Lone Star Aviation KMD-150 User manual

LONE STAR AVIATION CORP. • 604 S Wisteria • Mansfield, TX 76063 • 1-682-518-8882 or 1-682-518-8831- FAX
INSTRUCTION SHEET
CONGRATULATIONS ON THE PURCHASE OF YOUR NEW DOCKING STATION FOR THE
ALLIED SIGNAL KMD-150 .
STEP 1 UNPACKING:
UNPACK YOUR DOCKING STATION FROM THE SHIPPING CONTAINER, CHECK FOR ANY
DAMAGE. IF THE CONTAINER AND PRODUCT HAS BEEN DAMAGED CONTACT LONE STAR's
CUSTOMER SERVICE REPRESENTATIVE TO REPORT THE INCIDENT.
A. THE ENCLOSED PACKAGE WILL CONTAIN THE FOLLOWING ITEMS:
1 ( ONE EACH ) KMD DOCKING STATION.
2. ( ONE EACH ) AC CORD.
3. THE APPROPRIATE CABLE ASSEMBLY ( ONE EACH, KMD-150 ).
4. PANEL FUSE.
STEP 2 READ INSTRUCTIONS:
READ THIS INSTRUCTION SHEET THOROUGHLY, IF YOU HAVE ANY QUESTIONS PLEASE CALL
YOUR LONE STAR AVIATION CUSTOMER SERVICE REPRESENTATIVE FOR CLARIFICATION.
STEP 3 SETUP:
SETUP THE DOCKING STATION ON A LEVEL DESK TOP OR BENCH NEAR A GROUNDED AC POWER
OUTLET SOURCE.
STEP 4 INSTALLING THE KMD-150 INTO THE CONTROL STATION :
THE DOCKING STATION COMES READY TO OPERATE, SIMPLY LOOSEN THE (4) SCREWS ON
THE LEFT & RIGHT SIDE OF THE TOP COVER SO THAT YOU CAN SLIDE THE CONTROL HEAD
INTO THE OPENING UNTIL THE CHASSIS’s FRONT BEZEL IS ALMOST INSERTED.
YOU SHOULDN'T HAVE TO MAKE ANY MAJOR ADJUSTMENTS ONCE THE UNIT IS POSITIONED
IN PLACE. SOME USERS KEEP THE FRONT SCREWS LOOSER THAN THE REAR. THIS WILL MAKE
IT EASIER AND QUICKER TO INSERT AND REMOVE THE CONTROL HEAD FROM THE DOCKING
STATION WHEN YOU USE IT.
THE COMMANDER 2900 DOCKING STATION FOR THE KMD-150 HAS AN OPTIONAL COOLING FAN
AVAILABLE, PART NUMBER LS03-02013.
CONGRATULATIONS:
REVISION 2-23-04 PRINTED IN USA
KMD-150
LSPE -00236
STEP 5 OPTIONAL COOLING FAN

kmd-150 INSTRUCTION SHEET
STEP 5 POWER UP UNIT:
ONCE THE KMD-150 IS INSTALLED INTO THE DOCKING STATION YOU
ARE READY TO POWER -UP THE STATION AND CONTROL HEAD.
FIRST: TOGGLE THE DOCKING STATION’s ON/OFF SWITCH TO THE OFF
POSITION.
SECOND: PLUG THE AC CORD INTO THE DOCKING STATION’s AC INLET RECEPTACLE
THEN INTO AN AC GROUNDED POWER SOURCE.
THIRD: MAKE SURE THE KMD-150 ON/OFF SWITCH IS IN THE OFF POSITION.
FORTH: INSERT THE ( 8 PIN DIN ) POWER CABLE ASSEMBLY INTO THE 8 PIN DIN
ROUND FEMALE RECEPTACLE ON THE DOCKING STATION’s BACK
ACCESSORY
PANEL. CONNECT THE GRAY FEMALE MULTI- PIN (37) PINdb CABLE
ASSEMBLY INTO THE TOP (37) PIN MALE CONNECTOR ON THE REAR OF
THE KMD-150.
FIFTH: TURN THE DOCKING STATION’s ON/OFF SWITCH TO THE ON POSITION.
SIXTH: TURN THE KMD-150’s POWER SWITCH TO THE ON POSITION.
THE DOCKING STATION’s POWER SUPPLY TAKES (4) SECONDS TO REACH FULL
POWER. THE RED LED INDICATES DC POWER IS ACTIVE FROM THE
POWER SUPPLY, THROUGH THE FUSE ASSEMBLY TO THE 8 PIN POWER
CABLE.
STEP 6 KMD-150 OPERATIONS:
FOR GENERAL OPERATING INSTRUCTIONS, TRAINING, OR PROGRAMMING
REFER TO YOUR OWNER’s MANUAL, PILOTS GUIDE, OR SERVICE INSTALL
DOCUMENTATION.
1. TRAINING - INITIAL-BASIC-TO ADVANCED OPERATIONS.
2. FIRMWARE UPGRADES / SYSTEM VERIFICATION CHECKS.
STEP 7 DOCKING STATION MAINTENANCE:
1. FUSE REPLACEMENT - REPLACE WITH 3 AMP FUSE - 1.25 X .025 FAST BLOW.
2. CLEANING - CLEAN WITH ALCOHOL.
3. POWER SUPPLY - N/A
4. CONNECTOR - N/A
STEP 8 PELICAN CASE: THE 1550 PELICAN CASE HAS SEVERAL OPENINGS FOR
VARIOUS PRODUCTS, ONE BEING THE KMD-150 THE TOP
INCORPORATES AN OPENING FOR A 1/2/ MANUAL. THE BOTTOM SECTION
HAS (2) TRIANGULAR SHAPES FOR CABLES, ADAPTERS, ETC. THE
PREDOMINATE OPEN AREA HAS BEEN SPECIFIED FOR YOUR SPECIFIC
EQUIPMENT.
2
OFF
ON
