Logic LG-HMS8x8S-H User manual

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
Model No. LG-HMS8x8S-H
Version: LG-HMS8x8S-H_2021

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in
Warning
▪Do not expose this device to Rain, Moisture, and Dripping.
▪Only use accessories specified by the manufacture.
▪Unplug this device during Lightning, Storms.
▪Product specifications may be subject to technical upgrades without further notice.

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in
Table of Contents
1INTRODUCTION.........................................................................................................................................1
2FRONT PANEL CONTROL ...........................................................................................................................1
3BACK PANEL..............................................................................................................................................2
4PC TOOL AND RS232/LAN CONTROL .........................................................................................................4
4.1 RS-232 CONNECTOR .....................................................................................................................................4
4.2 ETHERNET CONTROL AND CONNECTION.............................................................................................................4
4.3 PC TOOL .....................................................................................................................................................5
4.3.1 UART Control ..................................................................................................................................... 5
4.3.2 Network Control ................................................................................................................................ 6
4.3.3 Configure the network module of the device .................................................................................... 8
4.3.4 Matrix Switch .................................................................................................................................. 10
4.3.5 Signal Setting................................................................................................................................... 10
4.3.6 EDID Control .................................................................................................................................... 11
5CONTROL VIA WEB..................................................................................................................................12
6ELECTRICAL PARAMETERS.......................................................................................................................13
7WIRING DIAGRAM ..................................................................................................................................13
8PACKAGE CONTENTS...............................................................................................................................14

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 1
1Introduction
LG-HMS8x8S-H is a high-performance seamless UHD matrix switcher with 8x HDMI inputs and 8x HDMI outputs. Audio
extract or insert can also be enabled on this device. IR matrix routing on this video matrix is followed with video
routing.
LG-HMS8x8S-H Key Features:
▪Support HDMI 2.0/HDCP 2.2
▪Support seamless switching
▪Support IR matrix
▪Support HDMI audio extract
▪Support external LR audio insert on HDMI stream
▪Support EDID management
▪HDMI video output resolution:
3840 x 2160@60, 3840 x 2160@30, 1920 x 1080@60, 1280 x 720@60,
1920 x 1200@60, 1360 x 768@60, 1280 x 1024@60, 1024 x 768@60
▪Front panel, RS-232, TCP/IP (LAN 10 m/100 m) control
2Front Panel Control
▪OUTPUT/INPUT buttons
Press buttons OUTPUT n + INPUT m+ TAKE by sequence, and user can switch matrix routing.
▪Press button POWER to make the matrix enter or release standby state. When standby, the power LED will be
lighted.
▪Press button LOCK, to lock or un-lock front buttons. When locked, the Lock LED will be lighted.
▪Press buttons ALL + INPUT m + TAKE by sequence, to switch input m to all the outputs.
▪Press button SAVE + OUTPUT n to save current routing scene as scene n. The maximum allowable scene No.
is 8.
▪Press button RECALL + OUTPUT n to recall routing scene n as current routing.

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 2
▪Press buttons RES + OUTPUT n + NEXT + TAKE, to change output resolution of OUTPUT n port.
Resolution Option:
3840 x 2160@60, 3840 x 2160@30, 1920 x 1080@60, 1280 x 720@60,
1920 x 1200@60, 1360 x 768@60, 1280 x 1024@60, 1024 x 768@60
▪Press buttons EDID + INPUT m + NEXT + TAKE, change the EDID mode of port INPUT m EDID option: Manual,
3840 x 2160@60, 3840 x 2160@30, 1280 x 1024@60
1920 x 1080@60, 1280 x 720@60, 1920 x 1200@60
3Back Panel
▪LAN (10 m/100 m), RS232 are for PC control.
▪Analog Audio IN/OUT ports are bond with corresponding HDMI ports.
For example, if INPUT HDMI 1 signal is DVI, matrix will use Analog AUDIO IN 1 as HDMI 1 audio source.
Note: Analog AUDIO IN is only available when the corresponding video input is DVI signal.
Analog AUDIO OUT n will always output the same audio content with HDMI OUTPUT n Analog Audio IN/OUT
connection.
▪IR IN and IR OUT
IR IN/OUT is for remote control routing, and followed with video routing,
For example, if input HDMI m is routed to output HDMI n1 and n2 ports, then IR IN n1 and n2 ports will be routed
to IR OUT m port. Please refer to bellow illustration.
Relationship between Video and IR Routing

