LPS SimPleX User manual

LPS-
Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone]
Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone]
77 www.lps-laser.de [e-mail]
Manual
As of November 014
P a g e 1 | 36
Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany

P a g e | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
Foreword
You have decided to buy a SimPleX show laser system.
We want to thank you for showing trust in us.
The SimPleX system is characterised by simple operation and comfortable application.
This manual should help to simplify working with this system. It also allows unpractised persons to
understand all functions easier.
Before you put the system into operation for the first time, please read the topics “laser safety” and
“starting”.
Our laser systems are equipped with high sensitive electronics and mechanics. Please pay attention
during transport to the security of your device. Strong shocks can cause significant damage to the
system. Furthermore, the lasersystem must be regulary maintained to guarantee an error-free
operation.
CAUTION!
Should an error occur due to improper handling or maintenance, there is no warranty.
We wish you much pleasure with your new laser system.
Yours LPS-Lasersysteme

P a g e 3 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
Contents
Foreword .........................................................................................................................................................
Contents .......................................................................................................................................................... 3
1. Starting ............................................................................................................................................... 5
1.1 Areas of use ........................................................................................................................................ 5
1. Electric Connection ............................................................................................................................. 5
1.3 Installation .......................................................................................................................................... 5
1.4 Operation ............................................................................................................................................ 5
1.5 Unpack and Connect ........................................................................................................................... 6
. Laser Safety ......................................................................................................................................... 7
.1 Legal notes .......................................................................................................................................... 7
.1.1 Laser Classification .............................................................................................................................. 7
. Dangers caused by Laser Radiation .................................................................................................. 11
.3 Safety Shutdown ............................................................................................................................... 1
.4 Mechanical Construction .................................................................................................................. 1
.5 Audience Area ................................................................................................................................... 13
.6 Show laser area ................................................................................................................................. 13
.6.1 Announcement of the Laser Show ................................................................................................... 14
.7 Control Units ..................................................................................................................................... 14
.8 Operating Stuff ................................................................................................................................. 15
.9 Medical Treatment of Eye Damage .................................................................................................. 15
.10 Misapplication/Behaviour in Case of Failure .................................................................................... 15
3. Technical Specification ..................................................................................................................... 17
4. Overview ........................................................................................................................................... 0
The overview will help you to find a better handle to the functions of the systems ................................... 0
4.1 Case front view ................................................................................................................................. 0
4. Case back view .................................................................................................................................. 0
5. Device Operation ..............................................................................................................................
5.1 Display section and projector settings ..............................................................................................
6. DMX Mode ........................................................................................................................................ 3
6.1 Basics of DMX control ....................................................................................................................... 3

P a g e 4 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
6. DMX Channels ................................................................................................................................... 5
6.3 DMX fault protection ........................................................................................................................ 7
6.4 Activation of the DMX mode ............................................................................................................ 7
7. ILDA Mode ........................................................................................................................................ 8
7.1 SUB-D Pin Konfiguration ................................................................................................................... 8
8. Autoplay ............................................................................................................................................ 9
8.1 Activation of the auto play modes.................................................................................................... 9
9. Animation Mode ............................................................................................................................... 9
9.1 Activation of the animation mode .................................................................................................... 9
9. Activation of PRG ILD list mode ........................................................................................................ 30
9.3 Create a PRG list at the laser system ................................................................................................ 30
9.4 Describe the SD card with own animations ....................................................................................... 30
9.5 Show lists in .prg file .......................................................................................................................... 31
10. Sound control ................................................................................................................................... 31
10.1 Activation of the sound control ........................................................................................................ 31
11. Safety devices ................................................................................................................................... 3
11.1 Emergency-Interlock (Remote) ......................................................................................................... 3
11. Key-Switch-Interlock (Remote) ......................................................................................................... 3
11.3 Scanner-Safety .................................................................................................................................. 3
1 . Maintenance ..................................................................................................................................... 3
13. Beam Adjustment ............................................................................................................................. 34
14. Attachment ....................................................................................................................................... 36

