Logik Sound Stage User manual

Instruction Manual
Sound Stage
L37SPB14

Contents
Safety Warnings.............................................................................................................................3
Unpacking......................................................................................................................................5
Product Overview..........................................................................................................................6
Front View.................................................................................................................................................................. 6
Top View..................................................................................................................................................................... 6
Rear View ................................................................................................................................................................... 6
Remote Control..............................................................................................................................7
Remove the Plastic Strip from the Remote Control ....................................................................7
Battery Replacement for the Remote Control.............................................................................8
Remote Control Operation Range................................................................................................9
Placing TV or Vision Device...........................................................................................................9
Connections .................................................................................................................................10
Using the OPTICAL Connection.......................................................................................................................10
Using the AUX Connection................................................................................................................................10
Using the MP3 LINK Connection.....................................................................................................................11
Connecting to the Mains Supply.....................................................................................................................11
General Operation.......................................................................................................................12
Selecting Modes....................................................................................................................................................12
Adjusting the Volume..........................................................................................................................................12
Selecting the Equaliser .......................................................................................................................................12
Adjusting the Brightness....................................................................................................................................12
Bluetooth® Operation .................................................................................................................13
Listen to Music from Bluetooth Device.........................................................................................................14
AUX / MP3 LINK / OPTICAL Operation........................................................................................14
Maintenance ................................................................................................................................14
Hints and Tips ..............................................................................................................................14
Specications...............................................................................................................................15

3
• Read all the instructions carefully before
using the unit and keep them for future
reference.
• Retain the manual. If you pass the unit
onto a third party make sure to include this
manual.
• Check that the voltage marked on the
rating label matches your mains voltage.
Damage
• Please inspect the unit for damage after
unpacking.
• Do not continue to operate the unit if you
are in any doubt about it working normally,
or if it is damaged in any way - switch o,
withdraw the mains plug and consult your
dealer.
Location of Unit
• The unit must be placed on a at stable
surface and should not be subjected to
vibrations.
• Do not place the unit on sloped or unstable
surfaces as the unit may fall o or tip over.
• The mains socket must be located near the
unit and should be easily accessible.
• This unit is designed for indoor use only.
Temperature
• Avoid extreme degrees of temperature,
either hot or cold. Place the unit well away
from heat sources such as radiators or gas/
electric res.
• Avoid exposure to direct sunlight and other
sources of heat.
Naked Flames
• Never place any type of candle or naked
ame on the top of or near the unit.
Ventilation
• To prevent the risk of electric shock or
re hazard due to overheating, ensure
that curtains and other materials do not
obstruct the ventilation vents.
• A minimum distance of 5cm around the
unit should be maintained to allow for
sucient ventilation.
• Do not install or place this unit in a
bookcase, built-in cabinet or in another
conned space. Ensure the unit is well
ventilated.
Safety Warnings
Safety
• Always disconnect the unit from the mains
supply before connecting/ disconnecting
other devices or moving the unit.
• Unplug the unit from the mains socket
during a lightning storm.
Mains Cable
• Make sure the unit or unit stand is not
resting on top of the mains cable, as the
weight of the unit may damage the mains
cable and create a safety hazard.
• If the mains cable is damaged it must be
replaced by the manufacturer, its service
agent, or similarly qualied persons in order
to avoid a hazard.
Interference
• Do not place the unit on or near appliances
which may cause electromagnetic
interference. If you do, it may adversely
aect the working of the unit, and cause a
distorted sound.
Batteries
• Batteries used in the unit are easily
swallowed by young children and this is
dangerous.
• Keep loose batteries away from young
children and make sure that the battery
holder tray is secure in the unit. Seek
medical advice if you believe a cell has been
swallowed.
• Please dispose of batteries correctly by
following the guidance in this manual.
• Do not expose the battery to direct sunlight
or sources of excessive heat.
Supervision
• Children should be supervised to ensure
that they do not play with the unit.
• Never let anyone especially children push
anything into the holes, slots or any other
openings in the case - this could result in a
fatal electric shock.

4
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the
presence of uninsulated“dangerous
voltage” within the unit’s enclosure that
may be of sucient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the manual
accompanying the unit.
Service
• To reduce the risk of electric shock, do not
remove screws. The unit does not contain
any user-serviceable parts. Please leave all
maintenance work to qualied personnel.
• Do not open any xed covers as this may
expose dangerous voltages.
Maintenance
• Ensure to unplug the unit from the power
supply before cleaning.
• Do not use any type of abrasive pad or
abrasive cleaning solutions as these may
damage the unit’s surface.
• Do not use liquids to clean the unit.

