10/100/1000Mbps PCI
Gigabit Ethernet Adapter
User’s Manual

FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply
with the limits of a Class B computing devices,
pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
If you suspect this product is causing interference, turn
your computer on and off while your radio or TV is
showing interference. If the interference disappears
then when you turn the computer off and reappears then
you turn the computer on, something in the computer is
causing interference.
You can try to correct the interference by one or more
of the following measures :
1. Reorient/Relocate the receiving antenna.
2. Increase the separation between the equipment and
receiver.
3. Connect the equipment into an outlet on a circuit
difference from that to which the receiver is
connected.
4. Ensure that all expansion slots (on the back or side
of the computer) are covered. Also ensure that all
metal retaining brackets are tightly attached to the
computer.

1
1Introduction
Thank you for purchasing our Gigabit Ethernet Adapter.
This guide is to provide the installation and usage of this
adapter for network installers and users. The Gigabit
network adapter complies to 64-bit or 32-bit PCI
specification and supports half-/full- duplex feature
which can double network speed.
This adapter supports 1000Mbps(Gigabit), 100Mbps and
10Mbps network speed, 1000BaseT operates on all four
pairs of category 5 UTP cable, 100BaseTX operates on
two pairs of category 5 UTP cable and 10BaseT operates
on Category 3, 4 or 5 UTP cable.
With the Auto-Negotiation technology, network speed is
auto detected. When you connect the adapter to Gigabit
Switch or another Gigabit NIC, the speed will be doubled
to 2000Mbps (1000Mbps Transmit and 1000Mbps
Receive). If you connect the adapter to 100BaseTX hub,
the network speed is 100Mbps. Similarly, if the hub is a
switching hub which supports full duplex function, then
the speed will be doubled to 200Mbps.
This adapter supplies many drivers including Microsoft
Windows 98, 98SE, Me, NT, 2000, XP, Netware Server
4.x/5.x/6.x, Netware ODI for DOS, Linux, Unix.
Whatever your requirements are ease of installation,
superior performance or responsive support backed up by
unlimited technical support, this adapter is the superior
choice.
1

2
2Features & Specifications
(1) Features & Benefits
ySupports 64/32-bit, 66/33MHz PCI Local Bus Master
Version 2.2/2.1.
yComply with the IEEE 802.3, IEEE 802.3u, IEEE
802.3ab, IEEE 802.3x.
ySupports IEEE 802.3x full duplex flow control.
ySupports Wake On LAN power management function.
yPlug and Play installation, auto-setup IRQ and I/O
address.
yAuto-Negotiation, full/half- duplex.
2

(2) Technical Specification
yTopology : Star
yConnector : RJ-45
yStandard : IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX
IEEE 802.3ab 1000BaseT
yTransmission Rate : 10Mbps/20Mbps
100Mbps/200Mbps
1000Mbps/2000Mbps
yHardware Required : IBM compatible PC with
available PCI slot
(PCI 2.2/2.1), 64-/32-bit,
66/33MHz
yIRQ Line : Assigned by system
yI/O Address : Assigned by system
yDrivers : Windows 98/98SE/Me/NT
Windows 2000/2003/XP,
Netware Server 4.x/5.x/6.x,
Netware ODI for DOS,
Linux, Unix
yLEDs : Speed, Link/Activity
yDimension : 163 x 45 mm (for 64-bit Model)
120 x 40 mm (for 32-bit Model)
yTemperature : 32-131°F (0-55°C)
yHumidity : 10% to 95% (Non-condensing)
yCertification : FCC Class B, CE Mark, C-tick,
VCCI
3

3
3Installation
(1) Hardware Installation
To insert the network adapter into your PC, follow the
steps as below :
1. Turn off the computer and remove its cover.
2. Insert the adapter into a PCI slot.
3. Secure this adapter to the rear of the computer
chassis and put back the computer cover.
4. Connect the adapter to the network using twisted-
pair cable.
(2) Driver Installation
Use the drivers supplied by the diskette included in this
product. For detail description, please execute the
readme.exe in the root directory of the diskette
provided by this product.
4

4
4Trouble-shooting
If you experience any problems with the adapter, please
make sure the appropriate driver is loaded, the proper
cable is connected to the adapter port and the hub/switch
complies with the adapter specification, such as 10Mbps
10BaseT, 100Mbps 100BaseTX and 1000Mbps
1000BaseT, then check the LED.
The adapter provides LEDs to indicate network status.
Speed
The LED indicates the adapter is connected to 10BaseT,
100BaseTX, or 1000BaseT network. When the light is
OFF, it indicates that the adapter is connected to
10BaseT network. When the light is ON in green color,
it indicates that the adapter is connected to 100BaseTX
network. When the light is ON in amber color, it
indicates that the adapter is connected to 1000BaseT
network.
Link/Activity
The LED indicates if the UTP has been LINK ok or not.
When the light is OFF, it indicates that the UTP port has
not been connected or LINK not ok. When the light is
ON, it indicates that the UTP port LINK ok. When the
light is BLINKING, it indicates that there is traffic flow
on the network which the adapter is connected to.
5

Copyright 2004/2005 by the manufacturer of this
product. No part of this manual may be reproduced,
transcribed, stored in a retrieval system, translated into
any language or computer language without the prior
written consent of the manufacturer.
All brand and product names are trademarks and/or
registered trademarks of their respective companies.
