Lonpoo LP-808 User manual
Thank you for purchasing the LONPOO CD Micro System
This CD Micro system delivers loud sound and deep bass.
TECHNICAL SPECIFICATIONS:
CONNECTIVITY FEATURES: IN THE BOX:
PowerOutput(RMS): 30W (2x 15W)
•
Blue tooth
• LONPOO
Micro System
Max. Power Output: 40W
•
USB2.0 port
•
User Manual
Woofer: 2x 4" up to 32Gb, FAT16/32 file system
•
Remote Control
Freq. Response: 40Hz - 20KHz
•
AUX In
Impedance:
4Ω
•
HEADPHONES
S/N: 80dB
FM Frequency Range: 87.5 - 108MHz
MP3/WMA Bit Rate: 32-320Kbps (MP3)
40-320Kbps (WMA)
OTHER FEATURES:
Rated Voltage: AC 100-240V, 50/60Hz
Power Consumption: ≤30W
•
CD/CD-R/CD-RW/MP3
Dimensions (MainUnit): 150x230x195mm
•
FM Radio
Dimensions (Speakers): 130x229x155mm (each)
•
LED Display
- Quick Guide -
LP-808
WARNING
1.
Thelightning flash with the arrowhead symbol within an equilateral
t
riangle alerts the user to the presence of un-insulated dangerous voltage
w
ithin the product’s enclosure that could cause electric shock.
2.
Theexclamation markwithinanequilateraltrianglealerts theuserto
t
he presence of important operating and maintenance instructions as well
as warnings in the user’s manual or on the product.
CLASS 1 LASER PRODUCT LABEL
T
hislabelisattachedtotheplaceasillustratedtoinformthatthisdevice
contains a laser component.
CLASS 1
LASER PRODUCT
CLASSE 1
LASER PRODUTO
KLASS 1
LASER APPARAT
KLASSE 1
LASER PRODUKT
CLASSE 1
PRODUIT LASER
For European Union:
This symbol on the product or on its packaging indicates
that this product shall not be treated as household waste.
By ensuring this product is disposed of correctly, you will hel
p
prevent potential negative consequences for the environmen
t
and human health, which could otherwise be caused by inap
-
propriate waste handling of this product.
It should be handed over to the applicable collection point fo
r
t
he recycling of electrical and electronic equipment. Please contact your loca
l
retailer. The recycling of materials will help to conserve natural resources.
DECLARATION OF CONFORMITY
Radio equipment and telecommunications terminal equipment, Directive 2014/53/EU
General instructions
Please read these safety instructions before using your device
and store them for possible future reference.
1.
Do not attempt to remove anyscrews, or open the cover of the unit;
there are no user serviceable parts inside, refer all servicing to qualified
service personnel.
2.
Thepower supply mustbe replacedbya newonein case ofmalfunction,
because this power supply is not repairable.
3.
The socket outlet shall be installed near the equipment and shall be easily
accessible.
4.
The product is not intended for use by persons (including children) with
reduced physical, sensory or mental capacity. Persons who have not read
the manual, unless they have received explanations by a person responsi-
ble for their safety and supervision, should not use this unit.
5.
Childrenshouldbemonitored toensurethattheydonotplayunattented
with the product.
6.
The cord should always be easily accessible.
7.
Thedeviceshould notbeexposed todrippingor splashingofwater or
liquids and no objects filled with liquids, e.g.flower vases, should be
placed on theproduct.
8.
Thenormalventilationoftheproductshallnotbeimpended forintended
use.
9.
Itisrecommendedtoleave aminimumdistance of10cmaroundthe unit
to ensure sufficient ventilation.
10.
Openflame sources,such as candles, shouldnot be placed on topof
the device.
11.
The device is intended for use only in a temperate climate.
12.
CAUTION:
Danger of explosion if battery is incorrectly replaced or not replaced by
the same type or equivalent.
13.
