LOWE'S KD100-23 User manual

CONSUMER SAFETY INFORMATION: PLEASE READ THIS MANUAL BEFORE
INSTALLING AND OPERATING THIS APPLIANCE. FAILURE TO FOLLOW THESE
INSTRUCTIONS MAY RESULT IN A POSSIBLE ELECTRIC SHOCK, FIRE HAZARD, AND/OR
INJURY AND WILL VOID THE WARRANTY.
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED, AN ELECTRIC
SHOCK OR FIRE MAY RESULT IN PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF
LIFE.
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
ELECTRIC FIREPLACE OPERATING MANUAL
261046
MODELS: KD100-23
KD100-26
KD100-30
The actual appearance should be subject to the purchase model
01 02 03 04 05 06 07 08 09 10

IMPORTANT INSTRUCTIONS
SAVE THESE INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to reduce the risk
of fire, electrical shock, and/or injury including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Keep
combustible materials, such as furniture, pillows, bedding, papers, clothes, curtains etc., at
least 3 feet (0.9 m) from the front of the heater and keep them away from the sides and rear.
3. Extreme caution is necessary when any heater is used by or near children or invalids and
whenever the heater is left operating and unattended.
4. Do not operate any heater after it malfunctions. Disconnect power at service panel and have
heater inspected by a reputable electrician before reusing.
5. Always unplug this appliance when not in use.
6. Do not operate any heater with a damaged cord or plug, after the appliance malfunctions, or if it
has been dropped or damaged in any manner.
7. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
8. Any repairs to this fireplace should be carried out by a qualified service person.
9. Under no circumstances should this fireplace be modified. Parts having to be removed for
servicing must be replaced prior to operating this fireplace again.
10. Do not use outdoors.
11. This heater is not intended for use in bathrooms, laundry areas and similar indoor locations.
Never locate this appliance where it may fall into a bathtub or other water container.
12. Do not run cord under carpeting. Do not cover cord with throw rugs, runners or the like. Arrange
cord away from traffic areas and where it will not be tripped over.
13. To disconnect this appliance, turn controls to the off position, then remove plug from outlet.
14. Connect to properly grounded outlet only.
15. This appliance, when installed, must be electrically grounded in accordance with local codes or,
in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code or for USA
installations, follow local codes and the National Electrical Code, ANSI/NFPA NO.70.
16. There is a protective thermostat limiter inside the heater. When the inner temperature
overheats, the thermostat limiter will shut off the power supply to avoid the risk of fire damage to the
appliance.
17. The heaters must not be located immediately below a socket-outlet.
18. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may
cause an electric shock or fire or damage the appliance.
19. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on soft
surfaces, like a bed, where opening may become blocked.
20. This appliance has hot and arcing or sparking parts inside. Do not use where gasoline, paint, or
flammable liquids are used or stored. This fireplace should not be used as a drying rack for clothing.
Christmas stockings or decorations should not be hung around it.
21. Use this appliance only as described in the manual. Any other use not recommended by the
manufacturer may cause fire, electric shock or injury to persons.
22. Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or
relocatable power tap (outlet/power strip).
01 02 03 04 05 06 07 08 09 10

ELECTRICAL SPECIFICATIONS
Voltage: 120VAC 60Hz
Watts: 1500 Watts
PACKAGE CONTENTS
Heater
Logset
Remote Control Manual
01 02 03 04 05 06 07 08 09 10
ITEM # KD100-23-A
ITEM # KD100-23-B

