LS tractor LM1160 User manual

LS LOADER OPERATOR MANUAL
LS LOADER
OPERATOR MANUAL
PO Box 70, Battleboro, NC 27809
Tel : [phone]
Fax : [phone]
www.lstractor.com
www.lstractorusa.com
INNOVATIVE
TECHNOLOGY
PARTNER
LM1160
LM1160
P/NO TM611-ME001
Revision : 07
TRACTOR Model
• MT125/MT122
LS BACK-HOE OPERATOR/SERVIVE MANUAL
OPERATOR MANUAL
MID MOWER
MID MOWER
SERVICE MANUAL

LS MID MOWER
OPERATOR MANUAL
Model : LM1160
MT122
MT125 40446580: Mulching Kit
Applied Tractor Loader Option

WARRANTY CONDITIONS
Warranty Coverage :
Warranty Provisions :
▶ Compensation is not paid for physical harm, deadlock, resulting damages or other losses.
Right To Make Design and Product Changes :
LSMtron'sliabilityunderthiswarrantyissubjecttotheobservancebythe Purchaser of the
following provisions:
It is further understood and agreed that the defect should be immediately reported to the Selling
Dealer. The Selling Dealer will generally perform Warranty repairs or replacements and the
Purchaser shall deliver the LS Mtron Mower to the Dealer's place of business or repair.
The obligation of LS Mtron to the Purchaser under this Warranty is limited totherepairor
replacement of defective parts by an authorized LS Mtron dealer. Repair or replacement in
accordance with this Warranty shall constitute fulfillment of all liabilities of LS Mtron and the
Selling Dealer in respect to LS Mtron Mowers.
LS Mtron reserves the right to make changes in the design and other changes initsLSMtron
Products at any time without incurring any obligation with respect to any product previously
ordered, sold or shipped.
▶ Temporary repairs or additional costs due to the work being performed after normal working
hours will not be compensated.
▶ The above warranty is in lieu of all other warranties on LS Mtron's behalf and neither party
assumes any other liability in connection with LS Mtron's Products.
▶ To obtain warranty service, the Purchaser must (1) report the product defect to an authorized
LS Mtron dealer and request repair within the applicable warranty term and (2) present evidence
of purchase.
▶ The Warranty shall be void if the LS Mtron Mower has been altered or repaired outside of a LS
Mtron dealership or travel of dealer personnel to customer location for Warranty repair. The
customer shall also pay any premium for overtime labor requested by the customer.
LS Mtron Tractor Division, herein referred to as LS Mtron, undertakes to replace or repair any part
of a LS Mower where damage has been proven to be caused by defects in material or
workmanship.
This Warranty is valid for a period of 1 year from the date of the original retail sale. Parts
replaced or repaired under the terms of this Warranty are guaranteed only until the original
warranty expires. Warranty only applies to the original purchaser.
▶ The purchaser shall at all times in the operation of any LS Mtron Product, use those brands
and grades of lubricating oils, lubricants or fuel and spare parts officially approved by LS Mtron.
▶ The LS Mtron Mowers shall have been used in accordance with the procedures specified in the
Operator's Manual. This Warranty does not extend to damage resulting from misapplication,
abuse, misuse, failure to preform maintenance, negligence, fire, accidents or changes or faulty
mounting carried out by the Purchaser. When making a Warranty exchange of parts, the
Purchaser shall compensate LS Mtron for the time that the parts have been used if they have
been exposed to extreme wear.
There are no warranties beyond those which expressly appear herein. Any implied warranty of
merchantability or fitness for a particular purpose is specifically exclude here from.
- 1 -

PLEASE NOTE :
Make sure all potential operators of the this equipment review this manual and all safety
messages contained within
This safety symbol indicates important safety messages in this manual. When you see
this symbol, carefully read the message that follows and be alert to the possibility of
personal injury or death.
- 2 -

Table of Contents
OPERATOR MANUAL
▣ Safety Precautions 4
▣ Safety Decals 7
▣ Mower Specifcation 9
▣ Introduction 10
▣ Operation 11
▣ Mounting Kit Installation 12
▣ Mower Deck Installation 13
▣ Adjusting 14
▣ Mower Deck Removal 16
▣ Lubrication And Maintenance 17
▣ Cutting Height Adjustment 19
▣ Blade Replacement 20
▣ Belt Replacement 21
▣ Mowing Problems 22
▣ Trobleshooting Problems 25
▣ Torque Tightening Chart 26
▣ Parts IIlustrations 27
General Information 27
Mid-Mower Assembly 28
Deck Assembly 30
Center Pulley Assembly 32
Side Pulley Assembly 34
Tensioner Assembly 36
Wheel Assembly 37
Decals 38
SERVICE MANUAL
▣ Mower Terminology 39
▣ Power Transmission 41
▣ Lifting Mechanism 42
▣ Disassembling And Assembling 43
- 3 -

