LRP electronic Quadra Pro 41280 User manual

1. connections / operation
2. settings
6. cycle
5. Discharge
NiMH 5.0A 00m35s
08.58V 0048mAh
3. specification
100-240V AC / 12V DC
ChArge-DisChArge-CyCle
1-14 Cells nimh/niCD
1-5 Cells lipo/liFepo
LA00043
user guiDe
Dimensions [mm] 145x160x60 Autostart Timer yes
Weight [g] 600 Partial Charge Mode yes
Input Voltage
[AC] 100-240V Cycle Mode
yes
[DC]
11-15 V
User Profile Memory
3
Charging Mode
Linear LCD 16x2, blue backlit
Charging
Capability
LiPo/LiFePo 1-5 cells Acoustic Signal Type
Buzzer
NiMH/NiCd 1-14 cells Buttons 4
Charge Current [A] 0.1 - 5.0 Advanced Digital yes
Trickle Current [A] 0 -0.25 Multi-Protection-System
yes
Delta Peak [mV] 5 - 200 DC Input Connection Alligator Clamps
Discharge Current [A] 0.1 -1.0 AC Input Connection AC connector
Discharge
Cut-Off Voltage
LiPo/LiFePo 2.5 - 14.0V Output Connection 4.0mm jacket
NiMH/NiCd 0.9- 16.0V
LRP electronic GmbH,
Wilhelm-Enssle-Str. 132-134, 73630 Remshalden, Germany
[e-mail] www.LRP.cc
Specifications subject to change without notice.
Dear Customer,
thank you for your trust in this LRP product. By purchasing a LRP QUADRA-PRO Professional Battery Manag-
ment System, you have chosen a high-performance product which has the latest technology incorporated
including the following High-Tech features:
• NiMH - NiCd - LiPo - LiFePo Charging • Dual Input (100-240Vac + 12Vdc)
• NiMH - NiCd - LiPo - LiFePo Discharging • Blue backlit 16x2 LCD
• Cycle Mode • Partial Charge & Autostart Mode
• Microprocessor Controlled • 3 User Profile Memories
• 25-Year Warranty • Multi-Protection-System
Please read the following instructions carefully before you start using your LRP QUADRA-PRO charger. This
user guide contains important notes for the installation, the safety, the use and the maintenance of this pro-
duct. Thus protecting yourself and avoid damages of the product.
Proceed according to the user guide in order to understand your LRP QUADRA-PRO charger better. Please take
your time as you will have much more joy with your product if you know it exactly.
This user manual shall be kept in a safe place. If another customer is using this product, this manual has to be
handed out together with it.
Order.NO.
41280
DC INPUT: connect to a suitable DC source
with 11-15V, using the supplied connection wire.
Caution: Be careful with correct polarity!
- Red = Plus
- Black = Minus
OUTPUT JACKET: connect battery to
be charged to the 4.0mm jacket, using sup-
plied charge wires.
Caution: Be careful with correct polarity!
AC INPUT: connect to main power
with 100-240VAC
Caution: Do not alter the wire or con-
nector as this will void your warranty!
4. charge
SET Battery Type: The QUADRA-PRO can charge 4 different cell types and incorporates the designated
charge algorithms for each particular cell type for best performance, reliability and safety.
NiMH/NiCd charging with constant current + delta-peak detection. This is the most popular charging
method for NiMH/NiCd-batteries in competition.
LiPo/LiFePo charging using the CC/CV-charging method. With this charging method, the battery gets
charged with a constant current first. As soon as the battery voltage reaches the max. charging
voltage of the LiPo- (4.2V/cell) or LiFePo- (3.7V/cell) battery, the charger automatically reduces
the charging current till the battery is fully charged.
Caution: Always choose the correct BATTERY TYPE setting for the battery you want to charge, as wrong
setting may result in damage to the battery, fire or explosion!
SET Charge Current: The charge current can be set from 0.1 to 5.0A. If not otherwise specified by the
battery manufacturer, choose 0.5C charge rate which is always a safe value!
SET Charge Delta Peak: With NiMH/NiCd-batteries, you only obtain the optimum battery performance
by slightly „overcharging“ the battery. In real terms, it will not be overcharged, but charged to an optimum
level. The battery voltage drops at the end of the charging process (delta). The size of the drop (delta peak) is
adjustable in the range between 5 - 200mV. The higher the value, the hotter the battery will be at the end of the
charge. We recommend to start with the works-default settings.