5
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new Logik Sound Stage.
We recommend that you spend some time reading this instruction manual in order
that you fully understand all the operational features it oers. You will also nd some
hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual
for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Remote Control
3.5mm to RCA Stereo
Audio Cable
3.5mm to 3.5mm
Audio Cable
Main Unit
Instruction Manual
EQ SOURCE VOL +
MUTE
PAIRDIM VOL –
Instruction
Manual
Mains Cable

6
Product Overview
Front View
Top View
Rear View
1. Speakers
2. Power Indicator
3. Display
1. Button
2. SOURCE Button
3. / PAIR Button
1. AC~ Socket
2. AUX (L/R) Sockets
4. Remote Control Sensor
5. Subwoofer
4. VOL – Button
5. VOL + Button
6. MP3 LINK Socket
3. OPTICAL Socket
21 13 4
5
SOURCE / PAIR VOL – VOL +
MP3 LINK
AC~ AUX
R
L
OPTICAL
1 2 3 4 5 6
1 2 3

7
EQ SOURCE VOL +
MUTE
PAIRDIM VOL –
1
3
2
4
5
7
9
10
8
6
Remote Control
1. Button
Switch the unit between On and
Standby mode.
2. SOURCE Button
Select the input source.
3. DIM Button
Adjust the display brightness level.
4. MUTE Button
Silence the unit or restore the sound.
5. Button
Skip backwards to the beginning of
the track or to the previous track in
Bluetooth mode.
Remove the Plastic Strip from the Remote
Control
Remove the plastic strip from the battery if the
battery is being used for the rst time. It is located
at the bottom rear of the remote control.
6. EQ Button
Select the preset equaliser.
7. VOL +/– Buttons
Adjust the volume.
8. PAIR Button
Activate the pairing function in
Bluetooth mode and disconnect the
existing paired Bluetooth device.
9. Button
Skip forwards to the next track in
Bluetooth mode.
10. Button
Play/pause/resume playback in
Bluetooth mode.

8
Battery Replacement for the Remote Control
The remote control requires a CR2025, 3V Lithium
battery.
1. Slide and hold the battery release tab in the
direction of the arrow.
Handling the Battery
• Improper or incorrect use of batteries may cause corrosion or battery leakage,
which could cause re, personal injury or damage to property.
• Install the battery correctly in the battery compartment.
• When the battery is exhausted, the remote control will not function.
• Only use the battery type indicated in this manual.
• Do not dispose of the used battery as domestic waste. Dispose of it in
accordance with local regulations.
• Small button cell batteries such as the one used in the remote control are
easily swallowed by young children and this is dangerous. Keep loose button
cells away from young children and make sure that the battery is secure in
the remote control. Seek medical advice if you believe a battery cell has been
swallowed.
Handling the Remote Control
• Take care of your ngernails when you slide and pull the battery release tab.
• Do not drop the remote control.
• Do not allow anything to impact the remote control.
• Do not spill water or liquid on the remote control.
• Do not place the remote control on a wet object.
• Remove the battery from the remote control when not in use for a long period
of time, as corrosion or battery leakage may occur and result in physical injury,
and/or property damage, and/or re.
2. Pull out the battery holder and remove the old
battery.
3. Replace with a new battery.
4. Insert the battery holder back into the remote
control.

9
Remote Control Operation Range
• The remote control sensor at the front unit is
sensitive to the remote control’s commands up
to a maximum of 6 metres away and within a
maximum of a 40° arc.
• Please note that the operating distance may
vary depending on the brightness of the room. 20° 20°
Max. 6 m
Placing TV or Vision Device
The unit supports a TV up to a maximum dimension of 48 cm (W) x 22 cm (D) for its base
and within a maximum load of 30 kg.
Ensure the TV or Vision Device is placed properly. Turning the volume
loud may cause the device to fall down.
EQ SOURCE VOL+
MUTE
PAIRDIM VOL–
Maximum dimension of the TV base:
48 cm (W) x 22 cm (D)

10
AC~ AUX
R
L
OPTICAL
AUX
R
L
OPTICAL
AC~ AUX
R
L
OPTICAL
AC~ AUX
R
L
OPTICAL
Connections
Using the OPTICAL Connection
Use an optical cable (not included) to connect the TV’s optical output socket to the unit’s
OPTICAL socket. Before inserting the optical cable, remove the OPTICAL socket cover.
OPTICAL cable
(not included)
3.5mm to RCA Stereo
Audio Cable
Using the AUX Connection
Use the 3.5mm to RCA Stereo Audio Cable to connect the TV’s headphone socket to the
AUX (L/R) Sockets of the unit.
Rear view of the unit
Rear view of the unit
red
white
Alternatively, you can also use an RCA Stereo Audio Cable (not included) to
connect the TV’s audio output sockets to the unit’s AUX (L/R) sockets.
If there is no sound output and the display shows PLEASE CHANGE YOUR
SOURCE DEVICE TO PCM MODE UNDER AUDIO OUTPUT SETTING, ensure the
audio setting of the input source (e.g. TV, game console, DVD player, etc.) is set to
PCM mode.