SAFETY PRECAUTIONS
THE TRACTOR
▶
▶ Read and understand all safety Precautions in the Tractor Operator's Manual.
▶
▶
▶
▶
▶
▶
▶
▶ Move and turn the tractor at low speeds. Avoid erratic operation and excessive speed.
▶ Keep the tractor in gear when traveling down hill.
▶
▶
▶ Do not allow anyone but the operator on the tractor or mower. Never allow riders on tractor.
▶ Use extreme caution when loading or unloading the tractor and mower from a trailer or truck.
THE MOWER
▶
▶
▶ Keep all shields and guards securely in place.
▶ Never operate the mower with the discharge deflector in raised position.
Wear personal protective equipment(PPE), such as, but not limited to, protection for eyes, ears, lugs,
head, hair, hands and feet when operating, servicing, or repairing the equipment. Avoid wearing
loose clothing or jewelry that may catch and entangle on equipment moving parts.
Stop tractor engine, place transmission in park(or neutral), engage parking brake, lower mower deck
to ground, allow machine moving parts to stop, remove ignition key to prevent unauthorized person
from starting tractor before servicing, repairing, or making adjustments to the equipment.
Do not operate the mower unless it is rigidly attached to the tractor. Failure to do so could result in
serious injury or death and equipment damage.
Make sure spring activated locking collar on Drive Shaft slides freely and is seated firmly in tractor
PTO spline groove.
Never leave the tractor seat with the mower blades rotating, with the tractor in motion, or the engine
running.
Use fender hand holds and steps when mounting and dismounting tractor to prevent falls. Keep steps
and Operator's platform clean and free debris.
Do not mow near drop offs, ditches, or embankments. The tractor could suddenly over turn if a wheel
travels over the edge of a ditch, or if an edge caves in.
Add wheel ballast for stability when operating on slopes. Use extreme care when operating on slopes
to maintain stability.
Read, understand and follow all instructions in the manual and on the machine before starting.
Failure to do so could result in serious injury or death and equipment damage. Keep this manual in a
safe place for future and regular reference and for ordering serivice parts.
Allow only responsible operators familiar with the instructions to operate the machine. Know the
controls and how to stop tractor engine and mower quickly in an emergency.
Tractor must be equipped with Rollover Protective System(ROPS) and seat belt for all mower
operation. Keep foldable ROPS locked in the up position at all times when operating the mower.
Falling off or overturning a tractor can result in death from being run over or crushed.
Always wear seat belt on ROPS equipped tractor . Do not wear a seat belt if the tractor ROPS has
been removed.
Most tractor and/or Mower equipment accidents can be avoided by following simple safety precautions.
The safety information given in this manual does not replace safety codes, insurance requirements,
federal, state, and local laws. Make sure your machine has the correct equipment required by your local
laws and regulations. Understand that you safety and the safety of other persons are measured by how
you service and operate this mower.
Know the position and operations of all controls before you try to operate. Make sure you check all
controls in a safe area before starting.
Read this manual completely and thoroughly and make sure you understand all controls. All equipment
has a limit. Make sure you are aware of the stability.
This safety alert symbol indicates important safety messages in this manual. When you see
this symbol, carefully read the message that follows and be alert to the possibility of personal
injury or death.
SAFETY PRECAUTIONS
- 4 -

