Lochinvar EcoSword LGC 160-210 G P CE Guide

Installation, Commissioning,
User & Maintenance Instructions
LV 313582 | May 2021
0313582 R4.0 / 1821 - Changes Reserved
Models:
LGC 160-210 G P CE and PG P CE
LGC 160-350 G P CE and PG P CE
LGC 200-210 G P CE and PG P CE
LGC 200-350 G P CE and PG P CE
LGC 245-420 G P CE and PG P CE
LGC 245-560 G P CE and PG P CE
LGC 285-420 G P CE and PG P CE
LGC 285-560 G P CE and PG P CE
LGC 380-560 G P CE and PG P CE
EcoSword
Gas Fired Condensing
Water Heater

These instructions must be read and understood before installing, commissioning, operating
or maintaining the equipment.
IMPORTANT INFORMATION
!

Preface
Copyright
Copyright © 2020 Lochinvar Ltd.
All rights reserved.
Nothing from this publication may be copied, reproduced and/or published by means of
printing, photocopying or by whatsoever means, without the prior written approval of
Lochinvar Ltd..
Lochinvar Ltd. reserves the right to modify specifications in this manual.
Trademarks
Brand names in this manual are registered trademarks of their respective owners.
Warranty
Refer to the appendix Warranty (see 13.6) for the warranty provisions.
Liability
User
Lochinvar accepts no liability when the water heater is not used correctly and requires the
user to:
•Read this manual carefully and obey the instructions.
•Ask your installation engineer for advise about the use of the water heater.
•Make sure that the service and maintenance activities are done by a qualified
engineer.
•Store the manual, in good condition, near the water heater.
Installation engineer
Lochinvar accepts no liability when the water heater is not used correctly and requires the
installation engineer to:
•Read this manual carefully and obey the instructions.
•Make sure that the entire water heater installation complies with the applicable
regulations (on page 4).
•Make sure that the water heater is tested before the installation is taken into use.
•Explain the correct use to the user.
•Notify the user when service and maintenance activities are necessary.
•Make sure that you hand over all applicable manuals.
0312582_EcoSword_V4.0, 03-05-2021 3

Supplier
The EcoSword water heater is designed in accordance with the applicable regulations. The
water heater is delivered with the CE-marking and all necessary documentation to obey
these regulations. See the compliance section. (on page 4)
Lochinvar accepts no liability for claims from third parties when:
•The instructions for the correct installation of the water heater are not obeyed.
•The instructions for the correct use of the water heater are not obeyed.
•The water heater did not have maintenance on the correct maintenance interval.
For more information, refer to the General Terms of Sales. These are available on request,
free of charge.
We believe that this manual provides you with accurate and complete descriptions of all
relevant components. If you, nonetheless find errors or inaccuracies in this manual, please
inform Lochinvar. This helps us to further improve our documentation.
Compliance
To safely produce domestic hot water, the design and construction of the EcoSword water
heaters is in accordance with:
•the European Regulations 2016/426 on appliances burning gaseous fuels (GAR).
•the European Standard for Gas–fired storage water heaters for the production of
domestic hot water (EN89).
•The European ECO-Design Directive.
•The European Energy Labeling Directive
Refer to the appendix Declaration of conformity (see 13.5).
Regulations
It is law that all gas appliances are installed by competent persons, in accordance with The
Gas Safety (Installation and Use) Regulations 1998. Failure to install appliances
correctly could lead to prosecution. It is in your own interest, and that of safety, to ensure
that this law is complied with. The installation of the equipment MUST be in accordance
with the relevant requirements of the Gas Safety Regulations, Building Regulations,
I.E.E. Regulations and the bylaws of the local water undertaking.
In addition, the installation should follow the relevant guidance offered in the following
documents. It is not practical to list all relevant information due to continuous changes but
emphasis is placed on the following documents, as failure to comply with the guidance
given will almost certainly result in an unsatisfactory installation:
•Institute of Gas Engineers and Managers (IGEM) Publications
•CIBSE Guides
•Clean Air Act
•H.S.E Guidance
Note
Manufacturer's notes must not be taken in any way as overriding statutory obligations.
Contact information
In the event of problems with your gas, electricity or water supply connections or when
you have any comments or questions, please contact your (energy/water) supplier.
n
4