11
SOURCE / PAIR VOL – VOL+
MP3 LINK
Connecting to the Mains Supply
• Ensure that the power supply voltage corresponds to the voltage printed on the back
or the underside of the unit.
• This unit is designed to operate with the provided mains cable.
• Connecting the unit to any other power source may damage the unit. Unwind the
mains cable to its full length.
• Connect the end of the mains cable to the AC~ Socket at the rear of the unit.
• Connect the mains plug to a mains socket. Make sure the mains plug is fully inserted
into the mains socket.
Using the MP3 LINK Connection
Use the 3.5mm to 3.5mm audio cable to connect the audio device’s headphone socket to
the unit’s MP3 LINK socket.
3.5mm to 3.5mm
audio cable
Top view of the unit
Audio device
To the mains
socket
• Ensure all audio connections of the unit are connected before connecting to
the mains power socket.
• Unplug the power cord from the outlet when the unit is not in use for an
extended period of time.
AC~ AUX
R
L
OPTICAL

12
General Operation
When you rst connect the unit to the mains socket, the unit will be in Standby mode. The
POWER Indicator will light up red.
• Press the Button to switch the unit on. The display will show a greeting message
HELLO and then the last used mode.
• Press the Button to switch the unit back to Standby. The display will show STANDBY
and then the unit will turn o. The POWER Indicator will light up red.
• Disconnect the mains plug from the mains socket if you want to switch the unit o
completely.
When the unit volume is close to mute or is idle for approximately 15 minutes, it
will automatically switch to Standby.
Selecting Modes
Press the SOURCE Button repeatedly to switch between AUX, BT, MP3 LINK and OPTICAL
mode.
Adjusting the Volume
• Press the VOL +/– Button to adjust the volume.
• If you wish to turn the sound o, press the MUTE Button on the remote control. Press
the MUTE Button again or press the VOL +/- Button to resume normal listening.
Selecting the Equaliser
Press the EQ Button on the remote control repeatedly to select a desired music mode.
(DEFAULT, MOVIE, MUSIC, TV).
• When AUX or OPTICAL mode is selected, the equaliser will be set to MOVIE.
• When BT or MP3 LINK mode is selected, the equaliser will be set to MUSIC.
Adjusting the Brightness
Press the DIM Button on the remote control repeatedly to select brightness level.

13
Bluetooth® Operation
You can listen to tracks from a media device if it is connected to the unit via Bluetooth.
• The operational range between the main unit and a Bluetooth device is
approximately 8 meters.
• Before you connect a Bluetooth device to this unit, familiarize yourself with the
Bluetooth capabilities of the device.
• Compatibility with all Bluetooth devices is not guaranteed.
• Any obstacle between this unit and a Bluetooth device can reduce the
operational range.
• Keep this unit away from other electronic devices that may cause interference.
To connect your device to the unit via Bluetooth, follow the steps below:
1. Switch the unit on. Press the SOURCE Button on the remote control repeatedly to
select BT mode. The display will show BT and then BT READY.
2. Press and hold the /PAIR Button on the unit or the PAIR Button on the remote
control to activate Bluetooth pairing.
3. The display will show “DISCONNECT” twice and then “BT READY“ when searching for
Bluetooth devices.
4. Activate your Bluetooth device and select the search mode.
5. “L37SPB14” will appear on your Bluetooth device list.
6. Select “L37SPB14” and enter “0000”for the password if necessary.
7. The display will show“PAIRED” when connection is successful.
8. To disconnect the Bluetooth function, switch to another function on the unit or disable
the function from your Bluetooth device.
• If there is an existing connection, press the /PAIR Button on the unit or the
PAIR Button on the remote control to re-activate the pairing mode, the existing
connection will be interrupted.
• If no other Bluetooth device pairs with this player within two minutes, the
player will recover its previous connection.
• The player will also be disconnected when your device is moved beyond the
operational range.
• If you want to reconnect your device to this player, place it within the
operational range.
• If the device is moved beyond the operational range, when it is brought back,
please check if the device is still connected to the player.
– If the connection is lost, follow the instructions above to pair your device to
the player again.