Note: The adjustable Delta-Peak value applies to the whole battery pack and not to one single cell!
SET Charge Trickle: This current, which flows after delta peak cutoff, is adjustable from 0.0A to 0.25A to
achieve the highest possible voltage for NiCd cells. Set this function to „Off“ for NiMH cells.
User Profile P1 P2 P3
Battery Type NiMH NiCd LiPo
Charge Current 4.0A 3.0A 2.0A
Charge D-Peak 20mV 50mV --
Charge Trickle 0ff Off --
Charge LiPo Volt -- -- 7.4V
Discharge Current 1.0A 1.0A 1.0A
Discharge Voltage 5.4V 5.4V 6.0V
The active profile P1, P2 or P3 is displayed
in the main menu. By pressing the INC+ and
DEC- buttons you can change between the
profiles and their settings.
To reset your QUADRA-PRO to works-default
settings, proceed as follows:
• Disconnect input voltage.
• Hold down MENU button while reconnec-
ting the input voltage.
The QUADRA-PRO allows you to save 3 individual user profiles. This means you can customize 3 personal
charge profiles individually and store them for later use. The QUADRA-PRO has 3 preset works-default settings
when shipped out: P1 (NiMH), P2 (NiCd), P3 (LiPo 2-cell). For details see the table below.
The QUADRA-PRO was developed with the main objective placed on easy operation of all features. Intuitive
navigation by means of 4 buttons makes it very easy to use and the 2-line blue backlit LC display offers perfect,
reliable control of all settings and functions.
BUTTONS:
MENU Scrolls/jumps through the function list.
DEC - Decrements the underscored value.*
INC + Increments the underscored value.*
START/STOP Next program step / Start a program / Cancel a running program.
* Button has high-speed function for rapid setting (hold down button to change value faster).
The adjustable discharge circuit (0.1 to 1.0A) can be used for 1-14 cell NiMH/NiCd-packs and 1-5 cell LiPo/
LiFePo-packs. The QUADRA-PRO informs you about all the data relating to the battery pack, e.g. discharge
time, capacity and average voltage.
By discharging your battery pack on the QUADRA-PRO after use, you obtain vital information about remaining
capacity for optimizing your motor or gear ratio for the next run. This also maintains your battery packs in good
condition.
SET Discharge Current: The discharge current can be set from 0.1 - 1.0A.
SET Discharge Voltage: The cut-off voltage can be adjusted from 0.9 - 14.0V depending on the number
of cells. We recommend a cut-off voltage of 0.9V/cell with NiMH/NiCd-, 3.0V/cell with LiPo-and 2.6V/cell with
LiFePo-batteries. This means for example
- 5.4V for 6-cell NiMH/NiCd
- 6.0V for a 2-cell LiPo
- 5.2V. for a 2-cell LiFePo
This fully automatic cycling/matching function allows you to determine the actual performance of your packs
before using them. Battery packs change during their life span. Use the QUADRA-PRO to detect the actual
quality of your packs. This prevents nasty surprises.
The “Cycle” mode uses the charge and discharge values of the currently selected programm, stored under
“Settings”. The pack is first discharged, then charged and finally discharged. At the end of the process, the pack
capacity and the average discharge voltage are displayed.
There is a short delay in the timer during cycle operation, in order not to overheat the batteries, which is as
following:
- Initial Discharge -> Charge: 1min (if discharge was finished within 10min), otherwise 5min
- Charge -> Discharge: 1min (if charge was finished within 10min), otherwise 5min
Note: The „Cycle“ function can of course be used for all types of cells (NiMH-NiCd-LiPo-LiFePo).
© LRP electronic GmbH 2008
16x2 LCD SCREEN:
Active function
Time elapsed since startCurrent
Capacity
Voltage at output connectors
Cell# LiPo LiFePo
13.7V 3.3V
27.4V 6.6V
311.1V 9.9V
414.8V 13.2V
518.5V 16.5V
SET Charge LiPo/LiFePo Volt (pack voltage): The packs
rated voltage for LiPo- and LiFePo-batteries must be set according to
the packs number of cells. See right table.
