Logic AV Products LG-HMS4x4-H User manual

4K60 HDMI Matrix 4x4
VER 1.1
Model No. LG-HMS4x4-H

Thank you for purchasing this product
Surge protection device recommended
Table of Contents
For optimum performance and safety, please read these instructions carefully
before connecting, operating or adjusting this product. Please keep this
manual for future reference.
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shook, lighting strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend
the life of your equipment.
1. Introduction..........................................................................................
2. Features................................................................................................
3. Package Contents..............................................................................
4. Specifications......................................................................................
5. Operation Controls and Functions.....................................................
5.1. Front Panel...................................................................................
5.2. Rear Panel...................................................................................
6. Remote Control....................................................................................
7. PC Controller User Guider...................................................................
8. Application Example...........................................................................
1
1
1
2
3
3
3
5
5
10
Model No. LG-HMS4x4-H

1. Introduction
2. Features
HDMI2.0, HDCP2.2/HDCP1.4 compliant.
Support video format up to 4k2k@60Hz with 24bit RGB/YCbCr 4:4:4/
YCbCr 4:2:2, and up to 4k2k@60Hz with 12bit YCbCr 4:2:0.
Support color space conversions among RGB, YCbCr4:4:4, YCbCr4:2:2
and xvYCC video formats.
Support all HDMI 3D formats up to 2160p@30Hz.
Support reception of any audio data conforming tothe HDMI specification
such PCM at up to 192kHz, compressed audio (IEC 61937), DSD, DST,
DTS and HBR.
Support smart EDID management.
Support RS-232, remote control and on-panel control.
3. Package Contents
1× 4×4 HDMI Matrix
1× 12V/2.5A Power Adapter
1× HDMI Matrix IR Remote
1× Phoenix Connector (3-pin, male)
1× User Manual
1/10
The 4×4 HDMI 2.0 Matrix simultaneously four HDMI sources to four HDMI
displays. It supports transmission of video resolution up to 4K×2K@60Hz
Ultra HD YUV4:4:4 and supports high resolution digital audio formats such as
LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD MasterAudio. It
works with Blue-Ray players, Set-Top boxes, Home Theater PCs and game
consoles. Any source accessible at all times by any display by selecting it
via the supplied IR Remote Control, RS-232 or select buttons on the front
panel. Support smart EDID management.
Model No. LG-HMS4x4-H

4. Specifications
Video Bandwidth 594MHz(18Gbps)
480i, 576i, 480p, 576p, 720p, 1080i, 1080p24/25/30/
50/60, 2160P24/25/30/50/60, 4K/60Hz YCbCr 4:4:4
4×HDMI Type A [19-pin female]
1×RS-232 [3-pin Phoenix Jack]
4×HDMI Type A [19-pin female]
Human-body Model:
±8kV (Air-gap discharge), ±4kV (Contact discharge)
Power Supply
Dimensions 150mm(W)×111mm(D)×32.2 mm(H)
Weight 585g
Metal Enclosure
Black
Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity 20~90% RH (non-condensing)
Power Consumption 12W
Video Resolution
Input Ports
Output Ports
ESD Protection
Technical
2/10
HDMI Compliance HDMI 2.0
HDCP Compliance HDCP 1.4/HDCP 2.0
Color Depth 8/10/12-bit (1080p@60Hz)
8-bit (4K@60Hz/YCbCr 4:4:4)
HDMI Audio Formats
LPCM, Dolby Digital/Plus/Ex, Dolby True HD, DTS,
DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master
Audio, DSD
Connections
Mechanical
Housing
Color
Input: AC100~240V 50/60Hz Output: DC12V/2.5A
(US/EU standards, CE/FCC/UL certified)
Color Space RGB/YCbCr 4:4:4, YCbCr 4:2:2 / 4:2:0
Model No. LG-HMS4x4-H

5. Operation Controls and Functions
5.1 Front Panel
OUT A OUT B OUT C OUT D
A B C D
POWER
1 2 34 5
4
Number Function description
1
2Nixie tube
3
4
LED
POWER
5OUTPUT button A/B/C/D output channel button.
IR
When the LED light is on, the product is displayed
as standby. When the LED light is off, the product
is working.
Displays information for each output channel.
IR receive window.
Device power button.
Name
5.2 Rear Panel
RS-232
TX RX
OUTPUT
INPUT
OUT A OUT B OUT C OUT D
IN 1 IN 2 IN 3 IN 4
EDID DC 12V
1111
0 0 0 0
1
234
5
34
Number Name Function descriptions
1
2
HDMI OUTPUT
HDMI INPUT
Connect to the HDMI display device, such as
TV or Monitor.
Connect to the HDMI source device, such as
DVD player or Set top box.
3/10
Model No. LG-HMS4x4-H

