Lorex SG7610B User manual

LOREX Technology Inc.
Copyright © 2007 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
Quick Set-up Guide
It’s all on the web
Product Information
User Manuals
Quick Start Guides
Specification Sheets
Software Upgrades
Firmware Upgrades
VISIT
www.lorexcctv.com
4. Camera Specifications H O M E & B U S I N E S S S E C U R I T Y
HIGH RESOLUTION
WEATHERPROOF COLOR CCD
CAMERA WITH NIGHT VISION
Dimensions:
Image Device 1/3” Color CCD
Effective Pixels NTSC:768Hx494(410K)
PAL:752Hx582V(470K)
Scanning System
Resolution
AES Shutter Speed
S/N Ratio
Sync. System
Min. Illumination
White Balance
Video Output
Lens
Power Supply
Power Consumption
Operating Temp
FOV (Diagonal)
2:1 interlace
NTSC: 525 Lines
PAL: 625 Lines
Horizontal 480 TV lines
NTSC: 1/60 ~ 1/100,000
PAL: 1/50 ~ 1/100,000
More than 48dB (AGC off)
Internal
1 LUX @F1.2 (no LED)
0 LUX (with LED)
AWB
1.0 Vp-p (75 ohms)
Fixed Lens (3.6mm)
DC 12V ±10%
230mA / 3.0W
14°F ~ 122°F
(-10°~ 50°C)
100 Degrees
Model: SG7610 Series
SG7610B (NTSC)
SG7610BP (PAL)
Refer to online Spec Sheet for specific
Packaging Configurations.

Features:
• Hi Resolution CCD Image Sensor (480 TV Lines and
410K pixels)
• 12 Hi Intensity IR LEDs provides effective night vision
range over 30 ft. (10 m)**
• Day / Night mode: Picture automatically switches
camera to B&W delivering better clarity in low light
conditions
• Ceiling or Wall Mountable Cameras with versatile stand
provides flexible mounting options
• Weatherproof*** Cameras ideal for Outdoor and indoor
applications (IP66)
• Plug and Play Cameras: all-in-one camera cable
(providing Video, audio & Power) plugs directly to the
monitor and eliminates the need for a separate power
adaptor
• 100 ft.(30m) extension cable included per camera
** Night Vision Range up to 30ft. (10m) in ideal conditions. Objects
at or beyond this range may be partially or completely obscured,
depending on the camera application.
*** Not for use in direct exposure to water, rain or snow
1. Package Contents 2. Installing the Camera 3. Camera Diagram
1 x CCD Color Day/
Night Camera
1 x Camera Stand 1. Mount the camera stand to the desired mounting
surface. Attach the camera to the supplied stand.
2. Aim the camera. Remove the protective film from
the lens.
3. Connect the 100ft Extension cable to the camera:
Connect the other end of the 100ft Extension
Cable to the Observation System or DVR.
Note: Confirm that the arrows on the DIN Extension cable
are aligned with the Camera
Cable and System ports when
connecting the cable. If the
pins in the DIN Cable are bent,
the Camera will NOT function
DIN System Connection Diagram:
1 x 100’ (30m) DIN
Extension Cable
Lift the plastic tab on
the lower edge of
the camera to
remove the
protective film.
1 x DIN to BNC Coupler
1 x Power Adaptor
*
* DIN to BNC Coupler and Power Adaptor are included with
the SG7610B Series only. This provides universal
compatibility to industry standard BNC connectors.
Note: Test the cameras prior to selecting a permanent
mounting location by temporarily connecting the
Cameras and Cables to the System.
DIN to BNC System Connection Diagram:
Cameras with 6 Pin DIN connections draw
power from the Observation System or DVR.
Additional power adapters are not needed for
these cameras.
Infra-Red
LEDs
Camera
Lens
Micro-
phone
Adjustable
Stand
DIN Input
Cable