14
Maintenance
Ensure the unit is fully unplugged from the mains socket before cleaning.
• To clean the unit, wipe the case with a slightly moist, lint-free cloth.
• Do not use any cleaning uids containing alcohol, ammonia or abrasives.
• Do not spray aerosol at or near the unit.
AUX / MP3 LINK / OPTICAL Operation
1. Ensure that the unit is connected to the TV or audio device.
2. Press the SOURCE Button repeatedly to select the desired mode.
3. Press the VOL+/– Button to adjust the volume.
4. Press the EQ Button on the remote control to select the desired equaliser.
• When connecting the external device, refer to the owner’s manual of the
external device, as well as the manual.
• Examples of External Audio Device that can be connected to the unit are:
Portable MP3 Players, Cassette Players, Mini Disc Players, DVD Players, etc.
Hints and Tips
If a problem occurs, it may often be due to something very minor. The following table
contains various tips.
Problem Solution
No power. • Ensure the mains cable is connected securely.
• Make sure that the unit is switched on.
Listen to Music from Bluetooth Device
• If the connected Bluetooth device supports Advanced Audio Distribution Prole
(A2DP), you can listen to the music stored on the device through the player.
• If the device also supports Audio Video Remote Control Prole (AVRCP), you can use the
player’s remote control to play music stored on the device.
1. Pair your device with the player.
2. Play music via your device (if it supports A2DP)
3. Use supplied remote control to control play (if it supports AVRCP)
• To pause/resume play, press the Button.
• To skip to a track, press the Button.

Specications
Model L37SPB14
Power
Power Supply 220-240V~ 50/60Hz
Power Consumption 18W
Speaker Output Power 15Wrms x 2 + 30Wrms (Subwoofer)
Feature
Connectivity AUX IN (L/R) Sockets, MP3 LINK Socket, OPTICAL Socket,
Bluetooth 3.0
Dimension (W) x (D) x (H) 525 x 305 x 75 mm
Net Weight 4.4kg
Features and specications are subject to change without prior notice.
Problem Solution
Loud hum or noise is
heard.
The plugs and sockets are dirty. Wipe them with a cloth slightly
moistened with an appropriate non-abrasive cleaning solution.
The remote control
does not function.
• Use the remote control near the unit.
• Point the remote control at the remote control sensor on the
unit.
• Replace the battery in the remote control with a new one.
• Remove any obstacles between the remote control and the
• unit.
The unit does not
respond when
pressing any buttons.
The unit may freeze up during use. Switch the unit off and then
on again at the mains socket to reset the unit.
No sound output. • Make sure that the unit is not muted. Press the MUTE or VOL
+/– Button to resume normal listening.
• Ensure the audio setting of the input source (e.g. TV, game
console, DVD player, etc.) is set to PCM mode while using
optical connection.
I cannot find
“L37SPB14” on my
Bluetooth device.
Ensure the Bluetooth function is activated on your Bluetooth
device.
If any functional abnormality is encountered, unplug the unit from the mains
socket and reconnect it again.

DSG Retail Ltd. (co. no. 504877)
Maylands Avenue, Hemel Hempstead, Herts., HP2 7TG, UK
IB-L37SPB14-140205V2
All trademarks are the property of their respective owners and all rights are acknowledged.
This symbol on the product or in the instructions means that your electrical and
electronic equipment should be disposed at the end of its life separately from your
household waste. There are separate collection systems for recycling in the EU.
For more information, please contact the local authority or your retailer where you
purchased the product.
Notes for battery disposal
The batteries used with this product contain chemicals that are harmful to the environment. To
preserve our environment, dispose of used batteries according to your local laws or regulations.
Do not dispose of batteries with normal household waste.
For more information, please contact the local authority or your retailer where you purchased the
product.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth®
SIG, Inc. and any use of such marks by DSG Retail Limited is as an Aliate under the
License held by DSG International Sourcing Ltd. Other trademarks and trade names
are those of their respective owners and all rights are acknowledged.
For general information about this appliance
and handy hints and tips, please visit
www.knowhow.com/knowledgebank or call 0844 5611234.
In the unlikely event of a problem developing, please contact the store where you purchased
your equipment.
We continually strive to improve our products; specications may change without prior notice.
For advice on where to purchase accessories, please contact the store where you purchased your
equipment.
Visit Partmaster.co.uk today for the easiest way to buy electrical
spares and accessories. With over 1 million spares and accessories
available we can deliver direct to your door the very next day. Visit
www.partmaster.co.uk or call 0844 800 3456 (UK customers only) Calls charged at National Rate.