About this manual
Scope
This manual gives information about safe and correct use of the water heater and how
installation, maintenance and service activities have to be done correctly. You must obey
the instructions in this manual.
Caution
Read this manual carefully before you start the water heater. It can cause personal injury
and damage to the water heater when you do not read the manual and/or do not obey
the instructions.
The purpose of this manual is to:
•describe the working principles and layout of the water heater
•explain the safety devices
•highlight possible hazards
•describe the use of the water heater
•describe the installation, service and maintenance of the water heater
This manual has two parts:
•An User part that describes the correct usage of the water heater.
•An Installation, Maintenance and Service part, that describes the correct installation
and maintenance procedures.
Target group
The information in this manual applies to three target groups:
•users
•installation engineers
•service and maintenance engineers
The User part is intended for the (end) users. The Installation, Maintenance and Service
part is intended for the installation engineers and the service and maintenance engineers.
Notation conventions
This manual uses the following text conventions:
•Numbers between parentheses e.g. (1), refer to elements in a figure that are
described by the text.
•Texts displayed on the user interface always are shown similar to the characters in
the display, for example parameter 120 or Off.
•Buttons are always shown between brackets, for example: [], [ENTER], [RESET].
•Cross-references to sections, tables, figures etc. are underlined and written as (see
section "..."). In the digital version, the cross-references function as hyperlinks that
can be used to navigate through the manual by clicking on them. Example: Safety
(see 2).
c
0312582_EcoSword_V4.0, 03-05-2021 5

This manual contains the following text styles/symbols for situations that may endanger
users/engineers, cause damage to equipment or need special attention:
Note
A note gives more information on a topic.
Caution
Obey the caution instructions to prevent damage of the water heater.
Warning
Obey the warning instructions to prevent danger of personal injury, and serious damage
to the water heater.
Document identification
Article number Language Version
0312582 EN 4.0
n
c
w
6

Table of Contents
Preface........................................................................................ 3
Copyright.......................................................................... 3
Trademarks....................................................................... 3
Warranty...........................................................................3
Liability.............................................................................3
Compliance....................................................................... 4
Regulations....................................................................... 4
Contact information............................................................ 4
About this manual....................................................................... 5
Scope............................................................................... 5
Target group......................................................................5
Notation conventions.......................................................... 5
Document identification.......................................................6
User part.................................................................. 11
1 Introduction.............................................................................. 13
2 Safety........................................................................................15
3 Interface................................................................................... 17
3.1 Operator interface............................................................ 17
3.1.1 Control Switch..................................................................17
3.1.2 Buttons........................................................................... 18
3.1.3 LCD display..................................................................... 18
3.2 Status of the water heater................................................. 19
3.2.1 Operating modes.............................................................. 19
3.2.2 Error conditions................................................................20
3.2.3 Service conditions.............................................................20
3.2.4 Anode warning................................................................. 21
4 Use............................................................................................ 23
4.1 Set a parameter value.......................................................23
0312582_EcoSword_V4.0, 03-05-2021 7

4.2 Turn on the water heater................................................... 23
4.2.1 Switch to ON mode........................................................... 23
4.2.2 Set the water temperature.................................................23
4.3 Turn off the water heater................................................... 23
4.3.1 Turn off for a short period.................................................. 23
4.3.2 Isolate from the mains...................................................... 24
4.3.3 Turn off for a long period................................................... 24
Installation, Maintenance and Service part.............. 25
5 Introduction.............................................................................. 27
5.1 About the water heater..................................................... 27
5.2 Working principle..............................................................27
6 Safety........................................................................................29
6.1 Safety instructions............................................................29
6.2 Instructions on the water heater.........................................30
6.3 Safety devices..................................................................31
6.4 Environmental aspects...................................................... 32
6.4.1 Recycling.........................................................................32
6.4.2 Disposal.......................................................................... 32
7 Water heater............................................................................. 33
7.1 Structure of the water heater............................................. 33
8 Installation............................................................................... 35
8.1 Packaging........................................................................35
8.2 Conditions....................................................................... 35
8.2.1 Ambient conditions........................................................... 35
8.2.2 Maximum floor load.......................................................... 35
8.2.3 Water composition............................................................ 36
8.2.4 Working clearances...........................................................36
8.2.5 Level the water heater...................................................... 36
8.3 Installation diagram..........................................................37
8.4 Water connections............................................................ 38
8.4.1 Cold water connection....................................................... 38
8.4.2 Hot water connection........................................................ 38
8.4.3 Circulation connection....................................................... 38
8.5 Condensate drain............................................................. 39
8.6 Gas connection.................................................................39
8.7 Venting system................................................................ 39
8

