Logic Instrument Fieldbook K122 User manual

Quick Start Guide
LOGIC INSTRUMENT
FIELDBOOK K122

EN
Table of contents
As we are often updating and improving our products, your device’s software may have
a slightly dierent appearance or modied functionality than presented in this Quick
Start Guide.
Package Contents 4
Description of the tablet 5
Replacing the battery 8
Inserting mini SIM & Micro-SD cards 10
Windows
Getting started 12
Connecting to a WiFi 14
Getting familiar with Windows 10 15
The Windows 10 interface 16
Windows notication center 18
Android
Getting started 20
4G & WiFi connections 22
Google & Contacts 24
Hints & tips 26

4
Package Contents
Check your product box for the following items:
-Fieldbook K101 with hand strap and battery
-Active Stylus pen
-Battery for stylus pen
-Micro USB cable
-USB host cable
-AC adapter with EU, UK and US plug
The items supplied with your device and available accessories may vary depending on
your region or service provider.
The supplied items are designed only for your device and may not be compatible with
other devices.
Unapproved accessories may cause your device to malfunction.

5
EN
Description of the tablet
1
2
3
Status LED
Webcam
Ambient light sensor
1 2 3

6
Description of the tablet
5 6 74 4
8
9
10
41112114
13
14
15
17 1816 16
1619201916 21
22

7
EN
4Screw thread for accessory
5Programmable buttons P1 and P2
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
Volume buttons +/-
Power button
USB Type A
COM2 - RS232
COM1 - RS232
Guide for docking station
Docking connector
RJ45 & DC-In
USB 3.0 Type A & USB 2.0 Type A
3.5mm Audio & mini HDMI & micro USB
Fixation hand strap
Camera
Barcode scanner (option)
Speaker
VESA 100 threads
Battery lock
Battery

8
Replacing the battery
WARNING: Make sure to turn o your Fieldbook before removing the battery.
Removing the battery
1. Press and hold down the button in the center of the battery lock (Picture 8.1 1)
2. Slide the battery lock to the left (Picture 8.1 2)
3. Release the center button
4. Pull out the battery (Picture 8.2 3)
Picture 8.1
1
Picture 8.2
3
2

9
EN
Inserting the battery
1. Insert the battery in the compartment like shown in the picture (Picture 9.1 1)
2. Push down the other side of the battery (Picture 9.1 2)
3. Slide the battery lock to the right to secure the battery in place (Picture 9.2 3)
Picture 9.1 Picture 9.2
12
3

10
Inserting mini SIM & Micro-SD cards
WARNING: Make sure to turn o your device before inserting a SIM or memory card.
To install or remove a SIM or SD card, the battery has to be removed rst.
Please refer to “Removing the battery” on page 8.
Inserting the mini SIM card
The slot accepts only mini SIM cards. Insert the card into the SIM slots like shown in the
picture on the right.
Inserting a SD card
Insert the micro SD card like show in the picture on the right.
Closing
Please refer to “Inserting the battery” on page 9.
Tip:
For the SIM card, a Pin number may be requested. Enter the SIM card pin number and
tap OK.

11
EN

12
Turn ON
1. Press and hold the ON/OFF button to turn on the device.
Turn OFF
1. Click on the Windows symbol on the lower left corner of the screen.
2. Select the Power button , then select Shut down.
Initial setup
The rst time you start up your device, the Windows Startup Screen will be the rst
screen displayed. Follow the on-screen instructions on each screen in order to properly
install the operating system. We strongly recommend that you create a Microsoft
account, so you can enjoy more features.
Windows // Getting started
Tip:
If the Fieldbook is used by more than one person, it is recommended to create an user
account for each person. Every user can set its default parameters to his needs.

13
EN
Microsoft account
A Microsoft account is an email address and password that you use to sign in to
Windows. It’s free and easy to set up, and you can do so with any email address you
choose, or get a new email address (for example, you can use an Outlook.com, Gmail, or
Yahoo! address for your Microsoft account.). With a Microsoft account, you can:
- get apps from the Windows Store
- back up all your important data and les using free cloud storage
- link your social networking accounts to the People app, and you’ll see
your friends’contact info and status updates in one place
For detailed information about how to use Windows 10, please visit:
http://windows.microsoft.com/en-us/windows-10/getstarted-get-to-know-windows-10

14
Make sure that you are in a WiFi zone.
1. Click on the arrow on the lower right corner and select the
WiFi icon .
2. Select the name of network you want to connect to, tap on
Connect and enter a password if required.
Windows // Connecting to a WiFi network
Tip:
- To get the correct WiFi password (or settings) for the network, contact
the WiFi network provider.
- If you want to connect to this network every time it’s in range, select
the ‘Connect automatically’ check box.

15
EN
Turning the device o
In Shut Down Mode, no data will be saved and the tablet will boot to the operating system’s
main screen the next time it is turned on. If you have entered data, either save it to the internal
storage or to other storage media.
1. On the left side of the screen, select the Windows button.
2. Select the Power button , then select Shut down.
Or press and hold the power button for about 2-10 seconds till the screen‘Slide to shut down
your PC’appears and then use the touchpad to slide down the screen.
Start screen tiles customisation
Pinning icons: Use the touchpad and the touchpad buttons to select the icon you want to
move from your apps list to the Start screen.
Moving icons: If you want to move an icon, Use the touchpad and the touchpad buttons to
select the icon and drag it to where you want it and drop it.
More options for icons: Use the touchpad and the right touchpad button to click a tile and
show options.
Windows // Getting familiar with Windows 10

16
Windows // The Windows 10 interface
Slide to the right
Slide from the left side of the
screen to the right to open the
running programs
Start Screen
The “Start” screen is the
launching pad to access your
favourite apps and websites
with only one click. To access
this screen, click the Windows
button on the lower left corner
of the screen.

17
EN
Slide to the left
Slide from the right side of
the screen to the left to open
the notication center
Slide down
Slide down from the upper
side of the screen while a
window is open. You can then
place the window on either
side to start the split screen.

18
Windows // Windows notication center
Click the icon in lower right corner of the screen to
display the notication center.
1 - To change from PC mode to tablet mode
2 - To turn on/o the screen rotation
3 - To take notes
4 - To access all settings
5 - To connect other devices
6 - To manage the device’s battery
7 - To make a VPN connection
8 - To turn on/o the Bluetooth connection
9 - To adjust the screen brightness
10 - To turn on/o the WiFi connection
11 - To turn on/o the Quiet hours option
12 - To turn on/o location services
13 - To turn on/o the ight mode
1 2 3 4
5 6 7 8
9 10 11 12
13

19
EN

20
Turn ON
1. Press and hold the ON/OFF button to turn on the device.
When you turn on your device, a PIN code may be requested.
2. Type the PIN code supplied with your SIM card.
Beware of typing a wrong PIN code.
3. Select ‘OK’.
Turn OFF
To turn o your device, press and hold the ON/OFF button, and then select Power o >
OK.
Sound & Notication proles
1. When the device is turned on, press the Volume Up/Down button.
2. Select an option.
Android // Getting started
Tip:
Your device goes in standby mode when you do not use it for a specified period of
time. To wake up your device, press the ON/OFF button.
To set the duration, go to Settings > Display > Sleep.