* C=Nominal capacity of the battery. E.g. with a nominal capacity of 3300mAh
(3,3Ah), the battery can be charged with a max. current of 3,3A.:

10. troubleshooting guiDe
7. partial charge
8. special features
9. recommenDeD charge settings
11. programme structure
Autostart Timer: This handy feature lets you preselect when you want to start charging your battery with
the QUADRA-PRO. The Autostart Timer is adjustable from 0 - 99min. If you stay in the „Autostart Display“ for
longer then 30sec without setting a value, the charging process will start automatically.
Changing the charge current on the fly: The charge current can be changed on the fly by pressing
INC+ or DEC- without interrupting the charging process. This change is not stored. The next time you start
charging, the QUADRA-PRO takes the data settings of each charge profile, stored under “Settings”.
PCS-4 (Peak Capacity System): The voltage charge curve of NiMH cells may vary considerably at
the start of charging due to cell construction. Conventional chargers interpret this incorrectly as „delta peak
reached“ and terminate the charging process (false peak). The QUADRA-PRO has the LRP-exclusive PCS-4
which contains advanced algorithms to detect this phenomenon: This ensures reliable full charging.
PCS-4 allows the perfect full charge of all NiMH cell types by means of an adjustable delta peak and high-
precision digital-filter detection of all parameters throughout the entire charging process. The QUADRA-PRO
signals full charge and end of charge by an alert buzzer that sounds for 3 minute.
Data View Function: at the end of each process (charge, discharge or cycle) you can view additional
data by pressing MODE button.
Also you can access DATA VIEW from initial screen by pressing MODE button, which allows you to view (press
MENU again to hop through data): DC input voltage / Battery voltage / Charge data from last process / Discharge
data from last process
Never store your batteries completely empty as this will harm them and lower their performance. Due to this
fact, the QUADRA-PRO features a „Partial charge“ mode. With this function, you can set a fixed capacity value
and the battery will be partially charged exactly to this amount.Thus you can always perfectly prepare your
battery for storage, if you want to store them over a longer period of time.
We recommend to completely discharge the battery first and then put about half of the nominal capacity back
into the battery. For example, a battery with a nominal capacity of 4200mAh should be partially charged with
2100mAh.
Note: NiMH batteries can be stored for about 1-2 months without problems using this method. LiPo/LiFePo
batteries can be stored for about 6 months without problems. After this time period, you should check the
battery and, if necessary, put some partial charge in again if you don´t use it regularly.
To partially charge a battery, follow these instructions (see chapter 11 „Programme Structure“ for further re-
ference):
1. Be sure, that the battery has been discharged completely.
2. Choose a suitable charging profile or adjust the charge setting in the „Settings“ menu so it fits the battery,
which you want to partially charge.
3. Choose „Charge“ from the menu and press the START/STOP button to get to the Autostart setting screen.
4. Now press the MENU button once, as long as you see the Autostart setting screen.
5. The screen now changes to „Partial Charge“ and 1.0Ah is preset.
6. You can now use the INC+ und DEC- buttons to adjust the amount of partial charge. After setting the partial
charge value, press the START/STOP button to start the partial charge process.
CAUTION
Battery Error
INTERRUPT
High Input Volts
- No battery connected?
- Wrong battery polarity, bad contact?
- Defective battery?
- Wrong LiPo-cell quantity?
- Input voltage too low/switched off (<11.0V on DC input)
- Bad contact on input clamps?
