LogiLink EC0001 User manual

- 1 -
According to the European WEEE directive, electrical and
electronic equipment must not be disposed with consumers waste.
Its components must be recycled or disposed apart from each other.
Otherwise contaminative and hazardous substances can pollute
our environment.
You as a consumer are committed by law to dispose electrical and electronic
devices to the producer, the dealer, or public collecting points at the end of the
devices lifetime for free. Particulars are regulated in national right. The symbol
on the product, in the user's manual, or at the packaging alludes to these
terms. With this kind of waste separation, application, and waste disposal of
used devices you achieve an important share to environmental protection.
1.0 Safety Instruction
- Don't plug in an appliance where the load exceeds 16Amp.
- Connect the device only directly to an outlet that has been
approved for the device. Never use an extension cable or an
adapter.
- The used outlet must always be easily accessible for unplug
easily in an emergency Case.
- Always ensure the plug of any appliance is fully inserted into
the timer outlet.
- The manufacturer recommends such appliances not be
connected to timers
- Do not let the product come into contact with rain, moisture or
other liquids to avoid damaging the device and to prevent
injuries due to short circuits.
- Never use a defective device
- Never open the device.
- If cleaning of the timer is required, remove from outlet and
wipe timer with a dry, lint-free cloth.
- Keep away from Children. Product is not a toy !!!
Congratulations to the Purchase of LogiLight Indoor
Remote Power Socket Starter kit!
Please read the Manual and Safety Instructions before using the
product for the first time. Otherwise damage can be the result.

- 2 -
2.0 Introduction
2.1 Specification:
Receiver:
Intelligent learn function
Manual on/off function
Red Power indicator
Power Supply: 230VAC, 50Hz
Rating: 16A, 3680W max.
Transmission range: 20m in open
area
Transmitter:
Receive range: >20m
Frequency range:
433.92MHz
Code: Self learning 1
million
Battery (1 x 12 V)
2.2 Package Contents
EC0001
2 x Indoor Power Sockets
1 x Remote Control
1 x Remote Control battery
EC0003
3 x Indoor Power Sockets
1 x Remote Control
1 x Remote Control battery
EC0005
1 x Indoor Power Socket

- 3 -
3.0 Installation
1.On the remote control, open the battery compartment and
place the provided battery in the right position.
2.Plug the receiver in a power plug. Press the ON button on the
receiver, then LED will light. And LED flashes one time per
second.
3.Press the ON button (lasting more than 2 seconds) of your
choice (1 to 5) on the remote control. The receiver will then
learn the code and store it in memory. When LED flashes
continuously in 2 seconds, it means the receiver learns the
code successfully.
4.Repeat these last two operations for all receivers and select a
different ON button for each receiver.
4.0 Operation
Plug the device you want to remotely operate into a receiver.
Press the corresponding ON or OFF button of the remote
control to operate the plug or
Press the direct ON/OFF switch on the receiver to activate or
inactivate it.
5.0 Trouble Shooting
If a receiver does not react to the remote control operation it can
be due to:
Low battery in the remote control –Replace it.
Distance too large between the remote control and the
receiver
The pressing time on the buttons must be at least 2 seconds

- 4 -
6.0 How to Decode
Press ON/OFF switch on receiver and last for 3 seconds.
After the LED flashes from quickly to once per second,
decoding is successful.
Press ALL OFF switch on remote control and last for 3
seconds. After the LED flashes from quickly to once per
second, decoding is successful.
CE Declaration:
This device corresponds to EU directive 2004/108/EC
and 2006/95/EC: With the CE sign Logilink® , a
registered trademark of the 2direct GmbH ensures, that the product
is conformed to the basic standards and directives. These standards
can be requested online on www.logilink.com.All trademarks and
registered brands are the property of their respective owners.