The battery should not be exposed to excessive heat such as sunshine,
fire or similar.
14.
Different types ofbatteries, new andused batteries shouldnot be mixed.
15.
The battery must be installed according to the polarity.
16.
If the battery is worn, it must be removed from the product.
17.
The battery must be disposed of safely. Always use the collection bins
provided for recycled items in order to protect the environment.
1 Year Warranty
LINE IN
RADIO
USB
CD
Blue tooth
Press SOURCE button on the
R
emote Control or Main Unit
toswitchbetweenavailablemodes.
Mode Selection
4
Unit:
1
.
To prevent shock hazard
d
isconnect from the AC power
s
ource when cleaning the device.
2.
Clean with a dry cloth.
A
dump cloth may be used on
the front panel.
Compact discs:
1.
Treat disc carefully holding it by its edges.
2
.
Clean with a soft, dry cloth. Wipe from
t
he center to the outer edge of the disc.
D
o not wipe in circular direction.
3.
Do not stick or write anything
on either side of the disc.
Caire & Maintenance
8
1.
AUX IN: Connect your external sound source via 3.5mm audio cable.
2.
USB:Play songs directly from aUSB flash drive. Won’t chargea device.
3.
HEADPHONES: Connect yourheadphones.
3. PHONES
2. USB
1. AUX IN
Wired Connection
3
REMOVE USB:
�
In order to safely eject
the USB flash drive,
change the SOURCE
before removing it.
Number Keypad
Stop
Memory
Save Radio Stations
Repeat
1
χ: One song
2
χ: All songs
3
χ: OFF
Previous track/radio station
Seekbackwards/manualtunning
Next track/radio station
Seek forward/manual tunning
Mute
VOL -/+
Play/Pause music
Increase/Decrease volume
Standby
On/Off
Controller
6
Slide out cover and place
2
AAA type batteries (not
i
nluded) with polarities as
shown below.
2. Connect the unit to the outlet:
•
Connect the mains plug into the electrical outlet.
3. Battery Installation:
1. Connect the speakers to the unit:
•
Connect each speaker to the respective terminal.
•
Speakers with 2-colour cable: black and red.
C
onnect red cableinto the red terminal(indicated as +),
Connectblack cableintothe black terminal (indicatedas -).
Set up
1
* The device will automatically connect to the last
paired Bluetooth device (smartphone, tablet etc.).
LONPOO
* In case you are asked for a pass-code, please type
in the numbers “1234”.
SOURCE
2. On your device,
t
urn BLUE TOOTH on
a
nd make itdiscoverable.
S
earch for LONPOO
and select it.
1.Press SOURCEbuttonontheRemoteControl
o
r Main Unit and select BLUE TOOTH mod
e
(bt indication on LED display).
You can pair LP-808 with any Blue tooth enabled device (phone, tablet etc.)
etc.)
etc) etc).
Wireless Connection
2
AUTOMATICALLY
RADIO mode:
P
ress SCAN button on
M
ainUnit toautomatically
s
earch and save available
radio stations.
SAVE
T
osavethestationpressΜ(PROG/SAVE)on
t
he Remote Control and choose the desired
p
osition by pressing CH- / CH+.
P
ress Μ(PROG/SAVE) once more to confirm
and save .
MANUALLY
RADIO mode:
L
ong press TUN- / TUN+
o
n the Remote Control
o
r Main Unit to manually
select a radio station.
Radio Tuning
5
USB port
Mains
Auxiliary
Input
Control
Buttons
Volume Knob
Headphones
Antenna
Cable
Equalizer
R
OCK/JAZZ/POP/
CLASSIC/FLAT
IRSensor
Mode
Button
ON/OFF
Standby
Rear View
Front View
7
3.5mm
Select Blue tooth, CD, USB
Radio, Line In Mode
Speaker
Terminals
Source
MODEL:LP-808
AC100-240V
50/60Hz
30W