ERROR-MESSAGES POSSIBLE CAUSES
INTERRUPT
Low Input Volts
- Input voltage too high (>15.0V on DC input)
The QUADRA-PRO is protected against faults and operator errors by the Multi-Protection-System. Faults/Er-
rors are displayed on the LCD screen and some faults/errors may interrupt the charging process to protect the
charger and the battery. The error messages are as follows:
P 1 MENU
Charge
menu
menu
menu
start
start
start
menu
start
menu
menu
menu
menu
start
menu
P 1 MENU
Discharge
Charge
Autostart: 00min
Partial Charge
Capacity: 1.0Ah
D-Peak: 10mV
Trickle: Off
NiMH 5.0A 00m35s
08.58V 0048mAh Done 50m03s
09.06V 4170mAh
P 1 MENU
Cycling
Discharge
Voltage: 5.4V
Disch1.0A 0012s
06.51V 0033mAh
P 1 MENU
Settings
SET Charge
Current: 04.0 A
SET Battery
Type: NiMH
Disch1.0A 0029s
07.61V 0080mAh
Done Avg:07.396V
07.74V 3950mAh
start
SET Battery
Type: NiCd
SET Battery
Type: LiPo
Inp13.7V 00m37s
08.59V 0051mAh
Done 1422s
07.75V 3950mAh
NiMH 5.0A 00m40s
08.60V 0055mAh
Cyc 5.0A 00m42s
08.60V 0058mAh
Disch1.0A 0120s
07.58V 0333mAh
Done Avg:07.383V
07.72V 4023mAh
Done 1448s
07.72V 4023mAh
SET Charge
D-Peak: 10mV
SET Charge
Trickle: Off
SET Discharge
Current: 1.0 A
SET Discharge
Voltage: 5.4 V
menu
menu
menu
menu
SET Charge
Current: 02.0 A
menu
SET Charge
LiPo Volt: 07.4 V
menu menu
Dec
inc Dec inc
SET Discharge
Current: 1.0 A
SET Discharge
Voltage: 6.0 V
menu
menu
menu
Dec
inc
press
EXPLANATION OF ICONS
start press
press
automatically
SET Battery
Type: LiFe
menu
SET Charge
Current: 02.0 A
menu
SET Charge
LiFe Volt: 06.6 V
menu
Dec
inc
SET Discharge
Current: 1.0 A
SET Discharge
Voltage: 5.2 V
menu
menu
menu
menu
SET Charge
Current: 03.0 A
SET Charge
D-Peak: 50mV
SET Charge
Trickle: Off
SET Discharge
Current: 1.0 A
SET Discharge
Voltage: 5.4 V
menu
menu
menu
Cyc 1.0A 0013s
06.52V 0035mAh
Cyc 1.0A 0121s
07.57V 0334mAh
Always follow the cell manufacturers charge-/usage-recommendations, never use batteries outside their
specifications!
Battery Type Voltage /
Cells
Battery
Type
Charge
Current
D-Peak Trickle LiPo
Volt
Dischg.
Current
Dischg.
Volt
NiCd Sportpacks (1600-2400mAh) 7.2V / 6 NiCd 3.0A 50mV 0.1A -- 1.0A 5.4V
NiMH Sportpacks (3000-4200mAh) 7.2V / 6 NiMH 3.0A 20mV OFF -- 1.0A 5.4V
NiMH Sportpacks (3000-4200mAh) 12.0V / 10 NiMH 3.0A 30mV OFF -- 1.0A 9.0V
NiMH Sportpacks (3000-4200mAh) 14.4V / 14 NiMH 3.0A 50mV OFF -- 1.0A 12.6V
NiMH Competition Cells 4.8V / 4 NiMH 5.0A 5mV OFF -- 1.0A 3.6V
NiMH Competition Cells 6.0V / 5 NiMH 5.0A 10mV OFF -- 1.0A 4.5V
NiMH Competition Cells 7.2V / 6 NiMH 5.0A 15mV OFF -- 1.0A 5.4V
NiMH Competition Cells 12.0V / 10 NiMH 5.0A 25mV OFF -- 1.0A 9.0V
NiMH Competition Cells 14.4V / 14 NiMH 5.0A 35mV OFF -- 1.0A 12.6V
AA/Mignon NiMH Cells (2000-2700mAh) 9.6V / 8 NiMH 0.5A 30mV OFF -- 0.3A 7.2V
2/3A NiMH Cells (1200-1600mAh) 6.0V / 5 NiMH 1.0A 15mV OFF -- 0.8A 4.5V
LiPo Pack Air ~480mAh (plane/helicopter) 11.1V / 3S LiPo 0.5A -- -- 11.1V 0.5A 9.0V
LiPo Pack Air ~1500mAh (plane/helicopter) 11.1V / 3S LiPo 1.5A -- -- 11.1V 1.0A 9.0V
LiPo Pack Air ~3000mAh (plane/helicopter) 11.1V / 3S LiPo 3.0A -- -- 11.1V 1.0A 9.0V
LiPo Pack Car ~1800mAh (Micro 1/18) 7.4V / 2S LiPo 1.8A -- -- 7.4V 1.0A 6.0V
LiPo Pack Car ~5000mAh (1/10) 7.4V / 2S LiPo 5.0A -- -- 7.4V 1.0A 6.0V
LiPo Pack „TX Only“ ~2700mAh 11.1V / 3S LiPo 1.5A -- -- 11.1V 0.5A 9.0V
LiPo Pack „RX Only“ ~1800mAh 7.4V / 2S LiPo 1.2A -- -- 7.4V 0.5A 6.0V
LiFePo Pack „RX Only“ ~1800mAh 6.6V / 2S LiFePo 1.2A -- -- 6.6V 0.5A 5.2V
LiFePo Pack Car ~4500mAh 6.6V / 2S LiFePo 4.5A -- -- 6.6V 1.0A 5.2V

!
