Lokkii 838H User manual

ASSEMBLY INSTRUCTION
PRODUCT GUIDE
Model. 838H
Features
• AllWeatherPowderCoatedFrame
• AllWeatherPowderCoatedFireBowl
• StainlessSteelFrameJoints
• 3-PiecePorcelainCookingSurface
• AdjustableCookingHeight
• UpperCookingRack
• 2sidetableswithaccessoryhooks
• StainlessSteelTemperatureGauge
• StainlessSteelHandle
• 2StainlessSteelAirVents
• AllTerrainRubberWheels
• EasyAssembly
Assembled Size
Width:26.5”/67cm
Height:37”/94cm
Length:45.5”/115cm
CookingHeight:30.7”/78cm
CookingSurface:29”x16.5”/54cmx42cm
PERFECTION half barrel
Thebrand“Lokkii”,“PerfectionBarbecue”andallTradeMarksUnderthebrandarethepropertyofGHHCL.
www.lokkii.com

Safety Instructions
Non-observanceofthesesafetyinstructionsandprecautionscanleadtoseriousinjury.
Pleasereadthefollowinginstructionsbeforeusingyourbarbecue.
1. Thisbarbecuemayonlybeusedoutdoors,neverindoors.
2. Beforeusingthebarbecue,positiontheBBQonaatsurface,awayfromoverhangsandtreesoutof
thewindasmuchaspossible.
3. Keepasecuredistanceof1.5metersfromcombustiblematerials.
4. Donotuseuidssuchaspetrolorsimilarhighlyammablespiritstolightorre-lightthebarbecueor
addtowarmorhotcharcoal!
5. ThemaximumamountoffuelfortheseBBQsis8KG(17.6Lb)
• Followinstructionsonthefuelbagcarefully.
• DonotputthelidontheBBQbeforetheamehasdiedout.
• “Donotcookbeforethefuelhasacoatingofash”.
Warning:
1. TheCharcoalwillbeveryhot,takesuitableprecautions.
2. Wearheatresistantovenmittswhengrillingoradjustingtheventholes.
3. Whenextinguishingcharcoalbriquettes,placethelidonthebowlandcloseallairvents.
Donotusewater.
4. Donotremoveashesuntilallcharcoalbriquettesarecompletelyburnedoutandfullyextinguished.
5. Removeashesbeforegrillingagain.Insuretheashesarecold.
6. Alwayskeepchildrenandpetsawayfromthebarbecue.
Maintenance:
•Cleanthegrillwithacleanersuitableforporcelainsurfaces.Cleanthedroppanwithsoapandwater.
•NEVERusesteelbrushes,aggressivedetergentsorsharpobjectsonporcelainsurfaces!
•Thiswilldamagethesurfaces.
•Toextendthelifeofyourbarbecue,useasuitablecover.
•StoretheBBQinadryarea.
“ATTENTION!
This barbecue will become very hot, do not move it during operation”
“Do not use indoors”
“CAUTION!
Do not use spirit, petrol or comparable uids for lighting or re-lighting”
“WARNING! Keep children and pets away”
P. 2

P. 3
Preparing to use your grill
Beforecookingwithyourgrill,thefollowingstepsshouldbecloselyfollowedtobothcurethenishand
seasontheinteriorsteel.Failuretoproperlyfollowthesestepsmaydamagethenishand/orimpart
metallicavourstoyourrstfoods.
• Brushallinteriorsurfacesincludinggrillsandgrateswithvegetablecookingoil.
• Buildasmallreonthecharcoalpan,beingsurenottolaycoalsagainstthewalls.
• Burnthecharcoalforatleasttwohours.Yourgrillisnowreadyforuse.
Rustcanappearontheinsideofyourgrill.Maintainingalightcoatofvegetableoilontheinteriorsur-
faceswillaidintheprotectionofyourgrill.Exteriorsurfacesofthegrillmayneedoccasionaltouchup.
Werecommendtheuseofcommerciallyavailableblackhightemperaturespraypaint.NEVERPAINTTHE
INTERIOROFTHEGRILL!
Please see information regarding Uncoated Cast Iron Grates below.
Cast Iron Inserts: (Sold Separately)
Beforeusingacastirongrateorothercastironcookingtool,washitthoroughlywithamilddishwashing
liquidtoremovetheprotectivewaxcoatingappliedforshipping.Rinsewithhotwateranddrycom-
pletelywithasoftclothorpapertowel.NEVERALLOWTODRAINDRYORWASHINDISHWASHER.Now
seasonthegratestopreventrustandsticking.
Lighting
RegularBriquette’s,InstantLightBriquettesorLumpwoodmayuseasafuelsourceforgrilling.When
ignitingregularbriquettesorlumpwoodcharcoal,donotuserelightersthathavepetroleumbasesor
thelikeasthesewilltaintthefoodyoueat.
DonotuseaChimneystarterforinstantlightbriquettes
Building Your Fire:
1. FormthecharcoalbriquettesorLumpwoodintoapyramidonthecharcoalgrate.
Themaximumamountofcharcoalforthisgrillis8KG(17.6LBS).
2. SolidFirestarters:           
A:Placetherestarterinthebaseofthepyramid.LighttheFirestartesinseverallocationstoensure
anevenburn.
3. LiquidorGelFirestarters,coatthebriquettesorlumpwoodwiththeliquidorgelandlightaccording
tothemanufacturer’sinstructions.
5.Neveraddcharcoallighteruidortheliketohotorwarmcoalsthiscanbeextremelydangerous.
6.Oncetherehasburnedoutthecharcoalhasturnedgrey,spreadthecharcoaloutusingalong
HandledBBQtool
7.Youarereadytocook
*Always use caution when handling hot coals to prevent injury.