P a g e 5 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
1. Starting
1.1 Areas of use
This device is designed for professional use, for example on stages, in discotheques,
theatres etc.
This laser must only be used for shows. The operation of a class 4 show laser is only allowed if it is
controlled by a skilled and well-trained operator.
Teenagers older than 16 years can only be employed in laser areas if necessary for
completing their job training and if their protection is guaranteed by a skilled person.
This device is designed for mobile use and for permanent installations.
Laser effects are not designed for permanent operation. Regular operation breaks will ensure that
the device will work for a long time without defects.
1.2 lectric Connection
This product is approved to be operated only with an alternate current of 100 - 40 V. Notice the
manufacture settings!
1.3 Installation
It is required to mount the device only with the mounting bail or an fixed base. In order to guarantee
sufficient ventilation, leave 50 cm free space minimum around the device.
Make sure that the area below the installation place is blocked when rigging, derigging or servicing
the fixture.
1.4 Operation
For a safe operation, the laser products must be equipped with all protective measures required for
their classification and use.
Operate the device only when familiar with its functions. Do not permit operation by persons not
qualified for operating the device. Most damages are the result of unprofessional operation!
Please consider that unauthorized modifications on the device are forbidden due to safety reasons!
Beachten Sie bitte, dass eigenmächtige Veränderungen an dem Gerät aus Sicherheits- gründen
verboten sind.

P a g e 6 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
If the device is operated in any way different to the one described in this manual, the product may
suffer damages and the guarantee becomes void. Furthermore, any other operation may lead to
dangers like short circuit, burns, electric shock, etc.
1.5 Unpack and Connect
Check the content of the package of its completeness.
The following parts are included:
-Laser system
-Manual
-Power plug (1 piece)
-Key for laser system
-Emergency strapping plug
-SD Card
Please read the chapter „Laser Safety“ precisely and conscientiously before you connect the system.
The system is working from 100 V to 40 VAC. Make sure that the current entry is provided.
Connecting the system is rather simple:
-Connect the D/A converter and laser system with the data cable
-Plug in the power supply of the laser system and the D/A converter (power plug).
-Make sure that the show laser system is mounted stable an cannot fall down.
Important note
By reasons of the laser- and operating safety, the current supply of the system has to be
lockable by an Emergency-OFF-Button. To operate without an Emergency-OFF-Button IS
NOT ALLOWED. There are already prepared connections for the Emergency-OFF-Button
inside the switch box of LPS-Lasersysteme.
Please note in the attachment the circuit diagram for the voltage supply in combination
with the Emergency-OFF-Button.

P a g e 7 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
2. Laser Safety
2.1 Legal notes
Despite all fascination of the “Magic Light”, it may not be forgotten that a laser involves
certain dangers. On these pages you will find out how it is possible, in spite of many
regulations, to produce a fascinating laser show without dangers for you and your guests.
2.1.1 Laser Classification
The government recommended safety practices for a given laser system which depend on its
classification. The following highlights the criteria that are used to classify lasers, as well as the key
safety considerations when operating a system with the indicated classification. The reader is
directed to the "Code of Federal Regulations" for a comprehensive discussion of
these safety topics.

P a g e 8 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
Classification Criteria:
Class 1 all wavelengths safe for the human eye
Class 1 30 ,5 nm – 400 nm
safe for the human eye if no optical
instruments are used; not safe if optical
instruments are used
Class 2 400 nm – 700 nm, up to 0, 5 s
safe for the human eye because of
aversion response and eyelid closure
reflex;
not safe if optical instruments are used
Class 2 400 nm – 700 nm, 0, 5 s
eyelid closure reflex; depending on
whether it
is a divergent or flared beam, it might be
unsafe with optical instruments
Class 3R
400 nm – 700 nm, 0, 5 s
30 ,5 nm – 400 nm
700 nm – 10 nm, 100 s
exceeds the maximum tolerable
radiation; radiation is max. five times
higher than the limit for accessible
radiation of Class 1 (respectively
Class ); dangerous for the human eye
Class 3B all wavelengths
laser facilities of power up to 0,5 W
dangerous for the human eye and in
certain cases for the skin
Class 4
all wavelengths
laser facilities of power more than
0,5 W
very dangerous for the human eye and
dangerous for the skin; additionally there
is the danger of combustion

P a g e 9 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
For the class 4 lasers (more than 0.5 W) which we mostly use, following points are to be considered
and avoided:
1. Danger to the eye
A human‘s most sensitive organ is the eye. A laser beam is coherent light with very high energy.
A laser beam keeps its intensity even on a large distance. If a laser beam hits a human eye, it
could lead to irreparable damages, the retina could be destroyed.
Therefore the following has to be considered:
Never look into a laser beam directly, and do not place any objects in the beam, because even
diffusely reflected beams will cause eye damage. Never point the laser beam at a person’s eyes.
2. Danger of skin damages
If a laser beam hits the human skin, it will cause painful burns due to its high energy density. The
beam also burns holes into textiles. Therefore never put your hands in the laser beam and do
not intercept the beam with any other part of your body.
3. Danger due to perilous High Voltage
Laser systems use fatally high voltages. When operating your laser system, always observe the
warning notes on the laser and the instructions concerning laser safety in the manual of your
laser. ake sure that no unauthorized persons have access to your laser system.
4. Danger of fire damages
If a laser beam hits easily inflammable material, for instance paper, this will ignite and may
suddenly cause a fire. Therefore you should always make sure that there is no inflammable
material in the path of the beam before turning the laser on. Moreover, check regularly your air
cooling system on the laser. Ecpecially the filters and fans should be checked in their functions,
so that defects due to over temperatures could be exclude.
The use of a laser can only be regarded as harmless if the main beam is sufficiently weakened,
expanded, divided or moved very fast.
In this case it will meet the eye only briefly and the values for the maximum permissible irradiation
are not exceeded (this depends on the wavelength, irradiation time and the repetition frequency
on pulse rates).