The crossed-out wheeled bin means that within the European Union the product must be
taken to seperate collection at the product end-of-life. Do not dispose of these products as
unsorted municipal waste.
No toy. Not suitable for children under 14 years.
Keep the product out of the reach of children.
Pay close attention to the following points, as they can destroy the product and void your warranty.
Non-observance of these points can lead to property damage, personal and severe injuries!
•Neverleavetheproductunsupervisedwhileitisswitchedon,inuseorconnectedwithapowersource.Ifa
defectoccurs,itcouldsetfiretotheproductorthesurroundings.
•Neverwrapyourproductinplasticfilm,metalfoilorsimilar.Infact,makesureitgetsenoughfreshair.
•Avoidincorrectconnectionsorconnectionswithreversedpolarityoftheproduct.
•Allwiresandconnectionshavetobewellinsulated.Short-circuitscanpossiblydestroytheproduct.
•Neverallowthisproductorotherelectroniccomponentstocomeincontactwithwater,oilorfuelsorother
electroconductiveliquids,asthesecouldcontainminerals,whichareharmfulforelectroniccircuits.Ifthis
happens,stoptheuseofyourproductimmediatelyandletitdrycarefully.
•Nevercutofformodifytheoriginalplugsandoriginalwires.
•NeveropentheproductandneversolderonthePCBorothercomponents.
•Neverusethisproductwhenthecaseisopen,damagedormissingorwhentheproductiswrappedina
shrink-fittube.Thiswillreduceprotection,maycauseshortcircuitsanddamagetheproduct.
•Alwaysremove thebatteryfrom yourproductor disconnecttheproductfromthe power source,if the
product is not in use.
•Inthecaseofdamage,theproductmustnotbeuseduntilithasbeencompletelyrepaired.
•Donotthrowawayusedbatteriesinthehouseholdgarbage,butonlygivethemtothecollectionstationsor
disposethemataspecialgarbagedepot.
•Alwayschargethebatteryoutsideoftheproductyouwanttouse.Theproductcouldgetdamaged,ifa
battery defect occurs.
•Avoidshortcircuits,overchargingandreversepolarityofthebatteryorsinglecells.Thiscanleadtofireor
explosion.
•Neverleavethebatteryunattendedwhilecharging.
•Duringcharging,thebatteryhastobekeptonanon-flammable,heat-resistantmat.Furthermorenoflam-
mableorhighlyinflammableobjectsmaybeclosetothebattery.
•Onlychargeinadryplace.
•Non-rechargeablebatteriesmustnotberecharged.
•Payattention,thatthechargerissettoLiPochargemodewhenchargingaLiPobattery.
•Thechargerhastobeusedinawellventilatedroom.
•Donotmanipulatetheinputpowercords.
•Neverleaveyourchargerconnectedtomainpowerwhennotinuse.
•Donotblockthefanorthecoolingslitsoftheproduct.Ensureagoodcirculationofairaroundtheproduct,
while in use.
•Alwayscomplywiththecharginginstructionsandrecommendedchargingcurrentsofthebatterymanuf-
acturersandmatchersandneverexceedtheirspecification.
•NeveruseaDCpower-sourcewithmorethan15Voutputvoltage.
•Newunitsmayproduceaslightodorinthefirstfewhoursofserviceduetomaterialscuringinsidethe
device.
•Ifindividualcellsinthebatterypackheatupexcessively,immediatelystopthechargingprocess.
