 6" 2" 34" 31" 11-3/4" 4-1/4" NA 3/4" 1-1/4" 4" 4" 224
Notes: Performance data based on manufacturer’s test results. Indoor installation only. All information subject to change. Change “N” to “L” for LP gas models.