SAFETY PRECAUTIONS
TRANSPORTATION
▶ Never allow riders on tractor.
▶
▶
▶ Use caution and reduce speed when transporting under adverse conditions, turning, or on inclines.
▶ Do not operate PTO during transport.
MAINTENANCE
▶ Protect your eyes - Wear Safety Glasses.
▶ Never run the tractor and mower inside a closed area. Engine exhaust fumes can be lethal.
▶
▶
▶ Avoid injury, do not adjust, service, clean, or unclog the mower when the tractor engine is running.
▶
▶
▶
▶
▶
▶
▶
HYDRAULIC
SEE A DOCTOR at once if injured by escaping fluid. Serious infection or gangrence can develop if proper
medical treatment is not administered immediately.
Keep tractor grill and radiator clean of clippings to prevent overheating of tractor cooling system.
Monitor temperature gauge. Clean as required.
Escaping fluid under pressure can have sufficient force to penetrate the skin and cause serious injury. Be
sure to stop engine and relieve all pressure before disconnecting lines. Be sure all connectings are tight
and that lines, pipes , and hoses are not damaged before applying pressure to the system. Fluid
escaping from a very small hole can be almost invisible. Use a piece of cardboard or wood - not your
hands - to search for suspected leaks.
Your Dealer can supply genuine replacement blades. Substitute blades may not meet original
equipment specifications and may be dangerous if installed.
To reduce fire hazard, keep the tractor and mower free of grass, leaves, or other debris build up.
Debris may build up on the mower deck or contact the tractor exhaust presenting a potential fire
hazard.
Naver alter safety devices. Check their proper operation regularly. Use all guards as instructed in this
manual.
It is not recommended to use a pressure water to clean the mower assembly. High pressure water
may cause damage to spindles, pulleys, belts, or bearing shortening lift and reducing servicealility.
SAFETY PRECAUTIONS
Always use accessory lights and devices when transporting on a road or highway to warn operators of
other vehicles. Check your local government regulations.
Be sure the Slow Moving Vehicle(SMV) emblem is visible to the rear. If there is no SMV sign, worn,
faded, or damage replace immediately.
Do not handle mower blades with bare hands. Wear leather gloves or wrap blades in the area where
they will be handled. Improper handling may result in serious injury.
Before performing any service work make sure hoist, floor jacks, and stands are in good working
order and are properly rated to support the tractor and mower.
Do not work under the tractor or mower unless they are secured by a hoist and jack stands. Never
place any body part underneath equipment or between moveable parts even after tractor has been
turned off. Hydraulic system leak downs. Hydraulic system failu
Frequently check the mower blades. They must be sharp and free of nicks, cracks and securely
- 5 -

SAFETY PRECAUTIONS
▶Workin
g
area
■ Before o
p
eration
(
Pre-o
p
eration
)
▶O
p
erator
■ O
p
eration
▶Startin
g
▶O
p
eration
2. Do not stand on the mower.
▶Machine, blades and e
q
ui
p
ment
2. The mower is equipped with many safety devices.
8. Replace damaged or illegible safety decals.
See next page for required labels.
Do not alter or remove any part of safety system
for your safety.
3. Keep all nuts, bolts and screws tight to be sure
the mower is in safe working condition.
5. Read and understand this manual and the
tractor operator's manual before operating
mower. Allow only a properly trained person to
operate the tractor.
4. Never allow children to operate the mower,
even under adult supervision.
8. Do not mow on steep inclines, rough terrain or
near drop-offs.
4. Check the blade bolts at frequent intervals for
proper tightness.
4. Do not mow while in reverse unless absolutely
necessary and then only after inspecting of the
entire area behind the mower. Be extra careful of
children.
5. Upon striking a foreign object, stop and inspect
the tractor and the mower for damage. Repair the
damage before resuming operation.
6. If the mower discharge deflector becomes
clogged, stop the tractor; disengage the mower
drive; shut off the engine and remove the key, and
clean out the deflector before continuing.
7. Hillside operation is dangerous and is not
recommended. If it is necessary to mow on a
hillside, use extreme caution. Never mow across
the face of a slope. Do not operate with the
Careful operation is your best insurance against
an accident. Read this section carefully before
operating the mower. All operators, no matter
how much experience they may have had, should
read this manual, tractor manual and other
related manuals before operating mower. It is the
owner's obligation to instruct all operators in safe
operation.
6. Always wear seat belt on ROPS equipped
tractor. Never use the seat belt when the tractor is
not equipped with a ROPS.
7. When using the mower, detach the backhoe
beforehand. Otherwise the machine may get
damaged during operation.
2. Before starting the engine, make sure that all
levers (including auxiliary control levers) are in their
"NEUTRAL" positions, that the parking brake is
engaged, and that both the PTO clutch lever and
the ran
g
e
g
ear shift lever (Hi-Lo) are disen
g
a
g
ed.
3. While making turns in rough terrain, reduce
tractor speed.
5. Inspect the blades for wear and damage. A
dull blade can be sharpened, but a blade that is
worn out, bent, cracked, or otherwise damaged
must be replaced.
3. Do not wear loose, torn, or bulky clothing
around machine. The clothing may catch on
moving parts or controls, leading to the risk of
2. Keep the area of operation clear of all persons,
particularly small children, and pets. All people
and pets should be kept at a safe distance from
the work area.
1. Never start engine or operate levers from
anywhere other than the seat.
1. Keep bystanders at a safe distance from the
machine during mowing operations.
1. Never operate the mower without proper
guards, shields, and the grass catcher bag or
discharge deflector in place.
Wear and use any additional safety items such
as hard hat, safety boots or shoes, eye and
hearing protection, gloves, etc., as appropriate or
required.
SAFETY OPERATION
1. Thoroughly inspect the area where the mower is
to be used. Remove all stones, sticks, wires,
bones and other objects that could be thrown at
high speed.
1. Do not operate the machine while under the
influence of alcohol, medication, other
substances or while fatigued.
2. Be thoroughly familiar with the controls and
learn how to stop quickly in an emergency. Know
your equipment and its limitations.
- 6 -