•Onlychargequick-chargeableNiMH,NiCdorLiPobatterieswiththisunit.Otherbatterytypescannotbe
chargedwiththisunit.
The manufacturer can not be held responsible for damages, which are a result of non-observance of the
warning notes and security advices.
warning notes
repair procedures / limited warranty
AllproductsfromLRPelectronicGmbH(hereinaftercalled“LRP”)aremanufacturedaccordingtothehighest
qualitystandards. LRP guaranteesthisproducttobefreefromdefectsin materialsor workmanshipfor90
days (non-european countrisonly)fromthe original dateofpurchaseverifiedby salesreceipt.Thislimited
warrantydoesn’tcoverdefects,whicharearesultofmisuse,impropermaintenance,outsideinterferenceor
mechanicaldamage.
„Thisappliesamongotherthingson:
• Cutoff/changedoriginalinput-and/oroutput-wires
• Mechanicaldamageofthecase,electroniccomponentsorPCB
• Humidity/Waterinsidethecase
• SolderedonthePCB“
• Chargerdisassemblybycustomer
• Anymodificationofthechargerdonebythecustomer
• Overtemperaturefailuresduetoblockingthefanorthecoolingslots
• ReversepolarityatDCoutput
Toeliminateallotherpossibilitiesorimproperhandling,firstcheckallothercomponentsinyourmodelandthe
troubleshootingguide,ifavailable,beforeyousendinthisproductforrepair.Ifproductsaresentinforrepair,
whichdooperateperfectly,wehavetochargeaservicefeeaccordingtoourpricelist.
Withsendinginthisproduct,thecustomerhastoadviseLRPiftheproductshouldberepairedineithercase.If
thereisneitherawarrantynorguaranteeclaim,theinspectionoftheproductandtherepairs,ifnecessary,in
eithercasewillbechargedwithafeeatthecustomersexpenseaccordingtoourpricelist.Aproofofpurchase
includingdateofpurchaseneedstobeincluded.Otherwise,nowarrantycanbegranted.Forquickrepair-and
returnservice,addyouraddressanddetaileddescriptionofthemalfunction.
IfLRPnolongermanufacturesareturneddefectiveproductandweareunabletoserviceit,weshallprovideyou
withaproductthathasatleastthesamevaluefromoneofthesuccessorseries.
Thespecificationslikeweight,sizeandothersshouldbeseenasguidevalues.Duetoongoingtechnicalimpro-
vements,whicharedoneintheinterestoftheproduct,LRPdoesnottakeanyresponsibilityfortheaccuracy
of these specs.
WithLRP25-YearsWarrantyproducts,thewarrantytermsontheLRP25-YearsWarrantycarddoalsoapply.
Thelegalwarrantyclaims,whicharoseoriginallywhentheproductwaspurchased,shallremainunaffected.
LRP-Distributor-Service:
• Packageyourproductcarefullyandincludesalesreceiptanddetaileddescriptionofmalfunction.
• SendparceltoyournationalLRPdistributor.
• Distributorrepairsorexchangestheproduct.
• ShipmentbacktoyouusuallybyCOD(cashondelivery),butthisissubjecttoyournationalLRPdistributor‘s
generalpolicy.
LA00044
allgemeine gewÄHrleistungs- und
reparaturBestimmungen
ProduktederLRPelectronicGmbH(nachfolgend„LRP“genannt)werdennachstrengstenQualitätskriterien
gefertigt.WirgewährendiegesetzlicheGewährleistungaufProduktions-undMaterialfehler,diezumZeitpunkt
derAuslieferungdesProduktsvorhandenwaren.FürgebrauchstypischeVerschleißerscheinungenwirdnicht
gehaftet.DieseGewährleistunggiltnichtfürMängel,dieaufeineunsachgemäßeBenutzung,mangelndeWar-
tung,FremdeingriffodermechanischeBeschädigungzurückzuführensind.