8.7.1 C13/C33 concentric systems.............................................. 41
8.7.2 C13/C33 parallel systems.................................................. 44
8.7.3 C43/C53/C63 systems.......................................................46
8.8 Electrical connections........................................................ 47
8.8.1 Preparation......................................................................47
8.8.2 Mains power.................................................................... 48
8.8.3 Optional electrical connections............................................48
8.8.4 Finalization...................................................................... 50
8.9 Commissioning.................................................................51
8.9.1 Filling..............................................................................51
8.9.2 Air pressure differential..................................................... 51
8.9.3 Gas supply pressure..........................................................52
8.9.4 CO2 value........................................................................53
8.9.5 Turn on the water heater................................................... 54
8.10 Decommisioning...............................................................54
8.10.1 Turn off the water heater................................................... 54
8.10.2 Draining.......................................................................... 54
9 Conversion of gas type.............................................................. 55
10 Settings.....................................................................................57
10.1 Operator interface............................................................ 57
10.2 Parameters...................................................................... 57
10.3 Hysteresis....................................................................... 59
10.4 Error history.................................................................... 60
10.5 Test cycle........................................................................ 60
10.6 Legionella prevention........................................................ 60
11 Maintenance.............................................................................. 61
11.1 Performance check........................................................... 61
11.2 Preparation......................................................................62
11.3 Water-side maintenance.................................................... 62
11.3.1 Descale the tank.............................................................. 62
11.3.2 Clean the condensate drain................................................63
11.4 Gas-side maintenance....................................................... 63
11.4.1 Clean the burner.............................................................. 63
11.4.2 Clean the combustion chamber...........................................65
11.4.3 Assemble the burner.........................................................66
11.5 Finalization...................................................................... 66
0312582_EcoSword_V4.0, 03-05-2021 9

12 Troubleshooting........................................................................ 69
12.1 Errors and warnings..........................................................69
12.1.1 General errors..................................................................69
12.1.2 Displayed errors............................................................... 72
12.1.3 Warnings.........................................................................78
13 Appendices................................................................................79
13.1 Technical details............................................................... 79
13.2 Dimensions......................................................................80
13.3 Gas details...................................................................... 82
13.3.1 Energy labeling................................................................ 83
13.4 Electrical wiring diagram....................................................85
13.5 Declaration of conformity...................................................87
13.6 Warranty......................................................................... 88
Index........................................................................................ 91
10

User part
0312582_EcoSword_V4.0, 03-05-2021 11

12

1 Introduction
The EcoSword water heater stores and heats water for sanitary purposes.
Cold water enters the bottom of the tank through the water inlet (1). The heated water
leaves the tank at the top through the hot water outlet (2). To operate the water heater,
the display (3) and control switch (4) are used.
Fig. EcoSword water heater
1
2
3
4
1. Water inlet
2. Water outlet
3. Operator interface
4. Control switch
0312582_EcoSword_V4.0, 03-05-2021 13

14 User part

2 Safety
Lochinvar cannot be held responsible for damages or injuries which can be lead back to:
•Failure to follow the instructions provided in this manual.
•Carelessness during use or maintenance of the water heater.
Every user must study the user part of this manual and must follow the instructions in this
part of the manual strictly. Do not change the sequence of the described actions. This
manual must be available for the user and service engineer at all times.
Warning
If you smell gas:
•Shut off the mains gas supply valve!
•Avoid causing sparks! Do not use any electrical equipment or
switch, i.e. no telephones, plugs or bells!
•No naked flames! No smoking!
•Open windows and doors!
•Warn occupants and leave the building!
•After leaving the building, alert the gas distribution company or
your installation engineer.
w
Caution
Do not store or use chemical substances in the room where the water heater is installed
because of the risk of explosion and corrosion of the water heater. Some propellants,
bleaching agents and degreasing agents etc. disperse of explosive vapors and/or cause
accelerated corrosion. If the water heater is used in a room where such substances are
stored or used, the warranty will be void.
Caution
Installation, maintenance and service may only by carried out by a qualified engineer.
Caution
The water heater is not intended for use by persons (incl. children under the age of 16)
with reduced physical, sensory or mental capacities, or who lack the necessary
experience or knowledge. When the person responsible for their safety is supervising or
has explained how the water heater should be used, these persons can use the water
heater.
Caution
This water heater is not intended to be used by children under the age of 16. Always
supervise children, and make sure that they do not play with the water heater.
Note
Regular maintenance extends the service life of the water heater. To determine the
correct service interval, the service and maintenance engineer must do a check on both
the water and gas side of the water heater three months after installation. Based on this
check, the best service interval can be determined.
c
n
0312582_EcoSword_V4.0, 03-05-2021 15