P. 4
Grill Maintenance
Rotisserie
Frequencyofcleanupisdeterminedbyhowoftenthegrillisused.Makesurecoalsarecompletely
extinguishedbeforecleaninginsideoftheunit.Thoroughlyrinsewithwaterandallowtoairdrybefore
usingagain.Wipeouttheinterioroftheunitwithaclothorpapertowels.
Whennishedcooking,andtheunithasadequatelycooled,cleanoutallremainingashes.Ashescollect
moisture,whichcanleadtoprematurerustinganddecay.Periodicallycoatingtheinteriorsurfaceswith
vegetableoilwillaidintheprotectionofyourunit.Also,occasionaltouchupoftheexteriorpaintwill
berequired.Black,high-temperaturespraypaintisrecommended.NEVERPAINTTHEINTERIOROFTHE
UNIT.
Porcelain Cooking Surface:
Thecookingsurfaceofyourgrillisporcelain.Donotusescrapers,sharpinstrumentsortheliketoclean
thegrillingsurface,thiswilldamagetheporcelain.Oncethegrillingsurfacehascooleddownthesurface
canbewashedwithmilddetergentandwater,besuretothoroughlydrythesurfaceonceclean.
PleasefollowtheseparateinstructionforuseofElectricRotisserie.

Package Contents
PART
A
B
C
D
E
F
G
H
I
J
K
L
M
DESCRIPTION
Warming Rack
Grill Back Panel
Grill Left Panel
Grill Racks
Charcoal Rack Lifter
Charcoal Rack
Side Support
Top Side Vent
Bottom Side Vent
Bottom Barrel
Side Rack
Upper Support Bar
Left Leg Joints
QUANTITY
1
1
1
3
2
1
2
2
2
1
2
2
2
PART
N
O
P
Q
R
S
T
U
V
W
X
Y
DESCRIPTION
Left Back Leg
Left Front Leg
Wheel Axle
Wheel Hub
Wheel
Bottom Frame
Right Back Leg
Right Front Leg
Centre Frame Panel
Handle
Grill Right Panel
Right Leg Joints
QUANTITY
1
1
1
2
2
1
1
1
2
1
1
2
P. 5

Hardware List
Preparation
Beforebeginningassemblyofproduct,makesureallpartsarepresent.Comparepartswithpackage
contentslistandhardwarecontentslist.Ifanypartismissingordamaged,donotattempttoassemble
theproduct.
Estimated Assembly Time: 30minutes.
ToolsRequiredforAssembly(notincluded):PhilipsHeadScrewdriverandAdjustableWrench.
P. 6
PART
AA
BB
CC
DD
EE
Qty
12 pcs
44 pcs
8 pcs
4 pcs
2 pcs
NAME
M6 Flange Nut
M6 x 12 Bolt
M6 x 20 Bolt
M8 Lock Bolt
Cotter Pin

Assembly Instructions
1
2
Hardware Used:
M6x12Boltx8
Hardware Used:
M6x12Boltx8
Payattentiononassemblytheholes
directionofL,YandM.
Payattentiononassemblythesideholes
directionofthelegs.
P. 7
Hole

3
4
Hardware Used:
M6x12Boltx8
Hardware Used:
CotterPinx2
Payattentiononlegscombinationside
holesaret.
P. 8

5
6
Hardware Used:
M6x12Boltx8
Hardware Used:
M6x20Boltx4
Donottightenthescrewstemporarily.
Tightenthescrews(Includeprevious
step)
P. 9

7
8
Hardware Used:
M6FlangeNutx2
M6x20Boltx2
Payattentiononassemblytheholes
directionofH,IandJ.
P.10
Hardware Used:
M6FlangeNutx4
M6x12Boltx4