Plan the installation of your fireplace to avoid the use of an extension cord, and ensure that you
have clear access to a grounded electrical outlet. The fireplace appliance comes with a standard
6-ft. (1.8m) 3-wire cord exiting from the rear of the heater. Once you have decided on a location,
position your assembled mantel close to the final location. You will need to have access to the back
of the mantel as the electric fireplace appliance will be installed from the back.
GROUNDING INSTRUCTIONS:
This heater is for use on 120 volts. The cord has
a plug as shown at (A) in figure 2. An adapter as
shown at (C) is available for connecting
three-blade grounding-type plugs to two-slot
receptacles. The green grounding lug extending
from the adapter must be connected to a perma-
nent ground such as a properly grounded outlet
box. The adapter should not be used if a
three-slot grounded receptacle is available.
NOTE: Adapters are NOT for use in Canada.
Grounding Pin
Cover of Grounded Outlet Box
Adapter
Grounding Lug
Metal Screw
Cover of Grounded Outlet Box
B
C
A
Figure 2
INSTALLATION INSTRUCTIONS
You should connect wire A to wire B before position assembled mantel to the final location.
Otherwise the fireplace will not work properly.
wire A
wire B
wire A
wire B
Connected
01 02 03 04 05 06 07 08 09 10

Do not share a socket with other appliances
when using the electric fireplace. Please use
a dedicated socket.
Never use with an extension cord or
relocatable power tap (outlet / power strip).
√××
×
01 02 03 04 05 06 07 08 09 10

OPERATING INSTRUCTIONS
On the top-right of the heater is the mechanical control panel. This panel contains the buttons to
properly operate the electric fireplace. The functions of buttons on the remote control are the same
as the control panel. The remote control has an effective range of up to 19 ft..
Digital Display
POWER
The POWER button turns the appliance on or off. It has a memory function,the button turns off all
functions at once but retains the settings in the memory (except timer). By pressing the button
again, the unit will turn on at the same settings. If the TIMER has set and the time has expired all
functions will stop. Press the POWER button start the appliance.
FLAME
The FLAME button is used to turn flames ON, to alter the flame brightness and to turn flames OFF.
There are 4 brightness levels（L4- L3-L2-L1）and an off position you can cycle through. Each time
the FLAME button is pressed, the intensity of the flame decrease.
While ‘L4-L1’ is displayed, press INCREASE/DECREASE button to change the speed of the flames
by cycling through three levels: Slow(1), Medium(2), Fast(3).
HEATER
The HEATER button is used to turn the heater on and off. Pressing the heater button once turns the
heater on. Pressing the HEATER button a second time within 10 seconds will turn the heater off.
When the heater is turned off, the quartz tubes will stop working first, and then the blower will stop
after 60 seconds.
When the heater is on, press the INCREASE/DECREASE button to change the desired tempera-
ture. There are 11 temperature settings: 82℉-ON - 64℉- 66℉- 68℉-70℉-72℉-74℉-76℉-78℉
-80℉(27℃-ON - 18℃-19℃- 20℃-21 ℃-22℃-23℃- 24℃-25℃-26℃). ON means the heater keep
working.
01 02 03 04 05 06 07 08 09 10

Temperature Unit Convert Function: The heater includes Celsius and Fahrenheit temperature
scales. To change the temperature unit, turn the heater on, and then press and hold the Power
Button for 5 seconds. The current temperature unit display will flash 3 times and convert to the
other temperature unit. Note: The remote control cannot convert the temperature units.
Lock and Unlock Heater Function: Press and hold the heater button for 10 seconds. The ember
bed will flash 6 times, indicating that the heater function is locked. To unlock the heater function,
press and hold the heater button for 10 seconds. The ember bed will flash 6 times, indicating the
heater function is unlocked. Note: The remote cannot set the lock and unlock heater function.
TIMER
The timer has adjustable settings from 1 hour to 9 hours and OFF. These are shown as:
1h-2h-3h-4h-5h-6h-7h-8h-9h-OFF. If the digital display turns on and no timer setting is chosen
within 10 seconds, the digital display will shut off automatically. Once you set the timer and the
timer is up, the unit will close all functions and enter standby mode. In this mode, you will need to
press the power button to restart the appliance.
INCREASE/DECREASE
This button is used to adjust levels for the flame speed and change the desired temperature. See
relevant section for more details.
BATTERIES REPLACEMENT
NOTE:
·Do not mix old and new batteries.
·Do not mix alkaine, standard (carbon zinc), or rechargable (nicad, nimh, etc.) batteries.
·Do not ingest batteries.
CAUTION:
·Always purchase the correct size and grade of battery most suitable for the intended use.
·Replace all batteries of a set at the same time.
·Clean the battery contacts and also those of the device prior to battery installation.
·Ensure the batteries are installed correctly with regard to polarity (+ and -).
·Remove batteries from equipment which is not to be used for an extended period of time.
·Remove used batteries promptly
01 02 03 04 05 06 07 08 09 10