16 User part

3 Interface
3.1 Operator interface
The operator interface consists of:
•a control switch (see 3.1.1) on the left side of the water heater
•5 push buttons (see 3.1.2) to navigate through the menu
•a LCD-display (see 3.1.3) that shows settings, functions, values and errors.
The operator interface is parameter driven and enables the user to change parameters and
to verify the status and history of the water heater.
Fig. Operator interface
2
1
1. LCD display
2. Push buttons
3.1.1 Control Switch
With the control switch you can activate and deactivate the controller of the water heater.
Warning
The power of the water heater stays on when the control switch is set to 0.
When the control switch is set to I, the display first shows ini for some seconds. After
that, the display shows OFF.
Fig. Display
w
0312582_EcoSword_V4.0, 03-05-2021 17

3.1.2 Buttons
The 5 buttons on the operator panel give access to the menu of the water heater.
Button Function
[ ] Scroll up / Raise
[ ] Scroll down / Lower
[ENTER] Enter / Confirm
[RESET] Reset / Cancel
[MENU] Go to menu
3.1.3 LCD display
The LCD display shows 7 different symbols around the outer edge of the display and 3
characters in the center of the display. The characters represent parameters.
Fig. LCD display
2
1
1. Characters
2. Symbols
The symbols on the display show visual information about the status of the water heater.
Symbol Explanation
Heat demand present
Water heater in operation
Water heater not in operation - ERROR
Frost protection is activated
Scroll through menu
Shown on the right side corners of the display
External ON mode is activated
Shown on the upper left side corner
18 User part

The user menu parameters are:
Parameter Description Unit/Value Adjustable Range Default
001 Turn the water heater on or off. OFF
ON
Yes OFF - water heater off (OFF
mode)
ON - water heater on (ON
mode)
OFF
002 Setpoint ON mode ºC Yes 40…max setpoint (1) 65
003 Hysteresis ºC Yes 2…15 10
004 Turn setpoint EXT mode (005)
on or off.
ENA
dIS
Yes ENA - Enable
dIS - Disable
dIS
005 (2) Setpoint EXT mode ºC Yes 40…max. setpoint (1) 70
1 - The maximal setpoint (parameter 207) is factory set at 70. A qualified engineer can modify this
value.
2 - Parameter 005 will only be accessible when parameter 004 is set on ENA.
3.2 Status of the water heater
During operation, the display shows the status of the water heater.
3.2.1 Operating modes
The EcoSword has 3 operating modes:
•OFF mode (see 3.2.1.1)
•ON mode (see 3.2.1.2)
•External ON mode (EXT mode) (see 3.2.1.3)
3.2.1.1 OFF mode
Use parameter 001 to switch the water heater to OFF mode.
In the OFF mode the water heater is de-activated. The display shows the characters OFF.
Fig. OFF mode display Fig. Frost protection is activated
To prevent that the water in the system freezes, the frost protection is activated when the
water heater is in OFF mode. The frost protection starts when the temperature of the
water drops below 5°C. The display shows the frost protection symbol.The water heater
will heat the water to 20°C and then turns back to OFF mode.
3.2.1.2 ON mode
Use parameter 001 to switch the water heater to ON mode.
In the ON mode the water heater continuously responds to the heat demand.
When the water heater is heating the water, the display on the operator interface
alternately shows two different screens. The first shows the actual temperature, the
second shows the setpoint temperature.
When the water heater is not heating the water, only the actual temperature is visible. The
symbols Heat demand and In operation will not be shown.
0312582_EcoSword_V4.0, 03-05-2021 19

Fig. Actual water
temperature
Fig. Setpoint Fig. Standby
3.2.1.3 External ON mode
In the external ON mode, the water heater will respond to a heat demand when the relay
switch is closed. Use parameter 004 to switch on the setpoint (parameter 005) of the
external ON mode.
3.2.2 Error conditions
If there is an error, the display shows an error code. Error codes always have one letter
and two digits.
Fig. Error code display
Note
When the display shows an error code, try to reset the water heater.
Contact your service and maintenance engineer or supplier when the water heater does
not restart or when the display shows the error code again.
3.2.3 Service conditions
When the display shows Src the water heater functions normally but requires periodical
service. Contact your service and maintenance engineer.
Fig. Service required display
Note
Regular maintenance extends the service life of the water heater.
n
n