P a g e 10 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
The legal instructions for using a laser product vary from country to country. The user must always
inform himself on the legal instructions valid in his country and apply them to his situation.
In Germany, the following instructions are binding:
DIN EN 608 5-1 "Safety requirements for laser systems; Part 1: “Equipment
classification, requirements and user policies“ www.din.de
E DIN 5691 "Safety requirements for Lightshow lasers and laser lightshow systems"
www.din.de
or DIN-Pocketbook 34 "event technology" http://www.dthg.de
Trade Association Ordinance laser radiation BGV B :
http://publikationen.dguv.de/dguv/pdf/1000 /b .pdf or
http://www .fz-juelich.de/gs/datapool/page/3 4/bgvb a10 007.pdf
Leaflet "laser equipment in nightclubs and st show events"
http://www.boku.ac.at/fileadmin/_/an-gesund/AUVA_lasersicherheit.pdf
Leaflet "Disco-Laser": http://www.salc.ch/pdf/unfallverh%FCtungsvorschrifen-laser.pdf
DIN EN 1 54, "Screens for laser working places – Safety requirements and testing” www.din.de
Equipment Safety Law (GSG)
http://bundesrecht.juris.de/bundesrecht/techarbmg/gesamt.pdf
Criminal Code § 3 ff: http://bundesrecht.juris.de/bundesrecht/stgb or
http://bundesrecht.juris.de/bundesrecht/stgb/gesamt.pdf
Further useful links:
University Essen
Selbstbau-Laser: http://pluslucis.univie.ac.at/FBA/FBA95/Matischek/laser3.pdf
We (LPS-Lasersysteme) are not responsible for the availability of these sites or
resources, and do not endorse and are not responsible or liable, directly or indirectly, for the
privacy practices or the content (including misrepresentative or defamatory content) of these
websites, including (without limitation) any advertising, products or other materials or services on
or available from these websites or resources, nor for any damage, loss or offence caused or
alleged to be caused by, or in connection with, the use of or reliance on any such content, goods or
services available on these sites or resources.

P a g e 11 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
2.2 Dangers caused by Laser Radiation
The first starting of a show laser of the classes 3 and 4 (for more information see page 6) must be
announced to the responsible authority for the industrial safety and to the responsible professional
association, because of the regulations for the prevention of accidents (BGV B ).
The service personnel and persons, who are in the area of the show laser, must be instructed. The
instruction includes the acquisition of knowledge regarding danger of laser radiation, other
possibilities of endangerment, protection regulations, behaviour in the area of the show laser, safety
precautions as well as the knowledge of the operating procedure with the use of a show laser
system.
For these regulations LPS-Lasersysteme will give a special one-day briefing on its premises to the
service personnel. Everyone who operates this system, has to participate in such a
course.
This course contains the following topics:
-reflecting power of laser beams
-damage of the skin
-inflammability
-classification of laser systems of LPS-Lasersysteme
-warning devices and safety precautions
-special safety references for the usage site of the laser
-limit values for harmless laser radiation
-laser safety regulations
-tasks and duties of the laser protection representative
-special regulations for show lasers used on stages
-safety device of the show laser area
-demarcations of the spectator range
-geometrical borders
-amenability
-adjustment of the laser system
-protection devices of stages
The company, which operates with laser classes 3 or 4, has to nominate in writing at least one
permanent employed person as laser protection representative. Furthermore the company has to
notify the laser protection representative to the responsible professional association.