„DiesliegtunterAnderemvorbei:
• Eingangs-und/oderAusgangssteckerabgeschnittenbzw.verändert
• MechanischeBeschädigungdesGehäuses,BauteileoderPlatine
• Feuchtigkeit/WasserimGerät
• AufderPlatinegelötet“
• DemontagedesLadegerätsseitensdesKunden
• JeglicheModifikationamLadegerätseitensdesKunden
• ÜbertemperaturdefekteaufgrundgeblocktemLüfterodergeblockterKühlschlitze
• VerpolungamDCAusgang
BevorSiediesesProduktzurReparatureinsenden,prüfenSiebittezunächstalleanderenKomponenteninihrem
ModellundschauenSieggf.inderFehlerfibeldesProduktes(sofernvorhanden)nach,umandereStörquel-
lenundBedienfehlerauszuschließen.SolltedasProduktbeiderÜberprüfungdurchunsereServiceabteilung
keineFehlfunktion aufweisen,müssenwirIhnenhierfür dieangefallenenBearbeitungskostenlautPreisliste
berechnen.
MitderEinsendungdesProduktesmussderKundemitteilen,obdasProduktinjedemFallrepariertwerden
soll.SolltekeinGewährleistungs-oderGarantieanspruchbestehen,erfolgtdieProduktüberprüfungundggf.
ReparaturinjedemFallekostenpflichtiggemäßunsererPreisliste.EinGewährleistungs-oderGarantieanspruch
kannnuranerkanntwerden,soferneineKopiedesKaufbelegsbeigefügtist.AufIhreausdrücklicheAnforderung
erstellenwireinenkostenpflichtigenKostenvoranschlag.WennSienachZusendungdesKostenvoranschlags
denAuftrag zurReparatur erteilen, entfallendieKostenvoranschlagskosten. AnunserenKostenvoranschlag
sindwirzweiWochenabAusstellungsdatumgebunden.FüreineschnelleAbwicklungIhresServicefallslegen
SiebitteeineausführlicheFehlerbeschreibungundihreAdressdatenderEinsendungbei.
Fallseinzurückgesandtes,defektesProduktvonLRPnichtmehrproduziertwird,undwirdiesesnichtreparieren
können,soerhaltenSiestattdesseneinmindestensgleichwertigesProduktauseinerderNachfolgeserien.
DievonLRPangegebenenWerteüberGewicht,GrößeoderSonstigessindalsRichtwertzuverstehen.LRP
übernimmtkeineformelleVerpflichtungfürderartigespezifischeAngaben,dasichdurchtechnischeVerände-
rungen,dieimInteressedesProduktsvorgenommenwerden,andereWerteergebenkönnen.
BeiLRP25JahreGarantieProduktengeltenzusätzlichdieGarantiebestimmungenaufderLRP25JahreGaran-
tiekarte.DieursprünglichenbeimKaufdesProduktesentstehendengesetzlichenGewährleistungsansprüche
gegenüberdemVerkäufersowiezwingendegesetzlicheHaftungsregelungennachdemProdukthaftungsgesetz
bleibenhiervonunberührt.
LRP-Werks-Service:
• ProduktmitKaufbelegundFehlerbeschreibungbruchsicherverpacken.
• Einsendenan:
LRP electronic GmbH – Serviceabteilung
Wilhelm-Enssle-Str. 132-134, 73630 Remshalden, Deutschland
Technik + Service Hotline: D: 0900577 4624 (0900LRP GMBH) (0.49€/Minute aus dem dt. Festnetz. Mobilfunkpreise können abweichen)
A: 0900 270 313 (0.73€/Minute aus dem öst. Festnetz. Mobilfunkpreise können abweichen)
eMail: [email protected]
Web: www.LRP.cc
• LRPrepariertdasProdukt.
• RücksendunganSieperNachnahme.
!
KeinSpielzeug.NichtfürKinderunter14Jahrengeeignet.
BewahrenSiedasProduktaußerhalbderReichweitevonkleinenKindernauf.
Beachten Sie unbedingt die folgenden Hinweise, da diese Ihr Produkt zerstören können und die Ge-
währleistung ausschließen. Nichtbeachtung dieser Hinweise können zu Sach- und Personenschäden
und schweren Verletzungen führen!
•LassenSiedasProduktniemalsunbeaufsichtigt,solangeeseingeschaltet,inBetriebodermiteinerStrom-
quelleverbundenist.ImFalleeinesDefektskönntediesFeueramProduktoderseinerUmgebungverursa-
chen.
•Wickeln Sie IhrProdukt niemals mit Plastikfolie,Metallfolie oder Ähnlichem ein, sondernsorgen Sie im
GegenteilfürFrischluft.