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 3
IR Extender Connectors (Not as Accessories)

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 4
4PC Tool and RS232/LAN Control
4.1 RS-232 connector
▪RS-232 control, baud rate 9600, DB9 connector
▪Pins configuration as bellow. User needs to use the corresponding cable, directly link cable
4.2 Ethernet Control and Connection

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 5
4.3 PC Tool
The PC tool needs no installation, support serial control, and network control. Please note, Fine Tune/OSD CTRL/TV Wall
pages are reserved for future use.
4.3.1 UART Control
Control steps as follows:
1. Connect PC and device with a straight serial port cable
2. Run PC control tool and switch to "Matrix Switch" page
3. Click to switch "Ctrl Mode" to "UART"
4. Click the combo box which is right to the "Port", select the right COM port (There may be some COM ports
connected to the PC)
5. Click the “Disconnected” button (which is right to "Status") to connect to the device
6. If connected successfully, the "Disconnected" button will show "Connected"
The UI after connected successfully will be as follows:

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 6
4.3.2 Network Control
Direct connection via Ethernet cable
Control steps as follows:
1. Connect the PC and device directly via an Ethernet cable.
2. Manually setting up the IP address of the PC, and the IP address of the PC and the device should be in a same
network segment (The default IP address of the device is 192.168.0.247, and the default network mask of the
device is 255.255.255.0). The screenshots of setting up the IP address are as follows:

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 7
Figure 1: Manually setting up the IP address of the PC
3. Run the PC control software (If the IP address of the PC changed after running the software, you should close
it and run it again.)
4. Click to switch "Ctrl Mode" to "Network".
5. Click the "Search Device" button.
6. Click the device you want to control in the result list (When you click it, the software will read the network
configuration such as network port and so on of the device automatically.)
7. Click the ‘Disconnected’ button (which is right to "Status") to connect to the device.
8. If connected successfully, "Disconnected" button will show "Connected".
The UI after connected successfully will be as follows:
▪Connection via LAN

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 8
Control steps as follows:
1. Connect the PC and the device to a same network router.
2. Setting up the IP address of the PC. Either manual (Static) mode or automatic (DHCP) mode is ok. Just make
sure the IP address of the PC and the device are in a same network segment. When the IP type is obtained
automatically, the network router that PC and the device connected to should support HDCP function.
3. Run the PC control software (If the IP address of the PC changed after running the software, you should close
it and run it again.)
4. Click to switch "Ctrl Mode" to "Network".
5. Click the "Search Device" button.
6. Click the device you want to control in the result list (When you click it, the software will read the network
configuration such as network port and so on of the device automatically.)
7. Click the ‘Disconnected’ button (which is right to "Status") to connect to the device.
8. If connected successfully, "Status" button will show "Connected".
4.3.3 Configure the network module of the device
1. Configuration via UART
Step A: Connected to the device via serial port cable at "Matrix Route" page.
Step B: Switch to "Network setting" page.
Step C: Click "Find via UART" button to read the configuration of the device.
Step D: Modify the IP address or the IP address type.
Step E: Click the "Save Config" button to save modification.
Step F: When the software shows a message of "Success", Click "Find Via UART" to load configuration again to make
sure your modification is saved successfully.

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 9
2. Configuration via Network
Step A: Switch to Ctrl Mode to "Network" page
Step B: Click the "Search Device" button to search devices.
Step C: Click the device you want to configure in the result list (When you click it, the software will read the network
configuration of the device automatically.)
Step D: Modify the IP address or the IP address type or other configuration.
Step E: Click the ‘Save Config’ button to save data.
Step F: When the tool shows message with "Success", Click "Search Device" button to search and load configuration
again to make sure your modification saved successfully.
NOTE:
1. Select the device, and it will display the matrix network board information. User can edit the device name, in
order to better identify matrix. User can set dynamic IP/ static IP, subnet mask, gateway, and other network
information. At the same time, user can also set the device port. Serial port baud rate is 9600 (the user
cannot change the baud rate, otherwise it will lead to the network control failed.).
2. Configuration via UART only support modify IP address or IP address type. If you want to modify another
configuration, please configure it via Network.