3
Notice The following is the EDID schema table.
0000
0001
0010
0011
0100
0101
0110
0111
1000
1001
1010
1011
1100
1101
1110
1080p, Stereo Audio 2.0
1080p, Dolby/DTS 5.1
1080p, HD Audio 7.1
1080i, Stereo Audio 2.0
1080i, Dolby/DTS 5.1
1080i, HD Audio 7.1
3D, Stereo Audio 2.0
3D, Dolby/DTS 5.1
3D, HD Audio 7.1
4K2K30_444, Stereo Audio 2.0
4K2K30_444, Dolby/DTS 5.1
4K2K30_444, HD Audio 7.1
4K2K60_444, Stereo Audio 2.0
4K2K60_444, Dolby/DTS 5.1
4K2K60_444, HD Audio 7.1
1111EDID is controlled by the host computer
EDID mode EDID description
3 RS-232
Connect PC or use 3-pin phoenix jack line
connect control system to transmit RS-232
commands.
4/10
4
5
EDID
POWER INPUT Plug 12V DC power supply into the unit and
connect adaptor to an AC outlet.
Selects HDMI output signal format via EDID
Selector. Please check the following EDID
schema table.
Model No. LG-HMS4x4-H

6. Remote Control
Pressing this button to open the power of the
Matrix or set it as a standby state.
Pressing these keys to select the Output A,
Output B, Output C, Output D output the
corresponding 1, 2, 3, 4 input source.
7. PC Controller User Guide
Install:
PC controller is a green software, you just need a cable to connect from PC
to RS-232. Copy“4×4 HDMI matrix Controller.exe”to PC and complete install.
Preparation:
Connect PC and Matrix by RS-232 cable (headers of both sides of cable
should be FEMAL).
Power-up Matrix.
Double click“4×4 HDMI matrix Controller.exe”icon to run it.
5/10
1
2
Model No. LG-HMS4x4-H

General page
Select the RS-232 COM port.
Click to connect the matrix, no click will not connect the matrix.
Click reset to factory settings state.
Click to restart the matrix.
Select‘Enable Beep’, the matrix button sound is opened No select and
the sound is off.
The matrix has been selected‘Power on’at work, When the user is not
selected and the matrix will go in standby mode.
Click refresh device status.
Click to clear device information.
Device information display column.
1
2
3
4
5
678
9
6/10
Model No. LG-HMS4x4-H

EDID page
The controller have 3 ways to set theEDID mode: ‘manual mode’ , ‘Copy
mode’ and ‘Open EDID file mode’.
Selecting user need EDID to one input source then click the ‘Set’ button.
Copying user is selected HDMI display device EDID to one HDMI input
source then click‘set’button.
Opening user is defined EDID file to one HDMI input source then click
‘Set’ button.
Click the ‘Status’ button for fresh input EDID again.
1
2
3
4
7/10
Model No. LG-HMS4x4-H

Matrix page
The number will display OUTPUT A the corresponding input source.
Click to select IN1/IN2/IN3/IN4 input source for OUTPUT A port.
Click to select the last or the next input source for OUTPUT A port.
1
2
3
8/10
Model No. LG-HMS4x4-H

Click to open FW file(file extension is “.fw”).
Display the FW file path.
Display the progress of the software upgrade.
Click to upgrade the Matrix software.
Display the message of the software upgrade.
Upgrade page
12
34
5
9/10
Model No. LG-HMS4x4-H

8. Application Example
RS- 232
TX RX
OUTPUT
INP UT
OUT A OUT B OUT C OUT D
IN 1 IN 2 IN 3 IN 4 EDID D C 12V
1 1 1 1
0 0 0 0
DVD or Blu-ray Player
Power Supply
DVD or Blu-ray Player DVD or Blu-ray Player DVD or Blu-ray Player Notebook
UHDTV UHDTV UHDTV UHDTV
HDMI HDMI HDMI HDMI
HDMI HDMI HDMI HDMI RS-232
10/10
