LogiLink AD0016 User manual

Best Connectivity
Features:
»Improve laptop performance and capacity with an extra
hard drive
»Ideal solution to upgrade laptops with SSD for faster speeds
»Fully integrated into laptops
»No cables/PSU/software drivers required
»Can replace a 12.7mm CD/DVD/Blu-ray drive of a laptop
»Fits for a 2.5” SATA HDD
»Fast & Reliable connection in laptops as the primary HDD
»Dimension: 129 x 128 x 12.7mm
»Compatible to Laptops e.g. Lenovo, Dell, ACER, ASUS,
BENQ, HP, FUJITSU, SONY
Fits for a 2.5” SATA HDD and can replace a 12.7mm CD/DVD/Blu-ray drive of a laptop.
HDD Caddy is a case for a hard drive which you can mount a second HDD or SSD into your
laptop easily. It is an ideal and easy solution if you need more storage space or if you want to
use a fast SSD with an extra HDD. This case fits perfectly in the bay where your CD/DVD/Blu-ray
drive is normally located. No need for any software installation, just plug and play.
Art. No.: AD0016
2nd SATA HDD Caddy
For universal 12.7mm high
CD/DVD/Blu-ray drive slot
Installation Instructions:
123

Best Connectivity
Package Contents:
»1 x Hard Drive Caddy
»1 x Front Panel
»4 x Hard Drive Screws
Package Informations:
»Packing Dimension: 160 x 194 x 25mm
»Packing Weight: 0.1kg
»Carton Dimension: 435 x 355 x 180mm
»Carton Q‘ty: 50pcs
»Carton Weight: 6kg
1. Unscrew the lateral screws at the bottom of the caddy.
2. Insert the hard drive into the caddy and connect the two
terminals firmly together.
4. Insert the caddy into the empty disk drive slot facing
upwards.
3. Re-connect the screws.
Installing the HDD to the HDD Caddy:
Art. No.: AD0016
2nd SATA HDD Caddy
For universal 12.7mm high
CD/DVD/Blu-ray drive slot