•VermeidenSiefalschenAnschlussoderVerpolungdesProdukts.
•AlleKabelundVerbindungenmüssengutisoliertsein.KurzschlüssekönnenunterUmständendasProdukt
zerstören.
•DiesesProduktoderandereelektronischeKomponentendürfenniemalsmitWasser,Öl,Treibstoffenoder
anderenelektrischleitendenFlüssigkeiteninBerührungkommen,dadieseMineralienenthaltenkönnen,die
elektronischeSchaltkreisekorrodierenlassen.BeiKontaktmitdiesenStoffenmüssenSiesofortdenBetrieb
einstellenunddasProduktsorgfältigtrocknen.
•DieOriginalsteckerundOriginalkabeldürfenniemalsverändertoderabgeschnittenwerden.
•ÖffnenSieniemalsdasProduktundlötenSiekeinesfallsaufderPlatineoderanderenKomponenten
•BenutzenSieIhrProduktnichtmitgeöffnetem,beschädigtemoderfehlendemGehäuseoderinSchrumpf-
schlauch.DiesmindertdenStörschutz,kannKurzschlüsseverursachenunddasProduktbeschädigen.
•EntnehmenSieimmerdenAkkuausIhremProduktbzw.trennenSiedasProduktvonderStromquelle,wenn
dasProduktnichtverwendetwird.
•BeieinemSchadendarfdasProduktbiszurvollständigenReparaturnichtmehrverwendetwerden.
•VerbrauchteBatteriennichtindenHausmüllgeben,sondernnurbeidenbestehendenSammelstellenoder
einemSondermüllplatzabgeben.
•LadenSiedenAkkuimmeraußerhalbdesProduktesauf,fürdenSiedenAkkubenutzenmöchten.Sollteder
AkkueinenDefekthaben,kanndieszueinerBeschädigungdesProduktsführen.
•VermeidenSieKurzschluss,ÜberladungundVerpolungdesAkkusodereinzelnerZellen.DieskannzuBrand-
entwicklungoderExplosionführen.
•LadenSiedenAkkunurunterAufsicht.
•WährendderLadungmusssichderAkkuaufeinernichtbrennbaren,hitzebeständigenUnterlagebefinden.
DesweiterendürfensichkeinebrennbarenoderleichtentzündlichenGegenständeinderNähedesAkkus
befinden.
•LadevorgangnurintrockenenRäumendurchführen.
•NichtaufladbareBatteriendürfennichtgeladenwerden.
•AchtenSiebeimLadenvonLiPoAkkusdarauf,dassichderLaderimLiPoLademodusbefindet.
•DasProduktdarfnuringutbelüftetenRäumenverwendetwerden.
•FührenSiekeineManipulationenandenNetzkabelndurch.
•LassenSieIhrenLaderniemalsamNetzangeschlossenwennSieesnichtinBetriebhaben.
•BlockierenSieniemalsdenLüfteroderdieKühlschlitzedesProdukts.SorgenSiefürguteLuftzirkulationum
dasProdukt.
•LadehinweiseundempfohleneLadeströmedesAkkuherstellersundSelektierersunbedingtbeachtenund
nichtüberschreiten.
•BenutzenSiekeinNetzteilmitmehrals15VAusgangsspannung.
•NeugerätekönnenbedingtdurchaushärtendeMaterialenindenerstenStundeneineleichteGeruchsent-
wicklunghaben.
•BeizustarkerErwärmungeinzelnerZellenimAkkupackdenLadevorgangsofortunterbrechen.
•LadenSiemitdiesemGerätnurschnellladefähigeNiMH,NiCdoderLiPoAkkus.AndereAkkuartenkönnen
mitdiesemGerätnichtgeladenwerden.
Der Hersteller kann nicht für Schäden verantwortlich gemacht werden, die infolge von Nichtbeachtung
der Sicherheitshinweise und Warnungen verursacht werden.
warnHinweise
DasSymboleinerdurchgestrichenenAbfalltonneaufRädernbedeutet,dassdasProduktin
derEuropäischenUnioneinergetrenntenMüllsammlungzugeführtwerdenmuss.DiesePro-
duktedürfennichtüberdenunsortiertenHausmüllentsorgtwerden.