Clean the metal trim using a soft cloth, slightly dampened with citrus oil based product and buff with
a clean soft cloth.
DO NOT use brass polish or household cleaners as these products will damage the metal trim.
Citrus oil based products can be obtained at supermarkets or hardware stores.
The motors used on the fan and the flame generator assembly are pre-lubricated for extended
bearing life and require no further lubrication. However, periodic cleaning/vacuuming of the fan/
heater unit is recommended. Make sure the unit is turn OFF and unplugged whenever you are
cleaning the heater of fireplace.
WARNING: Make sure the power is turned off before proceeding. Any electrical
repairs or rewiring of this unit should be carried out by a licensed electrician in
accordance with national and local codes. If repairing or replacing any electrical
component or wiring, the original wire routing, color coding and securing locations
must be followed.
WARNING: Electric outlet wiring must comply with local building codes and
other applicable regulations to reduce risk of fire, electric shock and injury to
persons.
WARNING: Do not use this fireplace if any part of it has been under water.
Immediately call a qualified service technician to inspect the fireplace and replace
any part of the electrical system.
WARNING: Disconnect the power before attempting any maintenance or clean-
ing to reduce the risk of fire, electrical shock or personal injury.
WARNING:During any service of this appliance, the power to the unit must be
turned off. Always remember to remove the electrical plug from the wall outlet.
WARNING: When the heater is not in use, the heater should be stored in a dry
location, away from possible damage. The power cord should be stored properly to
avoid contact with hot or sharp objects.
MAINTENANCE
01 02 03 04 05 06 07 08 09 10

TROUBLESHOOTING
Fault code Fault Cause Solution
E1 Heater is overheating Contact customer service
Heater is not workingE3
FCC STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the following two condi-
tions: (1) This device may not cause harmful interference, and (2) this device must accept any inter-
ference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that inter-
ference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is con-
nected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the party responsible for compli-
ance could void the user's authority to operate the equipment.
Turn the unit off and unplug it from the electrical
outlet. Check for dirty or clogged vents. Clean the
dust and debris from the vent area. Wait 5 minutes,
plug in the fireplace, and then turn it back on. If the
heater still doesn't work, contact customer service.
01 02 03 04 05 06 07 08 09 10

1 YEAR LIMITED WARRANTY
Our electrical fireplace is free from manufacturing and material defects for a period of one year from
date of purchase, subject to the following conditions and limitations.
1. This electric fireplace must be installed and operated at all times in accordance with the installa-
tion and operating instructions furnished with the product.Any unauthorized repair, alteration, willful
abuse, accident, or misuse of the product shall nullify this warranty.
2. This warranty is non-transferable, and is made to the original owner, provided that the purchase
was made through an authorized supplier of the company.
3. The warranty is limited to the repair or replacement of parts found to be defective in material or
workmanship, provided that such part(s) has(have) been subjected to normal conditions of use and
service, after said defect is confirmed by the Company’s inspection.
4. The Company may, at its discretion, fully discharge all obligation with respect to this warranty by
refunding the wholesale price of the defective part(s).
5. Any installation, labor, construction, transportation, or other related costs/expenses arising from
defective part(s), repair, replacement, or otherwise of same, will not be covered by this warranty, nor
shall the Company assume responsibility for same.
6. The owner/user assumes all other risks, if any, including the risk of any direct, indirect or conse-
quential loss or damage arising out of the use, or inability to use the product, except as provided by
law.
7. All other warranties - expressed or implied - with respect to the product, its components and
accessories, or any obligation/liabilities on the part of the Company are hereby expressly included.
8. The Company neither assumes, nor authorizes any third party to assume, on its behalf, any other
liabilities with respect to the sale of our product.
9. The warranties as outlined within this document do not apply to 3rd party accessories used in
conjunction with the installation of this product.
This warranty is void if:
a. The fireplace is subjected to prolonged periods of dampness or condensation.
b. Any unauthorized alteration, willful abuse, accident, or misuse of the product.
c. You do not have the original receipt of purchase.
Made in China
Printed in China
01 02 03 04 05 06 07 08 09 10