SAFETY DECALS
Safety Decal Loacations
Care of Safety Decals.
▶ Keep safety decals clean and free of obstructing material.
▶ Clean safety decals with soap and water and dry with a soft cloth.
▶ Mount new safety decals by applying on a clean dry surface
and pressing air bubbles to outside edges.
▶ Replace damaged or missing safety decals with new decals
from your LS Mtron Dealer.
▶ If a component with a safety decal(s) affixed is replaced
with a new part, make sure new safety decal(s) are attached
in the same location(s) as the replaced components.
3103E-00029
3102E-00104
3102E-00103
3104E-00016
- 7 -

SAFETY DECALS
3106E-00002 3102E-00105
3103E-00030
3103E-
- 8 -

MOWER SPECIFICATION
Mid-Mower Model
Discharge Type
Cutting Width 1521 mm 60 "
Cutting Height 25~102 mm 1~4 "
Max. height
(from ground to mower bottom surface)
Adjustment of cutting height
Gear Type
Ratio of Gear
Max. Blade spindle speed 2795 rpm 46.6 r/s
Max. Blade Tip Speed 76.2 m/s 14,998 fpm
Number of Blade
Mounting method
Thickness of Deck 3.2 mm 0.126 "
Overall Specification
Width (with out linkage) 1921 mm 75.6 "
Length (with out linkage) 1014 mm 39.9 "
Height (with out linkage) 276 mm 10.9 "
Total weight 129 ㎏ 283.8 lbs
Main Deck 110 ㎏ 242.0 lbs
Mounting Kit 19 ㎏ 41.8 lbs
Drive Type
Lifting Type
Attach/ Detaching Type
Compatible with Loader
U-Joint & V-Belt(Double)
LM1160
Side Discharge
Dial
Spiral Bevel Gear
Posible
152 mm 6 "
3-Point upper link
Side loading type
1 : 1.06
3
Linkage
- 9 -

INTRODUCTION
▶ Important
▶ Warranty Registration
▶ Serial Number and Location
The purpose of this manual is to assist you in maintaining and operating your Mower.
Read it carefully, it furnishes information and instructions that will help you achieve years of
dependable performance.
Some information may be general in nature due to unknown and varying conditions. However,
through experience and these instructions, you should be able to develop operating procedures
suitable to your particular situation.
"Right" and "Left" as used throughout this manual are determined by facing the direction the
machine will travel when in use.
The photos, illustrations and data used in this manual are current at the time of printing, but
due to possible in-line production changes, your machine may vary slightly in detail. The
manufacturer reserves the right to redesign the machine as may be necessary without
The serial number is important information about the machine and it may be necessary to know
it before obtaining the correct replacement part. The serial number plate is located on the
RH(right hand) rear area of Mower. The serial number should be recorded on the Delivery and
Registration form and also below for your reference.
The Delivery and Warranty Registration forms must be filled out and signed to validate your
warranty protection. The items on the form under "I hereby Acknowledge" should be read and
understood. The terms and conditions of the warranty on this machine are specified in the front
Illustrations used in this manual may not show all safety equipment that is recommended to
ensure safe operation of tractor and Mower. Refer to the Safety Precautions section of this
manual for information concerning safety. consult your dealer for further information.
Model Name
Serial Number
M
id-Mower Serial Number Informatio
n
- 10 -