P a g e 1 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
Eye damage caused by unskilled operation of laser products can be considered as physical injury and
can be persecuted by law.
Please note that the organizer is responsible for keeping all specified protective measures.
If a laser gets out of control, the performance has to be cancelled immediately.
If the organizer does not fulfill his safety duties, he is reliable by civil law for any damages occurred,
like:
-Paying the injured person‘s treatment expenses.
-Paying damages for pain and suffering to the injured persons.
-If financial loss was caused by the operator of the laser product, compensation payment might
be claimed.
Please note:
LPS-Lasersysteme cannot be made liable for damages caused by incorrect installations and
unskilled operation!
Protective measures for a safe operation
For producing and operating laser radiation the following regulation is binding:
DIN EN 608 5-1 "Sicherheit von Laser-Einrichtungen", E DIN 5691
"Showlaser und Showlaseranlagen", die berufsgenossenschaftliche Vorschrift
Laserstrahlung BGV B , Merkblatt "Lasergeräte in Diskotheken und bei
Show-Veranstaltungen", Merkblatt "Disco-Laser", all governmental regulation and all enerally
binding rules of technology.
The following are excerpts from the regulation mentioned above. This information is based on
regulations given on the date of printing. When operating a laser product in public or industrial
areas, a set of safety instructions has to be followed that this manual can only give in part. The
operator must therefore inform himself about the latest safety instructions and follow them.
2.3 Safety Shutdown
Show lasers must provide a safety shutdown enabling to interrupt the laser radiation directly at any
time.
2.4 Mechanical Construction
The show laser must be protected against re-adjustment, rotation and tilting.
The show laser must be installed in a way that the beam cannot be emitted in an unwanted way. If
there are optical efficient components (e.g. mirrow), they must be firmly fixed at the wall etc. All
load-bearing elements must also be firmly fixed.

P a g e 13 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
2.5 Audience Area
In the audience area, the maximum permissible values for radiation and radiation intensity must
never be exceeded.
People must never be exposed to laser radiation that exceeds the highest allowed level.
The operator has to make sure by technical or organizational measures that laser radiation as well as
reflected laser radiation does never exceed the allowed level.
2.6 Show laser area
The initial installation is performed by LPS-Lasersysteme.
Nevertheless, the following steps have to be carried out by the laser protection
representative every time before starting:
Before using the laser system, the device must be examined by a visual inspection if safety-relevant
modifications have been made.
This contains the following topics:
Is the laser system in the same position it was installed in?
Are there no inflammable articles, like decoration, in the path of the beam?
Is the housing of the system closed?
Are all plugs plugged in, particularly all energized plugs, and have they no safety deficiencies as for
example defect of the casing or isolation?
If one of the problems mentioned above did occur, the laser system must be immediately repaired.
Please contact LPS-Lasersysteme (phone: [phone]).
When operating show lasers, there is a hazard zone, the so-called laser saftey area, in which the laser
radiation duration and power might be higher than the highest allowed level. This area must never
be entered by unauthorized persons.
The laser saftey area must only be entered by trained and authorized persons. Suitable protective
measures must be carried out.
If it is unavoidable to enter the show laser area, it has to be guaranteed that the laser saftey area can
only be entered from instructed and authorized persons. In this case suitable preventive measures
must be observed. If it is necessary for the stage scene that persons stay in the show laser area,
suitable preventive measures are to be observed to avoid endangerments, e. g. and by marked
positions.
The geometric borders of the laser saftey area must be calculated or measured before starting the
operation.

P a g e 14 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
Uncontrolled reflected radiation of laser products must be avoided, specular or reflective objects or
areas must be kept out of the laser beam, they must be removed or covered.
In order to protect from dangerous reflections, tools, accessory and adjustment devices being used in
the laser area should not have specular surfaces and people in the laser area should not wear
specular objects.
The laser saftey area must be safely shielded from the audience area, e. g. by a higher stage area
(minimum height: 0.8 metres) or grids. The safety distance between the laser saftey area and the
audience area must be 1 metre to the sides. The distance from the lowest point of audience area to
the top must be .70 metres at least.
If walls are used for shielding laser areas, walls made of brick, limestone or concrete are considered
as suitable. Other shieldings may also be used if they comply with the
requirement of E DIN EN 1 54.
2.6.1 Announcement of the Laser Show
Each laser show must be announced to the responsible professional association and to the trade
supervisory board and must be permitted by them.
If a laser show is performed outdoor, it must be also announced to the air traffic control or to the
public order office.
2.7 Control Units
The control units of a show laser must be outside the laser saftey area and the complete laser saftey
area must be visible from this point. The laser product may only be accessible by authorized persons.
The show laser must never be operated unsupervised. During a show, the laser product must never
be repaired or adjusted in a way that the laser beam is corrected.
Outside the area where the laser show takes place, the beam must be interrupted close to the laser
or it must be shut off. After moderations that might affect the safety of the show laser system (like
changing the path of the beams) it is necessary to have the system checked by experts again.
The system must be protected against unauthorized starting or operating. If the system is not in
operation, it must be ensured that the key of the system is taken off and kept safely.
Before the audience arrives, it is absolutely essential to check if every single beam still meets its
reflection mirrors (beam trajectory according to the expert). An adjustment might be required.