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 10
4.3.4 Matrix Switch
When the PC-tool connect to the matrix via UART or Network, the PC-tool will display the matrix input and output
information.
1. User can click the mouse to switch the input and can edit the input source name (for example, the user can
edit the input 1 name to set-top box). User can also edit the output name to show which sink is connected
(for example, the output 1 users can edit the name to TV.)
2. Support scene save (the user can pull down the corresponding drop-down menu, to save the current input
and output relationship to mode X, support 8 different modes.)
3. Support scene recalls (the user can drop down the corresponding drop-down menu, to set the mode X input
and output relationship to the matrix.)
4. Support one input output to all outputs (the user can drop down the "All set" drop-down menu, to set the
input X output to all the output ports)
5. Support system reset, click “Reset” button, after the user confirmed, then reset the matrix to the factory default
settings.
4.3.5 Signal Setting
Only the red field can be changed for different output resolution, others are only for read

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 11
4.3.6 EDID Control
Click the ‘EDID’ button on "Matrix Switch" page, open EDID control window.
1. Read EDID: Select the output port, then click the "Read " button to read EDID.
2. Write EDID: First read a EDID from output port, or open a EDID file that saved before then select the input
port and click the "Write" button to write EDID.
3. Save EDID: After reading EDID successfully, click "Save" button, and select the save path and file name for
saving.
4. EDID Manual: The written EDID above will be as the manual EDID data. When user select EDID mode with
Manual mode by front panel for one input port, matrix system will use this data as the EDID data for the port.

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 12
5Control via Web
If do not know the matrix IP address: Click on the Network Settings page, and then click Search Device, and then
select the device that found. Click Open Website to open the web control web site, or can input the IP on the web
browser, then enter the username: admin Password: admin, then can control the matrix switch function and use the
website.
NOTE: The computer IP and matrix IP must be in the same segment and the same local area network. For example,
the matrix IP is 192.168.1.xxx, then the computer IP must be 192.168.1.yyy. Otherwise need to change the matrix IP or
the computer IP. The browser must support HTML5 feature, which must be IE10 and above.
If the matrix IP address is known: Input the IP on the web browser, then enter the username: admin Password: admin,
and then can control the matrix switch function and use the website.
Note: The browser must support HTML5 feature, which must be IE10 and above.

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 13
6Electrical Parameters
HDMI audio format: LPCM 2/5.1/7.1, Dolby Digital, DTS 5.1, Dolby Digital+,Dolby TrueHD, DTS-HD Master Audio,
Dolby Atmos, DTS:X
HDMI audio format
HDMI-A
HDMI /DP /VGA Version
HDMI 2.0, HDCP 2.2
Bandwidth
18 Gbps
Video Resolution
Input
800 x 600@60Hz,1024 x 768@60Hz,
1280 x 768@60Hz,1280 x 800@60Hz,
1280 x 1024@60Hz,1360 x 768@60Hz,
1366 x 768@60Hz, 1400 x 1050@60Hz,
1440 x 900@60Hz, 1600 x 1200@60Hz,
1680 x 1050@60Hz, 1920 x 1200@60Hz.
480p, 576p, 720p, 1920 x 1080i, 1920 x 1080p,
3840 x 2160@24Hz/25 Hz/30 Hz/50 Hz/60 Hz,
4096 x 2160@24Hz/25 Hz/30 Hz/50 Hz/60 Hz.
Output
1920 x 1080@60Hz, 3840 x 2160@30Hz,
3840 x 2160@60Hz, 1280 x 720@60Hz,
1024 x 768@60Hz, 1360 x 768@60Hz,
1600 x 1200@60Hz, 1920 x 1200@60Hz,
HDMI Amplitude
T.M.D.S +/- 0.4 Vpp
Differential Impedance
100±15 ohm
RS232/Ethernet Control
Baud Rate and Protocol
Baud rate 9600, data bit 8,
stop bit 1, no parity checking
Ethernet
IE10.0+, HTML5
Power
Max. Consumption
100 W, 110-240 VAC
Matrix Mechanical Dimensions
Size (mm)
430 (L) X 300 (W) X 44 (H)
Weight
5 kg
Other
Operating Temperature
0 to 40 °C
Storage Temperature
-20 to 70 °C
Permissible Humidity
10% - 50%
7Wiring Diagram

8 x 8 Seamless UHD Matrix-LG-HMS8x8S-H
www.logicav.in 14
8Package Contents
Item
Quantity
LG-HMS8x8S-H unit
1
LG-HMS8x8S-H User Manual
1
Bracket
0
AC Power Cord
1