OPERATION
WARNING
WARNING
WARNING
After the first two passes have been completed,
reverse direction to have the discharge deflector
pointed outward. This will give a better appearance to
the lawn.
Make sure Discharge Deflector is
installed and correctly functioning to
prevent injury. Never operate mower
with Deflector moved or raised out of
operating position.
Blade sharpness will affect the appearance of the
area cut. Dull or damaged blades will cause the
grass to appear torn, rather than cut cleanly.
To avoid injury never direct the
discharge of material towards
bystanders or allow anyone near the
machine while in operation.
Do not cut the grass too short. Short grass will
promote weed growth and yellows in dry weather.
Allow grass to grow longer in hot, dry conditions. The
additional length reduces heat build-up, preserves
needed moisture and protects the grass from heat
damage.
To avoid injury and damage, re-torque all
fastening hardware, including blades and
spindle retaining hardware after the first hour
of operation.
M
ow o
ft
en.
D
ono
t
a
ll
ow
th
e
g
rass
t
o
g
e
t
t
oo
t
a
ll
.
Mowing areas with tall grass may require cutting at
the maximum height as a first pass. After completing
the mowing operation at the maximum height, the
area can be recut with the mower set at the desired
height
Safe operation of the tractor and mower is the
responsibility of the operator. Operator must be
familiar with tractor and mower controls and how
they function, and all Safety Precautions before
starting operation. The mower is designed as a
finish cut mower.
At certain times of the year and under some
conditions, the mower may leave streaks of uncut
grass. The general cause is tall grass and weeds.
With this type of condition, it may be necessary to
make a second pass over the cut area to get an even
cut.
Do not allow anyone but the operator on the
tractor or mower. Never allow riders on tractor.
For best results, it is recommended that the first
two passes around the area to be mower has the
discharge deflector directed towards the center.
Clean the underside of the mower deck using a
scraper.
The mower is equipped with ground following
front and rear gauge wheels, and is designed to
be operated with the wheels as the ground
surface. The deck cutting height is set by the
control dial. Refer to "Cutting Height Adjustment"
section of this manual for proper adjustment.
Cutting off too much at one time chocks the plant's
growth system and weakens the grass plants. A good
guideline to follow is the 1/3 rule: cut no more than
one third of the grass height, and never more than 1
inch at a time.
Mow when the grass is 3 to 4 inches tall.
Th
e
g
au
g
e w
h
ee
l
s on eac
h
s
id
e o
f
th
e mower
deck can serve as a guide for mowing. When
mowing, position the mower deck such that the
caster wheel overlaps the edge of the grass
previously cut. This will assure full mower cut
coverage
The time of da
y
and condition of the
g
rass will affect
the results you obtain when mowing. Mow at the time
of day when the grass is cool and dry. Late afternoon
of early evening will provide the most ideal
conditions. Do not mow when the grass is wet or
heavy with dew. Wet grass can build up on the
underside of the deck, creating an imbalance through
the blades and spindles, causing possible damage to
the mower deck belt. Wet grass also leaves unsightly
clum
p
s on the lawn.
Mowing should be performed with the tractor
engine operating at the recommended RPM. Do
not mow at high ground speed. Operating at
recommended RPM will insure proper blades
speed for effective cutting and discharge of grass
from the deck.
Should the mower deck become plugged, raise
deck, shut off engine set parking brake.
- 11 -

MOUNTING KIT INSTALLATION
IMPORTANT :
Install main arm link ass'y(9,10) to tractor both
side, secure with hinge pin(11), and bolt(12).
After assembling the above three, use a washer(4)
and pin, cotter(5) to connect the links.
Park the tractor on a smooth hard surface. Stop
engine. Set parking brake and remove ignition
Install pull link ass'y (1) to arm hinge of tractor,
secure with arm bolt(2), nut(3), washer(4) and
pin, cotter(5).
It is ready to mount the mower deck.
Install main link ass'y(6) to frame of tractor ,
secure with plate(7), and bolt(8).
- 12 -