9
10
Hardware Used:
M6FlangeNutx4
M6x12Boltx8
M6x20Boltx2
P.11

11
12
P.12

13
14
Hardware Used:
M6FlangeNutx2
P.13
Hardware Used:
M8LockNutx4

15
P.14
TightenAllHardware.

P.15
Limited Warranty
Date Purchased:
Retailer: Serial Number:
* To activate your warranty, register your products within 7 days of purchase.
Go to www.lokkii.com to register your BBQ.
Thiswarrantyonlyappliestounitspurchasedfromanauthorizedretailer.Manufacturerwarrantstothe original consumer-purchaser onlythatthisproductshall
befreefromdefectsinworkmanshipandmaterialsaftercorrectassemblyandundernormalandreasonablehomeusefortheperiodsindicatedbelowbeginning
onthedateofpurchased*.Themanufacturerreservestherighttorequirethatdefectivepartsbereturned,postageandorfreightpre-paidbytheconsumerfor
reviewandexamination.
*Note: A dated sales receipt WILL be required for warranty.
The original consumer-purchaser will be responsible for all shipping charges for parts replaced under the terms of this limited warranty.
ThislimitedwarrantyisapplicableintheEU,UK,Australia,NewZealandandScandinaviaonlyandisonlyavailabletotheoriginalowneroftheproductandisnot
transferable.
Manufacturer requires proof of your date of purchase. Therefore keep your sales slip or invoice.
ThislimitedwarrantyappliestothefunctionalityoftheproductONLYanddoesnotcovercosmeticissuessuchasscratches,dents,corrosionsordiscolourationby
heat,abrasiveandchemicalcleanersoranytoolsusedintheassemblyorinstallationoftheappliance,surfacerust,orthediscolourationofsurfaces.
RUST is not considered a manufacturing or materials defect.
This limited warranty will not reimburse you for the cost of any inconvenience, food, personal injury or property damage.
Scope of Coverage:
All Parts
180 Days from Purchase
ITEMS MANUFACTURER WILL NOT PAY FOR:
1. Shippingcost,standardorexpedited,forwarrantyorreplacementparts.
2. Repairswhenyourproductisusedforotherthannormal,single-familyhouseholdorresidentialuse.
This warranty does not cover commercial use of this unit.
3. Damage,failures,oroperatingdicultiesresultingfromaccident,alteration,carelesshandling,misuse,abuse,re,ood,actsofGod,improperinstallationor
maintenance,installationnotinaccordanceoruseofproductsnotapprovedbythemanufacturer.
4. Anyfoodlossduetoproductfailuresoroperatingdiculties.
5. Repairstopartsresultingfromunauthorizedmodicationsmadetotheproduct.
DISCLAIMER OF IMPLIED WARRANTIES and LIMITATION OF REMEDIES
Repairorreplacementofdefectivepartsisyourexclusiveremedyunderthetermsofthislimitedwarranty.Intheeventofpartsnolongerbeingavailable,themanu-
facturerreservestherighttosubstitutelikeorsimilarpartsthatareequallyfunctional.
Manufacturerwillnotberesponsibleforanyconsequentialorincidentaldamagesarisingfromthebreachofeitherthislimitedwarrantyoranyapplicableimplied
warranty,orforfailureordamageresultingfromactsofGod,impropercareandmaintenance,greasere,accident,alteration,replacementofpartsbyanyoneother
thanManufacturer,misuse,transportation,commercialuse,abuse,hostileenvironments(inclementweather,actsofnature,animaltampering),improperinstallation
orinstallationnotinaccordancewithlocalcodesorprintedmanufacturerinstructions.
THISLIMITEDWARRANTYISTHESOLEEXPRESSWARRANTYGIVENBYTHEMANUFACTURER.NOPRODUCTPERFORMANCESPECIFICATIONORDESCRIPTION
WHEREVER
ITMAYAPPEARISWARRANTEDBYMANUFACTUREREXCEPTTOTHEEXTENTSETFORTHINTHISLIMITEDWARRANTY.
ANYIMPLIEDWARRANTYPROTECTIONARISINGUNDERTHELAWSOFANYCOUNTRY,INCLUDINGIMPLIEDWARRANTYOFMERCHANTABILITYORFITNESSFORA
PARTICULARPURPOSEORUSE,ISHEREBYLIMITEDINDURATIONTOTHEDURATIONOFTHISLIMITEDWARRANTY.
Neither dealers nor the retail establishment selling this product has any authority to make any additional warranties or to promise remedies in addition to
or inconsistent with those stated within this warranty.
Manufacturer’smaximum liability,inanyevent,shallnotexceedthepurchasepriceoftheproductpaidbytheoriginalconsumer.
If you wish to obtain information or Warranty Issues
Contact:
perfec[email protected]
ConsumerreturnswillnotbeacceptedunlessavalidReturnAuthorizationisrstacquired.Authorizedreturnsmustbeclearlymarkedontheoutsideofthepackage
withReturnAuthorizationnumberandthepackageisshippedfreight/postagepre-paid.Consumerreturnsthatdonotmeetthesestandardswillberefused.
PERFECTION half BARREL
M.838H
