logika WL-ZRPMNPW-G11-01 User manual

© 2019 Logika Limited
Smart Repeater
WL-ZRPMNPW-G11-01
Product Manual
Version 1.0

1
Logika Limited
E
-Centre, Massey University, Gate 5, Oaklands Road
Albany, Auckland 0632, New Zealand
www.logika.nz
·[e-mail]
Introduction
Thank you for choosing Logika. Please take a moment to carefully read through the manual to
ensure safe and proper installation and use.
•Before use, the product must be properly installed as described in this manual by a qualified
technician.
•The product should be used with the supplied accessories.
•Do not disassemble or modify the product.
•Logika is not responsible for any loss due to improper installation or use of this product.
•Please visit our official website at www.logika.nz for more information.
•You can also contact us at the following email address: [e-mail].

2
Device Layout
System Indicator
Plug
Multi-Functional Key

3
Features
•Communication Mode: IEEE 802.15.4 Zigbee.
•Extends gateway communication coverage.
•Stable signal transmission.
•Direct plug-in power supply and space-saving.
•Easy setup.
Specifications
Communication Mode IEEE 802.15.4 ZigBee
Antenna Type Internal Antenna
Power 100-240V AC, 50/60Hz
Standby Power Consumption ⩽0.5W
Wireless Communication Distance 500m (Visible)
Dimension (mm) 54x54 (mm)
Material & Colour PC, White
Flame Retardant Rating UL94V-0
Working Temperature -10°C - +45°C
Working Humidity ⩽95%RH (Noncondensing)
Installation Method Portable
Net Weight (g) 39g
Storage Temperature -20°C - +60°C

4
Installation Steps
Hardware Installation
The Smart Repeater is designed to strengthen the signal to devices that are too far away from the
rest of the devices, which form the mesh network.
If the devices are to far to get a signal, the Smart Repeater can act as a Gateway that they can
connect to. If, however, you install this Repeater first, it will act as another device, which extends the
existing range of the original Gateway and devices. This latter option is the preferred method for
installation as it makes things a lot simpler.
Mobile Device
Logika Gateway
Smart Repeater
Smart Devices

5
Adding the Device to the Smart Home Network
Use the Logika Smart Home app to add the device to the Smart Home system. Please refer to the
Logika Smart Mobile App user guide which will take you through the process of adding smart
devices to the system.
Refer to the information below to locate the device in the Device Add screen. Once selected, the app
will walk you through how to add the device to the system.
Device Category:
Repeater
Device Name:
Repeater

6
Device Functions
When the device is first powered on, it will normally automatically attempt to connect to the Zigbee
Smart Home network. The System Indicator light will flash as it’s searching for the network. If it
connects, the light will remain on for 2 seconds and then go out.
If this does not happen, you can manually connect via the mobile app and follow the instructions
below.
Join the Zigbee Network
Press the Multi-Function Button once. The System Indicator light will start flashing, signifying it’s
searching for the network.
When it successfully connects, the System Indicator light will stay solid for 2 seconds then go out.
Connect Other Devices
Use this function if the device is already too far to get any signal from the Gateway/mesh network.
Press the Multi-Function Button 6 times in quick succession. The System Indicator will flash once,
signifying that the Repeater is now ready to accept devices to join. This will remain active for 4
minutes.
If the device is already getting a weak signal and/or the device is to be mounted after the Smart
Repeater, you do not need to perform this step. The range should already have been extended,
assuming the Repeater is already connected to the main Logika Gateway.
Quit the Zigbee Network
Long press the Multi-Function Button for 6 seconds. The System Indicator light will flash 4 times and
go out. The device has now been successfully removed from the network and been reset to the
factory defaults.

7
Safety Precautions
• Disable any power prior to connecting the device to the main supply.
• The device must be installed by a qualified electrician.
• Do not disassemble or refit this product or its accessories.
• The device should be mounted in a dry environment. It is not designed to be used
outdoors.

8
Troubleshooting
The device cannot be added to the Zigbee network.
The device may be registered to another network. In rare occasions this can happen if the device
was not removed from the test network at the factory.
Perform the Quit the Zigbee Network procedure mentioned in Device Functions section to clear this
setting. You should now be free to add the device to the local smart network.
The issue you are experiencing is not mentioned here.
Please contact us at [e-mail] with your issue and we will do our utmost to help!