P a g e 15 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
2.8 Operating Stuff
Only qualified persons are entitled to run the laser show. These persons must control the laser beam
during the show and immediately switch off the device or interrupt the laser beam in case of failure
of the device or insecure operational conditions (Push the Emergency-OFF-Button!).
The operator has to make sure that employed persons, who are operating laser products of the
classification to 4 or who move in laser areas of the classification 3B or 4, are qualified. The service
personnel must be aware of the fact that the laser system can be a dangerous instrument, when it is
incorrectly or carelessly handled. It might cause irreparable damage, particularly to the eyes.
Therefore the laser system must always be operated with extreme caution and consistent
compliance with the safety regulations.
For show lasers, the operator has to instruct the employed persons on how to keep the accessible
radiation as low as possible. The employed persons have to follow these instructions.
At least once a year, the operator has to make sure that the employed persons are informed about
the dangers of laser radiation, the safety installations and the required protective measures, if laser
products of the classification to 4 are operated.
The operator must not employ teenagers in laser areas where laser products of the classification 3B
or 4 are operated. Teenagers older than 16 years may only be employed in laser areas if it is essential
for completing their job training and if their protection is guaranteed by an expert.
The operator has to make sure that only employed persons who are absolutely necessary can enter
the laser area.
2.9 Medical Treatment of ye Damage
If laser radiation has caused eye injuries, the operator has to make sure that the employed person
will immediately be treated by an eye specialist.
2.10 Misapplication/Behaviour in Case of Failure
This laser product must NEVER be operated by private persons as they cannot shield and control
laser safety areas and as children might play with the laser product.
This laser must NEVER be operated, if it is not equipped with all protective measures for a safe
operation.

P a g e 16 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
CAUTION!
If you use controls or adjustments or if you perform procedures other than those specified here, this
might result in hazardous radiation exposure!
If the laser beam in the scanner way does not move after switching on the device, this device must
immediately be taken out of operation. Please let the device be checked by a technician of
LPS-Lasersysteme.
Laser products of the classification to 4 must be installed in a way to prevent unintended radiation.
Unintended radiation is, when laser radiation emits from the laser product without using the normal
control elements, e. g. due to damaged isolation or interferences or if it is possible to operate control
elements without intention.

P a g e 17 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
3. Technical Specification
Laser source Laser diode, DPSS
Operating voltage 100 VAC – 40 VAC
Voltage line frequency 50 Hz / 60 Hz
Operating current
SimPleX 850RGB:
0.4 A
SimPleX 1300RGB:
0.5 A
SimPleX 1800RGB:
0.7 A
Power consumption
SimPleX 850RGB:
90 W
SimPleX 1300RGB:
150 W
SimPleX 1800RGB:
161 W
Cooling requirements air-cooled
Degree of protection IP 0
Protection class 1, protection ground
Operating temperature 10° - 35° C
Warm-up time < 15 minutes

P a g e 18 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
Total laser power
SimPleX 850RGB:
850mW
SimPleX 1300RGB:
1.3W
SimPleX 1800RGB:
1.8W
Modulation analogue modulation up to 50 kHz
Wavlength
SimPleX 850RGB:
00mW red@638nm LD, 150mW DPSS green@53 nm,
500mW blue@445nm LD
SimPleX 1300RGB:
00mW red@638nm LD, 300mW DPSS green@53 nm,
800mW blue@445nm LD
SimPleX 1800RGB:
500mW red@638nm LD, 300mW DPSS green@53 nm,
1W blue@445nm LD
Scanner
SimPleX 850RGB:
0 kpps scanner
SimPleX 1300RGB:
30 kpps scanner
SimPleX 1800RGB:
30 kpps scanner
Deflection angle maximal 60°
Dimension and Weight
SimPleX 850RGB:
3 0 x 60 x 160 mm,
4,1 kg

P a g e 19 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
SimPleX 1300RGB:
460 x 3 0 x 160 mm,
8,15 kg
SimPleX 1800RGB:
460 x 3 0 x 160 mm,
8,5 kg
Technical changes and design changes without notice and errors excepted.

P a g e 0 | 36
LPS-Lasersysteme Siegmund Ruff / CEO Haidschwaerze 18 7 131 Ofterdingen Germany
Phone: [phone] www.lps-laser.de [e-mail]
4. Overview
The overview will help you to find a better handle to the functions of the systems
4.1 Case front view
1 Laser output window
4.2 Case back view