MOWER DECK INSTALLATION
BEFORE INSTALLING
IMPORTANT :
INSTALLING MOWER DECK
Step 1. Pull out the L-pin(1) of main arm ass'y and
put in hinge-boss(3) through the hinge bracket(2).
Tighten all hardware to torque requirments
specified in torque chart at back of manual.
Step 2. Hang a fix lever ass'y(7) on side plate
ass'y(6). and hang a front link ass'y(4) on the hook
bracket(5).
Check the front and rear wheels locate at the
lowest position.
Shut off engine and remove ignition key when the
mower located between front and rear wheels of
tractor.
Step 3. Hang a hinge load(8) on a fix lever ass'y(1).
Pull a lever(9). Pull and release the L-pin(10) of the
fix lever ass'y to automatically lock it.
Turn the wheel of mower sideways and slide the
mower into the tractor.
Step 4. Install Drive shaft to mower gear box.
Note - Make sure to assemble
the grease nipple of anti scalp
wheels directed outside
Step 5. Install Drive shaft to tractor mid-PTO.
Step 6. Lift up the mower deck to the maximum
height by using hydraulic system.
Note - When installing drive shaft to tractor mid-
PTO, pull the cap of drive shaft and slide smoothly
this to tractor mid-PTO untill the cap returns previous
position.
After installing mower, check all pins, bolts, and nuts secured. Start tractor, lift-up and down the mower
several times.
Set the cutting height control dial to "0". Lower
the three point hitch lever to attach mounting
links to the mower.
Put the wheel of mower back in place.
Step 7. Turn the wheel forward.
- 13 -

ADJUSTING
F : 50mm R : 36mm
4. Stop the engine and remove the key.
5. Set the cutting height control dial(2) at "2" grade and
move the hydraulic control lever forward to fall down the
link to the "2" grade position.
Adjusting Front and Rear Cutting Height
Setting Mower Deck after installed
1. Park the machine on a firm, flat and level surface.
3. Start the engine and move the hydraulic control lever(1)
rearward to raise the link to the highest position.
2. Tire pressure must be correct.(See Tractor Operator's
1. Adjust the left and right side with bolt(1) until the deck
height become 36mm from ground to bottom of deck rear
side.
Adjusting Left and Right Cutting Height
2. Tighten the nut (2) to fix the height adjusting bolt(1).
1. Check front height "F" and rear height "R" with below.
2. If not, adjust nuts(1) until the "F" become around 50mm.
3. Tighten the nuts(1) to fix the fron theight(F).
- 14 -

ADJUSTING
1. Start the engine and move the hydraulic control lever
rearward to raise the link to the highest position.
Note - All dimensions can be little different depending on the several factors.
Note - Do not adjust transfer height(gap "A") less than
5mm.
After adjusting mower, check all pins, bolts, and nuts secured. Start tractor, lift-up and down the mower
several times, and check the mower hang on the ground horizontally.
2. Adjust nut(1) until the gap of lifted mower deck(A)
become 5mm.
Adjusting Transfer Height
- 15 -

MOWER DECK REMOVAL
BEFORE REMOVING REMOVING
Ste
p
3. Remove the mower.
Disconnect the drive shaft from tractor mid-PTO.
Set the cutting height control dial to "0".
Park the unit on a smooth hard surface. Drop
mower to the ground. Shut off engine, set
parking brake and remove ignition key.
Step 1. Pull out the L-pin(1,2). Be careful of sudden
drop of front link from the mounting.
Placing wood "blocking" which will act as a
"ramp" at the back and front of the mower.
Step 2. Remove the front link ass'y(3) from mower
hook.
- 16 -

LUBRICATION AND MAINTENANCE
▶
※NOTE
Gear box Oil
• Do not operate the Mower if the fittings are leaking or if the hoses are damaged.
A sudden line burst could cause the mower to drop suddenly, causing damage to the tractor or
Mower or injury to personnel.
• Operate the Mower only when you are on a tractor seat.
• Do not stand under a raised Mower.
Accidental movement of control lever or leak in hydraulic system could cause mower to drop,
causing severe injury.
WARNING
• Do not perform and service or maintenance Operations with mower raised off the ground.
CAUTION
Important
Lower the mower to the ground to perform any service or maintenance operations on the tractor.
• Grease all “GREASE" points daily(10 hours). Refer to Operator's Manual for lubricant
recommendations.
-After the first 50 working hours and, later, every 800 working hours, replace the oil in the gear box.
Use oil SAE EP 80W90
Check the tractor hydraulic system as outlined in the Tractor Operator's Manual.
• When checking Gear box oil level, the mower should be on the ground horizontaly.
No. Quantity
SAE EP 80W90 230~240ml
Oil
- 17 -

LUBRICATION AND MAINTENANCE
ITEM SERVICE SERVICE INTERVAL
Gear box Oil Level Check Daily/10 hours
Gear box Oil Lubricate Daily/10 hours
Pulley Ass'y Lubricate Daily/10 hours
Wheel Shaft Check Daily/10 hours
Main Link Ass'y Check Daily/10 hours
All the hardwares Check visually and Re-Torque Daily/10 hours
- 18 -