Made in China
We appreciate the trust to purchase our electric fireplace media mantel. We strive to
continually create quality products designed to enhance your home. Visit us online to see our
full line of products available for your home improvement needs. Thank you for choosing us!
THANK YOU
ASSEMBLY, CARE & USE INSTRUCTIONS
W100-23KD-GW Gray Wash Color
W100-23KD-RB Reclaimed Barnwood Color
55" TV MEDIA STAND WITH ELECTIC FIREPLACE
KD INSERTS HEATER

Before you begin, locate the instructions and hardware. Take out all the parts
and compare them to the diagramsbelow. Be sure you have all the parts and
can identify them.
Two people are required to assemble this product. Assembly time will take
approximately 30-90 minutes.
Before assembly, use scissors to unwrap the parts from the packaging.
DO NOT use a box cutter or exacto-knife as you may cut into the mantel
pieces inside the box and damage the finish.Check for the hardware tie
which is RED and located inside the packaging, taped to the top box.
DO NOT discard any pieces.
ASSEMBLY TIPS
-1-
There are small components used in the construction of this product.
Loose items should be kept away from pets and children to avoid a choking
hazard. keep all plastic and packaging film away from pets and children to
avoid suffocation.
CAUTION
1. Dust your fireplace mantel regularly with a soft non-lint producing cloth
or household dusting product.
2. You can clean your fireplace insert with a gentle non-abrasive household
cleaner. Make sure to dry your fireplace immediately with a soft cloth or towel.
CARE AND MAINTENANCE
TOOLS REQUIRED ( NOT INCLUDES )
Safety goggles
Phillips screwdriver

PARTS LIST
-2-

Assembly steps(EN)
1 PC 1 PC 1 PC 1 PC
1 PC 1 PC 1 PC 1 PC
1 PC 1 PC
-3-
2 PCS
2 PCS 1 PC 1 PC
1 PC
1 PC
1 PC 1 PC 2 PCS 1 PC
2 PCS 1 PC 1 PC 1 PC

A
32 PCS
B
32 PCS
ø15*12
C
40 PCSØ8*30mm
D
2 PCS
E
4 PCS
F
4 PCS
G
8 PCS
H
1 PCS
I
20 PCS
J K
48 PCS 24 PCS
M
10 PCS
L
32 PCS
N
6 PCS
O
4 PCS
P
4 PCS
ø4*16mm
-4-
HARDWARE LIST:
M4*23mm
ø3.5*14mm
ø7*40
M4
ø4*35mm
Q
4 PCS
R
2 PCS
T
8 PCS
ø3.5*12mm
4 PCS
ø4*35mm
S
ø3.5*14mm

STEP 1
Assembly steps(EN)
-5-
C22 Ø8*30MM
A4
A
A
A
A
C
C
C
C
C
C
C
CC
C
C
C
C
C
C
C
C
C
C
C
C
C

STEP 2
Assembly steps(EN)
-6-
STEP 3
N3Ø4*35MM
T4Ø3.5*12MM
N
N
N
T
T
T
T

STEP 4
Assembly steps(EN)
-7-
STEP 5
T4Ø3.5*12MM
T
T
T
T
M2Ø7*40MM
M4
H
M
M
H

STEP 6
Assembly steps(EN)
-8-
STEP 7
M4Ø7*40MM
M4
H
M
M
M
M
H
B4
13
2Tighten
B
B
B
B
B

STEP 8
Assembly steps(EN)
-9-
STEP 9
M4Ø7*40MM
M4
H
The power cord passes through the gap
M
MM
M
H
